Parquet production line

Soest UVE-3-400

Condition: used, Year of construction: 2013, functionality: fully functional, Fisher+Rueckle FZR-24 Veneer cross-gluing machine, year 2013 for sale! Veneer strip length 400-1100 double lane/ 350-2100 mm single lane Veneer strip width 50-500 mm Veneer strip thickness 0.3-1.5 mm Max nominal output /machine cycles 30 cycles/min Average production speed 17-20 cycles/min Effective length of heating zone 2478 mm Connection power 22 kW Nwedpfx Abjumrf Ajkjh Compressed air 6 bar Glue types PVA or UREA based

Condition: used, machine/vehicle number: 008502, Max. panel width: 3800 mm Max. panel length: 3800 mm Nwjdpey Edp Hefx Abkeh Main saw blade projection: 115 mm No of Grippers: 11

Condition: good (used), Year of construction: 2003, Automatic hydraulic gluing press Kallesoe Type LV 7821 press is used for gluing wooden elements, e.g. tabletops with maximum dimensions of 7800 mm x 2100 mm, the factor which accelerates gluing is warm water supplied to the press shelf and being in continuous circulation (it can be supplied from CO or heated by heaters mounted on the press) Heating power of the press 72kW Maximum capacity of the press up to 2000 m2 / 7.5h Njdporqzgksfx Abkjwh Glue applicator with feeder for Kallesoe press Type KL40 - used to automatically apply glue to each lamella and transfer directly to the press LV7821

Condition: new, Year of construction: 2025, total length: 1,600 mm, total width: 2,200 mm, total height: 2,350 mm, overall weight: 250 kg, type of input current: three-phase, working width: 1,400 mm, Paint booth, paint wall, suction TQN1414 With right or left side discharge. Working dimensions (mm): 1400 (width) x 1400 (height) x 800 (depth) Overall dimensions (mm): 1600 (width) x 2350 (height) x 1250 depth SPECIFICATION: • Fan power 1.5 kW, • Efficiency 6,500 m³/h, • 2 x 100% polyester filter • Filtration degree at the level of 99.9%, • Control panel IP 66, • Automatic filter cleaning • Hermetic lighting IP 65. • Paint tank Cabin available immediately (Stock status) Nwjdpfx Asd S N I Nsbkoh SELECT BUMEX SP. Z O.O. Very high quality machines among those offered on the market. Professional advice and service. Warranty. Warranty and post-warranty service. Full technical documentation. 100% satisfaction of our customers. All BUMEX SP. Z O.O. brand products have an EC certificate. We offer our own transport - prices are set each time, for a given offer. We issue VAT invoices. Short lead times! Possibility to order machines in various, personalized configurations and dimensions! Please contact us.

Condition: excellent (used), Year of construction: 2001, Complete Parquet painting shop Nedpsrdgrvofx Abkswh Manufacturer - SORBINI/ VIET Year - 2001 Capacity - 800 m2/shift Time of one cycle - 8 min. Lenght of the line - 42 m

Condition: good (used), Code: 0749 Brand: TAGLIABUE - COSTA LEVIGATRICI Model: TT 3 1300 Automatic sanding machine for worktops, furniture, panels, tables Technical data: Working width mm 1300 Max working thickness mm 130 Min working thickness mm 1 Composition: 1° Transversal belt - Motor Hp 15 - Electronic speed variator with display Nsdeh T Dzqopfx Abkswh 2° Transversal belt - Motor Hp 15 - Electronic speed variator with display Transversal sanding belt size mm 1350 x 150 Chevron belt size mm 5510 x 140 Belt blowers Belt feed speed mt/min 5/25 Fixed table and mobile head for on-line set-up Panel cleaning rotary blowers Vacuum table Belt cleaning brush Infeed roller conveyor Installed power Kw 32 Compressed air 7 Atm Suction inlets: n° 2 diameter mm 200 - n° 2 diameter mm 150 - n° 2 diameter mm 100 Overall dimensions mmm 4400 x 2500 x 1600 h Weight kg 5000

Condition: used, Year of construction: 1995, functionality: fully functional, total length: 36,000 mm, Ironing dryer, working width 4,600 mm, length 22,000 mm, of which 10,000 mm with press rollers, separate press cooling field, hot water heating medium, semi-automatic feeding device, type BFT46 and lifting platform, max. veneer length: 4,600 mm, roll width 600 mm, total length: 36,000 mm, 11 fans, PLC control renewed in 2017 A second ironing dryer of a similar design is available. Nedjv Hygfepfx Abkswh

Condition: used, Year of construction: 1999, functionality: fully functional, Complete line consisting of: 1. Angelo Cremona Veneer Peeler – detailed description available below 2. Angelo Cremona Dryer – description and photos available in the listings 3. CMP Press – description and photos available in the listings 4. Imeas Sander – description and photos available in the listings 5. Raute Composer – description and photos available in the listings PEELING PLANT Nwodpfx Abovm An Ejkeh Comprising of: Centering Loader 1. Model CE08 2. Angelo Cremona 3. Positions logs for loading onto the veneer peeler 4. Power supply: 400Vac/50Hz – 50kW Maximum hydraulic pressure: 100 bar Compressed air consumption: 0 L/min Weight: kg Maximum dimensions: 600x300x400 mm 5. Production capacity: 4 logs per minute Veneer Peeler 1. Model SFH870 2. Angelo Cremona 3. Peels a sheet of wood from the rotation of the log 4. Power supply: 400Vac/50Hz – 240kW Maximum hydraulic pressure: 100 bar Compressed air consumption: 10 L/min Maximum dimensions: 600x400x300 mm 5. Production capacity: 50 cubic meters per shift Cutting and Sorting Line 1. Model TSR27 2. Angelo Cremona 3. Transports the peeled ribbon to the guillotine for optimized sheet cutting 4. Power supply: 400Vac/50Hz – 70kW Maximum hydraulic pressure: 100 bar Compressed air consumption: 0 L/min Maximum dimensions: 300x200x200 mm 5. Production capacity: 50 cubic meters per shift Sorting Line and Vacuum Stacker 1. Model LTR27 2. Angelo Cremona 3. Separates and stacks recovered sheets from full-size sheets 4. Power supply: 400Vac/50Hz – 180kW Compressed air consumption: -- Maximum dimensions: 300x1300x500 mm 5. Production capacity: 50 cubic meters per shift

Condition: used, CNC machining center BIESSE Rover C 6.50 CONF.2, year 2007 Nwodpjw Rpd Sofx Abkjh Working area: approx. 140 × 460 cm Machine dimensions: 300 × 650 cm Weight: approx. 6,100 kg Two working heads Tool magazine: 22 positions Vertical drilling spindles: 28 pcs Horizontal drilling spindles: 12 pcs Price negotiable, available immediately. Price is without VAT.

Year of construction: 2001, condition: like new (used), Roller coater Brand:Sorbini Type:T/20-MF No:MR1RFF21488 Year:2001 Njdpfefw Nc Ujx Abkewh The T20 roller coater has been designed as an addition to SORBINI´S extended line of products. The machine is used for finishing flat boards in general with various types of coating products (e.g.polyurethane, polyester, acrylic and water-based finishes) The modular design makes it possible to obtain a wide range of applications which cater for all specific user requirements. Techn info: Working width max 1300mm Thickness of workpiece 0-80mm Feeding speed 3-20 m/min Feeding motor0,737kw Doctor roller motor 0,75kw Applicator roller motor 0,75kw Doctor roller diameter 174mm Applicator roller diameter 248mm Working hight 80 till 950mm Compressed air requirements 6 bar 9l/min Air pump pressure 2-10bar Air pump capacity at max pressure 30l/min of 10 bar Dimension 950x2550x1450mm (lengthxwidthxhight) Total weight 1220Kg Stock no:104326BXA
