Used Vollmer Chd 250 for sale (98)

Condition: excellent (used), Carbide saw grinder VOLLMER model CHD250R2 Duodjyxmnrjpfx Ag Dsr

Condition: excellent (used), Carbide saw grinder VOLLMER model CHD250 Dodpehh A E Nsfx Ag Dour

Condition: excellent (used), Carbide saw grinder VOLLMER model CHD250R2 with 3 stations loader VOLLMER model ND230 Dodpfxsipqzto Ag Dour

Year of construction: 2015, condition: used, Disc EDM machine for the complete machining of rotationally symmetrical workpieces with cutting edges made of ultra-hard cutting materials. The workpieces are mounted vertically (suspended). Accessories: Total enclosure, Software for woodworking tools Software for P-system peeling cutters Software for scoring saws/radius cutters Software for 360° path programme Software for 360° peeling cutters Workpiece magazine N250 (pallet magazine for max. 28 workpieces), Disc changer for up to 6 eroding/grinding discs, Adaptation to A-axis on HSK 63- F, Coolant system with pump & cooling unit Automatic central lubrication Dusdpfx Aexy Ryrsg Djr Automatic fire extinguishing system Automatic shut-off flap Gripper fingers for workpiece automation, 4 workpiece holders for workpiece magazine, 1 exchange element with flushing kit, Mechanical mist separator N183, Test mandrel HSK63F. Maximum workpiece outer diameter.: 320 mm workpiece length: max. 250 mm Travel path X1: 520 mm Bore diameter: Max. 60 mm Travel path Y1: 970 mm Travel path Z1: 420 mm Rotation range axis E1: 210° Grinding spindle speed infinitely variable: 0 - 4500 rpm. Rotation range axis A1: 360° Rotation range axis B1: +/-20° Connected load approx.: 8.7 kVA / 6.8 kW (400 V/50 Hz) Weight approx.: 7100 kg Dimensions L x W x H: 4012 x 2889 x 2611 mm colour: RAL 7047 telegray 4 / RAL 7045 telegray 1

Year of construction: 2017, condition: used, Disc EDM machine for the complete machining of rotationally symmetrical workpieces with cutting edges made of ultra-hard materials. Workpieces are mounted vertically. Accessories: Total enclosure External PC incl. CAD/CAM and ExLevel Pro software Dedpfx Asxy Ry Ssg Deur Software package with additional functions for metalworking tools, Wheelchanger for up to 6 eroding/grinding discs, Adaptation to A-axis on HSK 63-A-E Coolant system with pump & cooling unit Automatic central lubrication Automatic fire extinguishing system Automatic shut-off flap Glass scales on the X, Y & Z linear axes, Mechanical mist separators N280, 3 grinding wheel change elements Test mandrel HSK63A. Also available with workpiece magazine as an option! Workpiece outer diameter: max. 320 mm Tool outer diameter: Max. 200 mm workpiece length: max. 250 mm Bore diameter: Max. 60 mm Travel path X1: 520 mm Travel path Y1: 970 mm Travel path Z1: 420 mm Rotation range axis A1: 360° Rotation range axis B1: +/-20° Rotation range axis E1: 210° Grinding spindle speed: stepless 0 - 4500 rpm (torque 6Nm) Connected load: approx. 8.7 kVA/ 6.8 kW mass: approx. 7100 kg Dimensions: W x D x H = 4012 x 2889 x 2611 mm colour: RAL 7047 telegray 4 / RAL 7045 telegray 1

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: CHD 251R2, grinding wheel diameter: 200 mm, input current: 380 A, We offer this excellent condition Vollmer CHD 251R2 ND300 saw-blade sharpening machine. The CHD 251 R2 automatic grinding machine with ND 230 Robot system as a service for fully automatic machining with 5 bay loading. Year of construction 2002. Manufacturer: Vollmer Werke Maschinenfabrik GmbH Model: CHD 251R2 ND300 Year of manufacture: 2002 Serial number: 575 Dsdsx R Eydepfx Ag Dsur Available Now If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: reconditioned (used), Year of construction: 2005, operating hours: 6,000 h, functionality: fully functional, saw blade diameter: 810 mm, grinding wheel diameter: 125 mm, CHP250 is an automatic machine for grinding the complete tooth geometry of carbide-tipped circular saw blades. Version with two CNC axes and a full enclosure. Technical specifications: Circular saws Outer diameter: 80 to 810 mm Dedpfx Aoykmxtsg Dsur Bore diameter: 10 to 220 mm Blade thickness: up to 8 mm Tooth pitch: 6 to 120 mm Rake angle: -30° to +50° Clearance angle: 5° to 45° Tooth height difference: up to 3 mm Back rake bevel: up to 45° Face bevel: up to 15° Grinding path: up to 20 mm Grinding wheel diameter: 125 mm CHP250 On the CHP250, two CNC axes control the bevel grinding and the infeed of the grinding wheel. This is a prerequisite for grinding any tooth geometry on the front (face) or back (flank) of the tooth in a single pass. Central lubrication and exhaust system are included. For effective coolant (oil or emulsion) cleaning, a Seitz-brand band filter system from 2010 is included. Up to 3 machines can be connected to the unit. The base is made of stainless steel. The condition is very good.

Condition: excellent (used), Carbide saw grinder VOLLMER model CHD350 Dusdpfx Aex Hp Scjg Dsr

Condition: excellent (used), Carbide saw double side grinder VOLLMER model CEF250 Dujdpoukgw Uefx Ag Dsr

Condition: used, Year of construction: 1970, total height: 1,700 mm, total length: 1,400 mm, total width: 900 mm, Empty weight: 500 kg - Year: 1970 - Documentation available: No Duodpfx Ajyxqzceg Dsr - CE certificate present: No - Serial number: CH - Motor power: 1.4kW - Transport dimensions: 1400mm x 900mm x 1700mm (l x w x h) - Transport weight [kg]: 500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2001, Suitable for automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as Saws, milling cutters, etc. using the wire electro-erosion process. Accesories: Total enclosure, Mist extractor Probe, Machine lamp, Automatic central lubrication, Coolant system dielectric fluid Duodsyzm Iwepfx Ag Dor Fire extinguishing system Measuring mandrel Alphanumeric keyboard cutter outer diameter max: 250 mm cutting length max.: 200 mm shank tool diameter: 10 - 250 mm cutting length: 200 mm Outside diameter of disc-shaped tools max.: 250 mm tool weight max.: 20 kg X-axis travel: 220 mm Y-axis travel: 300 mm W axis travel: 200 mm A-axis rotation range: 60 ° A-axis taper: ISO 40 E-axis swivel range: 120 ° number of revolutions: 80 - 2000 rpm. Dimensions L x W x H: 2235x2630x2130mm mass: approx. 4500 kg Connected load approx.: 400V / 50Hz / 4.5KW colour: turquoise RAL 5021/grey RAL 9002

Year of construction: 1992, condition: used, Vollmer Saw blade shearing machine type NS 700 Duodpjkmnyfofx Ag Dsr Year 1992

Year of construction: 2025, condition: used, Wire guide elements for metal, spacing 100-200 mm, 15 mm longer Using these wire guide elements reduces the diameter of the workpieces that can be machined. Suitable for Vollmer machine types: QWD 76 P / QWD 750 / QWD 760 / QWD 750 H / QWD 760 H / VPulse 500 Djdpfxswl Agqo Ag Dour

Year of construction: 2025, condition: used, Adaptor for A-axis HSK63-B,F For manual and automatic loading. Suitable for Vollmer machine types: QWD 750 / QWD 760 / QWD 750 H / QWD 760 H / VPulse 500 and all models from the QXD series (200/250/400) Dedjwl Aixepfx Ag Dsur

Year of construction: 2025, condition: used, HSK63-B,F Test Mandrel Suitable for Vollmer machine types: QWD 750 / QWD 760 / QWD 750 H / QWD 760 H / VPulse 500 and all models from the QXD series (200/250/400) Duodpfxowl Alao Ag Dsr

Condition: used, Year of construction: 2007, Suitable for the automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as Saws, milling cutters etc. using the wire-electro-erosion method. Accessories: Total enclosure, Cooling unit for dielectric, automatic fire extinguishing system, Mist extractor N181 Probe, Machine lamp, automatic central lubrication, Workpiece carrier ISO50, Measuring mandrel, Cutter outside diameter: Max. 250 mm Cutting length: max. 260 mm Shank tool diameter: 10 - 250 mm Outside diameter disc-shaped tools: Max. 250 mm Tool weight max.: 20 kg X axis travel: 275 mm Y-axis travel: 300 mm W-axis travel: 200 mm A-axis mounting cone: ISWO 50 E-axis swivel range: 180 ° Required space for the machine: 2535 x 2200 x 2220 mm Weight approx.: 4500 kg Djdpfx Ajwtmg Dsg Djur Connected load: 4.5 kW (400 V / 50 Hz) colour: gray RAL 7045/7047

Condition: used, Year of construction: 2013, Suitable for automatic tooth flank grinding on both sides of carbide-tipped circular saw blades. Accesories: full fairing coolant system Automatic central lubrication. Measuring system for measuring saw blades. Control panel with LCD color display. DNC service. Alphanumeric keyboard. Grinding speed and grinding path depending on the tooth surface, can be adjusted as required. 2 grinding wheel mounts Coolant level monitoring Automatic grinding wheel compensation Prepared for robot operation with automatic loading door oil pan 2 x saw blade magnet holder >Ø 320mm, >Ø 180 mm 1 centering ring. Circular saw blade diameter: 200 - 840mm Circular Saw Bore Diameter: from 16 mm Duedpfx Aov Sbmqog Dor Tooth pitch: 6 - 180mm grinding path: up to 25 mm tangential relief angle: 0 to 10 degrees max. grinding wheel diameter: 125 mm Grinding wheel bore diameter: 32 mm Grinding spindle variable: 1600 - 5500 rpm, Connected load approx.: 8kVA (400V / 50Hz) Dimensions W x D x H =: 2770x1900x2045mm mass: approx. 4700 kg colour: Gray

Year of construction: 2005, condition: used, CNC-controlled erosion machine for the processing (erosion, grinding, polishing) of PCD tipped tools up to 400 mm diameter and 400 mm length, according to disc-electrical-erosion processes for use in service and in production. Accessories: Total enclosure Software path management Software P- System for peeling cutters, Software shaft endmills (207/208) Software discoid tools face (221/222/223/224) Software profiled workpieces (233/234/239/240) Software hoggers, profiled hoggers (255/256/257/258/260/261/262/263) Software discoid tools (264/265) Software shaft and jointing cutters (267/268/277/278) Software step tools (271) Software scoring saws (299) Software saws flat tooth (301) Software saws single sided with chamfer (302/303) Software saws alternate tooth (304) Software saws triple chip (309) Software saws flat top tooth (310) Duedpew S I Dgefx Ag Dor Software saws flat trapezoid tooth (311) Software saws alternate tooth with chamfer (312) Software shaft and jointing cutters (7/8) Software shaft and jointing cutters profiled (33/34) Software hoggers, profiled hoggers (53/54/55/56/57/58) Software discoid tools (64/65) Software shaft and jointing cutters (67/68/77/78) Software compensation (90) Software saws flat tooth (101) Software saws single sided with chamfer (102/103) Software saws alternate tooth (104) Software saws triple chip tooth (109) Software saws flat top tooth (110) Software saws triple chip tooth (111) Software saws alternate tooth with chamfer (112) Software for polishing of profiled hoggers (757/758/760/761) Filter system with chiller for dielectric fluid Automatic fire extinguishing system DIN 14497 Standard programs for measuring, eroding etc. Program for chamfering of workpiece cutting edges, Automatic Diagnosis program for machine operational status with text output on screen Loader for workpieces, with CNC-controlled pivot for loading and unloading to a magazine, 6 sided erosion wheel changer, Workhead SK 50 with adapter to 12 HSK 63 A, Turntable workpiece magazine for 12 workpieces SK 50, Turntable workpiece magazine for 4 workpieces SK 50, 6 flush sets QXD250 CAD/CAM for external PC workstation including ARES drawing program, Industrial PC external PC workstation with desktop PC, monitor, keyboard, and mouse, 1 HSK63 F adapter for measuring the machine. X axis travel: 730 mm B axis travel: +/- 30 ° Y-axis travel: 840 mm Z axis travel: 500 mm E-axis: 330° A-axis: 360° Workpiece carrier: SK50 workpiece length max.: 400 mm Workpiece diameter max.: 400 mm workpiece weight max.: 15 kg Connected load approx.: 6.7 kW (400 V / 50 Hz Dimensions W x D x H approx.: 2160 x 3435 x 2190 mm Weight approx.: 7800 kg colour: RAL 7047 Telegray 4, color RAL 7045 Telegray 1

Condition: used, Year of construction: 2002, Suitable for the automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as Saws, milling cutters etc. using the wire-electro-erosion method. Accessories: Total enclosure, Cooling unit for dielectric, Djdoylby Ijpfx Ag Dour automatic fire extinguishing system, Mist extractor Probe, Machine lamp, automatic central lubrication, Workpiece carrier ISO50, Measuring mandrel, Tailstock. Cutter outside diameter: Max. 250 mm Cutting length: max. 260 mm Shank tool diameter: 10 - 250 mm Outside diameter disc-shaped tools: Max. 250 mm Tool weight max.: 20 kg X axis travel: 275 mm Y-axis travel: 300 mm W-axis travel: 200 mm A-axis mounting cone: ISWO 50 E-axis swivel range: 180 ° Required space for the machine: 2535 x 2200 x 2220 mm Weight approx.: 4500 kg Connected load: 4.5 kW (400 V / 50 Hz) colour: gray RAL 7045/7047

Condition: used, Year of construction: 2014, Suitable for attachment to a carbide saw blade grinding machine of the type Vollmer CHD 250/CHD 251/CHD 270, CHF 270/CHF 350, loading system for saw blades with up to 630 mm diameter. Accessories: DES 300 data input station 3 loading trolleys Oil collection tray, Automatic central lubrication, Control cabinet cooler. Simplest stack circular saw blade outside diameter: 100 to 630 mm double stack: 100 to 305 mm maximum saw blade weight single-sided occupancy: 9 kg Dedpfx Asylhtujg Deur double-sided occupancy: 6 kg Bore diameter: 16 to 180 mm sheet thickness: up to 5 mm Stack height: < 300 mm Connected load approx.: 1.8 kVA (400 V / 60 Hz) Weight approx: 1400 kg colour: Gray RAL 7035

Condition: used, Year of construction: 2010, Suitable for automatic grinding of tooth faces, tooth backs, and bases on carbide-tipped circular saw blades in a single setup. All common tooth geometries (flat, alternate, trapezoidal, etc.) can be ground automatically and in a single pass. Accessories: Full enclosure Measuring probe Grinding device with oil cooling Automatic fire extinguishing system Grinding mist extraction system N 183 Alphanumeric keypad Oil drip tray Machine light saw diameter: 80-840 mm Bore diameter: from 10 mm sheet thickness: < 8 mm Duodjwp Ebljpfx Ag Djr Tooth pitch: 6 - 120 mm Cutting length:

Condition: used, Description: external data input station for use with Vollmer ND brand saw blade handling systems. Serves for individual input of the various processing steps of a saw blade. The data input station with integrated router takes over the interface between the machines, to the customer's own server or PC Dedpfxsv Saqze Ag Djur

Year of construction: 2012, condition: used, Description: external data input station for use with Vollmer ND brand saw blade handling systems. Serves for individual input of the various processing steps of a saw blade. The data input station with integrated router takes over the interface between the machines, to the customer's own server or PC Duodpfx Asv Sarxjg Dor

Year of construction: 2006, condition: used, Loading trolley for all Vollmer ND loading centers available in as-is condition, unpainted or completely new and freshly painted. Duedpfx Agoupia Ao Dsr

Condition: used, Year of construction: 2008, Suitable for the automated machining of PCD-tipped milling cutters, end-cutting tools, and disc-shaped tools such as saws, milling cutters, etc., using wire EDM. Accessories: Total enclosure External PC with contour management and Exprog software Cooling unit for dielectric fluid Automatic fire extinguishing system Automatic central lubrication Extraction system, Measuring probe Machine lamp Workpiece carrier SK 40 Measuring mandrel SK 40 cutter outer diameter: Max. 320 mm Shank tool diameter: 10-320 mm Outer diameter disc-shaped tools: Max. 320 mm Cutting length: max. 480 mm X-axis travel: 500 mm Tool weight: max. 20 kg Y axis travel: 300 mm Travel path W-axis: 200 mm Machine space requirements: 2535 x 2200 x 2280 mm A-axis rotation range: 360° Dusdpjxy Rx Isfx Ag Djr E-axis swivel range: 180° Weight approx.: 4800 kg Connected load: 5,4 kW colour: grey RAL 7035/7043
