Used Thread Milling And Hobbing Machine for sale (69,120)

Condition: good (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 3600120, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 3,150 rpm, spindle speed (min.): 63 rpm, mount diameter: 40 mm, total height: 2,200 mm, total width: 2,000 mm, total length: 2,500 mm, table width: 500 mm, table length: 900 mm, overall weight: 3,000 kg, INTOS SNGJ 50 Tool Milling Machine - Operating voltage: 400 V - Frequency: 50 Hz - Power supply: 12 kVA - Table with 10 T-slots - Tool holder: SK 40 The machine is equipped with a three-axis digital readout from HEIDENHAIN. Giodpfx Aeyizqhjfnjn FCA D-73235 Weilheim Teck – loaded onto truck

Condition: new, The Servomill® FPK 500 is a state-of-the-art Conventional Vertical Milling Machine from KNUTH, designed for superior performance in toolmaking and mechanical manufacturing. This versatile tool seamlessly integrates modern electronics, making it intuitive and capable of operating with exceptional precision. Its robust construction features a console design made of high-quality grey cast iron, ensuring durability and dimensional stability during operation. Noteworthy attributes include powerful servo feed technology with electronic handwheels, enabling infinite variability in feed speeds and precise control across all axes, accompanied by ball screws that eliminate backlash for enhanced accuracy. With a comprehensive variety of standard equipment such as a coolant system, LED worklight, and an automatic lubrication system, the Servomill addresses operational efficiency while minimizing maintenance needs. Perfect for both skilled operators and training environments, this machine exemplifies the best in modern milling technology. Whether you're looking to enhance your production capabilities or train the next generation of machinists, the Servomill® FPK 500 is an ideal choice. Request a quote today to elevate your milling operations with this advanced Conventional Vertical Milling Machine. Gedpewa Ah Rofx Afnjin

Condition: good (used), Year of construction: 2013, operating hours: 4,951 h, functionality: fully functional, machine/vehicle number: 1002823, travel distance X-axis: 1,020 mm, travel distance Y-axis: 830 mm, travel distance Z-axis: 240 mm, total height: 2,000 mm, total width: 2,000 mm, total length: 3,500 mm, table width: 1,000 mm, table length: 1,400 mm, table height: 960 mm, table load: 200 kg, overall weight: 2,000 kg, operating hours of spindle: 2,803 h, DATRON M 10 PRO A CNC Milling Machine - Operating voltage: 3 x 400 V - Frequency: 50 Hz - Rated current: 16 A Giedpfxoxxwxfs Afnon - Operating pressure: 7 - 10 bar - Travel (X-axis): 1020 mm - Travel (Y-axis): 830 mm - Travel (Z-axis): 240 mm - X and Y travel restricted by tool changer: 1020/720 mm - Gantry clearance: 200 mm - Bushing spacing: 100/100 - Table cutout (width/depth): 630/348 mm - Table width: 1000 mm - Table depth: 1400 mm - Table height: 960 mm - Max. table load: 200 kg - Distance to outer edge: 175/148 mm - Indicated machine hours: 4951 h - Spindle running hours: 2803 h The machine is equipped with a tool presetting device from SCHUNK, type TRIBOS. Includes various holders and a vacuum pump. FCA D-73235 Weilheim Teck – loaded on truck

Condition: new, The FPK 4.3 is a powerful toolroom milling machine that belongs to the category of Conventional Vertical Milling Machines. This versatile tool-milling machine, renowned in tool and mold making, offers a compact design that combines flexibility with ease of use. The premium cast-iron machine column ensures maximum dynamic rigidity and constant precision, complemented by precision preloaded ball screws on all axes for enhanced performance. Operators will appreciate the ergonomically arranged controls and the swivelling control panel that, alongside the standard digital position indicator, provide maximum comfort. With a large work table measuring 400x800 mm and a travel capacity of 500 mm on the X-axis, the FPK 4.3 is perfect for diverse applications in both training and manufacturing environments. Additionally, it features an automatic feed on all axes with infinitely variable speed settings, and a rigid outer arbor for horizontal milling, making it robust yet precise. Explore the extensive accessory package and take advantage of KNUTH’s reputation for quality – order online today and elevate your workshop with this exceptional milling machine. Godeuyh Dispfx Afnoin

Condition: used, Year of construction: 2022, x-travel 1350 mm Gisdpfjxfwg Nex Afnsn y-travel 950 mm z-travel 600 mm Control MAX 5 total power requirement 35 kW weight of the machine ca. 14 t dimensions of the machine ca. 3100x4535x3495 m

Condition: good (used), Year of construction: 1996, x-travel 800 mm y-travel 340 mm z-travel 460 mm Control Fanuc Giodpfx Asv H Sfysfnsn weight of the machine ca. 3,5 t

Condition: used, Year of construction: 2017, x-travel 500 mm y-travel 450 mm Gedpfx Afswm Rthsnoin z-travel 400 mm Control DMG MORI

Condition: used, Year of construction: 2020, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, RepairFIT by Dornhöfer The Difference. Including installation & commissioning! TECHNICAL MAIN DATA Year of manufacture: 2020 Capacities / Travel distances: Longitudinal (X): 3,000 mm Vertical (Y): 1,500 mm Transverse (Z): 1,500 mm Clamping area NC rotary table: Indexing plate: 2,400 x 1,900 mm Max. load capacity (with centrical load): 10,000 kg Positioning accuracy arc/sec ±2.5” Max. swing diameter: approx. 2,900 mm Paintwork: RAL 7024 graphite grey RAL 7038 agate grey Tool holder: DIN 69871 AD (ISO50) Big Plus Pull stud: DIN 69872 Type A Main spindle drive: Motor / manufacturer main spindle drive Heidenhain Max. drive power: 32 kW from 376 rpm Max. torque: 1,085 Nm (constant up to 376 rpm) Speed control/gearbox: 3-stage (oil-cooled), automatic gear shifting Spindle speeds: 6,000 rpm: low range rpm 0–738 medium range rpm 739–1,842 high range rpm 1,843–6,000 Axis drive / axis feed: Axis motors: Manufacturer Heidenhain (digital drives) Rapid traverse max.: X, Y, and Z axis 25,000 mm/min Max. working feed: X, Y, and Z axis 15,000 mm/min Max. mean acceleration: 2 m/s² Max. feed force: X, Y, and Z axis 26,000 N Axis drive systems: X-axis (longitudinal) preloaded ball screw Ø 63 x 40 Z-axis (vertical) preloaded ball screw Ø 63 x 20 Y-axis (transverse) preloaded ball screw Ø 50 x 20 Guideway systems: X-axis (longitudinal) 6 pcs Type: INA RUE 55 EL Z-axis (vertical) 4 pcs Type: INA RUE 65 EL Y-axis (transverse) 8 pcs Type: INE RUE 55 E-HL plus additional damping unit Clamping table / Table surface: T-slot size 10x: 22 H12 mm Reference slot, center 1x: 22 H8 mm T-slot spacing: 150 mm (pitch of outer slots 1,800 mm) Weight: Weight RT3000 approx. 32,000 kg Connected load: approx. 53 KVA Heidenhain TNC 640HSCI Gisdpfoygiwqjx Afnen Automatic tool changer with 80 stations Automatic oil-cooled milling head 2.5° x 1° 2 chip conveyors Coolant system with increased pressure to 37 bar ICS Special operating mode 4 RepairFIT is our proven package for a profitable entry into our product lines. Machines available in this line are sourced through a strict selection process and undergo a thorough inspection (deep-dive check). After intensive cleaning, any found defects and faults are professionally repaired by our expert service team.

Condition: used, Year of construction: 2014, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, spindle speed (min.): 20 rpm, RepairFIT by Dornhöfer The Difference. Installation & Commissioning Included! TECHNICAL MAIN DATA Year of manufacture: 2014 Travel/Capacity: Longitudinal (X): mm 3,000 Transverse (Y): mm 1,200 Vertical (Z): mm 1,500 Clamping table/Clamping surface: Length: mm 3,200 Width: mm 1,000 Number of T-slots on table surface: pcs. 7 T-slot size: mm 22H12 Reference slot: mm 22H7 Distance between slots: mm 140 Maximum transport load: kg 11,000 Paint: graphite grey RAL 7024 and agate grey RAL 7038 Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Main drive: Maximum drive power, from 198 rpm: kW 30 Spindle speed range: Spindle speed: rpm 20-6,000 Maximum torque: Nm 935 Speed control: 3-stage (oil-cooled) with automatic changeover Feed rates: X, Y and Z axes mm/min: 2 – 15,000 Maximum rapid traverse speed: X, Y and Z axes mm/min: 25,000 Maximum feed force: X, Y and Z axes: N 22,000 Space requirements: Length approx. BT3200: mm 8,100 (without cross conveyor +1,280 mm) Height approx. (at Z = 1,500 mm): mm 3,800 Width approx. (at Y = 1,200 mm): mm 5,000 (with spacer 4,500 mm) Gijdpfx Afsygipajnjn Weight: approx. kg 20,200 Connected load: approx. KVA 52 HEIDENHAIN iTNC 530 HSCI Automatic MTE universal milling head Diagonal 2.5° x 2.5° Automatic tool changer with 40 positions 2 chip conveyors + cross conveyor Coolant system with 20 bar & through-spindle coolant RepairFIT is our proven offer for a profitable entry into our product lines. The machines available in this line are sourced through a strict selection process and undergo thorough inspection (Deep-Dive Check). After intensive cleaning, any identified obvious defects and faults are professionally repaired by our qualified service team.

Condition: used, Year of construction: 2017, x-travel 1016 mm Giodjyhrbnjpfx Afnen y-travel 660 mm z-travel 635 mm

Condition: new, Year of construction: 2022, New machine Year of manufacture 2022 Save working time with recallable tools; once set up, the drive unit can be brought back to the preset position with a single movement Mobile and flexible in use; beveling, grooving, flush milling Addition to table and CNC milling machines Giedpfxow I Upzj Afnon Table size 520 x 430 mm with fine adjustment #10450 Availability: short-term Storage location: Flörsheim

Condition: used, Year of construction: 2004, Technical details: max. wheel diameter: 200 mm gear width: 60 mm max. module: 7 Gijdpexc E H Sjfx Afnjn weight of the machine ca.: 15 t table diameter: 180 mm table turning speeds: 100 U/min hob turning speeds: 750 U/min Machine in good condition, without feed, without automation Available 24.08.2024 *

Condition: excellent (used), Year of construction: 2014, operating hours: 39,000 h, functionality: fully functional, machine/vehicle number: 3325, Model S-191FTL-PRM Ø 50 mm Axis travel Milling vertical axis Z = 200 mm Milling transverse axis Y = 200 mm Milling longitudinal axis X = 410 mm Power / Thrust Z-Y 2.5 kW / 550 daN X 4.5 kW / > 550 daN X-Y-Z Traversing speed: 40 m/min Acceleration: 10 m/s² Resolution X-Y-Z: 0.0001 mm Measuring system: glass scale MAIN SPINDLE C (Horizontal turning axis) Power: 15 kW Torque / peak: 22 / 28 Nm Measuring system: direct Resolution: 0.0001° Accuracy: 0.001° Bar capacity: Ø 32 mm (option 50 mm) Turning spindle speed: 72,000°/min Giedpfow T Sl Dsx Afnon Clamping force, turning: 4,900 N at 6 bar B-AXIS SPINDLE INCLINATION (machining) Power: 4.3 kW Torque: 119 / 226 Nm Angular travel: -25° / +115° Measuring system: direct Resolution: 0.0001° Accuracy: 0.001° Rotational speed: 36,000°/min Locking torque: 200 Nm MACHINING SPINDLE Power: 8 kW Torque: S1 = 9.5 Nm / S6 = 11.5 Nm Max speed: 30,000 min-1 (option 40,000 min-1) Tool clamping force: 1,000 N Locking torque: mechanical locking with straight toothing Tool holder taper: HSK-40 (A or E) Through-spindle lubrication: 30 to 100 bar (optional) TOOL CHANGER Number of tools: 30 (option 60) Number of indexed tools: all Tool change time: 1.2 sec. Chip-to-chip time: 4.4 sec. Max tool diameter: Ø 40 mm (80 mm if adjacent station empty) Max tool length: 130 mm Max tool weight: 1.5 kg MISCELLANEOUS Installed power: 25 kVA Operating voltage: 3/N/PE/400V/230V 50 Hz Pneumatics: 6 bar (dry air) CNC CONTROL: Fanuc 31i Screen: 15'' color Keyboard: alphanumeric Control panel features: - 1 key switch for functions - 1 feedrate potentiometer 0–120% - 1 spindle speed potentiometer 50–120% - 1 quick-selection button for machine functions - 1 integrated electronic handwheel CNC Options - Data server with ATA Flash, 1GB memory capacity - J947 1 MB RAM memory - S677 TCPC (tool center point control for 5-axis machining) - S808 Al nano HPCC (Al high precision contour control II) - J930 tool tip radius compensation - J893 coordinate system rotation - J819 Helix (cylindrical) interpolation - J953 memory capacity for 1,000 programs - J828 tapping without compensation chuck - S615 insertion of radii and chamfers - J894 workpiece coordinate system - S993 part setup error - R522 inclined machining plane control with guidance Interfaces - Bumotec-specific programming to minimize collisions - Simplified tool management to prevent input errors - Tool management by threshold value, change according to part count or tool life - Automatic tool setting on machine for easier tool handling - Part counter and production management Y-AXIS (horizontal cross milling axis) Travel: 200 mm Power / thrust: 4.8 kW / 240 daN Resolution: 0.0001 mm Max travel, V1: 50 m/min Max travel, V2: 20 m/min Measuring system: glass scale Z-AXIS (horizontal longitudinal milling axis) Travel: 400 mm Resolution: 0.0001 mm Max travel, V1: 50 m/min Max travel, V2: 20 m/min Measuring system: glass scale Includes 8kW cooling unit Emergency braking system integrated Subject to errors and omissions, technical specifications are provided without obligation.

Condition: used, Year of construction: 1972, Milling machine used Make:Kunzmann Model: UF6N year of construction: 1972 Technical data: Table longitudinal travel automatic: 440 mm Table longitudinal travel by hand: 450 mm Transverse table travel 200 mm Table vertical travel horizontal/ vertical 465/500 mm Table size 860x240 mm Table swivels 45° on both sides Distance table/spindle 430 mm Spindle holder ISA 30 Quill stroke 60 mm Gedpfoudb N Djx Afnjin Tiltability of the spindle head +/- 90 18 spindle speeds horizontal 32-1342 rpm 18 spindle speeds vertical 72-2888 rpm 6 automatic feeds lengthwise 13.12-164 mm/min 6 automatic cross feeds 26.24-328 mm/min. Spindle drive 1.8/2.6 kW with inclinable vertical milling head/clamping vice/ Counter holder/collet chuck with collets Weight approx. 850 kg Dimensions approx. 1400x1900x1800 mm

Condition: new, The UWF 5 is a state-of-the-art universal milling machine that falls under the category of Conventional Vertical Milling Machines and is part of the Universal Milling Machines product group. This top model in the UWF series boasts a large work area of 1325 x 360 mm and supports a table load capacity of up to 500 kg, making it ideal for both repair shops and production departments. Constructed with a robust machine bed from high-strength HT-200 cast iron and precision-ground guideways, it ensures long-term accuracy and wear resistance. The universal cutter head can swivel on two planes, allowing for quick changes between horizontal and vertical machining, while the powerful servo axis motor enables finely stepped motorized feeds in all axes. Additionally, the 5.5 kW main drive guarantees high torque, significantly enhancing productivity and offering features like a 3-axis position indicator and a user-friendly control panel. With extensive standard equipment, including a coolant system and tool storage, the UWF 5 is built for ease of use and maintenance-free operation. For those interested in enhancing their machining capabilities, request a quote for this impressive milling machine today. Godep Aucwopfx Afnoin

Condition: used, Year of construction: 2001, x-travel 400 mm y-travel 320 mm z-travel 450 mm Control Haidenhain TNC 124 drive of main spindle 3 kW number of spindle speeds 63-3150 u/min tool taper SK 40 stroke of quill vertical 60 mm feed speeds 5-2000 mm/min rapid traverse 2 m/min work table: 800x320 mm coolant 20 l/min total power requirement 5 kW Gedjxndahepfx Afnein weight of the machine ca. 1,7 t dimensions of the machine ca. 2,2x2,4x1,6 m

Condition: excellent (used), operating hours: 8,064 h, Brand : LAGUN Model : GBM-22E Type : CNC 5 EJES Cnc :HEINDENHAIN 530 Table dimensions : 2.200 x 1000 mm Number and width of T slot: 7 x 22 mm Distance between T slots: 140 mm Axis travels (X,Y,Z) : 2.000 x 1.200 x 1.000 mm Head type : Automático Spindle speed : 4.000 rpm Taper : ISO 50 DIN 2080 Main motor : 28 kw Continuusly variable speeds : 50➗ 4.000 Speed range : 2 Rapid traverse : 10.000 mm/min Machine weight : 15 tn Electronic hand-wheel : Yes Working hours : Gjdpjyg R Abjfx Afnsin Machine running: 22.924 h Control on : 23.132 h Automatic cycle: 8.064 h

Condition: excellent (used), Year of construction: 2008, operating hours: 50,236 h, functionality: fully functional, travel distance X-axis: 2,360 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 800 mm, spindle speed (max.): 9,000 rpm, For sale is a 6-axis machining center from AXA, model VHC 2-2360-XTS / 50. The machine is in good condition and fully operational, used primarily for light machining such as aluminum. Notably, each of the two NC tables allows for workpiece clamping up to Ø1,100 mm (see drawing). A fixed milling table can also be mounted. High-speed spindle insert SK50 is available for this machine. Technical data: Year of manufacture: 2008 Control: Heidenhain iTNC 530 Operating hours: 50,236 Spindle hours: 16,319 X-axis: 2,360 mm Y-axis: 600 mm Z-axis: 800 mm Spindle taper: SK 50 Spindle power: 56 kW Torque: 355 Nm Tool changer: 52 positions (2 chains) NC rotary tables (2 units) Type: SKH-NC 7/T Table diameter: Ø 630 mm Max load: 750 kg Clamping: Hydraulic Dimensions: 5,650 mm × 3,700 mm × 3,200 mm Weight: approx. 22,000 kg Equipment includes: 50 bar high-pressure coolant system, band filter, Heidenhain RCN 729 measuring system, Renishaw OMP 60 3D probe, electronic handwheel, 2x Visiport (viewing windows), chip conveyor. Tool holders are not included in the offer, but may be provided at additional cost. Transport and loading can be organized throughout Europe for an additional fee upon request. All prices are subject to VAT. Inspection by appointment is possible. Please contact us; our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase/sale BUYING & SELLING OF PRODUCTION AND METALWORKING MACHINES, AND MORE. Are you looking for a high-quality but affordable metalworking machine for your production? Or do you want to sell yours? Giedpoyi Er Asfx Afnen For more information or to contact us, please visit our website.

Condition: used, Year of construction: 1996, total height: 3,200 mm, total width: 3,200 mm, total length: 8,000 mm, Empty weight: 26.000 kg Price: On request Bed Milling machine Bed Miller Model: CNC Manufacturer: Anayak Type: FBZ-HV-4000 CNC: Heidenhain Year: 1996 Bed-dimensions: 4500x800mm X-travel: 4000mm Gisdjwnhnfepfx Afnon Y-travel: 935mm Z-travel: 1000mm Rotatable Fräsekopf Spindle-speed: 3000rpm Spindle-take: ISO 50 Incl. peripherals and documents Dismantled for transport Video available! Machine-dimensions: 8000x3200x3000mm Machine-weight: 26000kg - Year: 1996 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 11676-FBZ - Number of axes: 3 - Travel X [mm]: 4000 - Travel Y [mm]: 935 - Travel Z [mm]: 1000 - Spindle speed max. [rpm]: 3000 - Tool holder: ISO50 - Table size length [mm]: 4500 - Table size width [mm]: 800 - Control type: Heidenhain - Control: CNC - Transport dimensions: 8000mm x 3200mm x 3200mm (l x w x h) - Transport weight [kg]: 26000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Year of construction: 1997, condition: used, Price: On request - Year: 1997 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Drive system: CNC - Control system brand: Heidenhain - Number of axes [pcs]: 5 - X-axis travel [mm]: 1200 - Y-axis travel [mm]: 880 - Z-axis travel [mm]: 800 - Table length [mm]: 5000 - Tool holder: SK40 - Max. spindle speed [rpm]: 18000 - Options: Digital readout - └ Type of digital readout: Heidenhain Gisdpfx Afswh Shvjnon Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Year of construction: 2007, condition: used, Empty weight: 2.500 kg Dimensions (LxBxH): 170 x 210 x 230 cm Price: On request - Year: 2007 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 750283 - Drive system: CNC - Control system brand: Siemens - Control system type: Sinumerik 802D - Power [kW]: 7.0 - Number of axes [pcs]: 3 - X-axis travel [mm]: 450 - Y-axis travel [mm]: 300 - Z-axis travel [mm]: 400 - Table length [mm]: 920 - Table width [mm]: 280 - Tool holder: ISO40 - Min. spindle speed [rpm]: 100 - Max. spindle speed [rpm]: 8000 - Transport dimensions: 1700mm x 2100mm x 2300mm (l x w x h) - Transport weight [kg]: 2500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Gedpfx Afewnip Rsnsin Lukas van Rossum

Condition: used, Year of construction: 2008, total length: 1,750 mm, total width: 1,500 mm, total height: 1,450 mm, Empty weight: 750 kg Price: On request - Year: 2008 Gsdeych Elepfx Afnein - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 108/1008-3 - Main motor power [kW]: 4.0 - Number of spindles [pcs]: 2 - Max. workpiece width [mm]: 180 - Transport dimensions: 1750mm x 1500mm x 1450mm (l x w x h) - Transport weight [kg]: 750kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 1991, Eye-level control panel, Aigner integral stop including feed with sliding carriage (without stop ruler), milling stop with digital display and swivel mechanism Gisdpfx Afjyi A Tdsnjn Storage location: Nattheim

Condition: like new (used), Year of construction: 2020, Console milling machine Reckermann 1300 Kombi Gedpfx Afex A Etfsnein The machine is in absolutely mint condition. The customer did not receive the parts for which the machine was intended.

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 550 mm, spindle speed (max.): 18,000 rpm, overall weight: 12,500 kg, We offer in very good condition Hermle C42U Dynamic with following options: Dynamic variant with Ø800 x 630 table Internal coolant with paperbelt filter Gjdpfx Aeya I Diofnjin Heidenhain Touchprobe Blum Laser
