Used Helical Gear Units for sale (39,360)

Year of construction: 2009, condition: excellent (used), functionality: fully functional, Technical details max. wheel diameter 2-45 mm gear width 250 mm max. module 1,5 mm min. module 0,5 mm Control Fanuc 18i-MB weight of the machine ca. 2,2 t dimensions of the machine ca. 2100 x 1440 x 1700 m Additional information Ksdpfx Ajxwuftoc Nsdw The combined CNC gear hobbing and worm milling machine KOEPFER MZ 120 is characterized by its flexible usability and is used in the small module area. Just by swiveling the milling spindle from the horizontal to the vertical position and selecting the corresponding operating mode of the CNC control, the worm milling machine becomes a gear hobbing machine and vice versa. CNC control Fanuc 18i-MB (Dialog/ISO) CNC axes = X-axis plunge axis Z-axis longitudinal axis C-axis workpiece spindle B-axis tool spindle V-axis loader axis longitudinal A-axis swivel axis tool spindle head (included as an option) Y-axis shift axis (included as an option) With the following production programs: Worm milling Hobbing Worm hobbing Bevel gear and spur gear milling Bevel gear hobbing Milling cycles = straight, oblique, crowned toothing, radial, radial-axial, co- and counter-rotating milling, roughing, finishing, worm gears, straight-toothed bevel gears, face gearing (option only in the partial process) Worms [Equipment] Coolant tank 300 liters KF with LNS Turbo MS 250 Chip conveyor, built in 2021!!! Kraft and Bauer fire extinguishing system Spiral conveyor Machine documentation [Technical data] Workpieces: Workpiece diameter 2-45 mm Max. workpiece length 250 mm Tooth length 150 mm Max. module in steel= 1 mm (gear hobbing) 1.5 mm (worm milling) 0.5 mm (bevel gear hobbing) Tools: Cutter diameter= 16-32 mm (gear hobbing) 40-63 mm (worm milling) Machine: Max. setting angle of milling head= +/- 45° (gear hobbing) +/- 30° (worm milling) Shift travel= 34 mm (manual adjustment) 34 mm (CNC axis) Collet/retraction mandrel W 20 Max. speed of workpiece spindle 770 rpm. Milling spindle drive 0.55 kW Max. milling spindle speed 8000 rpm Axis drives = X-axis (plunging) / travel 80 mm via CNC Z-axis (longitudinal feed) / travel 190 mm via CNC C-axis (workpiece axis) via CNC Rapid traverse = X-axis 6000 mm/min. Z-axis 6000 mm/min. Hydraulic unit 0.37 kW

Condition: used, Gleason No 24A Complete with change gears. Kedjw A Rytepfx Ac Nedw "CONIFLEX" STRAIGHT BEVEL GEAR GENERATING MACHINE COMBINATION ROUGHER/FINISHER, SUITABLE FOR "GENERAL JOBBING" PRODUCTION OF STRAIGHT BEVEL (CONIFLEX/CROWN) GEARS UP TO 35.5 (901MM) PITCH DIAMETER, (AT 10:1 RATIO), 6" (125MM) FACE-WIDTH, WITH CUTTING CAPABILITY UP TO 1.25 DP (20.4 MODULE) Specifications Manufacturer GLEASON Model 24A Condition Used Serial Number 637001.0 Stock Number 28603 Longest cone distance (1 3/4" stroke) 18" (457MM) Shortest cone distance 0" 10 to 1 ratio 35.5" (901MM) 2 to 1 ratio 31.75" (805MM) 1 to 1 ratio 25" (635MM) Minimum pitch angle 5.42 DEGREES Extreme ratio 10 TO 1 Maximum pitch 1.25 DP (20.4 MODULE) Maximum pitch angle (shafts at 90 degrees) 84.18 DEGREES Maximum face length 6" (152MM) Diameter (large end of taper) 6" (152MM) Taper per foot .75" (18MM) Depth of taper 6" (152MM) Diameter of thru bore 5” (127MM) Spindle nose to machine center 5”-26” (127-660MM) Cutter speeds (strokes per minute) 22 TO 170 Feeds (seconds per tooth) (22 feeds) 23 TO 645 Floor space required 74" X 105" (1880X2660MM) Machine net weight 24,400 LBS. (11,295 KGS)

Condition: good (used), Year of construction: 1998, Number of working hours 126348.3 h control Siemens SINUMERIK voltage 400 V weight of the machine ca. 8,0 t Key data Normal module: 6 mm Max. workpiece pitch circle diameter: 250 mm Max. tooth width (straight teeth): 60 mm Helix angle adjustment: 45° to +0.5° Axis angle: 0° to 90° Center distance workpiece/jigging spindle: –80 mm to +320 mm Stroke position, stroke length Max. stroke position range (depending on stroke length): 0 mm to 80 mm Stroke position adjustment range: 0 mm to 80 mm Stroke drive Stroke rates infinitely variable Standard: 100 to 1200 DH/min Motor for stroke drive: 9 kW Maximum cutting speed: 150 m/min Kdedoxyadtjpfx Ac Now Feeds Rotation axes (tool C1, workpiece C2 axis): Feed stepless relative to 100 mm pitch circle diameter: 1.0 to 9420 mm/min Radial axis (column slide X1 axis): Feed continuously variable: 1.0 to 9420 mm/min, rapid traverse corresponds to maximum feed rates Connected load / weight Total connected load: 26 kVA Total weight (standard version): approx. 9,000 kg

Condition: used, Year of construction: 1954, total height: 2,000 mm, total width: 1,600 mm, total length: 2,400 mm, Empty weight: 1.000 kg Price: On request Chuck: 700mm  Kdjdpsxbq U Ssfx Ac New Workpiece maximum height: 550mm  X axis displacement: 450mm - Year: 1954 - Documentation available: No - CE certificate present: No - Transport dimensions: 2400mm x 1600mm x 2000mm (l x w x h) - Transport weight [kg]: 1000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), Gear motor, electric motor, electric gear motor -Speed: 116 rpm -Power: 0.25 kW Ksdsc U Hgzjpfx Ac Nedw -Diameter: Ø 16 mm -Construction: B5 -Protection class: IP 54 -Number: 7x motors available -Price: per piece -Dimensions: 340/180/H145 mm -Weight: 9.8 kg

Condition: good (used), Year of construction: 2008, 8 units Muratec turning centers. MURATEC MW 120, year 2003 MURATEC MW 200, year 2003 MURATEC MW 120, year 2004 MURATEC MW 120, year 2004 MURATEC MW 120, year 2007 MURATEC MW 120, year 2007 MURATEC MW 120, year 2008 MURATEC MW 120, year 2008 Ksdpfoxwb Smjx Ac Nodw

Condition: used, weight / kg Kedpfexwdyajx Ac Nedw taper MK /

Condition: good (used), Year of construction: 1992, functionality: fully functional, Technical Data – Lorenz LS 180 CNC External gear cutting – max. outside diameter: 280 mm Internal gear cutting – max. inside diameter: 100 mm + cutter diameter Max. workpiece outside diameter: 420 mm Max. module: 5 Max. stroke length: 60 mm Stroke rate (stepless): 250 – 1250 strokes/min Machine weight: approx. 7,500 kg Machine dimensions (L × W × H): approx. 4,500 × 2,500 × 2,700 mm Additional Information Kdodexyatuepfx Ac Njw Year of manufacture: 1992 Condition: good, well maintained Operational status: fully functional, ready for operation Location: Turkey Availability: immediately Inspection: test under power and inspection on site possible at any time by appointment

Condition: new, power: 316 kW (429.64 HP), fuel type: diesel, tire size: 315/80R22.5, axle configuration: 4x2, wheelbase: 3,800 mm, fuel: diesel, color: white, driver cabin: sleeper cab, gearing type: automatic, emission class: euro3, suspension: steel-air, Equipment: air conditioning, fridge, = Additional options and equipment = - Sleeper cab = Notes = Kedew Np Alspfx Ac Nsdw Fuel tank: 770 ltr. with step Air conditioning Cab air suspension Fridge Radio with Bluetooth and DAB = Further information = Transmission: TX-12M, automatic Tyre size: 315/80R22.5 Front axle: Steered; Suspension: Air suspension Rear axle: Suspension: Leaf suspension Gross vehicle weight: 20,000 kg

Condition: ready for operation (used), Habermann Pump-units Kdsdji A Aqvspfx Ac Njw 1=Type HPK 150/450 In 200mm, Out 150mm Cap.: 400-600 cub/h Driving: E-Motor 90 kW 2=Type HPK 200/560 In 250mm, Out 200mm Cap.: 450-800 cub/h Driving: E-Motor 90 kW Both including : Chassis and Spare-parts

Condition: good (used), Year of construction: 2004, Ref. -No.: 10612 Manufacturer: LIEBHERR Type: LC 3002 Kdjdpfsxxpdgjx Ac Now Year of construction: 2004 Type of control: CNC Control: LIEBHERR Storage location: Halberstadt Country of origin: Germany Serial no.: 30XX Max. Module: 30 mm Min. Module: 4 mm Max. Workpiece Diameter: 3000 mm ambient temperature: +15...+38 ° cutting speed: 25 - 250 m / min Milling head swivel angle: 0,001 ° Resolution accuracy: 0,1 Degree Workpiece table load: 300 kN Operating voltage: 400 V control voltage: 24 V frequency: 50 Hz Max. rated current: 230 A Fuse in the supply line: 250 A Max. milling diameter spur gears/helical gears: 3.000 mm Further information: Suitable for internal and external gear cutting. The machine can be viewed by appointment.

Condition: excellent (used), Gear motor, electric motor, electric gear motor, stainless steel motor, stainless steel gear motor, stainless steel bevel gear motor Gearmotor: SEW-Eurodrive type SA87R57DRN80M4 -Speed: 17 rpm -Power: 0.75 kW -Hollow shaft: Ø 60 x 250 mm -Protection class: IP54 -Dimensions: 840/310/H370 mm Ksdew A Abijpfx Ac Nodw -Weight: 128 kg

Year of construction: 2015, condition: excellent (used), Polygon and surface machining, gear and spline shaft machining, gear tooth pointing, shift stop machining, chamfering and deburring, SCUDDING See document Kdedpfxexupg Ts Ac Nsw

Condition: excellent (used), Year of construction: 2011, operating hours: 74,533 h, functionality: fully functional, LIEBHERR LC-380 (2011) – 6/7-Axis CNC Gear Hobbing Machine MARCH 2025 Service Report from LIEBHERR included in the documentation Ø 380 mm | Module up to 7 (hobbing) / 9 (profile grinding/milling) | 600 mm face width | Siemens 840D sl Very well-equipped, late 2011 model (s/n FN9014) with special filtration for non-ferrous metals. Wet or dry machining possible; includes oil/media cooler, paper band filter, extensive hobbing arbors and accessories. The machine is fully enclosed and described as being in very well-maintained condition. Equipment & Options: - Siemens 840D sl CNC with hand-held control unit (teach) - Full enclosure, table clamping - Tangential hobbing device for high accuracy - Measurement system for A-axis swivel accuracy - Device for single-track measurement/spindle approach & probing function - Programmable tailstock - Paper band filter for non-ferrous material, scraper chip conveyor - Oil cooler, English language option - Several hobbing arbors/mandrels, HSK-A50 interface - Complete set of books & manuals Technical Data: - Max. gear diameter: 380 mm - Min./Max. center distance: 15 / 400 mm - Max. axial travel: 600 mm - Max. module (hobbing): 7 - Max. module (profile gear milling): 9 - Table diameter: 320 mm | Max. table load: 18 kN - Head swivel range (FK2.2): ±35° - Main drive power: 14 kW - Max. hob speed: 1,200 min⁻¹ - Max. tangential travel: 300 mm - Max. tool diameter × length: 160 × 330 mm - Tailstock column axial travel: 540 mm - Interface: HSK-A50 - Electrical: 220 V / 60 Hz - Machine weight: approx. 15,000 kg - Machining: wet or dry - Serial number: FN9014, year of manufacture 2011 - Stock no.: 16634234 | Model: LC-380 Kedpfxjxlz Nbs Ac Nsdw Key Customer Benefits - Flexibility: Wet/dry machining + filtration suitable for non-ferrous metals → wide material range - Accuracy: Tangential hobbing & A-axis measurement device → high gear quality - Productivity: 1,200 min⁻¹ hob speed, 600 mm face width → large parts in a single setup - Process Reliability: Oil/media cooling, table clamping, full enclosure - Turnkey Package: Multiple hobbing arbors and mandrels + complete documentation

Condition: new, power: 349 kW (474.51 HP), fuel type: diesel, tire size: 315/80R22.5, axle configuration: 4x2, wheelbase: 3,800 mm, fuel: diesel, color: white, driver cabin: sleeper cab, gearing type: automatic, emission class: euro3, suspension: steel, Equipment: air conditioning, fridge, = Additional Options and Equipment = - Sleeper cab = Notes = Fuel tank: 700 ltr. Air conditioning Cab air suspension Roof spoiler Fridge Bluetooth DAB radio Kodpfx Acow Np D Ao Nsdw = Further Information = Transmission: TX-12M, automatic Tyre size: 315/80R22.5 Suspension: leaf spring Front axle: steered Gross vehicle weight: 20,000 kg

Condition: ready for operation (used), Eagle Gear Box Reduction : i = 1 : 85 Kdjdpfx Aei A Ap Ajc Njw Dimensions : 1100 mm x 800 mm x 400 mm Ext. Axle : diam. 50 mm, with Pulley SPC 400-3 Int. Axle : diam. 100 mm, with socket

Condition: used, Year of construction: 1959, total height: 1,900 mm, total width: 2,200 mm, total length: 1,500 mm, Empty weight: 2.500 kg Price: On request - Year: 1959 - Documentation available: Yes - CE certificate present: No - Serial number: 80 - Control: Conventional - Motor power: 5.0kW - Transport dimensions: 1500mm x 2200mm x 1900mm (l x w x h) - Transport weight [kg]: 2500kg - Transport packages [pcs.]: 3 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Kdjdpfewniiksx Ac New Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), Gear motor, electric motor, electric gear motor Kdjdpfx Aceci N Hhe Njw -Speed: 33 rpm -Power: 1.1 kW -Design: B3 -Diameter shaft: 40 mm -Protection rating: IP 54 -Height shaft axis: 155 mm -Long distance between holes: 115mm -Hole spacing across: 200 mm -Number: 1x motors available -Price per piece -Dimensions: 580/270/H260 mm -Weight: 49kg

Condition: good (used), Year of construction: 1975, max. wheel diameter 630 mm gear width 425 mm table hole 125 mm clamping table 550 mm max. module 10 axial-feeds 0,40 - 6,80 mm/U radial feeds 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle 50 - 425 mm no. of teeth min. 8 milling cutter dia. x width 192 / 215 mm shifting 200 mm main drive motor 7,5 kW total power requirement 22,5 kVa weight of the machine ca. 8,2 t Machine equipment: - Universal milling head with tangential displacement - Pressure reducing valve for counterholder - Magnetic chip transport --> Working range Largest module to be milled (in steel 600 N/mm²): 10 mm --> Straight gear teeth: --> Largest workpiece diameter: 630 mm --> Largest axial slide travel (Z-axis): 425 mm --> Smallest number of teeth to be milled: 8 --> Dimensions Diameter of workpiece table: 550 mm --> Diameter of table bore: 125 mm --> Diameter of workpiece mandrel: 36 mm --> Largest milling cutter that can be clamped: --> Diameter: 192 mm --> Width: 220 mm --> Diameter of milling cutter mandrels: 32 mm --> Centre distance between milling cutter and workpiece: Kdsdpfjw A Am Sjx Ac New --> Maximum distance: 425 mm --> Minimum distance: 50 mm --> Drive taper for cutter mandrels: Morse taper 5 --> Maximum cutter displacement: 200 mm --> Speeds and feeds Cutter speeds: 45 - 280 rpm --> Axial feed (Z axis): 0.40 - 6.30 mm/rev --> Radial feed (X axis): 0.10 - 1.60 mm/rev --> Tangential feed (Y axis): 0.14 - 2.24 mm/rev Translated with (free version)

Condition: like new (used), Year of construction: 2019, operating hours: 3,000 h, functionality: fully functional, LIEBHERR LK 200 – CNC Gear Skiving Machine Main technical data CNC control: Siemens HMI (Liebherr LHStation / LHMobile operator concept) Max. module: approx. 3.0 mm Max. workpiece diameter: approx. 200 mm Max. workpiece weight: approx. 25 kg Table diameter: approx. 285 mm Axial travel: Axial stroke up to approx. 500 mm Machining stroke / shift distance: approx. 400 mm Max. spindle power: 16 kW Max. workpiece spindle speed: 3,000 min⁻¹ Max. feed rate (radial): 7,500 mm/min Hob / tool speed: up to 4,000 min⁻¹ Max. tool diameter: approx. 150 mm Wet machining Especially for internal gears, wet machining offers major advantages: During the skiving process the cutting edges are cooled and lubricated, which significantly reduces the thermal load on the tools. The chips produced are reliably removed and are not drawn back into the cutting zone. Optimal chip evacuation leads to improved gear accuracy and superior surface quality. LHStation & LHMobile operator concept Liebherr intelligently separates programming and machine operation into two units: LHStation (fixed operator panel / monitor): Kdedsxwzvlopfx Ac Now Large screen area for data input and process monitoring Multi-touch surface with additional tactile elements Increased operating speed and process reliability LHMobile (mobile handheld unit): 10" multi-touch as standard Context-sensitive views such as PLC/NC keys, program status and messages Wired signal transmission for maximum safety during setup Ideal for ergonomic, user-friendly operation directly at the machine Skiving³ – overview of advantages Machine Very rigid machine design with cast-iron bed to absorb process forces Ringloader concept for fast workpiece change Tailstock for shaft machining and optimum workpiece clamping Optional chamfering during the machining process Burst-proof enclosure, suitable for both dry and wet machining (oil or emulsion) Tool Design and manufacture of conical and cylindrical skiving cutters Process-optimized tool design for every workpiece Tools available in PM-HSS and solid carbide versions Process Comprehensive process analysis and simulation to determine optimum cutting conditions Use of technology applications for customized process optimization Collision analysis with calculation software to secure the process Machine concept – efficiency through gear skiving Gear manufacturers are looking for alternatives that are: More productive and cost-effective than gear shaping At the same time more flexible than broaching The LK 200 is designed exactly for this: The basis is the high rigidity of the machine bed and skiving head (special bearing concepts, also for longer tool holders – crucial for internal gears). Combined with a burst-proof housing, the machine is suitable for both dry and wet cutting. The integrated tailstock unit makes the system universally usable for: External and internal gears Shafts and short gears on one machine By combining machine, tool and process (Skiving³), the LK 200 offers a fully integrated solution for highly productive gear skiving.

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, CNC Gear Hobbing Machine Horizontal . no tailstock, just for chuck parts . max. gear diameter: 90 mm Kdodpoqaf U Tjfx Ac New . max gear width (b): 50 mm . max module: 3

Condition: used, Year of construction: 1998, impressions 76 Mio. Kodow Ny Tnepfx Ac Nsdw max. printing speed sheets 15000 /h max. paper size 37 x 52 cm dampening system Alcolor plate clamping system Autoplate machine control CPC 1-04

Condition: excellent (used), Year of construction: 2006, operating hours: 53,244 h, functionality: fully functional, Technical Data – Gleason Phoenix II 600HC (CNC Hypoid Gear Cutting Machine) Kdodpfsxwzu Ijx Ac Njw Working Area Max. workpiece diameter: Ø 600 mm Max. tooth depth: 24.6 mm Max. gear width: 110 mm Number of teeth: 1–300 Cutterhead size face milling (FM): 18" diameter Cutterhead size hobbing (FH): 210 mm radius Max. cutter spindle speed: 600 min⁻¹ Work Spindle Front taper diameter: Ø 203 mm Taper bore diameter: Ø 181 mm Bore depth: 884 mm Max. work spindle speed: 600 min⁻¹ Dimensions and Weight Footprint L × W × H: 4.4 × 3.5 × 3.5 m (incl. peripherals) Machine weight: 26,000 kg Connection Data Total connected load: 139 kVA Main fuse: 200 A Operating voltage: 400 V Mains frequency: 50 Hz Control voltage: 24 V DC

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 27506, Complete overhaul in 2009 Kdjdpsxtpg Refx Ac Nsw CNC gear hobbing machine Pfauter PE 150 Serial number: 27 506 Year of manufacture: 1991 – complete overhaul in 2009 CNC control: SINUMERIK 840 D

Condition: used, Year of construction: 1975, max. printing speed sheets 8000 /h max. paper size 32 x 46 cm dampening system Aquatron Kjdpjxu Nudjfx Ac Nedw numbering unit incl N+P
