Used Fast Radial for sale (3,639)

Condition: used, Year of construction: 1957, Technical details: bore capacity in steel (diameter): 32 mm arm length:: 1000 horizontal adjustment of the boring slide: 700 mm vertical adjustment of arm: 600 (motorisch) mm swivel range of the arm: 90° rechts/links Grad distance table - lower edge spindle: min./max.: 200 / 1120 mm spindle taper MT: 4 bore spindle stroke: 420 (manuell-automatisch) mm range of revolutions per minute - continous: 20 - 2000 / 3 step U/min feed: 01, / 0,2 / 0,3 / 0,4 / 0,8 / 1,2 mm/U column diameter: 250 mm base plate surface area: 1100 x 600 mm total power requirement: 4,6 kW weight of the machine ca.: 2,5 t dimension machine xH: 1,8 x 0,8 x 2,5 m Tool ejection via expulsion wedge Equipment: Coolant system with pump (without feed) Drill cube L: 760 x W: 500 x H: 510mm / horizontal surface 760 x 500mm and vertical surface 760 x 510mm Machine ilumination Njdpfx Asvhbpqsmnolb *

Condition: used, Year of construction: 1971, Technical details: bore capacity in steel (diameter): 23 mm workpiece height max.: ./x. 2 mm drill capacity in cast iron: Ø 26 mm spindle taper: MK 3 bore spindle stroke: 135 (manual/automatic) mm range drill spindle revolution per minute: 7step U/min feed range: mm/U Table dimensions: 1200 x 500 mm Nljdev Ay T Djpfx Amnob table surface area: 1070 x 400 mm total power requirement: 3,55 kW weight of the machine ca.: 1,4 t dimension machine xH: 1,7 x 1,2 x 2,2 m Jib Length Arm: -vertical adjustment: 450mm and horizontal adjustment: 610mm -swiveling 360°, hydr. lock Right/left rotation for thread cutting with automatic switchover Operation via control panel Coolant tank with pump *

Condition: used, Year of construction: 1960, Technical details: workpiece height max.: 600 mm Arm length: ca. 700 mm bore capacity in steel (diameter): 25 mm Table dimensions: 1100 x 400 mm Nledpfxjx Afn Ne Amneb

Condition: used, Radial drilling machine WEBO Type R4bR Serial No. 15 / E195 Year of manufacture: approx. 1965 Drilling capacity: 50 mm Spindle taper: MT 5 Maximum spindle outreach: approx. 1250 mm (to column) Clamping surface: 1400 x 1000 mm Column diameter: 315 mm Nledpfxju T Ty He Amnob Spindle speed: 30 - 1325 rpm, 9 steps Feed: 0.12 - 2 mm/rev, 9 steps Electrical connection: 380 Volt, 50 Hz - Spindle speed in 9 steps - Motorized height adjustment of the boom Required floor space for operation (L x W x H): 220 x 100 x 285 cm Transport dimensions (L x W x H): 220 x 100 x 260 cm (without motor for height adjustment) Weight: approx. 2.8 t.

Condition: used, Radial drilling machine with plate field WEBO type HRH 100 / 3000 Machine. No. 10009555/7 -- 1110185 -- 6046 Year of manufacture 1979 Drilling capacity Ø 100 mm in ST 60 at feed rate 0.5 mm/rev. Nljdofbt Huspfx Amneb Nominal throat depth 3000 mm Max. throat depth max. 3100 mm Spindle holder MK 6 Spindle speed 22.4 - 1600 rpm 36 steps Feed rate 0.05 - 2.5 mm/rev 18 steps Spindle - base plate distance 970 - 2335 mm Pinol stroke 325 mm Swivel range of the arm 360 movable on bed, bed length 7500 mm Clamping area panel field 8000 x 2100 mm - Electrical central clamping - Drilling unit can be moved lengthwise on the machine bed by electric motor - Panel field consisting of 2 clamping plates with 7x T-slot, (length 4000 x width 2100 x panel thickness 360 mm) Space requirement L x W x H 8000 x 4550 x 4300 mm Maximum height 4300 mm Transport height (bed with drilling machine) approx. 3150 mm Transport weight (bed with drilling machine) approx. 20 tons Transport dimensions of panel section L x W x H 4000 x 2100 x 900 mm (2 panels stacked on top of each other) Transport weight panel field approx. 14 ton. good condition

Condition: used, Year of construction: 2006, Radial drilling machine Manufacturer: Valmer Type: TR 80/2500 SP Year of manufacture: 2006 Table dimensions: 1,000 x 800 x 560 mm Maximum drilling diameter: 80 mm Maximum threading diameter: 42 mm Distance between spindle axis and column, maximum: 2,500 mm Distance between spindle axis and column, minimum: 500 mm Head movement, horizontal: 2,000 mm Distance between spindle nose and work surface, maximum: 2,000 mm Distance between spindle nose and work surface, minimum: 550 mm Spindle stroke: 450 mm Morse taper: MT 6 Power: 7.5 kW Njdpfx Aow Dbgyjmnjlb Machine dimensions: 3,730 x 1,400 x 3,825 mm Weight: 11,000 kg 19526

Condition: good (used), Year of construction: 1998, functionality: fully functional, DONAU DANUMERIC 440, year of manufacture 1998 Technical specifications: - Table 1800 x 600 mm, 4 T-slots - Drilling radius 540 – 1590 mm - Spindle taper SK40 Nodsy Txlropfx Amnolb - Speed range 15 – 2800 rpm - Motor power 5.5 kW - Weight approx. 2,800 kg

Condition: used, Year of construction: 2007, bore capacity in steel (diameter) 40 mm arm length 1050 mm turning speeds 15 - 2800 U/min feed range 0,075 - 0,45 mm/min dimensions 2450 x 1300 x 2300 mm Weight 1500 kg Equipment: Machine in top condition 2026 serviced and repaired by the factory customer service Machine design - Work table 1800 x 600 mm with 4T-slots - Boom travel 1050 mm - SK 40 drilling spindle with tool clamping device - Infinitely variable speed programming - Infinitely variable quill feed via three-phase servo motor - 2 T-slots 18 mm on the machine base at the rear - 2 T-slots 18 mm on the left machine base frame - Thread cutting device - Central lubrication - Coolant device - Machine light - CE marking - Safety device - USB interface Dimensions and travels Tool holder SK 40 Column diameter mm 195 Table dimensions mm 1800 x 600 Nsdpfjy Nd T Hox Amnelb Number of T-slots 4 Distance between T-slots mm 125 Quill stroke (Z-axis) mm 200 Column stroke (W-axis) mm 410 Distance spindle bottom edge - min mm 70 Table top edge max. mm 680 Distance spindle bottom edge - min mm 970 Floor max. mm 1580 Drilling radius mm 540 - 1590 Worktable height mm 900 Cutting values Drilling capacity into solid St 60 ? 40 GG 22 ? 50 Thread cutting St 60 M 36 GG 22 M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100 % ED. Speed range: min -1 15 - 2800 Torque Nm max. 250 constant from min -1 15 - 2000 Feed drives X-axis - AC - servo motor kW 0.25 Y-axis - AC - servo motor kW 0.25 Z-axis - AC - servo motor kW 4.50 W-axis - AC - servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min. 7,5 / 7,5 / 5 Rapid traverse speeds (W): m/min. 3 Feed rates stepless mm/min 5 - 2000 Accuracy Positioning accuracy X-, Y-axis to 1200 mm mm ± 0.075 Electrical data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Hydraulic unit for clamping kW 0.75 Total connected load kVA 13.0 Weight Danumeric 440 (without packaging) with table 1800 x 600 mm kg 2800 CNC control Axes: 3 (X, Y, Z, ) Processor: 32-bit CPU Screen: TFT flat screen, backlit, easy to read from all sides readable from all sides, 215 x 160 mm Position information: Cartesian or polar, absolute or incremental measurements, Unit of measurement: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: tool management, tool suggestions according to machining type, material-dependent cutting data suggestions Tool management: max. 500 tools Subroutine technology: yes Standard software options: Programming in dialog, 38 zero offsets, rotation and mirroring, teach-in for X,Y,Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for by manually probing the workpiece for: - any clamped rectangular parts - any clamped round parts - Mediation of cast and flame-cut parts - Angular position detection for round parts by touching reference edges or surfaces Test graphic Graphic display of drilling patterns

Condition: reconditioned (used), functionality: fully functional, Drilling Machine Brand: GSP Model: 407C22 Reach: 2250 mm Drilling capacity (steel): - Normal feed: 70 mm diameter - Slow feed: 90 mm diameter Carriage travel on arm: 1900 mm Drilling radius (min. - max.): 630 - 2500 mm Nledpfx Amsy D Hr Ueneb Height (min. - max.): 500 - 1750 mm Vertical arm travel: 850 mm Spindle stroke: 400 mm Spindle speeds: 25 to 1400 rpm Motor power: 6 kW Spindle taper: MT 5

Condition: refurbished (used), Year of construction: 1996, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Dimensions and travel paths Tool holder SK 40 Table dimensions mm 4000 x 800 Number of T-slots 6 Distance between T-slots mm 140 Distance between spindle bottom edge min. mm 140 Table top edge max. mm 740 Drilling radius min mm 540 max. mm 1590 U-axis travel path mm 2600 Y-axis travel path mm 1050 Quill stroke (Z-axis) mm 200 Column stroke (W-axis) mm 400 Cutting values Drilling capacity into solid material St 60 mm 40 GG 22 mm 50 Thread cutting St 60 M 36 GG 22 M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100% duty cycle. Speed range: min -1 15 - 2800 Torque Nm max. 250 constant from min -1 15 - 200 Feed drives X-axis - AC servo motor kW 0.25 Y-axis - AC servo motor kW 0.25 Z-axis - AC servo motor kW 4.50 W-axis - AC servo motor kW 2.50 U-axis - AC servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min. 7.5 / 7.5 / 5 Rapid traverse speeds (U/W): m/min. 7.5 / 3 Feed rates infinitely variable mm/min. 5 - 2000 Feed force N 12000 Accuracy Positioning accuracy X, Y axis up to 1200 mm mm ± 0.075 Repeatability X, Y axis mm ± 0.03 Positioning accuracy Z axis mm ± 0.05 Repeatability Z axis mm ± 0.03 Positioning accuracy W axis mm ± 0.05 Repeatability W axis mm ± 0.03 Electrical data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Total connected load kVA 13.0 CNC control Njdpfxjv If T Ts Amnslb Axes: 5 (X, Y, Z, W, U), expandable Screen: TFT flat screen backlit, easy to read from all sides Position information: Cartesian or polar, dimensions absolute or incremental, Unit of measurement: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: tool management, tool suggestions according to machining type, cutting data suggestions depending on material Tool management: max. 500 tools Sub-program technology: yes Machining cycles: cycles for centering, drilling, thread cutting, reaming, countersinking and boring, freely programmable cycle for special tools, dwell time possible for each cycle Chip breaking / chip removal: possible for drilling cycle Drilling patterns: row of holes, circle of holes, matrix Basic software: programming in dialog, 38 zero point shifts, turning and mirroring, teach-in for X, Y, Z, restart in the program with optional functions for targeted entry Zero point determination: cycles for determining zero points by manually touching the workpiece for: - any clamped right-angled parts - any clamped round parts - mediation of cast and burnt parts - Angular position detection for round parts by touching - reference edges or surfaces Data interfaces USB interface Painting (new painting) Standard painting, two-component textured paint Machine upper part light gray RAL 7035 Machine lower part signal blue RAL 5005 Documentation Operating and programming instructions Electronics circuit diagram Spare parts drawings Test report for mechanics, electrics and safety equipment

Condition: used, Year of construction: 2000, functionality: fully functional, feed length X-axis: 4,000 mm, feed length Y-axis: 1,050 mm, feed length Z-axis: 200 mm, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Dimensions and Travel Ranges Tool holder: SK 40 Table dimensions: 4000 x 800 mm Number of T-slots: 6 T-slot spacing: 140 mm Distance: Spindle lower edge min. 140 mm Table upper edge max. 740 mm Boring radius: min. 540 mm max. 1590 mm Travel range U-axis: 2600 mm Travel range Y-axis: 1050 mm Quill stroke (Z-axis): 200 mm Column stroke (W-axis): 400 mm Machining Data Drilling capacity in steel St 60: 40 mm Drilling capacity in cast iron GG 22: 50 mm Thread cutting: St 60: M 36 Thread cutting: GG 22: M 42 Main Spindle Drive AC motor, frequency-controlled: 5.5 kW at 100% duty cycle Speed range: 15 - 2800 min-1 Torque: max. 250 Nm Constant from: 15 - 200 min-1 Feed Drives X-axis - AC servo motor: 0.25 kW Y-axis - AC servo motor: 0.25 kW Z-axis - AC servo motor: 4.50 kW W-axis - AC servo motor: 2.50 kW U-axis - AC servo motor: 2.50 kW Rapid traverse rates (X/Y/Z): 7.5 / 7.5 / 5 m/min Rapid traverse rates (U/W): 7.5 / 3 m/min Feed rates, stepless: 5 - 2000 mm/min Feed force: 12000 N Accuracy Positioning accuracy X, Y-axis on 1200 mm: ± 0.075 mm Repeatability X, Y-axis: ± 0.03 mm Positioning accuracy Z-axis: ± 0.05 mm Repeatability Z-axis: ± 0.03 mm Positioning accuracy W-axis: ± 0.05 mm Repeatability W-axis: ± 0.03 mm Electrical Data Operating voltage / frequency: 400 / 50 V / Hz Control voltage: 24 V Total connected load: 13.0 kVA CNC Control Axes: 5 (X, Y, Z, W, U), expandable Display: TFT flat screen, backlit, easily readable from all sides Position data: Cartesian or polar, dimension data absolute or incremental Units: mm or inch, or in degrees Interpolation: 2 axes (X, Y) Technology database: Tool management, tool suggestions based on machining process, material-dependent cutting data suggestions Tool management: max. 500 tools Subprogram technique: yes Machining cycles: Cycles for centering, drilling, thread cutting, reaming, countersinking and counterboring, freely programmable cycle for special tools, dwell time possible for each cycle Chip breaking / chip removal: possible during drilling cycle Drilling patterns: hole pattern, hole circle, matrix Basic software: Programming in dialog mode, 38 zero point offsets, rotation and mirroring, teach-in for X, Y, Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for: Nsdpfx Asy Ttrtomnslb - rectangular parts mounted in any way - round parts mounted in any way - determination of castings and forgings - angle detection in round parts by probing reference edges or surfaces Data interfaces: USB interface Painting (Repainting) Standard painting, two-component textured paint Machine upper part: light gray RAL 7035 Machine lower part: signal blue RAL 5005 Documentation Operating and programming manual Electrical circuit diagram Spare parts drawings Test report for mechanics, electrical components and safety devices

Condition: ready for operation (used), DONAU DR 23 - High-speed radial drilling machine - Drilling capacity / steel approx. 28 mm - Arm length 700 mm - Morse taper MK 3 - Speed range 70-1550 rpm (gearbox) Nedpfx Aey Uv Tvomnolb - Automatic feeds 0.075-0.3 mm - Thread cutting device - Drilling depth approx. 130 mm - Hydraulic clamping - Documentation Dimensions: L x W x H 2 x 1.7 x 1.9 meters / Weight 1900 kg Subject to errors and omissions.

Condition: used, Year of construction: 1965, bore capacity in steel (diameter) 45 mm arm length 325 / 1000 mm workpiece height max. ca. 1000 mm spindle taper MT 4 spindle turning speed range 40 - 1700 U/min Nlodpfx Ajvh Nb Ijmnjb feeds 0,125 - 1,25 mm/U distance spindle/base plate 385 / 1400 mm quill stroke 325 mm crossrail adjustment vertical 700 mm 360 ° boring head horiz. adjustable 675 mm base plate surface area 1300 x 800 mm total power requirement 6,2 kW weight of the machine ca. 3,8 t dimensions of machine L x W x H 2,30 x 0,98 x 2,82 m - autom. feed - right-/left spindle run Accessories: box table 1000 x 750 x 500 mm, hydr. vice, width of jaws 200 mm, coolant

Condition: used, Year of construction: 1980, bore capacity in steel (diameter) 50 mm arm length 1250 mm distance spindle/base plate 1350 mm bore capacity in cast iron 60 mm spindle taper MK 5 spindle turning speed range 12,5 - 1000 U/min feeds 0,06 - 0,5 mm/U crossrail adjustment vertical 620 mm column diameter 350 mm total power requirement 7,7 kW weight of the machine ca. 4,6 t dimensions of machine L x W x H 2,53 x 1,15 x 2,82 m Nedpfx Aevh Nbzsmnslb Accessories: swivelling box table, coolant - additional column guide at the end of arm -

Condition: used, Year of construction: 1991, bore capacity in steel (diameter) 50 mm arm length 1100 mm workpiece height max. ca. 1000 mm Nlsdpfx Amou Sblwsnjb bore capacity in cast iron 60 mm spindle taper MK 5 spindle turning speed range 28 - 2500 U/min feeds 0,05 - 2 mm/U quill stroke 300 mm distance basic plate - spindle nose 630 - 1380 mm crossrail adjustment vertical 750 mm total power requirement 6 kW weight of the machine ca. 4 t dimensions of machine L x W x H 2,74 x 1,14 x 2,59 mm - with thread cutting attachment - Accessories: box table 550 x 550 x 550 mm, vice, coolant

Condition: used, Year of construction: 1970, bore capacity in steel (diameter) 50 mm arm length 1250 mm workpiece height max. ca. 1150 mm bore capacity in cast iron 60 mm spindle taper MK 5 spindle turning speed range 25 - 2000 U/min feeds 0,06 - 0,5 mm/U crossrail adjustment vertical 620 mm column diameter 350 mm total power requirement 7,5 kW weight of the machine ca. 4,6 t dimensions of machine L x W x H 2,50 x 1,08 x 2,50 m Nledpfovh Nbhjx Amnob Accessories: box table 1100 x 700 x 550 mm, coolant pump

Condition: used, bore capacity in steel (diameter) 120 mm arm length 2500 mm workpiece height max. ca. 1800 mm bore capacity in cast iron 160 mm drilling radial min./max. 880 / 2825 mm throat min. 555 mm column diameter 650 mm bore spindle diameter /taper 90 / MK 6 mm diameter of quill 160 mm bore spindle turning speed range 10 - 660 U/min bore depth 650 mm feeds 0,07 - 3,0 mm/U distance spindle/base plate min. 300 / max. 2100 mm vertical adjustment of the arm 1150 mm base plate surface area 3000 x 1550 mm Nsdpfovh Ncxex Amnolb total height of machine 4500 mm total power requirement 15 kW weight of the machine ca. 16 t - right-/left spindle run - thread cutting device Accessories: DRO HEIDENHAIN on X-and Z-axis (arm and boring depth)

Condition: good (used), Asquith radial drilling machine offered. Type: ODI X-travel: 910 mm Z-travel: 640 mm Stroke spindle: 350 mm Diameter spindle: 65 mm Speed max: 1550 RPM Table: 510 x 1000 mm Bed: 1280 x 795 mm Dimensions: 240x125x293 cm LxWxH Nlodpfeh U Iaxsx Amnjb For more information call us or send an e-mail.

Condition: ready for operation (used), Year of construction: 1995, Drilling capacity St 60/GG 22: 40/50 mm Nlodpfx Asy I Ua Iemneb Thread cutting St 60/GG 22: M 36/M 45 Clamping area of the table: 600 x 1800 mm Height adjustment of the boom: 450 mm Min./max. drilling radius: 305/1305 mm Spindle taper: SK 40 Quill stroke: 200 mm Infinitely variable spindle speeds: 15 - 2800 rpm Infinitely variable feeds: 5 - 2000 mm/min Spindle drive, frequency controlled: 5.5 kW Electrical connection: 400 V, 14 kVA Weight: 3400 kg Space required: 3800 x 2000 x 2500 mm

Condition: excellent (used), Rapid radial drilling machine / Radial drilling machine / Drilling machine (used) Manufacturer: Mikrosa Year of manufacture: 2001 Type: SRB 35 Drilling capacity: - Steel: 35 mm - Cast iron: 40 mm Thread cutting: - Steel: M20 - Cast iron: M24 Spindle taper: MK 4 Spindle speed: 20 – 2800 rpm, infinitely variable Automatic feed: infinitely variable Spindle stroke: 140 mm Arm reach: 1000 mm Table size: 1050 x 400 mm Column diameter: 200 mm Installation height: 600 mm Nodpey Skrzsfx Amnjlb Connected load: 7.8 kW Space requirement: approx. width 1250 mm, depth 2100 mm, max. height 2700 mm Weight: approx. 2000 kg Hydraulic clamping Thread cutting device Depth stop Lateral clamping surface Drill chuck 2 gearbox stages The machine is in very well-maintained condition, runs very smoothly, and is ready for immediate operation. Forklift available, free loading on truck. Affordable shipping possible. Location of the machine: 48477 Hörstel

Condition: repair required (used), bore capacity in steel diameter / mm arm length 1000 mm workpiece height max / mm - throat (max) 1000 mm - sleeve stroke 250 mm MILLING SPINDLE / HEAD / - spindle revolutions (min) 47.5 /min - spindle revolutions (max) 2120 /min - spindle diameter 60 mm - space requirements -left/right- 2000 mm - space requirements -front/back- 750 mm - total height 2160 mm - total weight approx. 2500 kg Machine is not 100% OK, and needs an overhaul. - Height adjustment and cross adjustment must be repaired Nledsvmtlhspfx Amnjb

Condition: good (used), Year of construction: 1999, Drilling capacity in steel (diameter): 60 mm / MK5 Nedpfxey Ukwve Amnjlb Quill stroke: 310 mm Spindle speed: 28...2500 rpm Table size: 1470 x 986 mm Total power requirement: 4 kW Machine weight approx.: 4.6 t

Condition: used, Year of construction: 1970, bore capacity in steel (diameter) 65 mm arm length 1600 mm workpiece height max. 1600 mm surface area 1800x800 mm Nedsy Tplvopfx Amnolb turning speeds 18-1800 U/min Feed -2,54 mm/U The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Donau Danumeric 440 Radial Drilling Machine Drilling capacity (steel): Ø 40 mm Thread cutting: up to approx. M36 (depending on material) Tool holder: SK 40 Spindle speed: approx. 15 – 2,800 rpm (infinitely variable) Feed: infinitely variable approx. 5 – 2,000 mm/min Quill stroke (Z): 200 mm Column stroke (W): 410 mm Arm traverse: 1,050 mm Drilling radius: approx. 540 – 1,290 mm Arm swivel range: approx. 330° Column diameter: 195 mm Nledpfx Ameyrdc Ssnsb You are welcome to arrange a viewing. We can also organize affordable shipping for you! You will receive a proper invoice. For international customers, a net invoice can be issued (a valid VAT ID number is required). Interim sale reserved. Visit our shop and take a look at our other offers. All company names and trademarks mentioned are the property of their respective owners and are used for identification and description purposes only. Technical data may vary and errors in the item description are reserved.

Condition: good (used), Machine type: Donau radial drilling machine DR 32 Year of manufacture: unknown MK 4 spindle taper Spindle speed: 41 – 1800 rpm Threading device Coolant pump Nlsdsy Tpq Ejpfx Amnob Weight: approx. 2500 kg Drilling capacity in steel: 32 mm Table size: approx. 1200 x 600 mm
