Used Elumatec Sbz 140 for sale (124)

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 1500050285, travel distance X-axis: 7,800 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 630 mm, spindle speed (max.): 24,000 rpm, number of slots in tool magazine: 14, Submitting a bid obligates the buyer to collect the item on time on 23.12.2025! Ksdpfexx Uf Nox Ablslt TECHNICAL DETAILS Travel X-axis: 7,800 mm Travel Y-axis: 1,000 mm Travel Z-axis: 630 mm Rapid traverse X-axis: 70 m/min Rapid traverse Y-axis: 40 m/min Rapid traverse Z-axis: 40 m/min Max. workpiece length: 7,300 mm Max. spindle speed: 24,000 rpm Spindle motor power: 15,000 W Number of spindles: 1 Number of tool magazine slots: 14 Tool diameter: 100 mm MACHINE DETAILS Input voltage: 400 V Type of input current: Alternating current (AC) EQUIPMENT Documentation/manual included Magazine can be equipped with nine standard tools, five special tools, and one saw blade Ten clamping devices Two separate work areas for pendulum operation 15" color display Floppy disk drive DOS operating system

Year of construction: 2006, condition: used, 3-axis machining center with automatic tool change for aluminum or PVC profiles Max. travel X-axis: 3,850 mm Max. travel Y-axis: 350 mm Max. travel Z-axis: 280 mm Control E 550 Stepless speed control up to 21,000 rpm Manual control device Minimal quantity spray Automatic tool changer with magazine (4 slots plus angle head) Spanner measurement and clamp displacement 4 pneumatic material clamps Light barrier Kjdpfx Abox Ecfkjljlt Weight: approx. 2,000 kg

Year of construction: 2010, condition: used, 3-axis machining center with automatic tool change for aluminum or PVC profiles Max. travel X-axis: 6,700 mm Max. travel Y-axis: 350 mm Max. travel Z-axis: 280 mm Control Windows 10 with a new computer in 2023 Speed continuously adjustable up to 24,000 rpm handheld control unit minimum quantity spraying Kledpfx Abewwukxjljt Tool changer with 2 magazines (total 10 places plus angle head) tensioner detection and tensioner displacement 2 pneumatically folding material stops and 2 light barrier areas, thus pendulum operation possible A total of 8 material clamps Spindle in very good condition, spindle pull-in force: 12.5 kN Safety fence dismantled, a demonstration is still possible by arrangement Weight: approx. 3,500 kg

Year of construction: 2007, condition: used, 5-axis machining center with tool changer for aluminum or PVC profiles Max. machining length: 9,000 mm Travel Y-axis: 1150 mm Travel Z-axis: 715 mm A-axis swivel angle: 0° - 180° Angle C-axis: 0° - 180° Max. speed 24,000 rpm. Spindle power: 21 kW Tool changer with 13 standard and 7 special tools minimum quantity spraying Clamp detection and automatic shifting 12 pneumatic material clamps Pendulum operation through two light barrier areas Manual control console Loading is included in the price Ksdpsxwydbsfx Ablelt Weight: approx. 8,500 kg

Condition: repair required (used), Year of construction: 2000, For sale: Elumatec cutting and machining centre, model SBZ 610. The machine has been preliminarily commissioned. Requires refurbishment. Kljdpfjy Avylox Abljt

Year of construction: 2022, condition: excellent (used), functionality: fully functional, machine/vehicle number: 122000029, We are offering this very well-maintained elumatec SBZ 122/75 profile machining centre, year of manufacture 2022. Type: 122/75 Serial number: 122000029 Year of manufacture: 2022 Voltage: 400 V Frequency: 50/60 Hz Power: 17.5 kW Current consumption: 25 A Kedpfx Ajywku Toblolt Maximum motor current: 20 A Short-circuit withstand strength (Ik/SCCR): 5 kA Compressed air pressure: 7 bar Weight: 3,800 kg Maximum profile diameter: 180 mm Spindle speed: 6,000 rpm Maximum speed: 20,000 rpm If you have any questions or require further information, please feel free to send us a message or give us a call.

Year of construction: 2001, condition: used, Pictures to follow - machine is being overhauled Technical data: - X-axis travel: 7300mm Klsdpfxot Ea Tfe Ablst - Y-axis travel: 1000mm - Z-axis travel: 650mm - Swivel angle A-axis: 0-90° freely programmable - Swivel angle C-axis: 0-355° freely programmable - Max. Machining length without end face machining: 7300mm - Max. Machining length with end face machining: 6980mm - Tool changer with 10 places and a saw blade holder - 9 material clamps - SK30 tool holder - 2-layer machining

Year of construction: 2014, condition: excellent (used), Elumatec SBZ 130 is a 3-axis profile machining centre designed for efficient processing of aluminium, steel, and stainless steel profiles. All operations, such as milling, drilling, and tapping, are performed on a stationary profile, which protects its surface. Axes: 3-axis control, with tool spindle as an additional axis. Machining length (X-axis): 7200 mm Klodpfx Absyt H Uyelst Travel (Y-axis): Typically 485 mm (max. 60 m/min). Travel (Z-axis): Typically 340 mm (max. 60 m/min). Spindle speed: Standard 6000 rpm or optionally high-speed spindle (18,000 rpm). Spindle power: 5.5 kW. Tool magazine: Integrated 8-position turret or 4 angle heads, ensuring short tool changeover times. Control: Windows operating system with eluCam software. 18.5” PC panel with USB ports and network connection. Clamping system: Automatic positioning of pneumatic clamps. Compressed air supply: 7 bar. MACHINE: Prepared tooling dedicated for PVC+STEEL machining: - tool holders, - reducer for steel machining, - special tools with chip breaker, - dedicated programs for machining door profiles,

Year of construction: 2002, condition: repair required (used), functionality: limited functionality, machine/vehicle number: 1300030418, For sale: CNC machining center for aluminum and steel profiles, Elumatec SBZ 130. The machine is company-owned and located in an indoor production facility, protected from external influences. Specifications and condition: Ksdoyz Dvropfx Ablslt Year of manufacture: 2002. Status: Currently not operational (requires pneumatic system servicing). History: The machine was in active use until 2014, after which it was stored indoors. Electronics: The computer is fully functional, the machine can be started for system testing. Required investment: Replacement of all pneumatic hoses and inspection/servicing of control blocks. Advantages: The machine is mechanically sound and has not been kept outdoors. Ideal opportunity for companies with technical capacity for overhaul or those seeking a reliable base for modernization.

Year of construction: 2018, condition: good (used), For machining aluminium and steel profiles Fully functional, in very good condition Machining length: 7200mm 3-axis control with 15" screen Tool changer: 8 positions / turret 8 pneumatic horizontal material clamps Autonomous clamp positioning Two separate work zones, suitable for pendulum operation 2 pneumatic material stops 8 tool positions / BT30 turret Barcode scanner Handheld control unit Safety light barrier at the front and side safety fence Minimal quantity lubrication Central lubrication Thread cutting without compensating chuck Simple programming at the control panel High-speed spindle up to 18,000 rpm Including 3 angle heads Kodpfx Aex Diqwoblelt X-axis [mm]: up to 7,200 / 7,200 Y-axis [mm]: up to 485 / 310 Z-axis [mm]: up to 340 / 260 Rapid traverse speed X/Y/Z axis [m/min]: 60/60/60 Max. milling cutter diameter: 25mm Max. saw blade diameter: 180mm Max. tool length: 200mm (tool + holder) Max. spindle speed: 6,000 rpm Spindle power: 6 kW Weight: approx. 5.5 t Total operating hours: 30,844 h Total spindle hours: 11,583 h

Year of construction: 2004, condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 9,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 630 mm, spindle speed (max.): 24,000 rpm, machine/vehicle number: 031809, TECHNICAL DETAILS X-axis travel: 9,500 mm Y-axis travel: 1,000 mm Z-axis travel: 630 mm Feed rate X-axis: 70 m/min Feed rate Y-axis: 40 m/min Feed rate Z-axis: 40 m/min Swivel angle A-axis: ±110°, freely programmable in 0.1° increments Swivel angle C-axis: ±182°, freely programmable in 0.1° increments Spindle speed: max. 24,000 rpm Spindle power: 15 kW S1 Maximum milling cutter diameter: 100 mm Maximum disc milling cutter diameter: 100 mm Maximum saw blade diameter: 400 mm Tool holder: HSK-63F MACHINE DETAILS Compressed air connection: 7 bar Klodpfoycul Sex Abljt Electrical connection: 400 V, 3~, 50 Hz, 80 A Air consumption: approx. 200 l/min with misting EQUIPMENT Machining operations: milling, drilling, tapping, thread milling, notching, and sawing with stationary profile bar 6-sided machining: front optional, underside possible Profile protection: machining with stationary profile bar Robust, low-wear direct drives on all axes Axes: 5-axis CNC control for complex 3D machining Display: 15-inch colour monitor Interfaces: USB ports, network connection 2-layer machining for pendulum operation Associated tooling (HSK tool holders) Two circular saws for aluminium Note: Documentation for disassembly of the machine is included.

Year of construction: 2016, condition: good (used), functionality: fully functional, machine/vehicle number: 6280028128, Machine is provided "free loaded truck". No dismantling and loading costs! TECHNICAL DETAILS Max. profile cutting width: 320 x 160 mm Min. profile cutting width (depending on gripper position): 30 x 10 mm Raw material system Length of the raw bar system: 7,600 mm Finished part system Finished part length: 3,500–4,600 mm Kurt cell Kurt cell (50-150/150-350): optional Feed system Shortest raw bar length: 1,500 mm Swing arm selection: 5 (option 9) Support plate: 10 (over 120 mm 5) Infeed Servo drive: linear Gripper adjustment electric: Y/Z Gripper guide: standard Remnant piece measurement: optional Remnant piece processing: fully automatic Processing station Number of axes: 5 Milling spindles: 8 (can be prepared) Saw Number of axes: 3 Saw blades (diameter): Ø 550 mm, optional Ø 650 mm Saw angle: 22.5°–157.5° (swivel) Klsdpfx Asvvu S Ijblot Notch cuts: standard (from above) Outfeed chip carriage Number of axes: 1 Outfeed conveyor Lifting station: yes Swing selection: 5 Width of outfeed conveyor: 4,000 mm MACHINE DETAILS Dimensions: 20 x 3 x 4 m Weight: 8.8 t Connection power: 39 kW Operating voltage: 3/N/PE 400 V EQUIPMENT - Feed magazine - Loading transport - Processing station with milling unit, saw unit and clamping blocks - Unloading transport of profiles (removal gripper) and unloading conveyor - Acoustic protection cabin - Control panel on the soundproof cabin - Control cabinet - Fencing and protective doors

Year of construction: 2007, operating hours: 4,100 h, condition: good (used), functionality: fully functional, The machine is not more needed for our production and therefore its for sale. The machine is in our ownership from 2007 and it is regularly maintained. Everything works normal. Dismantling and load on truck are in price. Some more informations: 5-axis profile machining centre Designed for flexible and efficient machining of aluminium Autonomous clamp positioning Max. working lenght: 9.300 mm Ksdpfewwtw Djx Ablelt 12 pneumatic clamps Tool magazine with 20 tools capacity and saw blade 500mm Spindle working hours 4100h Additional tehnical specifications available on request

Condition: excellent (used), Year of construction: 2024, operating hours: 193 h, functionality: fully functional, travel distance X-axis: 7,200 mm, travel distance Y-axis: 480 mm, travel distance Z-axis: 340 mm, cutting width (max.): 335 mm, workpiece length (max.): 6,000 mm, milling spindle speed (max.): 6,000 rpm, section length (max.): 6,000 mm, TECHNICAL DETAILS - Profile Milling Machine Processing length: 7,200 mm Number of axes: 4 Control: eluCAM graphical, Windows XP user interface Workstations: 2 independently operating stations Turret tool changer: 8 tools, servo motor driven Tool holder: BT 30 Disc mill diameter: 180 mm Tool length: 150 mm (from point of attachment) Travel distances Travel X-axis: 7,200 mm (without end-face processing), 7,080 mm (with end-face processing) Travel Y-axis: 480 mm Travel Z-axis: 340 mm Rapid traverse X-axis: 60 m/min Rapid traverse Y-/Z-axis: 30 m/min Positioning accuracy: ±0.1 mm/m Spindle Milling spindle speed: 1 to 6,000 rpm Milling spindle power: 6.0 kW Supply Air connection: min. 7 bar Air consumption: 100 l/min Electric connection: 400 V, 3~, 50 Hz, 35 A EQUIPMENT two independent workstations with light barrier and camera system Non-swiveling inclined milling head for 2 tools, Er20A, up to 18,000 rpm Inclined milling head swiveling 4 × 90°, Er20, up to 22,000 rpm Inclined milling head non-swiveling for steel, Er20A, 1,554 rpm Fixed saw head i=1:1, for D=300 mm saw blade, suitable for 90° cross cuts Carbide saw blade Z=100, D=300 mm, cutting width 3.2 mm Tool holder i=1:3.86 for 18,000 min⁻¹, ER25 Cooling/lubricating unit for steel processing Disc milling holder BT30, D=16 mm Disc cutter D=92 × 6 mm, Z=14, D=16 mm, carbide teeth Kjdowprmzjpfx Ablslt TECHNICAL DETAILS - Double Mitre Saw Max. cutting length: 6,000 mm Min. cutting length at 90°: 335 mm Min. cutting length at 45°: 335 mm Saw blade diameter: 420 mm Cutting angle (rotation): pneumatically adjustable 90° and 45° inside, intermediate angles and 22.5° acute manually adjustable with digital display Cutting angle (tilt): pneumatically adjustable 90° and 45° inside Saw direction: saw blades move from bottom to top Control Control type: E580/1 Length adjustment: automatic with positioning control Saw blade tilt: pneumatically automatic between 90° and 45° Positioning accuracy: ±0.1 mm/m Positioning: pneumatic locking Operating system: Windows Saw unit Speed: 2,800 rpm Power per motor: 4,000 W (5.5 HP) Saw blade cooling: available Air consumption per cycle without cooling: 40 l Air consumption per cycle with cooling: 64 l Supply Electric connection: 230/400 V, 3-phase, 50 Hz Air connection: 7 bar Dimensions and Weight Length: 7,550 mm Width: 1,600 mm Height: 1,450 mm Weight: 1,750 kg EQUIPMENT Automatically closing protective covers Electronic positioning of the heads with +/- 0.1 mm/m accuracy Digital angle display for manually adjustable special angles Pneumatically adjustable saw blade rotational and tilt angles Operation via Windows control with 8.4" display and handwheel Cooling system for saw blades included Saw unit with bottom feed for optimal cutting force

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 12200991016, rotational speed (min.): 24,000 rpm, overall weight: 1,635 kg, tool weight: 2,900 g, input voltage: 400 V, For economical and efficient machining of aluminium, plastic and thin-walled steel profiles All machining processes such as milling, drilling and thread cutting take place on a stationary profile, protecting the profile surface Improved work results thanks to the use of intelligent control technology Fast positioning of the machining unit at up to 60 m/min thanks to the use of dynamic servo drives Thread cutting without compensating chuck Automatic clamp recognition and positioning Automatic tool magazine with four tool shelves (without tools) Modern, 3-axis control Ergonomic work thanks to the use of a modern inclined bed No need for a reference movement of the axes thanks to the use of absolute encoder-based systems Collision avoidance thanks to automatic clamp recognition and positioning Power-Torque milling motor with closed speed control ensures short start-up and deceleration times spindle Certified, drive-integrated safety functions Low power consumption thanks to intelligent control technology Increased energy efficiency thanks to the connection of axis drives between circuits Uninterruptible power supply (UPS) Windows operating system 15.6" Panel PC, i3 processor, USB ports and network interface Easy and convenient program entry via eluCam on the operator panel, even during machining Remote online maintenance Machine equipment Air-cooled 8 kW milling spindle, S1 Cabin for operator protection Four horizontal pneumatic clamps for clamping the material Material stop, left side HSK-F63 tool holder Minimum quantity lubrication High-performance coolant Manual control panel Depth gauge Options Tools Tool holders Automatic tool magazine for up to four standard tools Kljdpfx Abswgmyqelet Automatic tool magazine for angle head Rotating head HSK-F63 angle for two tools Green-line cooling unit for control cabinet with reduced energy consumption Barcode scanner Protective cabin, optionally with all-round closure Four clamps as standard. Expandable to eight clamps Right reference material stop for placing workpieces with overlength processing Additional stop for overlength processing on the left Length measurement on both sides Double clamp and additional accessories upon request Panel PC 18.5", i5 processor Panel PC 21.6", i7 processor Note holder Sound-absorbing hood Chip disposal using chip trays

Year of construction: 2010, operating hours: 11,200 h, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 12222321222, Equipment: type plate available, Elumatec SBZ122/33 profile machining center, year 2010 Technical data: Working area: X - 3850 mm, Y - 350 mm, Z - 280 mm Electrospindle 10 kW - max. 20,000 rpm (overhauled in 2023) (RF-HSK-F63 125/125x430 24/6.5) Tool holder HSK-63 F Tool changer Work table with 4 clamps with automatic positioning Pneumatic clamping operation Photoelectric safety barrier Operator handheld terminal Control panel workstation USB connection Operating software: Windows 7 system Kjdpfsw Rv A Uex Abljlt Production software: EluSoft, EluCAM Numerical control: Ferrocontrol Protective fencing with doors (laser safety barrier) Automatic and central lubrication of linear guides Weight: 1,940 kg Total connected load: approx. 14 kW Machine dimensions: 4,670 x 2,000 x 2,540 mm Required space: 5,165 x 3,000 x 2,540 mm Machine used for aluminum profile processing. Serviced and ready for operation.

Year of construction: 2010, condition: used, functionality: fully functional, SBZ 122/33 Profile Machining Center 3.8m, WK 4x90°, eluCam Description: Efficient machining of aluminum, plastic, and steel profiles Working length: 3800 mm Automatic clamp positioning Complete profile machining with stationary profile bar to protect the profile's visible surface. Latest generation CNC 3-axis control with industrial PC based on Windows XP 15" flat-screen monitor and 2 USB ports for online connectivity, barcode scanner, and label printer. Network connection: RJ 45 10/100 MBit User-friendly input via eluCam 3D visualization Rapid positioning of the machining unit (up to 60 m/min) on the X-axis thanks to robust and low-wear direct drive. High-resolution absolute encoders eliminate the need for axis referencing. Technical Data: X-axis travel: 3800 mm Max. travel speed: 60 m/min Y-axis travel: 350 mm Max. travel speed: 30 m/min Z-axis travel: 280 mm Max. travel speed: 30 m/min Max. machining length with end machining left and right: 3700 mm Positioning accuracy: +/- 0.1 mm Milling spindle speed: 1 – 24,000 rpm Milling spindle output: 7.0 kW S1 with spindle return Tool magazine for 6 tools (5 standard positions, 1 position for rotary angle head) Tool holder: HSK F63 Included Accessories: Kljdpfsw Dzagex Ablot Automatic tool changer with 6 tool positions (without tools) Safety fences left and right Light barrier at the front 4 horizontal pneumatic material clamping devices Automatic clamp positioning 1 foldable material stop Central chip extraction with chip box Dosing spray device Milling spindle with integrated rotation unit for angle head Rotary angle head – 122 20 56 37 HSK-F63 for 2 tools UPS (uninterruptible power supply) Important: The profile machining center is factory-equipped with a front light barrier system as standard. Lateral protection is provided by safety fences. Any necessary rear protection must be provided on-site or ask us for a quote for safety fences. Includes: Length measurement for profile bar Additional automatic tool changer Various used tool holders and milling cutters

Year of construction: 2005, condition: used, CNC Machining Center Elumatec SBZ 122, year of manufacture 2005, designed for machining aluminum profiles for windows, curtain walls, and light metalwork. This is a robust and reliable industrial machine, highly regarded for its machining precision and operational continuity. Main features: - 3-axis CNC machining center - High-rigidity steel frame - Vertical spindle for milling, drilling, and complex operations - Worktable with pneumatic vices for stable and precise clamping - Long-travel longitudinal axis, ideal for processing profiles of considerable length - Protective enclosure with chip conveyor - Elumatec CNC control unit - Ideal for medium to high production and repetitive operations Applications: - Milling - Drilling - Slotting - End and face machining - Production of aluminum frames and special profiles Key data: - Manufacturer: Elumatec - Model: SBZ 122 - Year of manufacture: 2005 - Condition: Used Condition: - Machine in good overall condition - Coming from an industrial environment - Can be seen in operation by appointment Klsdpfxjyg Ht Ao Ablst Included equipment: - Complete workbench - Pneumatic clamping system - Control panel - Original covers and safety guards

Condition: used, Press height 140 mm Press force 70 kN (7 t) Hydropneumatic drive Compressed air connection 7 bar Air consumption per operating cycle 35 l Length 1,100 mm, Depth 950 mm, Height 1,230 mm Ksdpfx Asy Tlgceblelt Weight 550 kg

Condition: ready for operation (used), Year of construction: 2020, overall weight: 2,485 kg, This 3-axis Elumatec DG 244 was manufactured in 2020. It features a cutting length of 6.0 m and a maximum saw blade diameter of 550 mm, providing efficient cutting capabilities. The machine includes a complete extraction unit and a mobile workpiece support for enhanced functionality. If you are looking to get high-quality circular metal cutting capabilities, consider the Elumatec DG 244 machine we have for sale. Contact us for further details. Kjdpoy Tm Saefx Ablolt - Cutting Length: 6.0 m- Saw Blade Diameter: Max. ø 550 mm- Saw Blade Bore: d 30 mm- Saw Blade Speed: 3000 1/min- Voltage: 3/PEN 400 V- Frequency: 50 Hz- Current: 21.8 A- Power: 9.2 kW- Operating Pressure: P 7 bar- Short-circuit current rating: Ik 10KA- Machine Weight: 2485 Kg- Included Components / Accessories:- Short-length stop for stationary aggregate- Complete extraction unit DG244 2x2.2kW- Profile lifting bar set for stationary and mobile aggregate- Pneumatic clamping device horizontal, per aggregate -230mm- Mobile workpiece support- Moving roller conveyor 1.5 m long, 400 mm wide for extraction unit

Year of construction: 1996, condition: used, Manual length adjustment via hand crank Klodpfxey Sn Tio Ablst For attachment to any Elumatec single-head saw (right) Max. feed length: 3,000 mm

Condition: used, functionality: fully functional, Lot of 3 copy routers Elumatec KF78/23. 2 units are fully operational (100%). The third is 50% operational, but can easily be refurbished or used for spare parts. Various spare parts included. Horizontal processing area: With stop: 300 x 100 mm With template: 270 x 70 mm Vertical processing area: With stop: 290 x 100 mm With template: 230 x 70 mm 12,000 rpm Klodsyzfl Iepfx Ablst Clamping range: 150 x 150 mm Supply voltage: 230/400V, 3-phase Price is for the lot of 3 machines, without feed tables.

Year of construction: 1995, condition: excellent (used), functionality: fully functional, machine/vehicle number: 20/192, We are offering this used elumatec KF 178 in very good condition, year of manufacture 1995. Model: KF 178 Machine no.: 20 192 Voltage: 230/400 V Frequency: 50 Hz Current: 3.6/2.1 A Speed: 12,000 rpm Operating pressure min.: 5 bar Operating pressure max.: 8 bar If you have any questions or need more information, please feel free to send us a message or call us. Klodey D I R Sopfx Ablst

Year of construction: 2005, condition: used, Manual length adjustment via handwheel with digital display For attachment to any Elumatec single-head saw (right) Max. insertion length: 4,500 mm Kodpfx Aboy N Dcbjljlt Pneumatic parking brake

Year of construction: 2004, condition: excellent (used), functionality: fully functional, 2004 Elumatec AKS 134 Notching Saw – High-Precision Notching for Curtain Walls, Skylights & Conservatories Manufacturer: Elumatec Model: AKS 134 Year: 2004 Condition: Very Good Now available: Elumatec AKS 134 Notching Saw, manufactured in 2004 and in very good condition. This robust, German-engineered machine is purpose-built for precise notching in aluminium profiles, specifically designed for fabricators working on curtain walls, conservatories, skylights, and other complex architectural aluminium systems. The AKS 134 features a dual-saw unit design — vertical and horizontal — offering exceptional flexibility, accurate angles, and safe operation. Combined with digital angle displays, hydro-pneumatic feed, and automated cutting cycles, this is a premium choice for serious aluminium fabricators. 🛠️ Key Technical Specifications: 🔻 Lower Vertical Saw Unit: Saw Blade Diameter: 550 mm Tilting Range: +45° forward to -60° rear Max Cutting Height: 210 mm Motor Power: 3 kW (with motor brake) Speed: 2,800 rpm Manual Tilt Adjustment with Digital Display 400V, 3~, 50Hz 🔺 Upper Horizontal Saw Unit: Saw Blade Diameter: 500 mm Tilting Range: +55° down to -60° up Max Notching Depth: 190 mm Motor Power: 3 kW (with motor brake) Speed: 2,800 rpm Travel Distance: up to 830 mm Manual Tilt Adjustment with Digital Display 400V, 3~, 50Hz ⚙️ Machine Features: Dual saw blades for versatile and complex notching Workpiece stays fixed – only the saw units move, enhancing precision Simultaneous vertical saw unit height adjustment via handwheel (with analogue readout) Digital angle displays for both saws and pivoting back fence Manually adjustable support table Horizontal and vertical pneumatic clamping Automatic cutting cycle at 90° with two-hand safety control for angled cuts Hydro-pneumatic saw feed for smooth, consistent cutting Compressed Air Supply: 7 Bar (35–45L per cycle) 📏 Machine Dimensions & Weight: Footprint: 3000 × 1420 × 1600 mm Weight: 1,250 kg 🏗️ Ideal For: Aluminium façade and curtain wall manufacturers Skylight and conservatory fabricators Precision aluminium notching applications Workshop environments needing multi-angle notching in high volumes 🧰 Reliable, accurate, and engineered for demanding tasks, the Elumatec AKS 134 is a proven performer in the architectural aluminium industry. Elumatec AKS 134 for sale Aluminium notching saw Ireland Curtain wall notching machine Elumatec saw for curtain wall systems Notching saw for aluminium profiles Elumatec AKS 134 specifications 550mm notching saw Klsdexyupkepfx Ablot Double blade notching saw Used Elumatec machinery Aluminium construction saw Notes: *Specifications are given in good faith but not guaranteed*
