Used Elumatec Crimp for sale (115)

Condition: used, Year of construction: 1993, Technical details: cutting diameter: 195 x 120 mm cutting range min.: 135 x 120 mm saw blade diameter: 380 mm cutting length min.: 500 mm cutting lenght max.: 6000 mm max. spindle speeds: 2800 U/min Lajdpfx Aswz Hygsa Esk total power requirement: 3 kW weight of the machine ca.: 850 kg

Year of construction: 2018, condition: good (used), For machining aluminium and steel profiles Fully functional, in very good condition Machining length: 7200mm 3-axis control with 15" screen Tool changer: 8 positions / turret 8 pneumatic horizontal material clamps Autonomous clamp positioning Two separate work zones, suitable for pendulum operation 2 pneumatic material stops 8 tool positions / BT30 turret Barcode scanner Handheld control unit Safety light barrier at the front and side safety fence Minimal quantity lubrication Central lubrication Thread cutting without compensating chuck Simple programming at the control panel High-speed spindle up to 18,000 rpm Including 3 angle heads X-axis [mm]: up to 7,200 / 7,200 Y-axis [mm]: up to 485 / 310 Z-axis [mm]: up to 340 / 260 Rapid traverse speed X/Y/Z axis [m/min]: 60/60/60 Max. milling cutter diameter: 25mm Max. saw blade diameter: 180mm Max. tool length: 200mm (tool + holder) Max. spindle speed: 6,000 rpm Spindle power: 6 kW Weight: approx. 5.5 t Total operating hours: 30,844 h Total spindle hours: 11,583 h Lsdsx Diqwepfx Aa Ejak

Year of construction: 1991, condition: used, functionality: fully functional, Industrial punching machine for processing aluminium and PVC profiles.The machine is fully operational and suitable for a wide range of applications in metal construction. Technical data: • Manufacturer: elumatec • Model: ST 225 • Punching force: 6,000 kp at 10 bar Laodpfx Aow Tcrhea Esk • Year of manufacture: 05/1991

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 20186/2006/01, travel distance X-axis: 7,200 mm, travel distance Y-axis: 480 mm, travel distance Z-axis: 325 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, feed length X-axis: 7,200 mm, feed length Y-axis: 480 mm, feed length Z-axis: 325 mm, controller manufacturer: Elumatec, workpiece length (max.): 7,200 mm, spindle speed (max.): 6,000 rpm, spindle motor power: 5,500 W, number of spindles: 1, number of slots in tool magazine: 8, input voltage: 400 V, type of input current: three-phase, Equipment: rotational speed infinitely variable, 2006 Elumatec SBZ 130 Profile Machining Centre – High-Performance Aluminium CNC Machine 📍 Location: Ireland 🛠️ Machine Type: 3-Axis CNC Profile Machining Centre 📅 Year of Manufacture: 2006 ✅ Condition: Very Good / Fully Operational 🔧 Brand: Elumatec – German Engineering Excellence 🔧 Machine Description: The Elumatec SBZ 130 is a high-precision CNC profile machining centre designed for efficient and versatile processing of aluminium, steel, and stainless steel profiles. With fully automatic 3-axis control and flexible machining capabilities, it's ideal for manufacturers in the window, door, façade, and industrial profile fabrication sectors. 🧰 Included Features & Equipment: Automatic Tool Turret with 8 Tool Positions • Holds standard tools or angle milling heads • Rapid rotation ensures minimal tool change times 2 x Angle Milling Heads – included for advanced profile cutting Automatic Length Measurement – improves precision and workflow Two Independent Machining Zones – for pendulum operation and non-stop production Tool Spindle with Additional Axis Functionality – enhances machining flexibility All Operations Performed with Stationary Profile Bar • Protects profile surface during milling, drilling, and threading Multi-position Pneumatic Clamping System Coolant & Minimum Quantity Lubrication System (MQL) Tool Holders in photos Included This 2006 model is in very good condition, fully functional, and ready to be put into service. 📐 Technical Specifications: X-axis Travel (Longitudinal): 7,200 mm Y-axis Travel (Transverse): 480 mm Z-axis Travel (Vertical): 325 mm Spindle Power: 5.5 kW Max Spindle Speed: 6,000 rpm X Axis Rapid Traverse: 60 m/min Y Axis Rapid Traverse: 30 m/min Z Axis Rapid Traverse: 30 m/min Tool Changer: Automatic 8 position magazine Angle Milling Heads: 2 Angle Milling Heads Speed: 10,000 rpm Control System: Elumatec ELMU with full NC control Machining Capabilities: • Drilling, Routing, Tapping, Notching, Slotting • Machining on 3 sides of the profile without repositioning Clamping System: Pneumatic profile clamps (movable and programmable) Compressed Air Connection: 7 Bar Compressed Air Consumption: 75 L/min with spraying Cooling/Lubrication: Minimum quantity lubrication (MQL) system Operation: Front-loading with safety light curtain 🧰 Machine Includes: Multi-position automatic tool changer Angle Milling Heads x 2 Ljdpfx Aowwau Nja Eoak Pneumatic profile clamping system Cooling/lubrication system Operator control console Selection of tool holders as seen in photos 💡 Key Features & Benefits: German-built machine with exceptional reliability High-speed 3-axis control for complex machining tasks Machining without profile repositioning – improved productivity Perfect for aluminium window & door fabrication, curtain wall profiles, industrial extrusion machining Can be integrated into automated production lines Ready to work – tested Elumatec SBZ 130 for sale used Elumatec machining centre CNC aluminium profile machining centre 3 axis profile router, aluminium window door CNC machine Elumatec CNC machine Ireland CNC notching machine used façade profile machine high-speed CNC profile mill Elumatec SBZ CNC profile router

Year of construction: 2016, condition: used, Max. saw blade diameter: 280 mm Pneumatic material clamps Rotatable table with locking points Minimum quantity spray device Lasdpfx Aoxrmyxea Ejk Roller conveyor and length stop on request

Condition: like new (used), Year of construction: 2016, operating hours: 22 h, functionality: fully functional, saw blade diameter: 500 mm, Elumatec Double Mitre Saw DG 142 with E580/1 Control – Precision Saw for Aluminium and PVC Profiles For sale is a high-quality Elumatec DG 142 double mitre saw equipped with electronic control system E580/1. This machine is ideal for the precise cutting of aluminium, PVC, and light metal profiles – particularly suited for window, door, and façade construction. Lodpfow D Rv Dsx Aa Eeak Technical specifications: Manufacturer: Elumatec Model: DG 142 Control: E580/1 (automatic positioning and angle adjustment) Mitre cuts: 45° – 90° (automatically adjustable) Cutting length: up to approx. 5,000 mm (depending on configuration) Blade diameter: approx. 500 mm Speed: approx. 2,800 rpm Connection: 400 V / three-phase Condition: used, technically flawless Availability: immediate +++ Operating hours: 22 HRS +++ Special features: - Automatic positioning of both saw units - Precise and clean cuts thanks to stable machine guidance - Programmable control for highly repeatable series cuts - Excellent cutting quality, also on demanding profiles - Ideal for metal fabrication, window production, and conservatory construction The machine is network-capable incl. extraction unit + SICK light curtain

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, type of input current: three-phase, Elumatec VS 750 four-head welding machine with EV850 4-axis CNC cleaning line. The welding machine and cleaner are currently programmed only for SCHÜCO profiles. Profile height range for welding: 30-185 mm Minimum window dimensions for welding: 350 x 350 mm Maximum window dimensions for welding: 2600 x 4000 mm Weld bead limitation: 0.2 mm and 2 mm The welding machine features a touch operator panel based on Windows XP The cleaner is also equipped with an operator panel Online connection is available between the welding machine and the cleaner After welding, automatic transport to the cleaner is provided The cleaner operates in both manual and automatic mode Ledpox E Rd Dofx Aa Eoak In automatic mode, the rotation station turns the window to each specific corner to be processed by the cleaner. We provide assistance with machine disassembly and loading for transport.

Condition: good (used), Double Mitre Saw Elumatec DG 740/02 – used, operational, ready for demonstration For sale is an Elumatec double mitre saw DG 740/02 in good, fully functional condition. The machine is immediately ready for use and can be demonstrated on site. Technical Data / Features: Model: Elumatec DG 740/02 Double mitre saw for precise cutting of aluminium and plastic profiles Robust construction, precise cut guidance Both saw units are pivotable / can perform mitre cuts Cleaned and well-maintained used condition Condition: The machine is in working order and in age-appropriate good condition. All functions can be tested live during viewing. The machine has been removed from production, cleaned, and is ready for demonstration in a warehouse until sold. Viewing & Collection: A non-binding inspection is possible by appointment. Collection by the buyer. Lajdpfxoxzdulo Aa Ejk Price: Negotiable If you are interested or have any questions, please feel free to contact us!

Year of construction: 1997, condition: used, functionality: fully functional, Industrial punching machine for processing aluminium and PVC profiles.The machine is fully operational and suitable for a wide range of applications in metal construction. Laedpfow Tcpyex Aa Eok Technical data: • Manufacturer: elumatec • Model: ST 225 • Punching force: 6,000 kp at 10 bar • Year of manufacture: 05/1997

Year of construction: 1999, condition: used, Used machine Year of manufacture: 1999 Lasdpfexqihisx Aa Eok Large milling area despite compact design Copy milling using lateral stops or templates at a 1:1 ratio Pneumatic copy pin, two-stage, for two different cutter diameters The patented suspension of the copying lever ensures precise milling with minimal effort Table height adjustment for extremely high profiles up to 400 mm Easy tool change via spindle lock Pneumatic material clamping device Metering spray unit Options: Copy templates milled for standard handle holes and PZ milling Copy pin Collet chuck Stop system Material clamping device with 2 clamping cylinders Milling cutter 8 mm Availability: short-term Location: Flörsheim

Year of construction: 2006, condition: used, Max. saw blade diameter: 280 mm Laedpfxjxrdp Re Aa Eek Pneumatic material clamps Rotatable table with locking points Minimum quantity spray device Suitable roller conveyors and length stops on request

Condition: good (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 1223030252, Model: SBZ 122/30 Year of manufacture: 2009 Control: CNC-controlled 3-axis profile machining Suitable for: Aluminium, PVC, and thin-walled steel profiles The machine is in very good technical condition Regularly serviced Immediately ready for operation Scope of delivery Complete SBZ 122/30 machine Original operator console/control Clamping devices Accessories available upon agreement On-site inspection possible by appointment. Laodpfexyv Afsx Aa Eok

Condition: excellent (used), Year of construction: 1989, functionality: fully functional, Horizontal cutting range using a stop 230 x 90 mm Horizontal cutting range using a copy template 230 x 90 mm Spindle speed 12,000 rpm Clamping range for profiles 180 x 130 mm Travel 110 mm Power supply 230/400 V, 3~, 50 Hz Power output 0.74 kW Compressed air supply 7 bar Air consumption per working cycle 12 l without spraying, 24 l with spraying Length 720 mm, depth 650 mm, height 1,440 mm, weight 120 kg Versatile for many applications in aluminium and PVC profile machining Laedpfxjxz Skns Aa Esk Precision routing with a minimum of effort and easy, two-lever operation Copy routing at a ratio of 1:1 transfers the cutting pattern from a template to the profile Your own custom templates can be created (by copying the template to a blank) Copy routing using stops is also possible (only rectangular cutting patterns) Can be set up in only a few steps Pneumatic material clamping unit Manual tracer point with three levels for different cutter diameters Pulsed coolant system Shipping on demand

Condition: used, Year of construction: 1999, x-axis 6450 mm y-axis 400 mm z-axis 380 mm working lenght 6500 mm Number of tools 8 St. tool taper BT30 tool changing time 1,2 sec diameter of tools max. 80 mm turning speeds 6000 U/min Feed speed X = 34 m/min. Feed speed Y+Z = 18 m/min. total power requirement 8,5 kW dimensions 9800 x 3000 x 2400/3300 mm weight 5400 kg Ljdpot H Sn Rsfx Aa Esak *Bar machining center, 3-axis machining of aluminum, plastic, steel and stainless steel profiles*

Year of construction: 2000, condition: defective spare-parts repository (used), functionality: unexamined, Elumatec SBZ 130 bar machining centre for sale as a parts donor. Laedpfow Talxsx Aa Ejk Offered as: untested, it may be non-functional. Please refer to the images (manual/nameplate) for the technical specifications. Inspection by appointment. Machine dimensions: 9000 mm × 2400 mm × 1420 mm (L × D × H) Control panel dimensions: 870 mm × 680 mm × 1570 mm (W × D × H)

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 1500050123, rotational speed (max.): 18,000 rpm, working length: 12,000 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Max. speed: 18,000 rpm Machining length: 12 m Pneumatic collets: 20 pcs MACHINE DETAILS Electrical data Voltage: 400 V Phases: 3 ~ Frequency: 50 Hz Current draw: 76 A Operating pressure: approx. 8 bar EQUIPMENT Automatic tool changer Angle head Lajdpfx Aexnz Ivsa Eok

Year of construction: 2010, condition: used, 3-axis machining center with automatic tool change for aluminum or PVC profiles Max. travel X-axis: 6,700 mm Max. travel Y-axis: 350 mm Max. travel Z-axis: 280 mm Control Windows 10 with a new computer in 2023 Speed continuously adjustable up to 24,000 rpm handheld control unit minimum quantity spraying Tool changer with 2 magazines (total 10 places plus angle head) tensioner detection and tensioner displacement 2 pneumatically folding material stops and 2 light barrier areas, thus pendulum operation possible Lsdswwukxjpfx Aa Ejak A total of 8 material clamps Spindle in very good condition, spindle pull-in force: 12.5 kN Safety fence dismantled, a demonstration is still possible by arrangement Weight: approx. 3,500 kg

Condition: good (used), Year of construction: 2008, functionality: fully functional, Technical information – Elumatec DG 244/2 year 2008 Control unit model: E355 Main electrical connection: 3/PEN/400V - 50 Hz Power consumption: 12.8 kW Additional information Advantages of the machine Technical advantages of the machine: - Saw blade diameter: 550 mm - Saw blade speed: 2,800 rpm Lajdpfx Aaew A Iubj Eok - Compressed air supply: 7 bar - Weight: 1,850 kg Machine can be inspected in operation in department 76 Available from week S38/S39 Price includes loading

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, CNC Bar Machining Centre | elumatec SBZ 130 - 8-position tool changer turret with driven tools - Material support with automatic clamping system - Operator console with touch panel - Separate Rittal control cabinet with cooling unit - Safety enclosure with SICK light curtain system Inspection is possible at any time by appointment. Laodsxn Scwspfx Aa Ejk - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: elu | SBZ | Bar Machining Centre

Condition: excellent (used), Year of construction: 2015, AUTOMATIC TWO-HEAD SAW ELUMATEC DG 244 + E580 -5 YEAR 2015 Laodjwltqaepfx Aa Eek

Condition: used, Year of construction: 2011, functionality: fully functional, machine/vehicle number: 0799336047, Elumatec double mitre saw Ledpfx Aoxf Dugea Esak

Year of construction: 2006, condition: good (used), functionality: fully functional, Technical Specifications - Elumatec SBZ 122/20 Year 2006 16KW General Data Measurement width: 4622.8 mm Measurement depth: 1828.8 mm Measurement height: 2489.2 mm Machine weight: 1814.9 kg Main Drive Spindle speed range: 21,000 rpm Spindle motor power: 8.5 HP Axis Travel X-AXIS Travel: 3777 mm Y-AXIS Travel: 350.5 mm Z-AXIS Travel: 279.4 mm Machine can be seen in operation in department 76 Available from week S38/S39 Lajdjw A Ipfopfx Aa Esk Price includes loading

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, CNC profile machining centre | elumatec SBZ 131 Laedpfoxn Sbmsx Aa Eok - 8-position tool turret with driven tools - Material support with automatic clamping system - Operator panel with touchscreen - Separate Rittal control cabinet with cooling unit - Mesh enclosure, SICK light curtain system An inspection is possible at any time by appointment. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: elu | SBZ | profile machining centre

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 12200991016, rotational speed (min.): 24,000 rpm, overall weight: 1,635 kg, tool weight: 2,900 g, input voltage: 400 V, For economical and efficient machining of aluminium, plastic and thin-walled steel profiles All machining processes such as milling, drilling and thread cutting take place on a stationary profile, protecting the profile surface Improved work results thanks to the use of intelligent control technology Fast positioning of the machining unit at up to 60 m/min thanks to the use of dynamic servo drives Thread cutting without compensating chuck Automatic clamp recognition and positioning Automatic tool magazine with four tool shelves (without tools) Modern, 3-axis control Ergonomic work thanks to the use of a modern inclined bed No need for a reference movement of the axes thanks to the use of absolute encoder-based systems Collision avoidance thanks to automatic clamp recognition and positioning Power-Torque milling motor with closed speed control ensures short start-up and deceleration times spindle Certified, drive-integrated safety functions Low power consumption thanks to intelligent control technology Increased energy efficiency thanks to the connection of axis drives between circuits Uninterruptible power supply (UPS) Windows operating system 15.6" Panel PC, i3 processor, USB ports and network interface Easy and convenient program entry via eluCam on the operator panel, even during machining Remote online maintenance Machine equipment Air-cooled 8 kW milling spindle, S1 Cabin for operator protection Four horizontal pneumatic clamps for clamping the material Material stop, left side HSK-F63 tool holder Minimum quantity lubrication High-performance coolant Manual control panel Depth gauge Options Laedpjwgmyqefx Aa Eek Tools Tool holders Automatic tool magazine for up to four standard tools Automatic tool magazine for angle head Rotating head HSK-F63 angle for two tools Green-line cooling unit for control cabinet with reduced energy consumption Barcode scanner Protective cabin, optionally with all-round closure Four clamps as standard. Expandable to eight clamps Right reference material stop for placing workpieces with overlength processing Additional stop for overlength processing on the left Length measurement on both sides Double clamp and additional accessories upon request Panel PC 18.5", i5 processor Panel PC 21.6", i7 processor Note holder Sound-absorbing hood Chip disposal using chip trays

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, CNC Profile Machining Centre | elumatec SBZ 610 - Power: 30 kW - Control: Beckhoff CP7032 - with material feed, automatic end stop, downstream material buffer An inspection is possible at any time by appointment. #Tags: elu | SBZ | Profile Machining Centre Lodpexn Nfcofx Aa Eeak
