Used Electromagnetic Plate for sale (13,006)

Condition: good (used), Clamping plate, welding table, welding table, straightening plate, perforated plate -Dimensions: 2280/1060/40 mm Ffsdpfxjb A Nbne Adaot -Table height: 960 mm -with supporting ribs -Cast iron plate -Weight: 1050 kg

Condition: good (used), Year of construction: 2004, machine/vehicle number: 69839, Offer 25493 Technical data: - Cutting length: 3050 mm - Cutting thickness at 400 N/mm² tensile strength: 13 mm - Cutting thickness at 400 N/mm² tensile strength (up to 1000 mm length): 15 mm - Cutting angle: 0.5 – 3° - Number of sheet hold-downs: 18 pcs - Strokes per minute: 10 – 23 min⁻¹ - Powered backgauge up to: 1000 mm - Rear area secured with light barrier - Front squaring arm: 1000 mm - HSLX version features: - CNC control HACO SC 5 controller (sheet thickness input in mm) - Automatic cutting angle adjustment by sheet thickness - Cutting length limitation - Automatic positioning of the backgauge (8 programs – 80 sets) with digital display and automatic backgauge retraction - Option for powered backgauge adjustment via 2 push buttons - Drive: 400 V / 22 kW Ffsdpfx Adjx D Uzzsaot - Electric foot pedal - Space requirement without support arms: approx. W 4200 x H 2250 x D 2200 mm - Weight: approx. 9000 kg - The machine has been welded in various places by the previous owner and has only been repainted on the front side.

Condition: used, Technical details: Ffsdju N D Dwspfx Adaet floor-plate length: 510 mm plate width: 270 mm Plate thickness: 65 mm very good steel plate for sale free, packed in oiled paper and foil Surface ground Ra 0.8 according to drawing T-slots according to DIN 650: a=36; h=65; b=60 c=26mm, chamfered approx. 1.5mm Distance from edge: 100mm; center distance: 100mm (without attached 4x swivel hoist ring) *

Condition: good (used), Clamping plate with T-slots, plate field, welding table, welding table, plate boring machine, T-slot plate, -T-slot plate: clamping plate with solid base frame -Length: 1350 mm -Width: 1150 mm -Plate thickness: 100 mm -Plate: with support ribs -Groove width: 26 mm -Groove spacing: 110 mm Ffsdpfx Adohuf Iasaot -Dimensions total: 1350/1150/H825 mm -Total weight: 1000 kg

Condition: used, Year of construction: 1965, Technical details: Fodpfxju Icppo Adaeft sheet width: 1200 mm plate thickness: 1,0 mm throat of pillar: 1200 mm number of cutting strokes max.: 45 p.Min. throat max.: 300 mm cutting gap adjustment: nein down holder: 5 Stück back gauge: ca. 500 manuell mm total power requirement: 2,2 kW weight of the machine ca.: 1,6 t dimension machine xH: 1,6 x 1,6 x 1,9 m further features: -with shear angle adjustment -operation via foot switch -voltage 380 V *

Condition: good (used), Mounting plate, scribing plate, measuring plate, measuring table, leveling plate, scribing plate -Mounting plate: with support ribs, on a solid mobile base -Clamping table: 1500 x 500 x 150 mm -Table height: 1010 mm -Sheet thickness: 30 mm Fjdpfx Aoqzl E Njdaoft -Plate: with supporting ribs -Overall dimensions: 1530/710/H1010 mm -Weight: 320 kg

Condition: used, Technical details: sheet width: 2300 mm plate thickness: 6 mm bending capacity max. - round: nicht bekannt mm distance between columns: 3210 mm roll dia. top roll: Ø 190 mm side roll diameter: Ø 150 / 2 Stück mm dimension machine xH: 3,55 x 1,2 x 1,6 m weight of the machine ca.: 2,3 t total power requirement: 9 kW Fodpfx Adou Icd Tsaoft Steel frame double T beam welded top roller: with running; adjustment= length 150mm via hand toggle; support block can be folded out for opening side rollers: motor driven; adjustment=fixed *

Condition: good (used), Clamping plate, plate field, welding table, welding table, plate boring mill, straightening plate, tool holder -with: drill holes -Width: 395 mm Fjdpfx Adsd R Ak Eoaoft -Length: 495 mm -Height: 30 mm -Weight: 53.5 kg

Condition: used, Year of construction: 1995, Technical details: sheet width: 3000 mm plate thickness: 12 mm distance between columns: 3500 mm control: Cybelec DNC 10 G back gauge: 1200 motorisch mm cutting angle: 1,2 - 2,73 ° cutting gap adjustment: ja mm cutting capacity : 66.000 daN daN Knife length: 3100 mm down holder: 17 Stück interface: RS232 Table dimensions: 3200 x 600 mm total connected load: 22 kW weight of the machine ca.: 11,0 + (1,0 to Anbauteile+Zubehör) t space requirements approx. LxWxH: ca. 4,5 x 2,6 x 2,1 m transport dimensions LxWxH: ca. 5,0 x 2,25 x 2,2 m The guillotine shear was put into operation for the first time in 1998. Fedpfxjvc Amto Adaoft The DNC 10 G control unit was specially designed for guillotine shears. It has a numerical axis for controlling the backgauge and automatically calculates and regulates the cutting gap, the cutting angle and the cutting depth, taking into account the material to be cut. (Data from the manufacturer) Table with side stopL:930 x W:105 x H:42 mm 2 table extensions L:1600 x W:100 x 83 mm Angle fence (attached to table extension) Operation via control panel with swivel arm and foot control Equipment: Drain with rollers for clippings 2x protective grid *

Condition: good (used), Magnetic plate, clamping plate, permanent magnet, magnetic clamping plate, magnetic clamping plate -Magnetic plate: clamping surface 800 x 250 mm -Voltage: 110V 1.7A -Transport box: included -Quantity: 1 piece available Fjdpfx Adjh R D Rdoaeft -Dimensions box: 1160/480/H250 mm -Weight: 112kg

Condition: used, Technical details: sheet width: 1500 mm plate thickness: 2,25 mm Ffsdpou Icn Eefx Adaet distance between columns: 1600 mm back gauge: nein cutting angle: nicht bekannt ° cutting gap adjustment: nein mm down holder: über Druckleiste Stück height over floor: 850 mm Table dimensions: LXB 1800 x 350 mm weight of the machine ca.: 0,85 t dimensions of machine: 2,0 x 0,8 x 1,3 m simple mechanical guillotine shear with shelf right/left 305 x 100mm operation via ON/OFF *

Condition: good (used), Mounting plate, scribing/marking plate, measuring plate, measuring table, welding table, welding table, straightening plate -Slab: planed -Width: 793 mm Ffedsctmv Sepfx Adast -Length: 997 mm -Height: 930 mm -Sheet thickness: 60 mm -Plate: solid -Weight: 418 kg

Condition: used, Technical details: Length: 400 mm width: 200 mm weight of the machine approx.: 24 kg dimensions L x W x H: 0,4 x 0,22 x 0,08 m MAGNETIC CLAMPING PLATE Magnetic core quantity 21 pieces, width 4x60mm and 1x80mm, distance to each other 80 / 90mm. The plate has a T-slot guide on the side. (WidthxDepth: 16 / 5mm) * Fjdpju Nklhefx Adaeft

Condition: good (used), Clamping plate, welding table, welding table, marking plate -Width: 450 mm -Length: 400 mm -Height: 50 -with fitting bore and threaded holes: M12 (threaded insert M16 x 1.5) -Weight: 60 kg Fsdpfxob A Nqgo Adasft

Condition: used, Year of construction: 1960, Technical details: Ffodpfxsu Icfws Adajt sheet width: 2000 mm plate thickness: 4 mm distance between columns: 2070 mm roll dia. top roll: Ø142 (getrieben) mm diameter of lower rolls: 1. Walze Ø 145 (getrieben) mm diameter of lower rolls: 2. Walze Ø 145 (mitlaufend) mm adjustment of lower rolls: manual/mech./hydr.: 1. Walze ca. 20 mm von Hand adjustment of lower rolls: manual/mech./hydr.: 2. Walze ca. 180 mm von Hand height over floor: 950 mm total power requirement: ca. 4,0 kW dimension machine xH: 3,0 x 1,0 x 1,2 m weight of the machine ca.: ca. 2,5 t Mechanical 3-roll plate bending machine Operation: Hand switch / foot switch forward/backward 2x EMERGENCY button *

Condition: good (used), Clamping plate with T-slots, plate field, welding table, welding table, pallet changer -comes from a CNC machining center MAHO type MC 600 Fodpsb A Hy Uofx Adaoft -Width: 500 mm -Length: 500 mm -Height: 180 mm -with supporting ribs -Groove width: 14 mm -Number: 1 table available Price: per piece -Weight: 200 kg/piece

Condition: used, Year of construction: 1993, Technical details: sheet width: 3050 mm plate thickness: 6,0 mm distance between columns: 3460 mm no. of strokes: min./max.: 9 / 17 Hub/min back gauge: 750 mm (motorisch) mm cutting angle: 0,5° - 3,0° ° Ffodpfju Rni Hex Adaet cutting gap adjustment: manuell mm down holder: 18 Stück (hydraulisch) Stück Table dimensions: 380 x 3100 mm total connected load: 7,5 kW weight of the machine ca.: 4,56 t dimensions of machine: L: 2,3 x B: 3,7 x H: 1,8 m Equipment: With side stop L: 1000 × W: 100 × H: 60 mm and stop bar 990 mm, with 8 supports Operation via control panel and foot switch Cutting zone lighting Stroke counter Machine feet *

Condition: good (used), Clamping plate with T-slots, plate field, welding table, welding table, plate boring mill -Width: 1100 mm -Length: 2250 mm -Height: 200/100 mm -Working height: 820 mm Ffedpfjb A Nv Isx Adaet -with supporting ribs -Groove width: 24 mm -Weight: approx. 2000 kg

Condition: used, Year of construction: 1992, Technical details: sheet width: 4050 mm plate thickness: 16 mm distance between columns: 4900 mm control for program: Robosoft SC5 Controller back gauge: 1000 motorisch cutting angle: 0,5° - 3° ° cutting gap adjustment: ja / jes mm down holder: 23 Stück height over floor: 1030 mm Table dimensions: L x B 4000 x 520 mm weight of the machine ca.: 19,2 t dimensions of machine: 5,2 x 2,2 x 2,78 m characteristics: - knife length 4100mm, 4 turns possible - Number of strokes: 5 - 11 strokes/min. - Table: side stop with linear scale, with stop bar 1000mm removable, feed aid via / with ball bearings - front support: LxWxH: 1600 x 1100 x 1000 mm; movable over roller rail, easy handling - backgauge adjustable, motor driven and foldable Operation via control panel with jib lenmgth arm and foot control Ffedpfju Icpcox Adaot Equipment: - light grid at backgauge - cut line ilumination Accessories: - 1 set (2 pieces) shearing blades *

Condition: good (used), Clamping plate with T-slots, plate field, welding table, welding table, pallet changer Fjdpfob A Ilwsx Adasft -comes from a CNC machining center MAHO type MCV 600 -Width: 500 mm -Length: 500 mm -with supporting ribs -with Span Index -Weight: 115 kg

Condition: used, Year of construction: 1992, Technical details: sheet width: 3000 mm plate thickness: 2,0 mm distance between columns: 3300 mm back gauge: 580 manuell mm cutting angle: Nein ° cutting gap adjustment: Nein mm down holder: 13 Stück Table dimensions: 3300 x 300 mm weight of the machine ca.: 3,0 t dimensions of machine: 3,7 x 1,5 x 1,8 m incl. 2x upper knife and 2x lower knife each 1500mm incl. table supports 1500 x 1500mm with roller elements Ffjdpfx Aeu Icnrodaot 2x profile strips L: 1400mm 1x side stop bar 1600mm operation via control panel and/or foot pedal *

Condition: good (used), Mounting plate, scribing/marking plate, measuring plate, measuring table, welding table, welding table, straightening plate -Width: 510 mm Fsdpfx Adeb A Raujajft -Length: 350 mm -Height: 60 mm -Dimensions: 510/500/H190 mm -Weight: 120 kg

Condition: good (used), Base plate, construction fence base, barrier base Fodpfxob A Nwvj Adaeft -Quantity: 16x made of plastic -TL-Footplate -K1 Dimensions: 800 x 400 mm -Insert pockets: 40 x 40 mm, 60 x 60 mm, 2x Ø 42 mm -Suitable for: shaft pipe, construction fence or barrier fence

Condition: good (used), Clamping plate, welding table, welding table, straightening plate Ffsdpfx Adeb A Hu Djaet -Width: 1750 mm -Length: 1400 mm -Elevation: 840 -with: supporting ribs -Weight: approx. 1000 kg

Condition: good (used), Clamping plate with T-slots, plate field, welding table, welding table, plate boring mill Fsdeb A Nn Iopfx Adaeft -Width: 190 mm -Length: 300 mm -Height: 240 mm -Table: 140 x 300 mm -Groove width: 14 mm -Weight: 24 kg
