CNC turning and milling center

Mazak Integrex E-1550 V/10

Condition: like new (used), Year of construction: 2003, x-travel 850 mm y-travel 700 mm z-travel 500 mm Control Heidenhain iTNC 530 tool taper HSK 63 voltage 400 V control voltage 24 V weight of the machine ca. 10,5 t - Current configuration C 40 U: o Vertical machining center o 4 axes o Travel ranges: X 850 mm, Y 700 mm, Z 500 mm o Table size: X 1070 mm, Y 700 mm o Carousel tool magazine, 40 positions o Max. tool length in magazine: 300 mm o Spindle: HSK63, 10,000 rpm, 25 kW, 159 Nm o Coolant system: AK, IKZ 40 bar, 1,000-liter capacity, steel filter o Blow-off air IK & AK o MMS system MHT Bjdpfjz Ebraox Aa Isdh o Scraper belt chip conveyor o Polycarbonate disc without Rotoclear o Heidenhain iTNC 530 machine control o Emulsion mist extraction (Preparation) o Installation dimensions with coolant system: 3,930 mm x 4,400 mm x 3,040 mm o Laser measurement system for tools, including breakage detection o 3D measuring probe o Spindle hours: 14,578 h o Machine hours: 47,069 h

Condition: used, Year of construction: 2010, turning length: 1,495 mm, spindle speed (min.): 35 rpm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,545 mm, workpiece weight (max.): 300 kg, total height: 2,577 mm, total length: 5,088 mm, total width: 2,450 mm, spindle nose: A2-6, spindle diameter: 660 mm, Equipment: documentation/manual, CNC Control Mazatrol Matrix Turning diameter 660 / 260 mm Turning length 1495 mm Spindle bore diameter 65 mm Spindle nose A2-6 Spindle nose sub spindle A2-6 Turning speed spindle 35 - 5.000 R/min Turning speed sub spindle 35 - 5.500 R/min Milling head speed 15 - 21.500 R/min Movement X-axis 580 mm Movement Y-axis 160 mm Movement Z-axis 1.545 mm B-axis travel 225° C-axis indexing 0,0001 (360) ° Bdjdpfx Aaozqt Umj Ioh Tool taper Capto C6 Tools in tool magazine 120 Barfeeder Irco-Breuning ILS-MUK If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 4304, rotary table diameter: 600 mm, grinding height: 450 mm, overall weight: 14,500 kg, Machine is equipped with 3 spindles, surface grinding, external grinding, bore grinding Turret head B-axis with 1° division Bdedpfx Aevt A Rtja Ioh Belt filter system included

Condition: used, Year of construction: 2011, operating hours: 26,476 h, functionality: fully functional, workpiece height (max.): 500 mm, workpiece diameter (max.): 630 mm, workpiece weight (max.): 200 kg, total height: 2,590 mm, total length: 4,780 mm, total width: 4,410 mm, table height: 390 mm, table length: 390 mm, overall weight: 5,900 kg, spindle speed (max.): 18,000 rpm, spindle motor power: 25 W, number of slots in tool magazine: 30, Equipment: chip conveyor, Year of construction: 2011 CNC controller: Heidenhain iTNC 530 Axes Bjdoz Dku Ujpfx Aa Iodh X-axis travel mm: 500 Y-axis travel mm: 450 Z-axis travel mm: 400 C-axis degrees: 360º (0,001) B-axis degrees: 0º/108º (0,001) Rapid traverse m/min: 80/50/50 Milling/turning table nc: Table dimensions mm: Ø390 Maximum workpiece size (D x H) mm: Ø630x500 Max. workpiece weight kg: 200 Spindle Spindle speed rpm: 18000 Spindle drive power kW: 35/25 (40%ED/cont) Spindle torque Nm: 130/87 Tool system Tool holder: HSK-A 63 Tool magazine slots: 30 With free neighboring places mm: 130 With occupied neighboring places mm: 80 Max. Tool Length mm: 300 Chip-to-chip time s: 5 Equipment Chip conveyor Infrared probe Rinsing gun blowing air through spindle center selectable via M-function Signal lamp Laser tool measurement for measuring tool length and diameter Programmable coolant nozzles Heat compensator Direct measuring system XYZ Electrical cabinet active cooling unit Oil skimmer Ready for internal cooling (40/80 bar) RENISHAW Measuring probe Automatic door Machine running times Under power: 43774 Spindle Working: 26476 Rated power kVA: 48 Basic machine dimensions / weight Length mm: 4780 Width mm: 4410 Height mm: 2590 Weight kg: 5900

Condition: ready for operation (used), Year of construction: 2017, operating hours: 6,117 h, - USED - 3-AXIS VERTICAL MACHINING CENTRE   X-AXIS TRAVEL: 1050 mm Y-AXIS TRAVEL: 570 mm Z-AXIS TRAVEL: 510 mm DISTANCE SPINDLE NOSE-TABLE: 150-660 mm RAPID FEEDS X-Y-Z: 36 - 36 - 30 m/min SPINDLE: 15000 rpm; 10 - 17 kW; ISO 40 - DIN TABLE SIZE: 1300 x 570 mm MAX ADMITTED LOAD: 1000 Kg TOOL MAGAZINE: CHAIN-TYPE ; 30 POS MAX TOOL DIAMETER: 80 (125) mm MAX TOOL LENGHT: 300 mm MAX TOOL WEIGHT: 8 Kg CONTROL UNIT: HEIDENHAIN TNC 620 WEIGHT: 6500 Kg OVERALL DIMENSIONS: 3110 x 2413 x 2985 mm ACCESSORIES: HIGH PRESSURE COOLANT ; Bdjdpfx Aaozhc Ano Ish SWARF CONVEYOR ; ETHERNET PORT ; USB PORT ; TOOL SETTER ; TOUCH PROBE ; PORTABLE HANDWHEEL

Condition: ready for operation (used), Year of construction: 1997, operating hours: 20,045 h, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 450 mm, spindle speed (max.): 60,000 rpm, spindle speed (min.): 9,000 rpm, table load: 300 kg, overall weight: 4,500 kg, travel distance W-axis: 450 mm, Equipment: documentation/manual, For sale: used Hauser S35-400 coordinate grinding machine, year of manufacture 1997, in well-maintained condition with various accessories as shown in the photos. Bsdpfxoyywb Sj Aa Ijdh Travel paths: X-axis: 500 mm Y-axis: 300 mm W-axis: 450 mm Z-axis feed rate, stepless: 0.5–14,000 mm/min Table size: 600 x 380 mm Maximum table load: 300 kg Control: GE Fanuc Series 16-M Dimensions (L/W/H): 4.25 m x 4 m x 3.25 m Total weight: 4,500 kg Machine is immediately available! Price includes loading onto truck!

Year of construction: 2016, condition: ready for operation (used), Offered is a high-precision worm and thread grinding machine MIKROMAT 20G, used as a test and trial machine, nearly all available options included, technically flawless condition. Capabilities: external thread grinding, internal thread grinding, whirling Whirling, grinding length max. 2000mm, workpiece diameter max. 320mm, distance between centers: 2250mm NC tailstock option: 2050mm, workpiece weight max. 200kg 350kg NC tailstock, pitch range: 0-400mm, 7-axis system, feed speed: up to 15000mm/min, setting angle: +/-40°, positioning accuracy: uncertainty 0.0024mm P, upgrade to 23.5kW continuous power/45kW maximum power, grinding wheel speed: up to 50m/s, special equipment internal grinding: internal thread diameter up to 100mm, length up to 50mm, coolant system: KNOLL compact unit vacuum rotary filter, 2500l tank volume and oil cooling, installation dimensions X/Y/Z: approx. 6500mm/4000mm/3000mm, total weight: approx. 13000kg, inspection possible by arrangement. Bdsdpfxeylbr Ds Aa Ijh

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, Precision machining center HSC 30 linear 5 axes Siemens 840D Travel range X/Y/Z 320 /300 /280 mm B-axis: +/- 120° Bdodpfx Aszlhmmea Ijh C-axis: 360° Rapid traverse rate 50 m/min Spindle speed range 0 - 40,000 rpm AC main drive with 19.5/15 kW and 16/12 Nm Incl. spindle cooling and rotary union Tool holder HSK-E 40 according to DIN69893 Linear axis drive package Tool magazine, 30 positions, double gripper Active cooling unit for main spindle and linear drives Direct absolute linear encoders 3D control Quick-change system EROWA ITS 150 Measuring probe Blum TC 52 Blum laser Interface for handling system EROWA IKZ 40 bar Electronic handwheel Coolant gun Compressed air Production package EROWA Robot Compact 80 50 pallet positions for ITS 148

Condition: used, Year of construction: 2023, turning diameter 380 mm turning length 1000 mm control Mazatrol SmoothG max. swing diameter over bed 695 mm Standard machining diameter 276 mm bar material dia. max. 80 mm x-axis 234 mm rapid traverse X-axis 30 m/min y-axis 100 mm rapid traverse Y-axis 21 m/min z-axis 1090 mm rapid traverse Z-axis 33 m/min w-axis 1050 mm rapid travel W 30 m/min turning speeds 35 - 4000 U/min spindle nose A2-8 spindle bore 91 mm Motor output (30-min. rating) 26/22 Max. Torque 465 (15% ED) Nm turning speeds 35 - 6000 U/min spindle nose A2-5 Motor output (25%ED) 11 Max. Torque 90 (15% ED) Nm Milling spindle speeds ( driven tools) 5000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW Milling spindle power 3,7 kW Numbers of tools 12 (angetrieben) Tool cross section (outside) 25 qmm Boring bar- Ø 40 mm Drill- Ø 20 mm Mill- Ø 20 mm Tap- Ø M20 x 2,5 coolant tank 270 l Chuck diameter main spindle 10 '' Chuck diameter counter spindle 8 '' total power requirement 37 kW weight of the machine ca. 6,6 t dimensions of the machine ca. 3,6 x 2 x 1,9 m Machine in standard configuration, equipped with the following optional equipment: Air blast through the turret Automatic operator door – opening and closing Air blast system at the main spindle chuck Chip conveyor High-pressure coolant system, 15 bar Robot interface (ADVANCE / Ethernet/IP) C-axis on the sub-spindle, input resolution (contour/indexing): 0.0001° Additional push buttons on the CNC control panel Sub-spindle tailstock function Rectangular 3-colour LED signal light Preparation for oil mist extraction, mechanical flange only, Ø 98 mm Absolent 10C oil mist extraction system Preparation for bar feeder Overload monitoring system Drilling cycle with torque-dependent chip breaking Engraving function Thread re-cutting function All dimensions, weight and performance specifications are non-binding. Bodpfx Ajzzd Rtsa Iodh Used machine – sold without warranty.

Condition: used, MAZAK QTN 200II MSY Year: 2007 Y-axis Counter-spindle Parts catcher Tool probe Max. diameter: 380 mm Max. length: 538 mm Max. bar capacity: 65 mm 12-position turret X-axis: 230 mm Y-axis: 100 (+/- 50) mm Z-axis: 575 mm W-axis: 585 mm Interface for bar feeder Hainbuch chuck on the main spindle Included with the machine: - Chip conveyor Bodpfx Aajzvn Ifo Isdh - Documentation - 11 collets, including 4 driven collets (2/2)
