Vertical Turning Machine

EMAG VL2

Condition: used, Year of construction: 2013, functionality: limited functionality, machine/vehicle number: 105032, Technical characteristics: Work Area - Maximum clamping plate diameter: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm - X-axis travel: 700 mm / Rapid traverse in X: 60 m/min - Z-axis travel: 375 mm / Rapid traverse in Z: 30 m/min - Standard integrated automation (number of loading nests by workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle according to DIN 55026: Size A5 - Maximum spindle speed: 6,000 rpm - Spindle power (100%/40% duty cycle): 18.1 / 13.9 kW - Spindle torque (100%/40% duty cycle): 77 / 59 Nm Tool Turret with Driven Tools - Tool holders according to DIN 69880: 12 positions - BMT65 - Maximum tool length including holder: 190 mm Dodpfx Aoxxwztodaoul - Maximum tool speed: 6,000 rpm - Maximum torque: 27 Nm (10% duty cycle), 14 Nm (100% duty cycle) Electrical Equipment - Operating voltage: 400–480 V, 80 A - Connected load: 27 kVA Dimensions - Overall dimensions: Length = 4,350 mm (with chip conveyor), Width = 1,600 mm, Height = 2,500 mm - Weight: 5,500 kg Main Features and Capabilities: - Vertical Design: Optimised for chip evacuation and easy loading/unloading - Control: GE Fanuc FS 32i B - High Precision: Positioning accuracy on X and Z axes ±0.001 mm, Haidenhain linear scales - Main Spindle: High power output and wide speed range - In-process Control: Marposs T25 measurement probe - Automated Loading/Unloading: Parts are automatically loaded and unloaded by integrated automation - Live Tooling: Capable of drilling and milling with driven tools - Tool Life Monitoring with Sister Tool Management - Chip Conveyor, Coolant System, Switchable Dual Cartridge Filter, High Pressure Pump (15 bar) - Fully Enclosed Work Area, Work Area Lighting - Documentation: Electronic available; paper manual not complete Machine Condition: WORKING - Operator panel safety switch is broken

Condition: good (used), Year of construction: 2014, functionality: fully functional, The following used CNC vertical turning machine EMAG VL2 is for sale. Manufacturer: EMAG Model: VL2 Serial Number: 105958 Year of Manufacture: 2014 Dsdpox N Rv Isfx Adajul Weight: 6,000 kg The machine is equipped with a robotic automation system. - 100% quality control ensured - Dry machining - No emulsion required - Air blow-through via the spindle (vertical spindle) - Dimensional tolerance (bore) +/- 0.006 mm The machine had a new monitor installed one year ago (cost: €9,000) Description: This is a reliable EMAG VL2 CNC vertical turning machine, ideally suited for precision machining of small and medium-sized parts. The machine is in good technical condition, has been regularly serviced, and is immediately available for use. The machine is suitable for both single-part and series production. The machine had to be disconnected from the power supply, so the spindle cannot be photographed at the moment, as access is not possible without power. The machine has produced components for companies such as Lindenmayer, Bosch, and Siemens, including parts for washing machines, among others.

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, General Control: Fanuc 31i-B5 Chuck diameter: 160 mm Turning length: 150 mm Workpiece diameter: max. 100 mm Workpiece length: max. 150 mm Travel X: 650 mm Travel Z: 375 mm Spindle Power: max. 15.4 kW Torque: max. 7 Nm Speed: max. 6,000 rpm Tool turret: 12 stations Mounting: BMT55 Rapid traverse X/Z: 60/30 m/min AGW speed: 6,000 rpm AGW torque: max. 23.7 Nm Automation Technology: Perimeter-type workpiece storage Workpiece height (incl. workpiece pallet): max. 150 mm Workpiece weight: max. 5 kg Workpiece handling: Via spindle (pick-up) Dusdpfx Adsx Ahbxjaol Equipment Chip disposal: Chip conveyor Coolant supply: High-pressure coolant, 15 bar Workpiece measurement: Measuring probe Emulsion mist separator: Mechanical Clamping cylinder: Hydraulic full clamping cylinder

Condition: new, functionality: fully functional, Spindle unit MKK05-012-25-60-080-00340 Original packaging, from stock with documentation EMAG order number: 20399062 Duedpfx Aoxz Al Asdael

Condition: used, Year of construction: 2014, max. turning diameter 160 mm max. turning height 150 mm max. workpiece diameter 100 mm max. workpiece height 150 mm max. turning speeds 6.000 U/min travel -x axis 700 mm travel -z axis 375 mm c-axis 360 ° control FANUC Vertical Turning Machine | EMAG - VL2 equipped with a workpiece conveyor belt. The machine is in very good condition. Please note that the technical details were added from comparable machines. Dedsqvd Iujpfx Adajul - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL-2 | VL 2

Condition: repair required (used), Year of construction: 2017, functionality: not functional, machine/vehicle number: 108113, Technical Characteristics: Duodpfsxxip Aex Adael Work Area - Maximum clamping plate diameter: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm - X-axis travel: 700 mm / Rapid traverse X: 60 m/min - Z-axis travel: 375 mm / Rapid traverse Z: 30 m/min - Standard automation with closed system (number of loading nests by workpiece diameter: 14/(80–200), 18/(30–160), 30/(30–85)) Main Spindle - Spindle interface per DIN 55026: Size A5 - Maximum spindle speed: 6000 rpm - Power (100% / 40% duty cycle): 18.1 / 13.9 kW - Torque (100% / 40% duty cycle): 77 / 59 Nm Tool Holder with Driven Tools - Tool shank per DIN 69880: 12 – BMT65 - Number of stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6000 rpm - Maximum torque (10% duty cycle): 27 Nm; (100% duty cycle): 14 Nm Electrical Equipment - Operating voltage: 400–480 V, 80 A - Connected load: 27 kVA Dimensions - Total dimensions (L x W x H): 4350 mm (with chip conveyor) x 1600 mm x 2500 mm - Weight: 5500 kg Main Features and Capabilities: - Vertical Design: Optimized for chip removal and easy loading/unloading - CNC Controller: GE Fanuc FS 32i B - High precision: Positioning accuracy in X and Z axes ±0.001 mm with Heidenhain linear scales - Main spindle: High power and broad speed range - In-process control: Marposs T25 measuring probe - Automated loading/unloading: Integrated automation for feeding and removing parts - Live tools: Capability for drilling and milling operations - Tool life monitoring and sister tool management - Chip conveyor & Knoll coolant filtration unit with paper filter and 40 bar pumps (suitable for filtering two machines) - Fully enclosed work area, with work area lighting - Documentation: Electronic version available, printed booklet incomplete Machine Status: - NOT WORKING - LT motor defective, repairable - Operator panel, safety switch, and two buttons broken and need replacement

Condition: new, functionality: fully functional, Spindle unit MKK05-026-23-60-080-01024 Factory-sealed, from stock with documentation Duedpfx Adexz Ahdeasl EMAG order number: 20596156

Condition: repair required (used), Year of construction: 2016, functionality: not functional, machine/vehicle number: 107965, Technical characteristics: Work Area - Maximum diameter of the clamping plate: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm Duodpfxjxw Svie Adajl - X-axis travel path: 700 mm / Rapid traverse in X: 60 m/min - Z-axis travel path: 375 mm / Rapid traverse in Z: 30 m/min - Standard enclosed automation (number of loading nests in relation to part diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle interface according to DIN 55026: Size A5 - Maximum rotational speed: 6000 rpm - Power at 100% / 40% duty cycle: 18.1 / 13.9 kW - Torque at 100% / 40% duty cycle: 77 / 59 Nm Tool Turret with Driven Tools - Tool shank as per DIN 69880: 12 positions - BMT65 - Number of positions: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6000 rpm - Maximum torque at 10% duty cycle: 27 Nm, at 100% duty cycle: 14 Nm Electrical Equipment - Operating voltage: 400 - 480 V, 80 A - Connected load: 27 kVA Dimensions - Total machine dimensions: Length = 4350 mm (with chip conveyor), Width = 1600 mm, Height = 2500 mm - Weight: 5500 kg Main Features and Capabilities: - Vertical construction: Optimized chip removal and easy loading/unloading - CNC controller: GE Fanuc FS 32i B - High precision: Axis positioning accuracy in X, Z ±0.001 mm (Heidenhain linear scales) - Main spindle: High power and wide speed range - Process control: Marposs T25 measuring probe - Automated loading/unloading: Parts are loaded and removed via integrated automation system - Live tooling: Enables drilling and milling operations in addition to turning - Tool life monitoring with sister tool management - Chip conveyor & coolant filtration system Knoll with paper filter and 40 bar pumps (capable of filtering 2 machines) - Fully enclosed work area; integrated work lighting - Documentation: Available electronically; hardcopy manuals incomplete Machine status: NOT WORKING - Live tool drive motor - Safety locking mechanism (Euchner) for loading door - Turret drive motor - Turret motor driver - Lubrication pump - Hydraulic manifold (4x electrovalves) - Lubrication pressure system - Rotary union - Hydraulic cylinder for loading door - Spindle clamping/unclamping sensor

Condition: repair required (used), Year of construction: 2016, functionality: not functional, machine/vehicle number: 107964, Technical characteristics: Work Area - Maximum diameter of the clamping plate: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm - X-axis travel: 700 mm / Rapid traverse in X: 60 m/min - Z-axis travel: 375 mm / Rapid traverse in Z: 30 m/min - Standard enclosed automation (number of loading nests by workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle interface according to DIN 55026: Size A5 - Maximum speed: 6000 rpm - Power at 100% / 40% duty cycle: 18.1 / 13.9 kW - Torque at 100% / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools - Tool holders with cylindrical shank according to DIN 69880: 12 - BMT65 - Number of stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6000 rpm - Maximum torque at 10% duty cycle: 27 Nm, at 100% duty cycle: 14 Nm Electrical Equipment - Operating voltage: 400 - 480 V, 80 A - Connected load: 27 kVA Dimensions Dodsxw Srkepfx Adaeul - Total dimensions: Length = 4350 mm with chip conveyor, Width = 1600 mm, Height = 2500 mm - Weight: 5500 kg Main Features and Capabilities: - Vertical Design: Enables optimal chip evacuation and easy loading/unloading. - CNC Control: GE Fanuc FS 32i B. - High Precision: Positioning accuracy on X and Z axes ±0.001 mm with Heidenhain linear scales. - Main Spindle: High power and wide speed range. - In-process Measurement: Equipped with Marposs T25 measuring probe. - Automated Loading/Unloading: Integrated automation for part loading and unloading. - Live Tooling: Capability for driven tools expands machining to drilling and milling operations. - Tool Life Monitoring: Sister tool management for tool life tracking. - Chip Conveyor - Fully Enclosed Work Area with Work Area Lighting - Documentation: Electronic available; hardcopy/incomplete book. Machine Status: NOT OPERATIONAL - Cooling pump x2 units - Live tool drive motor - Lubrication pump - Operator panel - touchscreen needs replacement - Hydraulic block valves x3 - Hydraulic loading door cylinder - Rotary joint - Lubrication pressure switch - Safety door, Euchner type

Condition: repair required (used), Year of construction: 2016, functionality: not functional, machine/vehicle number: 107786, Technical characteristics: Work Area - Maximum clamping plate diameter: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm - X-axis travel: 700 mm / Rapid traverse in X: 60 m/min - Z-axis travel: 375 mm / Rapid traverse in Z: 30 m/min - Standard closed automation (number of loading stations per workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle as per DIN 55026: Size A5 - Max. speed: 6000 rpm - Power at 100 / 40% duty cycle: 18.1 / 13.9 kW - Torque at 100 / 40% duty cycle: 77 / 59 Nm Tool Turret with Driven Tools - Toolholders per DIN 69880: 12 × BMT65 - Number of stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6000 rpm - Maximum torque at 10% duty cycle: 27 Nm; 100% duty cycle: 14 Nm Electrical Equipment - Operating voltage: 400 - 480 V, 80 A - Connected load: 27 kVA Dimensions - Overall dimensions: Length = 4350 mm (with chip conveyor), Width = 1600 mm, Height = 2500 mm - Weight: 5500 kg Main Features and Capabilities: - Vertical construction: optimal chip evacuation and easy part loading/unloading - Control: GE Fanuc FS 32i B - High precision: positioning accuracy in X and Z axes ±0.001 mm (Heidenhain linear scales) - Main spindle: high power and wide speed range - In-process control: Marposs T25 measurement probe - Automated loading/unloading: integrated automation feeds and removes workpieces - Driven tools: enhances machining capabilities for drilling and milling - Tool life monitoring with sister tool management - Chip conveyor - Fully enclosed work area; workspace lighting - Documentation: Electronic available; physical manual incomplete Duodpfxoxw Slks Adajl Machine Condition: NOT WORKING - Operator panel touchscreen needs replacement - Hydraulic cylinder for loading door broken - Emulsion pump - Hydraulic pump - Spindle clamp/unclamp sensor - Hydraulic accumulator - Turret motor
