Vertical Machining Centre

DMG MORI DMC 1035V

Condition: used, Year of construction: 2008, functionality: fully functional, DMG MORI SEIKI - DMC 1035 V ecoline Offer Details Stock number: 1039-9218 Type of machine: Vertical Machining Center Manufacturer: DMG MORI SEIKI Model: DMC 1035 V ecoline Year of manufacture: 2008 CNC Control: 810 D Powerline Siemens Location: D-59302 Oelde, Germany Country of origin: - Availability: by arrangement Delivery terms: ex site Additional Information: CNC Vertical Machining Center DMG MORI SEIKI - DMC 1035 V ecoline - Only 3,800 spindle hours WE OFFER YOU: - workshop-tested machines - loaded onto truck free of charge - NO auction fees - delivery possible (at extra cost) - unloading and commissioning (at extra cost) Technical Specifications: Travel X-axis: 1,035 mm Travel Y-axis: 560 mm Travel Z-axis: 510 mm Control: 810 D Powerline Siemens Main spindle: - Speed range (main spindle): 20 - 8,000 rpm - Drive power (main spindle): 13 / 9 kW - Max. torque: 83 / 57 Nm - Tool holder: SK 40 Worktable: - Table clamping area: 1,200 x 560 mm - Max. table load: 1,000 kg - Table height above floor: 720 mm - T-slots: 4x H12 / 1x 14 H7 Todpfext Ec Ijx Ahujf Tool changer: - Number of tool stations: 20 positions - Max. tool diameter: 80 mm - Max. tool diameter with free adjacent pocket: 130 mm - Max. tool length: 300 mm - Max. tool weight: 6.0 kg - Tool change time: 1.6 sec - Chip-to-chip time: 7.0 sec Feeds: - Feed rate: 20,000 mm/min - Rapid traverse: 25 m/min Total connected load: 17 kVA Machine weight approx.: 4.1 t Space requirements approx.: 4.0 x 4.0 x 2.5 m Equipment/Accessories: - Documentation - Signal lamp - 20-position tool changer - Coolant system - Chip conveyor - Electronic handwheel

Condition: excellent (used), Year of construction: 2000, DESCRIPTION Hermle C 800 V CNC vertical machining center was built in 08.2000 in Germany. The milling center operates in three axes and the maximum X / Y / Z travels are 800, 600 and 500 mm. The machine is equipped with a Sinumerik 840D numerical control with a LAN cable to an external computer. In addition, the lathe is equipped with, among others: Chip conveyor, Hydraulic clamping, Magazine for 87 tools, Turning finder and Control cabinet air conditioning. The spindle rotates at a maximum speed of 15,000 rpm. Spindle hours approx. 4500 h. The total weight of the milling center is approx. 7 tons. Technical data of the Hermle C 800 V CNC milling center - Travel X / Y / Z axis: 800/600/500 mm - rapid traverse: 35 m/min - maximum spindle speed: 15.000 rpm oil mist extraction - spindle power: 19 kW - operating voltage: 400V; 3PH; 50Hz - control voltage: 220V AC; 24V DC - machine dimensions (L x W x H): 2,3 x 3 x 2,65 m - Total weight: 7000 kg Equipment of the Hermle C800V CNC milling center - CNC control: Sinumerik 840D - Tool magazine capacity: 87 pieces - Lamp sockets: SK40 - cooling pump through the tool: 40 bar - control cabinet air conditioner - rotating viewfinder - chip conveyor Tsdpfjiva Dksx Ahujf Separately additionally available with to see on the photos! tool presetter Various SK40 holders Touch probe Heidenhain TS32 Neuwetig

Condition: good (used), Year of construction: 2008, MACHINE SPECIFICATIONS X travel: 1035mm Y travel: 560mm Z travel: 510mm Rapid traverse X/Y/Z: 25m/min Feed: 20m/min Table dimensions X: 1200mm Table dimensions Y: 560mm Maximum table load: 1000kg Spindle speed: 9000rpm Power: 13kW, torque: 83Nm Tool holder: SK40 Tool positions: 20 Maximum tool diameter: 80mm/130mm Maximum tool length: 300mm Maximum tool weight: 6kg Machine dimensions X: approx. 4000mm Machine dimensions Y: approx. 4000mm Machine dimensions Z: approx. 2500mm Weight: approx. 4100kg Control: FANUC 32 Tjdpfx Asxq Hbtehuof Operating hours: 23918h Processing hours: 11991h Including chip conveyor DMG EcoLine UNO 115 tool presetter Probe tool

Condition: used, Year of construction: 2008, x-travel 1.035 mm y-travel 560 mm z-travel 510 mm Tedpfstzvy Tsx Ahujf control 810 D Powerline Siemens Main spindle: turning speed range - main spindle 20 - 8.000 min/-1 power capacity - main spindel 13 / 9 kW max. Torque 83 / 57 Nm tool taper SK 40 work table: table surface area 1.200 x 560 mm max. table load 1.000 kg table height over floor 720 mm T-slots 4x H12 / 1x 14 H7 Tool-Presetter: number of toolpositions 20 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool length 300 mm max. tool weight 6,0 kg change time 1,6 sec change-time chip to chip 7,0 sec feeds: feed speeds 20.000 mm/min rapid traverse 25 m/min total power requirement 17 kVA weight of the machine ca. 4,1 t dimensions of the machine ca. 4,0 x 4,0 x 2,5 m CNC - Machining Center Vertical DMG MORI SEIKI - DMC 1035 V ecoline - only 3.800 spindle hours

Condition: used, Year of construction: 2004, Technical Specifications: Travel X/Y/Z: 650 / 500 / 450 mm Clamping Area: 1000 x 600 mm Todpfx Ahewglapjuof Spindle Mount: SK 40 Spindle Speed: 6500 rpm Max. Table Load: 400 kg Number of Tool Magazine Positions: 20 Power: 24 kVA Machine Weight, Approx.: 5500 kg Equipment: - Motorized Spindle 12000 rpm - 20-Station Tool Changer - Heidenhain Tool Probe - Heidenhain Workpiece Probe - Heidenhain Handwheel - Menzel Minimum Quantity Lubrication - Approx. 25 Tool Holders

Year of construction: 2010, condition: ready for operation (used), Travel X/Y/Z: 1035mm/560mm/510mm, rapid traverse X/Y/Z: 25m/min, feed: 20m/min, table dimensions X/Y: 1200mm/560mm, max. table load: 1000kg, spindle speed: 9000rpm, power: 13kW, torque: 83Nm, tool holder: SK40, tool positions: 20, max. tool diameter: 80mm/130mm, max. tool length: 300mm, max. tool weight: 6kg. Machine dimensions X/Y/Z: approx. 4000mm/4000mm/2500mm, weight: approx. 4100kg, control: Siemens Sinumerik 810D, operating hours: 23918h, machining hours: 11991h. Including chip conveyor, DMG EcoLine UNO 115 tool presetter, machine vices, clamping tools and various tool holders. The buffer battery is empty and may need to be replaced. Documentation available. On-site inspection is possible. Todpfx Aevxvfhshusf

Condition: new, New lathe with large spindle bore. Brand : KMS Type : CS6250C TDC : 1000mm Turning diameter over bed : Ø 500 mm Turning diameter over slide : Ø 300 mm Turning diameter in bag : Ø 710 mm Turning length in bag: 240 mm Bed width : 390 mm Spindle diameter : Ø 105 mm Spindle speeds : 12 (36 - 1600 rpm) Tailstock spindle diameter : 75 mm Tailstock range : 150 mm Tailstock recording : MC 5 Machine dimensions : ± 2630 x 975 x 1270 mm (L x W x H) Machine weight: ± 2100 kg Machine equipped with: Tsdpfx Ajhhm Edshuof - Longitudinal and transverse feed. - Rapid traverse on longitudinal and transverse feed. - Movable and adjustable stops for automatic longitudinal feed. - Thread cutting shaft (Metric/Inch/Module/DP thread cutting possible. - Multifix type quick change tool holder. - 2-axis digital readout (Brand: Sino). - 3-jaw chuck Ø 315 mm, bore 100 mm (Camlock). - 4-jaw chuck Ø 400, bore 105 mm (Camlock). - Drive plate Ø 630 mm (Camlock). - Steady rest Ø 120- Ø 260 mm. - Follow rest Ø 20 – Ø80 mm. - Coolant device.

Year of construction: 2006, condition: ready for operation (used), Travel X/Y/Z: 835mm/510mm/510mm, speed: 12000rpm, spindle power: 14kW, table dimensions X/Y: 1000mm/560mm, table load capacity: 800kg, max. workpiece height: 720mm. Tool positions: 20, tool holder: SK40, max. tool diameter: 80mm/130mm, max. tool length: 250mm, rapid traverse: 30m/min, feed: 20m/min. Machine dimensions X/Y/Z: approx. 3500mm/3500mm/2700mm, weight: approx. 4500kg, control: Heidenhain iTNC 530, operating hours: 112962h, spindle hours: 30702h. Including chip conveyor, IKZ, distance measuring system. Documentation available. On-site inspection is possible. Tedpov H Dgpofx Ahusf

Condition: good (used), Year of construction: 2007, Gildemeister lathe NEF 600 year of construction 2007 Heidenhain Plus control Turning diameter max. 600 mm Center distance 1.250 mm Swing diameter over bed 600 mm Cross stroke 320 mm Main spindle: Speed range - main spindle max. 3,000 min/-1 Tjdpfxsucl Alo Ahusf Spindle bore 90 mm Chuck diameter 320 mm Tool turret: Number of tool positions 8 pos. Total power requirement 42 kVA Weight of the machine approx. 5.0 t Space requirement approx. 3.6 x 2.14 x 1.95 m Accessories: , flushing gun, Schunk lathe chuck 315 mm, Tailstock MK 5

Condition: good (used), Cylindrical Grinder STUDER Favorit S35 Todpferakibex Ahusf
