5-axis machining center

BIESSE ROVER A - SYNCHRO

Condition: like new (used), Year of construction: 2020, operating hours: 250 h, functionality: fully functional, 1.1 TECHNICAL DATA 1 x Waterjet cutting machine, NCP 4020 D 1 x FANUC 31iB d 1 x IGEMS Professional 1 x BevelJet cutting heads for AWJ abrasive waterjet cutting 1 x Fixed cutting heads for AWJ abrasive waterjet cutting 2 x SM3000 feed systems 1 x KMT, Jetline 50 HP, 3.8 l/min, 4100 bar 1 x Cooling unit control cabinet 1 x Hose reel with spray nozzle 1 x Tool kit 1 x Machine zone safety guard 1 x PanelOne HMI operator interface "EDGECUT" 1 x Remote control for high-pressure pump Dcsdpsxgua Aefx Am Rjh 1 x Remote maintenance system 2 x Diaphragm pumps and 2 x extraction units 1 x Waste container 1000 l 1 x Pressure vessel 200 l or 2-ton abrasive online conveyor/online abrasive hopper 1 x Head protection package (zero-point measurement head 1) 1 x IGEMS 5X CAM 1 x MPG, portable handheld pendant 1 x Rotary unit SS (chuck 240 mm) Price €21,000 1.1.1 MACHINE DATA Table size (W x D): 4200 x 2275 mm - Machining area (W x D): 3980 x 2010 mm - X-axis travel 2D: 3530 mm - X-axis travel 3D: 3220 mm - Y-axis travel 2D: 2010 mm - Y-axis travel 3D: 1405 mm - Z-axis travel: 250 mm - Positioning accuracy (X/Y): +/- 0.050 mm/m - Repeatability (X/Y): +/- 0.025 mm - Rapid traverse (X-axis): 30,000 mm/min - Rapid traverse (Y): 15,000 mm/min - Rapid traverse (Z): 5,000 mm/min - Minimum distance between nozzles: 450 mm - Maximum distance between nozzles: 2,010 mm 1.2 CONNECTION DATA 1.2.1 MACHINE CONNECTION • Electrical connection: 3 x 400 V+PE, 16 A, 50 Hz • Pneumatic supply volume (incl. pressure vessel): 500 l/min • Pneumatic supply pressure: min. 6.5 bar 1.2.2 HP PUMP DATA/CONNECTION HP pump data: - KMT 50, Jetline, 4100 bar - 37 kW, circuit breaker at 400/50 Hz, 80 A CAD/CAM software: - IGEMS Professional

Condition: ready for operation (used), Slab recovery line with below machines: One 2-blade board edger One single blade horisontal resaw Dodjgwqk Sopfx Am Roch Conveyors system between the machines included.

Condition: used, Year of construction: 2006, functionality: fully functional, center height in crank: 1,100 mm, workpiece weight (max.): 180,000 kg, grinding length: 11,000 mm, grinding wheel diameter: 1,066 mm, total length: 11,700 mm, quill travel distance: 11,700 mm, workpiece weight between centers: 180,000 g, distance between centers: 11,700 mm, POMINI CNC Roll Grinder Model HD-425-2-7L Siemens 840D, 12 Axes. Built in 2006. Two flatbed system grinding and workpiece ways are separate. Machine accuracy. Straightness 0.001-0.002 mm/m. Roundness 0.001-0.002 mm. Eccentricity 0.002 mm. Profile for crown height up to 0.1 mm ±0.002 mm/m. Surface finishing without chatter marks and no feed marks after finishing grinding stage. On an independent bed: Auto Caliper Diameter 870 - 2,250 mm. Eddy current crack and bruise detector probe. Ultrasound depth probe up to 180 mm. High Pressure wheel cleaner. Wheel dynamic balancing electromagnetic automatically or manually. Wheel dressing device with diamond. 2 Hydrostatic Steadies. 2 Hydrodynamic Steadies. 4 Soft landing for roles. Wheel quick change device incl motor. Dsdpfxjwdmy So Am Roch Jib crane. Vibration Measurement, recording on: Headstock base Neckrests Foot stock Wheel head Wheel head back Carriage Lateral side. Working Capacity. Grinding length 11,000 mm Max diameter with 1,066 mm Grinding wheel 2,200 mm Min diameter with 1.066 mm Grinding wheel 800 mm Center distance 11,700 mm Max Roll weight 80 Tons Max Roll weight with Steadies 180 Tons Min distance between wheel center and roll axis 845 mm Max distance between wheel center and roll axis 1,635 mm Carriage Axis Z, Hydrostatic Feeds, Infinitely variable 0-6,000 mm/min Oil film thickness 0.020 mm Distance between carriage ways 1,500 mm Ways width 160 mm Total length of the carriage on ways 3,385 mm Wheelhead on Carriage Axis X, Wheel Probe Axis A, Inspector Axis A1, Wheelhead cross travel Ballscrew, Axis X 940 mm Resolution axis X 0.0001 mm Wheel Spindle length 1,695 mm Spindle bearing, hydrostatic, diameter 254 mm Resolution Infeed micrometer handwheel, Axes X 0.00001 mm / division Continuous wheel infeed, U axis on radius 0 - 0.35 mm/min Rapid wheel indeed, axes X 0-830 mm/min Wheel motor, AC 130 kW Wheel Speed 400-1,100-1,600 rpm Wheel Cutting Speed infinitely variable Surface speed wheel diameter 1,066 mm 45 m/sec Surface speed wheel diameter 670 mm 45 m/sec Wheel hole, diameter 508 mm Wheel thickness 76 - 152 mm Wheel diameter 670 - 1,066 mm Crowning, Axis U. Max crown on the diameter 10 mm Max concavity on the diameter 10 etc Head stock Workpiece rotating speed 5 - 50 rpm Headstock motor 200 kW Max transmissible torque 76.5 kNm Faceplate control system V Belts Max Center diameter, metric type 160 mm Stroke of Quill 150 mm Length of headstock 3,110 mm Tail stock Quill diameter 260 mm Stroke of quill 750 mm Maximum center diameter, metric type 160 mm Taper Metric 5% on the diameter Tailstock length 1,300 mm Stroke of tailstock 8,000 mm Caliper, Arm Axis C, Carriage Axis V, Rotation Axis B. Max measurable diameter 2,250 mm My measurable diameter 870 mm Machine Dimensions. Machine weight 130 tons Length 19.5 m. Width 5.5 m. Height 3.2 m. Foundation depth 3.8 m.

Year of construction: 1999, condition: ready for operation (used), Working width: 230mm, working height: 160mm, number of spindles: 5, spindle diameter: 50mm, spindle power: 4x 5.5kW/2x 11kW, feed rate: 24m/min, input table length: 3000mm, vertical spindle axial stroke: 80mm, horizontal spindle axial stroke: 45mm. Connected load: 126kW, air requirement: 8400-9600m³/h, machine dimensions X/Y/Z: approx. 3500mm/2000mm/1800mm, weight: approx. 3500kg. Including Weinig EM-11 slide-in unit and suitable distributor for the extraction system. Documentation available. On-site inspection is possible. Djdpou Damdefx Am Roch

Condition: used, Year of construction: 2005, Three knife trimmer Kolbus HD 150.B Year: 2005 Description: - Right hand infeed - Automatic hopper feeder for inline production - Cut counter - Exchangeable cutting tables (standard set) Dedpfxjvf Dtys Am Rjch - Knife pre-setting device - Set of knife holders: 2 - Sets of knives: 2

Condition: new, functionality: fully functional, Randek Truss System NT produces roof trusses using C-press heads, movable magnetic fixtures on a steel floor and one of our many crane systems. Crane systems: Wall mounted crane Dodexwkuqspfx Am Rjch Column crane Motorized overhead crane Counter balanced crane Press head: 23T, 27T, 35T, 50T Laser system as an option.

Condition: excellent (used), Year of construction: 2018, Type: K324AC8VA Serial number: S8-00324-0256-18 Year of construction: 2018 Bowl: 325 litre Knife speed: 6 steplessly programmable speeds Bowl: 2 speeds Mixing: 2 reverse mixing speeds Controls: Auto-Command 1500K Vacuum pump: Elmo Rietschle L-BV5, 200 m3/h Compressed air: 6 - 10 Bar Dedpfx Asx Eia Iom Rech Water: 4 - 6 Bar Power: 3 x 400V, 50Hz, 157kW Dimensions: 2600 x 3650 x 1700 mm Weight: 4300 kg Including unloader and BW200 loading device With water counter

Condition: used, machine/vehicle number: 008438, Max. panel width: 4500 mm Max. panel length: 4500 mm Main saw blade projection: 50 mm No of Grippers: 8 Djdpfxjyngy Se Am Roch

Condition: used, Year of construction: 2005, Distance between centers 3050 mm Center height 280 mm Travel paths: Z-axis 2800 mm X-axis 400 mm U-axis 160 mm W-axis 160 mm Max. workpiece weight 1000 kg Dcedowz Rg Djpfx Am Rsh Grinding wheel: Outer diameter (new) 1050 mm Max. width 120 mm Bore 304.8 mm Grinding wheel peripheral speed 6-50 RPM Accessories: - Measuring system - Tailstock - Coolant system - Documentation

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,600 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, spindle speed (max.): 6,000 rpm, table length: 2,500 mm, table width: 2,000 mm, table load: 30,000 kg, spindle motor power: 38,000 W, rotary table diameter: 2,000 mm, feed length W-axis: 1,500 mm, Equipment: rotational speed infinitely variable, CNC travelling column milling machine MECOF EMCO mod. MASTERMILL-HPC3 Heidenhain iTNC 530 CNC control X axis 4,000 mm Z axis (vertical) 3,000 mm Y axis (cross) 1,600 mm Ram section 500 x 500 mm Rapid feeds 30,000 mm/min Rotary-translating table 2,000 x 2,500 mm Table load capacity 30,000 kg Translation 1,500 mm Continuous rotation and translation Automatic bi-rotary head with 360,000 positions A axis 0.001° B axis 3° Spindle taper ISO 50 Dcsdpfswzxiyex Am Reh Maximum speed 6,000 rpm Spindle power 38 kW Tool changer with 80 positions Complete with: - Renishaw tool measurement system - Internal high-pressure coolant 20 bar - Chip conveyor
