CNC lathe

ANGELINI Oscar

Condition: excellent (used), Year of construction: 2003, CNC lathe Angelini Oscar, built in 2003; GE Fanuc Series 21i - T Permissible diameter on the slide: 320 mm Recommended turning diameter: 220 mm Maximum turning diameter: 320 mm Hsdpfxevt U Hyo Ag Ujfb Turning length with chuck: 600 mm X-axis travel: 270 mm Z-axis travel: 720 mm C-axis 12x -VD30 X-axis rapid traverse: m/min 24 Z-axis rapid traverse: m/min 32 Spindle nose: ASA 5" Spindle bore: 61 mm Bar capacity: 52 mm Spindle motor power: kW 15 Maximum spindle speed: 4,500 rpm Hydraulic chuck diameter: 210 mm Tailstock quill diameter: 70 mm Tailstock quill stroke: 190 mm Collet chuck Dimensions: 402 x 130 x 199 h cm Weight: 4,500 kg Accessories: various holders and driven holders

Condition: good (used), Year of construction: 2008, Parts shown by hand not included. 12.000 rpm X 610 mm Y 420 mm Z 450 mm Hedpfx Agjuc Tpgo Uofb

Condition: used, Year of construction: 1965, honing diameter 80 mm stroke 280 mm throat 300 mm total power requirement 6 kW weight of the machine ca. 2,6 t Honing Ø 10 - 100 mm Max. honing depth, approx. 250 mm Max. spindle stroke 260 mm Distance between spindle and column 300 mm Mounting height 1,000 mm Table size 350 x 500 mm Height of table above floor 500 mm Spindle speeds in 2 steps, infinitely variable, approx. 85 - 300 rpm 170 - 600 rpm Stroke speed, infinitely variable, hydraulic 0 - 23 m/min Spindle drive 2 kW Total electrical load 6 kW - 380 V - 50 Hz Weight 2,600 kg Accessories / Special Features * Built-on 2-station tilting table which accommodates 2 workpieces. Mechanical workpiece clamping, using a manual lever. * Hydraulic infeed of the tool. Hsdpfx Aget Hwupo Uofb * Switch-off via timer. * Air measuring device (probably). * Honing oil unit. * Various splash shields, etc. Condition : Good. Machine can be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. Thank you for your interest. We have a selection of honing machines available. Please let us know what you need.

Condition: used, Year of construction: 1995, TORNADO 200 year of manufacture 1995 GE FANUC Series O-T control system Maximum machining diameter: 254 mm Maximum turning length: 400 mm Axis travels X : 215 mm Z : 400 mm Maximum spindle speed: 3500 rpm Spindle motor power: 18.5 kW Konik Tool system : VDI 40 Tool head : 12 positions Dimensions of the machine length : 2455 mm Hedpeua Uyujfx Ag Usfb width : 1420 mm weight : 3000 kg

Condition: used, Year of construction: 2003, turning diameter max. 420 mm turning length 1090 mm control FANUC Serie 18i-TB turning spindle Durchlass 108 mm 250 / 315 turning speed range 0-3750 U/min Feed speed 18/24 m/min. workpiece 12 quill stroke 100 mm diameter of quill 110 mm taper MK 4 number of driven tools 12 mm Hfedpoucgylofx Ag Uob turning speeds 3000 U/min 22 nm coolant tank 140 l total power requirement 22/18,5 kW weight of the machine ca. 6500 KG

Condition: reconditioned (used), Year of construction: 1999, Universal Tool Milling Machine TOS FNGJ 32 3-axis Heidenhain digital readout Year of manufacture: 1999 Travel: X 600 Y 400 Z 400 mm Spindle speed range: 40 – 2000 rpm Supplied with the following accessories: Hfsdpfxoxc It Ie Ag Ujb Fixed angle table, 800 x 400 mm clamping surface Vertical milling head Extendable quill Various SK 40 tool holders Safety guard Chip tray Machine lamp Automatic central lubrication pump for X, Y, Z axes Coolant system 4 machine leveling pads

Condition: used, Year of construction: 2003, turning diameter 190 mm Hfodpfjxiy Ausx Ag Uob turning length 620 mm control Fanuc Series 18i-TB total power requirement 15 kW weight of the machine ca. 13,5 t dimensions of the machine ca. 5350X3350x2395 m

Condition: used, Year of construction: 2000, Lathe Mori Seiki SL 200 MC, year of manufacture 2000 Hsdpfx Aexyvkvsg Ujfb

Condition: reconditioned (used), Year of construction: 1984, Universal Tool Milling Machine DECKEL FP 3 With 3-axis active digital display Heidenhain TNC 11 Year of manufacture: 1984 Travel: X 500 / Y 300 / Z 400 mm Speed range: 25 – 2500 rpm Hjdpjxuh Rdsfx Ag Uefb Including the following accessories: - Rigid angle table, 850 mm x 400 mm clamping surface - Swiveling rotary table Ø 450 mm with dividing disks - Slotting head - Movable vertical milling head - Extendable quill for drilling - Infinitely variable feed via potentiometer - Various milling arbors SK 40 / S22 x 2 - Chip tray - Automatic central lubrication pump for X, Y, Z axis - Machine lamp - Coolant system - 4 machine feet - Operating manual

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MAIN SPINDLE - Spindle nose : A2-8 - Spindle power : 18,5 [kW] - Spindle speeds : 4000 [rpm] - Max. bar diameter : 80 [mm] - Max. turning diameter : 366 [mm] - C axis indexing precision : 0.001 [°] TURRET - Number of positions : 12 - Number of motorized positions : 12 - X/Z stroke : 280 x 785 [mm] - Y stroke : +/- 50 [mm] - Live tools speed : 6000 [rpm] * Live tools power : 5,5 [kW] TAILSTOCK - Tailstock type : Numérique - Type of cone : CM5 - Distance between centers : 705 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 39 [kVA] - Number of hours under power : 24151 [h] - Number of working hours : 5144 [h] Hjdpfxoxxb Tyo Ag Usfb WEIGHT & DIMENSIONS - Machine floor space : 3800 x 2143 [mm] - Machine height : 2232 [mm] - Machine weight : 6100 [kg] EQUIPMENT - CNC : MORI MSX-850 III (Mitsubishi 720BM) - Tool probe - 3 colors status lamp - Coolant tank - Chips conveyor - Parts catcher - Predisposition for barfeeder - Chuck 3 jaws : hydraulique - Number of turning tool holders : 5
