Condition: used, Year of construction: 2018, operating hours: 4,854 h, Functionality: fully functional, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 32 m/min, total height: 2,746 mm, total length: 2,810 mm, total width: 2,210 mm, spindle speed (min.): 50 rpm, spindle speed (max.): 15,000 rpm, tool length: 300 mm, working range: 1,000 mm, Dear customer, we have an Okuma M460R-VE in very good condition in stock for you. We look forward to your inquiry and remain with best regards, Your Neff – The Okuma Specialist Team Technical data: Dimensions of the work table (L x W): 1000 x 460 mm Axis travel X/Y/Z: 762/460/460 mm Rapid traverse in the X/Y/Z axis: 40/40/32 m/min Maximum spindle speed: 15000 rpm Minimum spindle speed: 50 rpm Maximum tool length: 300 mm Positioning accuracy of the X, Y and Z axes: ± 0.004 mm Positioning repeatability of the X, Y, Z axes: ± 0.0015 mm Spindle taper: BT 40 Spindle torque: 146-199 Nm Connected load: 37.5 kVA Power supply: 3x 400 V; 50 Hz Dimensions (L x W x H): 2810 x 2210 x 2746 mm Kwjlhcdwevtfkiozjw Weight of the machine: 6500 kg Equipment of the OKUMA M460R VE milling center: Tool magazine with 32 spaces Metrol tool breakage control Marposs radio measuring probe WRI Small coolant system with additional filter Chip conveyor About us: Neff The Okuma specialist and NeffBuy We are also happy to provide you with the all-round carefree package, a tour of our showroom (30 Okuma machines) including demonstration and acceptance, loading, transport, assembly and commissioning of the machine as well as an instruction and subsequent service. We operate Okuma CNC service throughout Europe, both electronically and mechanically, and on top of that we have a 1200 m2 inventory of all Okuma spare parts. Please visit our homepage for more information.

Condition: good (used), Year of construction: 2009, Functionality: fully functional, travel distance X-axis: 900 mm, travel distance Y-axis: 780 mm, travel distance Z-axis: 780 mm, total height: 31,500 mm, Equipment: documentation/manual, rotational speed infinitely variable, Dear customer, we have an Okuma MA 500 HB 6APC in good condition in stock for you. We look forward to your inquiry and remain with best regards, Your Neff - The Okuma Specialist Team Data sheet: Kwelhcdevta Sbjwzew Control: OSP P200-M Travel paths X-axis: [mm] 900 Y-axis: [mm]: 780 Z-axis: [mm]: 780 B-axis: [degrees] 1; 360 degree incrementation Tool changer 200 ATC MAS BT50 Tool positions: 200 Tool holder: MAS BT50 Maximum tool weight: [Kg] 500 Maximum tool length: [mm] 450 Main spindle Max. speed: [1/min] 6,000 Drive power: [kW] 33 Pallet station 6 APC Pallet dimensions: [mm] 500×500 Workpiece weight: [Kg] 950 Workpiece size: [mm] 800×1000 Other features: – Renishaw Probe – Renishaw Tool Break Control – Mayfran Concept with high pressure pump Neff The Okuma specialist and NeffBuy We are also happy to provide you with the all-round carefree package, viewing in our showroom including demonstration and Acceptance, loading, transport, assembly and commissioning of the machine as well as instructions and subsequent service. We operate Okuma CNC service throughout Europe, both electronically and mechanically, and on top of that we have a 1200 m2 inventory of all Okuma spare parts, please visit our homepage.

Condition: good (used), Year of construction: 1999, Functionality: fully functional, Okuma Macturn 30 1SW 1000, OSP 7000M, chip conveyor, ATC 24 BT40, coolant pump 8 bar, gear milling option, approx. 12,500 spindle hours, HS Big Bore, GS Standard Bore Neff The Okuma specialist and NeffBuy We are also happy to provide you with the all-round carefree package, a tour of our showroom (30 Okuma machines) including demonstration and acceptance, loading, transport, assembly and commissioning of the machine as well as instruction and subsequent service. Bjsvkhv0lno We operate Okuma CNC service throughout Europe, both electronically and mechanically, and on top of that we have a 1200 m2 inventory of all Okuma spare parts, please visit us on our homepage. Kwolhcdwevta Rkezjw

Condition: good (used), Year of construction: 2004, Functionality: fully functional, turning length: 600 mm, turning diameter: 400 mm, spindle speed (min.): 3,800 rpm, power: 22 kW (29.91 HP), Equipment: documentation/manual, rotational speed infinitely variable, Okuma LU300MY, with E-100L control, A-turret V12 all driven VDI4-40 M-function for milling, B-turret V-8, tailstock, chip conveyor, coolant system 8 bar, MY function Y-axis, touch setter, approx. 15,500 spindle hours, built in 2004, good condition and fully functional, available immediately. Kwolhcdwsvta Nyjzsw Neff The Okuma specialist and NeffBuy We are also happy to provide you with the all-round carefree package, viewing in our showroom including demonstration and acceptance, loading, transport, assembly and commissioning of the machine as well as instruction and subsequent service. We operate Okuma CNC service throughout Europe, both electronically and mechanically, and on top of that we have a 1200 m2 inventory of all Okuma spare parts, please visit us on our homepage.

Condition: good (used), Year of construction: 1993, Functionality: fully functional, turning diameter over cross slide: 530 mm, turning length: 850 mm, turning diameter: 450 mm, spindle bore: 80 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 10 rpm, travel distance X-axis: 330 mm, travel distance Z-axis: 850 mm, spindle motor power: 30,000 W, total height: 1,800 mm, power: 30 kW (40.79 HP), Equipment: documentation/manual, Okuma LB35 II M, OSP 5020LG, tailstock, touch setter, extraction, coolant pump 8 bar, chip conveyor, in good condition in relation to its age, very few spindle hours and very well maintained. Neff The Okuma specialist and NeffBuy We are also happy to provide you with the all-round carefree package, a tour of our showroom (30 Okuma machines) including demonstration and acceptance, loading, transport, assembly and commissioning of the machine as well as instruction and subsequent service. Kolovta H Eehcdwzsww We operate Okuma CNC service throughout Europe, both electronically and mechanically, and on top of that we have a 1200 m2 inventory of all Okuma spare parts, please visit us on our homepage.
