Used Stylus Grinding Machine for sale (65,014)

Condition: good (used), Year of construction: 1985, functionality: fully functional, The ELB SW 4/2 is a classic conventional surface grinding machine. Specific data may vary depending on the version (e.g., VA I, VAI-Z), but the key technical specifications typically fall within the following range: Machine type: Surface grinding machine (horizontal) Working area Grinding length: approx. 450 mm Grinding width: approx. 250 mm Max. workpiece height: approx. 280 mm Grinding spindle Grinding wheel: Ø 250 mm × 25 mm width Bore: 51 mm Speed: approx. 1,430 / 2,900 rpm Spindle motor: approx. 2.5 kW (total power ~4.5 kW) Bedpfsyy Aczsx Acvsda Axis travels Vertical travel (Z): approx. 400 mm General data Total power: approx. 4.5 kW Machine weight: approx. 1,800 kg Dimensions (L×W×H): approx. 1,800 × 1,400 × 2,000 mm

Condition: used, Year of construction: 2014, functionality: fully functional, grinding length: 600 mm, grinding width: 300 mm, Main machine data: - Table size (W x L): 600 x 300 mm - Electro-magnetic chuck: 300 x 600 x 70 mm - Grinding wheel size: 355 x 25 x 127 mm Drive performance: - Spindle motor: 2.2 kW Machine dimensions: Dimensions: - Length: 2,300 mm - Depth / Width: 1,550 mm - Height: 1,950 mm - Machine weight: 1,650 kg Standard equipment: Bdodeyyymwopfx Acvsa - CNC-controlled vertical feed AD1 - Electro-magnetic chuck - Automatic demagnetizing device - Electronic cross-feed adjustment via operator panel - Coolant system with extraction, paper filter, and magnetic separator - Parallel dressing device (head-mounted) - Dressing device for table mounting - Motorized rapid traverse adjustment (vertical) - Grinding wheel flange - Grinding wheel - Halogen lighting - Balancing arbor - Balancing scale - 1 set of splash guards Incl. 3 grinding wheel flanges Incl. fine-pole electro-magnetic chuck 300 x 600 mm Pole pitch: 3 mm, pole width: 1 mm Instead of standard electro-magnetic chuck

Condition: excellent (used), Year of construction: 1988, functionality: fully functional, machine/vehicle number: 1, center height: 150 mm, center width: 480 mm, grinding diameter: 299 mm, New arrival 1 Hydraulic Universal External and Internal Cylindrical Grinding Machine TSCHUDIN HTG 410 U – Year 1988, partial overhaul in 2026 – 150 mm center height x 480 mm center distance – workpiece spindle head MK 5 with stepless speed adjustment. Grinding wheel left and right – swiveling internal grinding attachment with 18,000 RPM Machine equipped with four-axis digital readout – X-axis – Y-axis and rotary encoder with one-micron resolution when swiveling the universal grinding spindle head and workpiece spindle head! Pneumatic air cushion lifting for effortless swiveling of workpiece spindle head and grinding spindle head. Machine includes four-jaw chuck, halogen lamp, paper band filter, folding dresser, and balancing arbor. Guideways in X-axis newly scraped – machine thoroughly inspected by specialist. Automatic cycle with "rapid traverse to automatic infeed – dwell time – retraction – infeed dimension remains set". Very little used machine from prototype manufacturing! Price on request (Domestic sales plus 19% VAT.) Technical data not binding – subject to prior sale and errors. Bdedjvdumbjpfx Acvja Best regards, INDUBA GmbH Mathias Becker D-78628 Rottweil

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, grinding length: 500 mm, grinding width: 250 mm, Young, like-new demonstration machine: High-precision surface grinding machine, "Optimal" series, available at a special net price. Grinding area: 500 x 250 mm Features: ● Surface grinding machine with automatic vertical feed ● Grinding sequence: roughing – finishing – spark-out ● Siemens S700 touchscreen panel and electronic handwheel for Y-axis ● Digital display for vertical axis Y and cross axis Z ● Table cover and splash guards in stainless steel design ● Electrical cabinet fitted predominantly with Siemens components ● Includes manual dressing device, electro-magnetic chuck, and coolant filtration system Main technical data: Grinding length mm 500 Grinding width mm 250 Distance table surface to spindle center mm 450 Table drive Hydraulic Table load kg 180 Longitudinal movement X Table speed, steplessly adjustable m/min 7 – 23 Max. longitudinal travel mm 560 Cross movement Z Max. travel speed mm/min 990 Max. cross travel mm 275 Vertical movement Y Max. travel speed mm/min 460 Grinding spindle / Grinding wheel Spindle power kW 2.2 Wheel dimensions mm 200x20x31.75 Spindle speed (speed control optional) min⁻¹ 2850 Dimensions Bdedpjyak Dlofx Acvea Machine weight (net) kg 1800 Machine dimensions (inc. reciprocation) Width mm 2300 Depth mm 1650 Height mm 1680 Power connection kW 3.7 All model series include standard accessories: ● 1 standard grinding wheel ● 1 wheel flange ● 1 dressing block with diamond ● 1 balancing arbor ● 1 balancing stand ● 1 machine lamp ● 1 set of machine tools ● 1 set of documentation with spare part list ● Machine in CE-conform (metric version) Precision and surface quality at optimal price. Fully equipped for universal use in a wide range of industrial and application areas. Machine comes with a 12-month parts warranty. By the way, aside from affordable new and certified used machines, we offer even more: • On-site consultation and solution finding • Organization of machine transport to your facility • Installation, commissioning, and turnkey handover • Spare parts supply • Control training for Siemens, Heidenhain, and Fanuc • Trained service staff available in your area and more • 24/7 telephone support • Tax-optimized trade-in of your old machine • Attractive financing options, even without down payment

Condition: not inspected (used), Year of construction: 1993, machine/vehicle number: 101472, ● Terms of delivery: Free loaded onto truck ● Location: 42477 Radevormwald ● Availability: By arrangement – Collection of the goods is scheduled for 06/05/2026. Unfortunately, collection outside this period cannot be considered. ● Payment terms: Advance payment by bank transfer ● Internal no.: DÄ27 ● Inspection under power: Yes Technical data: ● Magnetic chuck approx.: 500 x 250 mm Bdsdpfsyv Hduex Acvja ● Grinding length approx.: 600 mm ● Grinding width approx.: 250 mm ● Grinding height approx.: 500 mm Scope of delivery: ● Various grinding wheels as per pictures Dimensions & weights: ● Installation dimensions L x W x H approx.: 2200 x 1700 x 2000 mm ● Weight approx.: 1500 kg Info: There is a small chipped area on the lower handwheel; however, this does not affect functionality. If you have any questions or would like to arrange a viewing, please feel free to contact us! Additional notes: ►Transport to the destination can be offered upon request ►The offer price is net plus VAT ►The goods are sold with exclusion of any warranty ►Technical data without guarantee ►Subject to prior sale ❗The sale is strictly to business customers only❗

Condition: refurbished (used), machine/vehicle number: 2257, Manufacturing origin France Voltage 380/50/3 Netweight 3000 kg Bdodpofnm Iiofx Acvsa Custom position 8460.29 20 Dimensions 2400x1550 mm TECHNICAL DATA Diameter capacity 80 mm Type 2HA : 120 mm Maximum infeed grinding length 200 mm Maximum throughfeed grinding length (with normal-type guides) 300 mm Grinding wheel : -diameter 400 mm -maximum width 200 mm -bore 203.2 mm Driving wheel : -diameter 254 mm -width 200 mm -bore 127 mm Main drive motor 11-22 kW Driving wheel motor 1,1 kW Driving wheel speed 10 – 200 U/Min Standard accessories : 1 flange with grinding wheel 1 flange with driving wheel 1 workpiece support bridge 1 set of shims for workpiece support -Hydraulic dressing and trueing device for grinding and driving wheels -Variable speed drive of driving wheel -Electrical equipment for 3x380 v, 50 Hz -Main drive motor, 11 kW -Ammeter for main drive motor Starter keys and operating manual errors and omissions excepted data given without obligation.

Condition: used, Year of construction: 2000, functionality: fully functional, Used Cylindrical Grinding Machine Reckord M 1432 B The Reckord M 1432 B is a high-performance universal cylindrical grinding machine that combines maximum precision with robust construction. With a minimum infeed setting of just 0.0025 mm and outstanding roundness accuracy, it is ideal for demanding grinding tasks in both single-part and series production. Your advantages at a glance: Maximum precision: Minimum grinding wheel infeed of 0.0025 mm ensures top surface finishes and form accuracy. Exceptional flexibility: External, internal, and face grinding – swiveling workhead (+90° / -30°) and table (+3° / -6°) for tapers and complex geometries. Robust construction: Heavy-duty machine bed weighing approx. 4,000 kg for maximum rigidity and vibration damping. Powerful drive: 4 kW grinding wheel motor for rapid stock removal and short machining times. Ergonomic operation: Clearly arranged controls for rapid operator familiarization and intuitive handling. Bdodsyxgldspfx Acvea Technical Data Manufacturer: Reckord Model: M 1432 B (Model 1000) Type: Universal cylindrical grinding machine Centre height: 180 mm Max. grinding length: 1000 mm Max. grinding diameter: 315 mm Max. workpiece weight: 150 kg Workhead speeds: 40, 72, 128, 228 rpm Grinding wheel dimensions: 400 x 50 x 203 mm Grinding motor output: 4 kW Total power consumption: 7.8 kW Machine weight: approx. 4,000 kg Machine dimensions (L x W x H): 3240 x 1760 x 1680 mm Colour: Blue (as existing) Condition: Used, fully checked and operational Availability: Immediately ex stock Stockstadt Additional Information Scope of delivery: Cylindrical grinding machine Reckord M 1432 B including standard accessories as per the operating manual. Fully checked and operational. Technical documentation: Supplied in German. Optional services: Commissioning and training by experienced technicians, maintenance contract, as well as financing and leasing options on request. Inspection: The machine can be inspected by appointment in Stockstadt am Rhein.

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 14556, grinding wheel diameter: 400 mm, travel distance X-axis: 900 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 360 mm, grinding spindle speed: 3,400 rpm, TECHNICAL DETAILS Travel X-axis: 900 mm Travel Y-axis: 550 mm Travel Z-axis: 360 mm Table width: 790 mm Table depth: 380 mm Max. grinding wheel diameter: 400 mm Max. spindle speed: 3,400 rpm Bdedpfx Ajyuamxocvea EQUIPMENT CE marking Documentation

Condition: excellent (used), functionality: fully functional, center height: 125 mm, grinding length: 600 mm, grinding diameter: 249 mm, control cabinet length: 1,200 mm, control cabinet width: 40 mm, grinding spindle speed: 1,530 rpm, control cabinet height: 1,500 mm, overall weight: 3,250 kg, For sale is a cylindrical grinding machine manufactured by Kellenberger. The machine is in very good condition. Make: Kellenberger Model: R 125x600 Technical Specifications: Centre distance: 600 mm Centre height: 125 mm Workpiece diameter: 249 mm Power requirement: 10 kW Table: Travel: 700 mm Travel per handwheel turn, coarse/fine: 20/2.5 mm Speed, hydraulically adjustable: 0.02–6 m/min Minimum reversing travel: 1.5 mm Dwell time at reversal, adjustable: 0–5 sec Swivel range: 11 degrees Cross slide: Travel with feed handwheel, coarse/fine: 220 mm Travel per handwheel turn, coarse/fine: 4/0.5 mm Rapid traverse and return, hydraulic: 50 mm Feed, electro-mechanical with stepper motor: 0–9.99 mm/Ø Micro-stop of feed, per graduation: 1 µm/Ø Plunge grinding: Feed rate coarse/fine: 1–49/0.2–2.8 µm/sec Grinding spindle head: Grinding wheel, diameter x width x bore: 500 x 80 x 203.2 mm Motor rating: 5.5 kW Grinding spindle speeds: 1220, 1360, 1530 rpm Workpiece spindle head: Swivel range: 360 degrees Speeds, steplessly adjustable: 20–400 rpm Spindle internal taper: Morse 5 Motor rating: 0.9 kW Tailstock: Quill internal taper: Morse 3 Bedpfx Ajyyn Ehscvsda Quill travel: 30 mm Machine dimensions: 2800 x 1850 mm Weight: approx. 3000 kg

Condition: excellent (used), Year of construction: 2006, operating hours: 53,000 h, functionality: fully functional, Full-option CNC gear grinding machine in outstanding condition, previously used in special-purpose machinery manufacturing. The machine produces up to 200 different gear types/products for special orders in batch sizes from 1 to 10,000. Manufacturer: Reishauer Model: RZ 150 Type: CNC Gear Grinding Machine Year of manufacture: 2006 Serial number: 7XXXX Machine specifications: - 2 identical workpiece spindles - Workpiece spindles with tailstocks - Turret design - Enclosed machining area - External loading and unloading station - Especially designed for run-in gearings Equipment: - Grinding worm profiling device Reishauer RP 120 - Hoffmann belt suction filter system HSF 150 - OLAER cooling unit CD35.02-NE - OLAER designation PC31.02NE-S - ELBARON extraction/filter unit RON/A2000V-2V-RH - 5-axis robotic automation (optional) Operating data: - Total operating hours: approx. 70,569.5 h - Run-time / part counter workpiece spindle / workstation 1: counter reading 01794635 - Run-time / part counter workpiece spindle / workstation 2: counter reading 002929 Hoffmann belt suction filter system HSF 150 - Connection: 400 V / 50 Hz - Phases: 3 / PE - Operating voltage: 400 V - Connected load: 31.4 kW - Nominal current: 56.9 A Bdjdpfx Aoyxrygecvsa - Control voltage: 24 V DC - PLC voltage: 24 V DC - Valve voltage: 24 V DC - Lamp voltage: 24 V DC OLAER cooling unit CD35.02-NE / PC31.02NE-S - Year of manufacture: 2005 - Refrigerant: R134a - Fill quantity: 2.1 kg - Max. permissible operating overpressure HD: 21.7 bar - Max. permissible operating overpressure ND: 10.6 bar - Voltage: 400 V / 3 Ph / 50–60 Hz alternative: 480 V / 3 Ph / 60 Hz - Max. current: 5 A - Power: 2.5 kW ELBARON RON/A2000V-2V-RH - Year of manufacture: 07/2005 - Weight: 74 kg - Connection: 3 x 400 V AC / 50 Hz alternative: 1 x 230 V / 60 Hz - Power: 3.56 kW - Current: 7.0 A - Protection class: IP54 - High voltage max.: 9.9 kV DC - Current max.: 24.8 mA Condition: - Machine under power - Operated in single-shift to two-shift operation - Preventatively maintained - Very well-kept condition - Comprehensive documentation available Scope of delivery: - Without tools - Without production fixtures - Without grinding wheels - 5-axis robotic automation optional - Comprehensive documentation available Availability: - Inspection by appointment - Available from 06/2026 Sales information: - Sale as seen and inspected - Warranty excluded

Condition: used, Year of construction: 1995, functionality: fully functional, Drum Grinding and Polishing Unit Manufacturer: UHLIG, Type UB 22 Year: 1995 Technical Data: Make: Werner Uhlig Model: UB 22 Year of manufacture: 1995 Drive: Worm gear with motor Rotational speed: 5.6 – 54 l/min Shaft diameter: 25 mm, max. torque: 34 Nm Motor power: 0.25 kW Dimensions: approx. 1.00 x 0.90 x 1.20 m Weight: approx. kg (not specified) Equipment: - Control with frequency inverter - 2 single-chamber drums, approx. 200 mm wide, diameter 260 mm - Infinitely variable drum speed - Fresh water rubber hose - Waste water drain connection All details are subject to change without notice. A demonstration under power is possible at any time in our exhibition hall. Bdjdeyw Rhmspfx Acvsa

Condition: good (used), Year of construction: 2013, Grinding wheel 400 x 203 mm Regulating wheel 225 x 127 mm Fire extinguishing system Kraft u. Bauer Bjdpfx Acoyxl Drsvjda Knoll microfilter Steuli lifting station

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, The machine is in very good mechanical condition and can be demonstrated under power. A selection of grinding pins, which can be used with the machine, can be selected and matched on site. The original operating manual and wiring diagram are available. Bsdpfx Aoyx Dqdocvsda

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, We are selling a beautiful high-precision surface grinding machine from AMADA. The machine has low operating hours and is available for demonstration under power at the seller’s location. The machine’s enclosure has been completely renewed and it is in very well-maintained condition. Technical Data: Clamping surface: 550 x 200 mm Travel paths: 600 x 250 mm Height to spindle center: 90 to 400 mm Standard magnetic chuck size: 400 x 200 x 100 mm Grinding wheel size: 225 x 25 x 31.75 mm Grinding wheel speed: 500 – 5000 rpm Year of manufacture: Nov. 2016 Installation dimensions and weight: 2700 x 2400 x 1900 mm // Weight: 2400 kg Machine equipment: Bjdpfxoyx A Nfs Acvsda - FANUC Series 32i-Model B control - Machine enclosure (new) - Flanges - Dressing spindles (profile and groove grinding) - Belt filter - Integrated probe - Linear drive - Automatic balancing MPM - Ball screws and linear drive

Condition: good (used), center height: 215 mm, grinding length: 1,500 mm, total width: 2,300 mm, total length: 5,530 mm, total height: 2,100 mm, grinding diameter: 430 mm, Matrix Okuma Universal Cylindrical Grinder Model: GU – 40 Max Dia Ground: 430mm Max Between Centres: 1500mm Bjdpfxeyglhfs Acvoda Wheel Size: 355 x 50 x 127mm Headstock Speed: 10-150 RPM Variable Table Swivels: 8 Degree Machine With: Coolant Filtration Tank Steadies Internal Grinding Attachment with Quill Dimensions: 5530 x 2300 x 2100mm High Weight: 6200 Kgs

Condition: good (used), center height: 200 mm, grinding length: 1,600 mm, grinding wheel diameter: 450 mm, grinding diameter: 400 mm, Mostana Horizontal Spindle Grinder Model: 3L722B-80 Capacity: 1600 x 400 x 400mm Long Travel: 1780mm Cross Travel: 430mm VerticalTravel: 415mm Grinding Wheel: 450 x 80 x 203mm Spindle Motor: 11 KW Machine With: Rapid Traverse Vertical Incremental Downfeed Magnetic Chuck: 1575 x 400mm Coolant Clarifier Digital Readout Bdjdpfx Asyglc Aocvea Dimensions: 5940 x 2660 x 2600mm High Weight: 8000 KGS

Condition: ready for operation (used), machine/vehicle number: 4105, Grinding area: approx. 130 x 255 mm Bdsdpfx Acjh Ugwvevja Grinding speed: 2800 rpm Table size: 150 x 300 mm Drive motor: 380 V, 1.5 kW Required space: 750 x 700 x 1700 mm Weight: about 380 kg Cup wheel Ø: 180 mm

Condition: used, machine/vehicle number: 0257391, height of centers: 160 mm distance between centers: 1500 mm grinding wheel measures: 500 x 127 x 40 mm grinding wheel rotations: 1570/2050 Upm electrical connection: 380 V kW space needed: 4400/6400 x 2000 x 1400 mm weight: ca. 4000 kg Bdedpfsgayiwox Acvsa

Year of construction: 1975, condition: ready for operation (used), machine/vehicle number: M-27 738, Center hight: 165 mm Center width/grinding length: 1000/1075 mm Gr. Grinding diameter: 250 mm Table swivel: +/- 8° Gr. Table longitudinal movement: 1210 mm Workpiece spindle stick swivel: 0 - 90° Spindle bore/cone: 38 mm/MK 5 Grinding spindle stick easily swivelling Hydr. Quick adjustment approx.: 50 mm Grinding wheel dimensions: 400 x 50 x 127 mm 2 grinding wheel speeds due to V-belt step disc Bodpfx Aed Rv Rbecvsda Drive power: 3 kW Space requirement: 2900 x 2200 x 1750 mm Weight: approx. 3.5 t

Year of construction: 1962, condition: used, machine/vehicle number: 35701, height of centers: Werkstueck- bzw. Schleif-Ø 500 mm distance between centers: ca. 2000 mm max. working piece weight: 1200 kg Bdedpfoz Hctsx Acvja grinding wheel measures: 600 Ø x 300 mm grinding wheel rotations: 965 Upm electrical connection: 380 V, ca. 15 kW space needed: 2300 x 9000 x 2000 mm weight: 13000 kg

Year of construction: 1962, condition: good (used), machine/vehicle number: 3791, max. grinding length: 620 mm max. grinding width: 250 mm table plate chuck: 200 x 620 mm Bsdpfx Acjd Ihiijvoda grinding plate measures: 200 x 220 x 51 mm electrical connection: 380 V, 1/1,8 kW space needed: 1650 x 1450 x 1800 mm weight: 1350 kg

Condition: ready for operation (used), machine/vehicle number: 27246, Dividing head carriage movement: 100 mm Table longitudinal movement: 260 mm Table height adjustment: 50 mm Swiveling the table slide by: 360 ° Bdjdpfsd Ivfysx Acvsa Swiveling of the vertical slide guide: 360 ° 2 spindle speeds by pole-changing motor: 3750/7500 rpm Drive motor, pole-changing: 0.5 / 0.6 kW Space required: 980 x 600 x 1500 mm

Condition: used, machine/vehicle number: 20308, gr. swing Ø: 600 mm Centre distance: 2200 mm gr. grinding-Ø with grinding wheel 800 mm Ø: 125 mm grinding wheel Ø when using the setting sticks: 20 - 125 mm grinding wheel dimensions: 800 x 28 - 800 x 42 x 305 mm 2 grinding wheel speeds 3 workpiece speeds: 32, 55 and 96 rpm table shift by hand coarse/fine: 10/2 mm Bdodpfx Acjcik N Ssvea automatic. Feed speed of grinding wheel: 0,005 - 0,025 mm 6 table speeds: 120 - 1540 mm/min Grinding headstock drive: 8 kW electrical connection: 380/400 V, 10 kW space requirement : 6100 x 2300 x 1600 mm weight : 7 t

Year of construction: 1975, condition: used, machine/vehicle number: 27749, height of centers: Schleif-Ø 250 mm distance between centers: Schleiflaenge 575 mm grinding wheel measures: 500 x 60 x 127 mm electrical connection: 380 V, ca. 9 kVA kW Bdedpfx Ajz Hc Iecvea space needed: 2650 x 2600 x 2240 mm weight: 3400 kg

Condition: used, abrasive belt measures: 50 x 100 Ø mm engine: 380 V, 0,7 kW space needed: 650 x 550 x 1050 mm Bjdpfx Acjb Tcv Hsvoda
