Used Profile Grinding Machine for sale (67,380)

Condition: ready for operation (used), cCenter height: 130 mm center width: 500 mm grinding wheel dimensions: 127/300 x 40 mm grinding wheel speeds: 2 rpm electrical connection: 380 V, approx. 4 kW space required: 1730 x 1100 x 1550 mm weight: approx. 1750 kg Bwodpevf Dmtjfx Acvek

Year of construction: 2001, condition: good (used), table diameter 200 mm workpiece height 100 mm number of wheels 1 Control Robot CNC total power requirement 6 kW weight of the machine ca. 1,8 t dimensions of the machine ca. 1,83 x 2,04 x 2,1 m Bedpfx Ajtt Tb Docvewk Technical data - Grinding capacity : Ø 0.025 –12.7 [mm] - Bar diameter : Ø 1.0 –12.7 [mm] - Grinding length : W15 (option W20) - Z-axis : 35[mm] Resolution : 0.5 [µm] – X- axis : 25 [ mm] Resolution : 0.1µm – Y-axis : 286[mm] Resolution : 0.5µm – U- axis : 15 [mm] Resolution : 0.1µm Head Motor: 0.70 [kW] Rotation: 300 – 3000 [rpm] Grinding - Raw grinding : 1.5 [kW] Spindle : Ø 60 [mm] Grinding wheel diameter : Ø 200 [mm] Cutting speed : 30 m/sec. - Completion: 0.75 [kW] Spindle: Ø100 [mm] Grinding wheel diameter: Ø150 [mm] Cutting speed: adjustable - Dimensions (L x W x H): 1830 x 2040 x 2100 mm - Weight: approx. 1800 [kg] Accessories - Loading and unloading robots - Fire protection device CONTROL axes; 4 axes + 2 programmable robots - simultaneously linear interpolation of the 4 axes + cylindrical interpolation of 2 robot axes

Condition: good (used), Year of construction: 1988, voltage 380 V connected load 7,5 kVA dimensions 2725 x 1930 x 1773 mm weight of the machine ca. 2500 kg --> Technical data Main data: --> Table surface: 605 x 300 mm --> Table longitudinal movement max. (manual): 750 mm --> Table transverse movement: 340 mm --> Grinding height between table/new grinding wheel min/max: 22.5 / 322.5 mm --> Standard size of magnetic clamping plate: 600 x 300 mm --> Workpiece weight incl. magnet: 420 kg --> X-axis / longitudinal movement: --> T-slots (number x width): 3 x 17 mm --> Table feed, hydraulic: 0.3 - 25 m/min --> Travel per handwheel revolution: 47 mm Bjdpsw Dvkaefx Acvjwk --> Y-axis / height movement: --> Automatic vertical feed - coarse in 12 steps: 0.001 - 0.03 mm --> Automatic vertical feed - fine in 8 steps: 0.001 - 0.01 mm --> Distance per handwheel revolution (x1/x10): 0.1 / 1.0 mm --> Graduation on handwheel (x1/x10): 0.001 / 0.1 mm --> Trigger strokes: 0 - 5 --> Rapid traverse: 400 mm/min --> Z-axis / transverse movement: --> Automatic transverse feed intermittent: 0.5 - 20 mm --> Automatic transverse feed / rapid traverse continuous: 0.1 - 1.0 m/min --> Distance per handwheel revolution: 5.0 mm --> Scale mark on handwheel: 0.02 mm --> Standard grinding wheel: --> Ø x width: Ø 355x38 (50) mm --> Bore: Ø 127 mm --> Speed: 1500 rpm --> Accessories Various grinding wheels --> Documentation

Condition: good (used), Year of construction: 2014, spindle turning speed range 170 - 18000 U/min weight of the machine ca. 7,5 t dimensions of the machine ca. 5,00 x 4,00 x 2,20 m --> Control conversion (2014) to Siemens Sinumerik 840D Solutionline --> Overhaul of the new control system in 2016 --> Technical data Grinding diameter: 20 - 300 mm --> Oscillation diameter: 350 (500) mm --> Workpiece length: 300 (1300) mm --> Recommended grinding depth up to: 300 mm Bedpfx Acew Intaovjwk --> Grinding table stroke Z-axis (total): 650 (950) mm --> Resolution: 0.001 mm --> Rapid traverse: 12 m/min-1 --> Grinding stroke speed: 0 - 9.99 m/min-1 --> Feed rate: 0 - 99.99 m/min-1 --> Step feed value during reversal: 0 - 0.999 mm --> Grinding table stroke X-axis (total): 150 mm --> Resolution: 0.001 mm / Ø --> Rapid traverse: 5 m/min-1/R --> Grinding stroke speed: 0 - 5 m/min-1/R --> Feed rate: 0 - 99.99 m/min-1/R --> Step feed value during reversal: 0 - 0.999 mm / Ø --> Swivel capability of the workpiece headstock: --> B-axis: -32° (-23°) / +2° --> Resolution: 0.0001° (0.36") --> U-axis stroke (total): 300 mm --> Resolution: 0.001 mm / Ø --> Travel speed: 5 m/min-1 --> Centre height above workpiece table: 200 (300) mm --> Centre height above grinding table: 330 (430) mm --> Workpiece spindle passage: 50 (70) mm --> new in 1988

Condition: good (used), Year of construction: 2013, grinding diameter 390 mm grinding length 650 mm centre height 200 mm total power requirement 46 kW Bwodjw Inr Nopfx Acvjk weight of the machine ca. 6 t dimensions of the machine ca. 3x3x2,4 m Universal cylindrical grinding – Type WUG21 (W27) Grinding length 650 mm EMAG Weiss stands for high-end technology in universal cylindrical grinding between centres. With its CNC-controlled WUG 21 machines, EMAG Weiss offers the right solution for virtually every user. --> Technical data Max. grinding length: 650 mm --> Centre height: 200 mm --> External grinding diameter: 1 – 390 mm --> Max. weight flying MK4: 100 kg --> Max. workpiece weight between centres: 250 kg --> Feed: --> X-axis travel: 480 mm --> Z-axis travel: 1.150 mm --> Workpiece headstock --> Tailstock --> Grinding spindle headstock --> Coolant device, manufacturer HYFRA, --> Belt filter, manufacturer Knoll, type KF 200 - year of manufacture 2012, --> Oil mist filter, manufacturer Cobaron

Condition: good (used), Year of construction: 1972, max. wheel diameter 80 mm gear width 60 mm max. module 3 min. module 0,1 total power requirement 0,4 kW weight of the machine ca. 120 kg Bedpfxsw N S D Sj Acvjwk dimensions of the machine ca. 0,6x0,6x0,75 m

Year of construction: 2022, condition: new, bearing diameter 120 mm motor Synchronmotor Nominal turning speed 3000 1/min Maximum turning speed 4000 1/min Torque 76,4 Nm current 38 A Unused grinding spindle for Höfler Rapid 1250 Bsdpfoua Itujx Acvjwk

Condition: used, Year of construction: 2003, Control BWO tip circle diameter max. 700 mm root circle diameter min. 50 mm height of profile max. 35 mm number of spindle speeds 0 - 5400 min-1 table load capacity max. 500 kg Overall size 370x220x300 cm Total weight, approx. 15000 kg Number of working hours 94082 h Equipment: BWO control system All axes CNC controlled Oil mist extraction Coolant cleaning system with cooling unit Dittel balancing unit Accessories: Grinding wheels Ø400mm incl. Grinding wheel flanges 1 diamond dressing roller, manufacturer Dr. Kaiser, Ø160mm Counterholder tip Control cabinet: Width 70 cm x length 280 cm x height 220 cm Bodpfxjxt Ur Ss Acvowk Machine: Width 220 cm x length 370 cm x height 300 cm Coolant system: Width 170 cm x length 240 cm x height 250 cm

Condition: ready for operation (used), Year of construction: 1990, functionality: fully functional, grinding length: 400 mm, grinding width: 150 mm, JUNG JF 415 Jung JF 415 Surface Grinding Machine with Flanges and Coolant Belt Filter * Table length: 400 mm * Table width: 150 mm * Maximum grinding length: 400 mm * Maximum grinding width: 150 mm * Maximum workpiece weight: 75 kg * Distance spindle to table: 400 mm * Table speed: 1–24 m/min * Grinding wheel diameter: 25 mm * Spindle speed: 900 – 4500 rpm Bwjdsytfbfjpfx Acvjk * Heidenhain digital readout * Year of manufacture: 1990, machine no.: 1566

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, single double edging machine with 12 cup wheels on each side max. glass size is 2600 mm Bodpfjywyvmjx Acvewk min. glass size is 170 mm machine sizes : L x W : 7700 x 4500 mm

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, 10 cup wheels vertical glass edging machine with a Schraml CLEAR Aquatec water centrifuge Bjdpfx Ajywykwjcvjwk miter angle : 0-45° speed : 0,35 - 5,4 m/min. arris width : 5 mm min. glass size 3-12 mm : 65 x 65 mm from 12-30 mm : 100 x 100 mm glass thikness : 3 - 30 mm electric power : 31 Kw 72A 400 V 50 Hz machine dimensions ; LxWxH(mm) 8400 x 1250 x 2900 mm

Condition: used, Year of construction: 1998, Technical details: height of profile: 180 mm max. dia. of grinding wheel: 200 / Topfscheibe mm grinding wheel hole diameter: k.A. grinding spindle speed: 2800 U/min Table dimensions: LxB: 500 x 160mm mm voltage: 220 / 380 V total power requirement: 3,0 kW weight of the machine ca.: 0,57 t dimension machine xH: 1,28 x 1,0 x 1,75 m Application for face grinding Magnet mount: LxW = 680 x 200mm; tilt approx. 15°; swivel 360° via radial scale Bodpeu Ngrqefx Acvswk magnet: Type S2D; permanent magnet, clamping surface 300 x 150mm. Grinding wheel support: -adjustment vertical = length 180mm manual; swivel = approx. 45° right/left manual. Operation via control panel on machine. Coolant tank with pump and feed *

Condition: good (used), functionality: fully functional, Year of construction: 1997, Used profile bending machine from Sahilner Model: PK 40 Shaft diameter: 40 mm 3 driven rolls Bedpfxeytb Afe Acvewk Including various tools Year of manufacture: 1997

Condition: used, Year of construction: 1992, grinding length 0800 mm grinding width 500 mm workpiece height 400 mm table-size 800 x 400 mm table speeds 1 - 25 m/min cross feed autom. 0 - 60 mm/Hub grinding wheel size 400 x 100 x 127 mm grinding spindle speed 1400/2800 U/min total power requirement 10 kW Bjdpfx Acswgnz Ajvewk voltage 380 V weight of the machine ca. 6 t Machine has cooling arrangement, auto. vert. feed, dressing arrangement and wheel flanges.

Condition: used, Year of construction: 1950, width of the strips 150 mm band length 6680 mm Bwjdpfx Aoua Ivcecvok volt 380 V weight 800 kg dimensions of the machine ca. 3,2x1,6x1,75 m Wood surface sanding machine Carriage length: table size 2500 x 800 mm Belt length: 150 x 6680 mm Manual processing table, adjustable Table height adjustable

Condition: used, TSCHUDIN GL 600 is a CNC centerless grinding machine designed for precision, high accuracy and reliable operation. Working capacities: grinding diameter 2–100 mm; grinding wheel Ø600 mm × 350 mm; regulating wheel Ø350 mm × 350 mm, swivelling range ±5°. Key specs: grinding spindle stepless, speeds up to 45 m/s; regulating spindle stepless 0–290 t/min; voltage 50 Hz 3x400 V; grinding motor 22 kW; total power 26 kVA; overall dimensions L2300 × W2000 × H2150 mm. Enables tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical sectors Bwedpfx Acjyxn Hpjvsk

Condition: excellent (used), functionality: fully functional, KELLENBERGER PRECISION UNIVERSAL CYLINDRICAL GRINDING MACHINE MODEL: 1000 U YEAR OF MANUFACTURE: 2000 PARTIAL OVERHAUL: 2026 Centre height: 175 mm Grinding length: 1000 mm Equipment: - Standard accessories - Standard workpiece headstock MK5 with adapter flange DIN 55027, size 5 - Splash guard hood for the above - Tailstock with fine adjustment, MK4 - Internal grinding attachment with protective cover for grinding spindle D:80 mm for belt-driven spindles Bwedpjyf E Sujfx Acvjk - FISCHER internal grinding spindle type HJN 842, incl. grinding mandrels (4 pieces, choice) - HJNZ 42 collet chuck - Oil mist lubricator for HJN spindles - STREULI magnetic paper band filter system, type: SPB 2 - Coolant supply through the workpiece spindle - HEIDENHAIN digital length measuring system on X and Z axes - Sine bar on the workpiece headstock incl. alignment arbor MK5 - Permanent magnetic chuck, D:200 mm - Three-jaw chuck, D:160 mm - Four-jaw chuck, D:160 mm - Collet attachment for Schaublin collets B32 - Set of B32 collets, D: 1.0–30.0 mm, increment 0.5 mm (59 pieces) - Dial indicator stop for table swivel with indicator 0.01 mm - Table fixed stop - Dressing stop for internal grinding - LED machine lamp - Various grinding wheel flanges, left (2 pieces) - Pneumatic table load relief - Swiveling dressing device for external, face, or internal grinding operations - Set of vibration damping pads - New three-color paint finish (light grey RAL 7035 / blue RAL 5012 / dark grey RAL 7016) - New acceptance protocol according to KELLENBERGER standard - Documentation - CE conformity The machine is currently being overhauled, sample photos shown!

Condition: good (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 0607H-07, Grinding length: 800 mm Grinding width: 400 mm Workpiece height: 342 mm Travel path x / y: 900x460 mm Grinding wheel dimensions: 355x38x127 mm Spindle speed: 2400 rpm - Grinding wheel 355x38x127 mm, magnetic chuck, dressing device, coolant system with paper filter and magnetic separator, Bsdpfx Aeyx S S Necvowk

Condition: used, Year of construction: 1976, magnetic clamping plate 1.000 x 600 mm In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved. Bsdpfxsywnwle Acvjwk

Condition: used, 1500 x 3000, 2017 model, made in Taiwan Bodpfjyxwfuox Acvswk

Condition: used, Make: DISKUS-WERKE, Model: ModuLine DS 300 SO, Year of manufacture: 2013, Machine No.: 2219, Control system: Siemens, Model Sinumerik 840D sl, 2 spindles, spindle distance 210 mm, max. speed approx. 4000 rpm, W-tool spindle / grinding spindle 2000 rpm, max. workpiece diameter 100 mm, max. workpiece height 40 mm, 8-position tool turret, manufacturer Sauter, model 0.5.480.516, tool holder type Capto C5, workpiece automation device, manufacturer DVS, model Moduline, transfer robot manufacturer Epson, PLC system control by Siemens, display with Simatic Panel Touch, coolant system by Knoll, type KF150/950, paper band filter, chip conveyor by Knoll, type 225S-2/170 Bodpfjx Ahg Ujx Acvewk +++ Note: This machine is part of an online surplus sale! +++

Condition: used, Make: BUDERUS, Model: CNC235, Year of manufacture: 2007, Machine no.: 9030, Control system: Siemens brand, Type: Sinumerik 840D sl Powerline, 2 workspaces, 2 cross slides, X/Z traverse path, 2 spindles, Speed, C-axis workpiece spindle: 3,000 [rpm], High-frequency internal grinding spindle: (51,000 [rpm]) (for grinding arbor), Max. feeds Z 30 m/min, X 90 m/min, Max. workpiece diameter: 100 mm, Max. workpiece length: 50 mm, 2x 8-position tool turret, Tool holder: Capto C5, Workpiece automation with drag conveyor system and gripper, Coolant system, Paper band filter, Oil separator, Manufacturer: Mahle, Type: LGA601, Oil mist extraction, Recooling unit, Manufacturer: Hydac, Chip conveyor, Manufacturer: Astos +++ Note: This machine is part of an online surplus sale! +++ Bedpfx Aox Ahivocvowk

Condition: used, Number of working hours 1717 h Bsdpfxoywnuqs Acvjwk

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 1761-1700, 457 x 152mm capacity. Equipped with magnetic chuck, power rise and fall to wheel head, table guard, coolant system, and dust extraction. SPECIFICATION Jones & Shipman Model 540P Working Surface of table 457 x 152mm Longitudinal traverse of table, hand and hydraulic 483mm Total cross traverse of table, hand and hydraulic 168mm Floor to table height 1035mm Table traverse speed range per min 1.5 – 18m Cross feed range per stroke at each reversal 0.178 – 1.78mm Bedjnxi Uujpfx Acvewk Micrometer cross feed graduated in Vertical feed adjustment in increments of 0.002mm Vertical movement of wheelhead (max) 280mm Wheel spindle center to table (min) 50mm Size of grinding wheel 180 x 13 x 31.75mm bore Speed of wheel 2880rpm Wheelhead motor 1.5kW Hydraulic pump motor 0.55kW Machine in Imperial execution MACHINE EQUIPPED WITH Magnetic chuck Power rise and fall to wheel head Table guard Wheel guard Coolant System Dust extraction

Condition: excellent (used), Year of construction: 1984, functionality: fully functional, machine/vehicle number: BO 94392, A familair machine in any toolroom, this Jones and Shipman 540P is equipped with a 6″ x 18″ magnetic chuck, power rise and fall, coolant system and dust extraction. A toolroom institution: USED Jones & Shipman Model 540P Horizontal Spindle Surface Grinding Machine Specification Working Surface of the table 457 x 152mm Longitudinal traverse of table, hand and hydraulic 483mm Total cross traverse of table, hand and hydraulic 168mm Floor-to-table height 1035mm Table traverse speed range per min 1.5 – 18m Cross-feed range per stroke at each reversal 0.178 – 1.78mm Micrometer cross feed graduated in Vertical feed adjustment in increments of 0.002mm Vertical movement of wheelhead (max) 280mm Wheel spindle centre to table (min) 50mm Size of grinding wheel 180 x 13 x 31.75mm bore Speed of wheel 3000rpm Wheelhead motor 1.5kW Hydraulic pump motor 0.55kW Machine in Imperial execution Machine equipped with Magnetic chuck Power rise and fall to wheel head Table guard Wheel guard Coolant System Dust extraction Lighting Bodpfx Acjnxi R Usvowk
