Used Capstan Lathe for sale (5,501)

Condition: used, Year of construction: 2012, functionality: fully functional, machine/vehicle number: G3169-0110, turning length: 530 mm, turning diameter: 420 mm, spindle speed (min.): 20 rpm, spindle speed (max.): 4,000 rpm, spindle bore: 65 mm, travel distance X-axis: 220 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 550 mm, overall weight: 4,700 kg, turning diameter over bed slide: 800 mm, HYUNDAI WIA L200SY CNC TURNING CENTER Year: 2012 | Fanuc 18i-TB CNC Control SN: G3169-0110 • 5-Axis CNC Turning Center – Hyundai WIA L200SY • Main Chuck: 8″ | Sub Spindle: 5″ • Live Tooling & Y-Axis + C-Axis indexing • Max Turning Diameter: approx. 419–420 mm / 16.5″ Iodpfex I A Hcex Ag Ustb • Max Turning Length: approx. 520–530 mm / ~20.5–20.9″ • Swing Over Bed: approx. 800 mm / 31.5″ • X Travel: approx. 220 mm / 8.7″ • Z Travel: approx. 550 mm / 21.7″ • Y Travel: approx. 80 mm / 3.1″ • Max Spindle Speed: up to 4,000 rpm • Main Spindle Power: ~20 HP (~15 kW) • Sub Spindle Speed up to 6,000 rpm • C-Axis indexing: 0.001° possible • Tool Stations: approx. 12 • Coolant system and chip conveyor included • Approx. Dimensions: 120″ × 68″ × 80″ • Approx. Weight: ~10,500 lbs (~4,760 kg) NOTE: MACHINE WAS REMOVED FROM GOOD WORKING CONDITION 2 YEARS AGO. PLANNED TO PUT BACK IN SERVICE BUT SELLER WILL NO LONGER BE DOING MACHINING.

Condition: excellent (used), Broadbent Heavy Duty Lathe 1041mm x 10,000mm Itedpfxjwhylvj Ag Ueb Year approx. 1973. Swing over bed 1041mm (41”) Swing bin gap1575mm (62”) Distance between centres 9300mm (30’ 6”) Spindle bore 115m (4 ½”) Spindle speeds (18) 3.3 – 360 rpm Spindle motor 30 HP or 40 HP (To be confirmed) Tailstock 6 MT Imperial & Metric screw-cutting with change gears. 36” Faceplate with 4 adjustable jaws, 54” Faceplate, Taper turning attachment, Power feed to top slide, 2 x 18” 3 point steadies, 24”/28” Steady.

Condition: good (used), Year of construction: 2012, functionality: fully functional, Schiess CNC vertical lathe with C axis, year 1992, retrofitted in 2012 CNC: NUM 1060 FLEXIUM 2 tables, table diameter 2000mm – max turning diameter 2500mm – max table speed 201 rpm – table power 56 KW Load capacity (table included): 16,000kg Movable crossrail with 12 positions, 50mm pitch Available space under spindle nose: min. 795mm, max. 1345mm RAM Z stroke: 1000mm C axis with 360,000 positions – milling spindle max speed 1600 rpm – milling spindle power 22KW – 2 gear ranges Tool magazine: 20 turning tool positions, 35 milling tool positions 1 milling head WIDAFLEX UTS80 1 milling head ISO 50 Renishaw MP60 touch probe (for parts) Itodpfx Aoxpqm Rsg Ueb Tool presetter – Transmit function: G20 / G21 – No rigid tapping Chip conveyor Front door: partial opening M0 / full opening

Condition: used, load capacity: 2,500 kg, lifting height: 6,000 mm, free lift: 1,650 mm, mast type: triplex, construction height: 2,660 mm, fork carriage width: 1,030 mm, fork length: 1,200 mm, empty load weight: 4,791 kg, total length: 23,000 mm, drive type: Elektro, construction width: 1,280 mm, Electric 4-wheel forklift Load center: 500 Fork width: 100 mm Fork thickness: 40 mm Mast type: Triplex Technical condition: Good Front tires type: Non marking Itjdjt Ddv Iopfx Ag Ueb Rear tires Type: Non Marking

Condition: new, Year of construction: 2025, turning diameter over cross slide: 250 mm, turning length: 730 mm, turning diameter: 500 mm, spindle speed (max.): 1,800 rpm, CNC lathe machine CK 6150 with flat bed We offer a new CNC lathe machine model CK6150. We use this machine in our production and you can see it in operation before ordering. The CK 6150 lathe has a flat bed and hardening guides, which ensures a long period of operation of the equipment. The machine is equipped with a CNC system, the GSK CNC system is installed as standard. Optionally, the machine can be equipped with a Fanuc or Siemens CNC system. The machine can have a tool holder for 4-6 or 8 tools, depending on the customer's wishes. It is possible to install a hydraulic chuck on the machine, which will greatly simplify the process of installing parts on it and a hydraulic tailstock. The CK 6150 lathe can be equipped with additional supporting frame for more accurate manufacturing of long parts. Technical specifications: Model CK 6150 x 1000 Maximum workpiece diameter over bed 500 mm Maximum workpiece diameter over support 250 mm Maximum workpiece length 1000 mm Maximum turning length 730 mm Spindle bore diameter 82 mm Spindle speed 150-1800 rpm Engine power 7.5 kW Mechanical chuck (hydraulic optional) Chuck size 250 mm. Iodpfx Aoxdmgvjg Ustb 4-position tool holder (6 or 8 optional) Maximum tool size for tool holder 25x25 mm Machine weight 2700 kg Machine dimensions 2650×1700×1820 mm We can also supply lathes CK 6140, CK 6150 and CK 6160 with other dimensions of the working part: CK 6140 dimensions of the working part 550/750 mm CK 6150 dimensions of the working part 1000/1500/2000 mm CK 6160 dimensions of the working part 1000/1500/2000 mm CK 6152E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6185E dimensions of the working part 1000/1500/2000/3000/4000 mm CK 61100E dimensions of the working part 1000/1500/2000/3000 mm CK 61125E dimensions of the working part 1000/1500/2000/3000 mm

Condition: ready for operation (used), Year of construction: 1986, functionality: fully functional, machine/vehicle number: 8531, Auction of a Famot MEXPOL TUM 35! Iedpfx Ajx Ngnmsg Ustb

Condition: ready for operation (used), Year of construction: 1998, operating hours: 7,984 h, functionality: fully functional, machine/vehicle number: 1408, turning length: 250 mm, turning diameter: 340 mm, spindle speed (max.): 4,500 rpm, bar passage: 65 mm, controller model: Okuma OSP7000L, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Maximum turning diameter: 340 mm Maximum turning length: 250 mm Main Spindle Technology: Motor spindle Speed: 4,500 rpm Power (max.): 22 kW Bar capacity: 65 mm Workpiece clamping: 3-jaw chuck, Kitagawa B-210 Tool Turret I (X/Z) Technology: 12-station turret Tool holder: VDI40 Travel in X: 260 mm Travel in Z: 640 mm Rapid traverse in X: 15 m/min Rapid traverse in Z: 20 m/min Tool Turret II (X/Z) Technology: 8-station turret Tool holder: VDI40 Travel in X: 140 mm Travel in Z: 615 mm Rapid traverse in X: 15 m/min Rapid traverse in Z: 20 m/min MACHINE DETAILS Control: Okuma OSP7000L Dimensions & Weight Dimensions (L x W x H): 3,305 x 2,100 x 1,927 mm Weight: 4,800 kg Electrical connection data Rated voltage: 400 V Number of phases: 3 Frequency: 50 Hz Iedpfx Agsx Hx Dnj Ujtb Power consumption: max. 30 kVA Total current: 43.4 A Motor current: max. 106 A Operating Hours Power-on hours: 36,348 h Cutting time: 7,984 h Spindle run time: 8,674 h EQUIPMENT Chip conveyor Coolant pump Automatic measuring arm Transformer

Condition: ready for operation (used), Year of construction: 2006, operating hours: 32,503 h, functionality: fully functional, machine/vehicle number: 01510006441, controller model: MANUAL PLUS 4110, TECHNICAL DETAILS Control: MANUAL PLUS 4110 MACHINE DETAILS Electrical Supply Rated voltage: 400 V Phases: 3~ Frequency: 50 Hz Performance Data Power: 24 kVA Rated current: 35 A Itsdpfex Uz Edjx Ag Ueb Fuse rating: 50 A Operating hours: 32,503 h

Condition: ready for operation (used), Year of construction: 1999, operating hours: 78,000 h, functionality: fully functional, turning length: 205 mm, spindle speed (max.): 10,000 rpm, bar diameter (max.): 20 mm, controller model: Fanuc 16i-T, number of axes: 9, CNC sliding headstock lathe with 9 axes! TECHNICAL DETAILS Axes: X / C1 / Y / E / B / A / X / C2 Maximum bar diameter: 20 mm Maximum turning length: 205 mm / 195 mm Maximum main spindle speed: 10,000 rpm Maximum sub-spindle speed: 10,000 rpm MACHINE DETAILS Control: Fanuc 16i-T Coolant: Oil Tank capacity: 170 L Operating hours: 78,000 h EQUIPMENT 4-position tool holder 3 cross drilling units Turret with 8 stations Various additional tool holders Tailstocks Parts conveyor Bar feeder FMB Turbo 3-26 /3200/A Itodpfxsx U Af Ss Ag Ueb Fire extinguishing system Kraft & Bauer Chip conveyor Mayfran

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, turning length: 205 mm, spindle speed (max.): 10,000 rpm, turning diameter: 20 mm, controller model: Cincom Mitsubishi Meldas, counter spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Bar diameter max.: 20 mm Turning length max.: 205 mm Main spindle speed max.: 10,000 rpm C-axis (main spindle): 0.001 degree Counter spindle speed max.: 10,000 rpm C-axis (counter spindle): 0.001 degree Tool capacity: 18 tools Axes: 7 MACHINE DETAILS Control: Cincom Mitsubishi Meldas Dimensions & Weight Machine dimensions (LxWxH): 2,540 x 1,450 x 1,850 mm Itsdpfxox U Afxe Ag Ueb Machine weight: 1,750 kg Bar feeder dimensions (LxWxH): 3,900 x 900 x 1,450 mm Bar feeder weight: 850 kg EQUIPMENT Parts conveyor belt Bar feeder FMB Turbo 3-26

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, turning length: 205 mm, spindle speed (max.): 10,000 rpm, turning diameter: 20 mm, controller model: Cincom Mitsubishi Meldas, counter spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Max. bar diameter: 20 mm Max. turning length: 205 mm Max. main spindle speed: 10,000 rpm Main spindle C-axis: 0.001 degrees Max. sub spindle speed: 10,000 rpm Sub spindle C-axis: 0.001 degrees Itjdpfsx U Ad Uex Ag Ujb Tool capacity: 18 tools Number of axes: 7 MACHINE DETAILS Control: Cincom Mitsubishi Meldas Dimensions & Weight Machine dimensions (LxWxH): 2,540 x 1,450 x 1,850 mm Machine weight: 1,750 kg Bar feeder dimensions (LxWxH): 3,900 x 900 x 1,450 mm Bar feeder weight: 850 kg EQUIPMENT Parts conveyor FMB Turbo 3-26 bar feeder

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, turning length: 81 mm, turning diameter: 99 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 300 mm, travel distance Z-axis: 240 mm, TECHNICAL DETAILS Isdpfx Agjx Upv Rs Ustb Maximum turning length: 81.3 mm Maximum turning diameter: 99.1 mm X-axis: 300 mm Z-axis: 240 mm Spindle head: A2-6 Spindle bore: 33 mm Variable spindle speed: 4,000 rpm Spindle motor power: 11 kW Number of turret tools: 8 Number of driven tools: 10 MACHINE DETAILS Control: Fanuc 21iT Dimensions & Weight Machine dimensions (incl. chip conveyor): 290 x 235 cm Machine weight: 4,000 kg Transformer station dimensions: 65 x 60 cm Transformer station weight: 150 kg Overall dimensions (L x W x H): 2,600 x 2,300 x 2,400 mm Total weight: 3,900 kg EQUIPMENT Chip conveyor

Condition: used, Year of construction: 1973, turning diameter over bed 2235 mm turning diameter over slide rest 2997 mm turning length 12200 mm Control SIEMENS faceplate diameter 2000 mm required space ca. 7 x 22 m weight of the machine ca. 220 t HOESCH MFD CNC HEAVY DUTY LATHE WITH SIEMENS CONTROL Type: D2000 SGK-1 Technical documentation is included Technical Specifications Space requirement: 7 x 22 metres + control cabinet 4.7 x 0.5 x 2 metres Faceplate 2006mm Centre Height 1,499mm Swing Over Saddle 2235mm Swing Over Bed 2997mm Turning Length 12192mm Min/Max Workpiece Held In Chuck Ø457/1600mm Maximum Workpiece Weight 110 Ton Speed Range 0.5- 140rpm (300hp Motor) Feed Range 0.0118-7.08''/Rev. Steady Capacity Ø356-902mm Copying Depth 508mm lnductive Maximum Cutting Force 30,000Nm Twin Barrel Steady Capacity Ø356- 902mm, 50 Ton Capacity, Roller Type. Machine Data 1.1 Total Machine Iodpfx Ajt Ei Husg Ujtb Max. Swing over bed slide 2,000 mm Center height over bed 1,500 mm Distance between centers 12,000 mm max. weight of workpiece 100,000 kp height measured from shop floor level up to machine axis 2,200 mm 1.2 Headstock Diameter of main spindle 670 mm Diameter of faceplate 2,000 mm Max. chucking diameter 1,600 mm Min. chucking diameter 455 mm Dead Center Angle 80 ° Faceplate Speed: Constant torque 1st range 0,5 – 2,6 2nd range 1,25 – 7,2 3rd range 3,1 - 18 4th range 7,8 - 45 Constant capacity 1st range 9,0 2nd range 22,6 3rd range 56 4th range 140 Capacity of Main Drive 220 HP Max. Torque faceplate 30,000 kpm Key Speed 5,7 rev/min 1.3 Saddle Max. admissible main cutting force 30,000 kp Feed Speed longitudinal 0,3 – 120 mm / min Feed Speed transverse 0,3 – 120 mm / min Rapid Traverse Speed longitudinal 2,000 mm/ min Rapid Traverse Speed transverse 1,000 mm/ min Max. copying depth 500 mm Max. length of tool carrier measured from front edge cross slide to front edge tool carrier 700mm Tool carrier – width 60mm 35 mm Cutting Edge height of tool units 60 mm Cutting edge height of shank-type tools beeing located on the clamping table 100 mm Travel of upper tool post 820 mm 1.4 Tailstock Tailstock barrel diameter 580 mm Adjustment of the barrel 150 mm Dead Center angle 80 ° Speed of rapid traverse 2,000 mm / min Positioning speed 500 mm / min 1.5 Steady Clamping range 350 – 900 mm ...

Condition: like new (used), Year of construction: 2018, operating hours: 50 h, functionality: fully functional, Heavy Duty Elevating Crossrail Ram Type CNC Vertical Boring and Turning Machine with Hardened & Ground Box Guideways CAPACITY Maximum Turning Diameter - Ø 1,600mm Maximum Turning Height - 1,400mm Maximum Torque - 17,885 Nm Maximum Cutting Force - 3,000 kgf Maximum Workpiece Weight - 8,000 kg TABLE Table Diameter - Ø 1,250 mm Table Speed - 0.9 ~ 360 RPM Table Speed Range - Automatic 2 Step RAM HEAD Tool Size - 32 mm² Spindle Taper - ISO 7/24 #50 Ram Cross Section - 220mm² TRAVEL AND FEEDRATE X-Axis Travel (Saddle Horizontal) - 1,060mm Z-Axis Travel (Ram Vertical) - 900mm Vertical Travel of Cross Rail - 700mm Maximum X / Z-Axis Cutting Feedrate - 7,500mm / Min X / Z-Axis Rapid Feedrate - 7,500mm / Min Cross Rail Rapid Traverse - 300mm / Min ATC Type of Tool Holder - MAS BT 50 12 Tool Magazine Capacity Maximum Tool weight - 50kg MOTOR Table Motor (Cont. / 30 min) - AC 37.0 / 45.0 kW X / Z-Axis Servo Motor AC - 7.0 kW POWER SOURCE Input Power Supply - 415V / 50Hz / 3PH Power Capacity - 80 kVA DIMENSIONS AND WEIGHT Height - 5,290 mm External Width (With Chip Conveyor) - 6,760mm External Depth - 4,565m Weight - 25,800 kg STANDARD SUPPLIED MACHINE FEATURES Fanuc 32i-A Control System Table, Servo Drives And Motors 4 Jaw Independent Chuck Automatic Tool Change System Lubrication Oil Cooler Hydraulic Power Unit Automatic Lubrication System For Guides Coolant System And Wash Gun Foundation Bolts And Nuts Tool Box Through Tool Coolant Operator And Programmer Manuals Splash Guard And Safety Guard Rail X-Axis Slideway Protect Steel Cover Work Light Patrol Lamp (Red, Yellow And Green) NC Power Off Itodpfeuu Rybsx Ag Uob Chip Pan Levelling Blocks Electrical And Mechanical Manuals FANUC 32I CNC

Condition: like new (used), Year of construction: 2018, operating hours: 50 h, Heavy Duty Elevating Crossrail Ram Type CNC Vertical Boring and Turning Machine with Hardened & Ground Box Guideways CAPACITY Maximum Turning Diameter - Ø 1,600mm Maximum Turning Height - 1,400mm Maximum Torque - 17,885 Nm Maximum Cutting Force - 3,000 kgf Maximum Workpiece Weight - 8,000 kg TABLE Table Diameter - Ø 1,250 mm Table Speed - 0.9 ~ 360 RPM Table Speed Range - Automatic 2 Step RAM HEAD Tool Size - 32 mm² Spindle Taper - ISO 7/24 #50 Ram Cross Section - 220mm² TRAVEL AND FEEDRATE X-Axis Travel (Saddle Horizontal) - 1,060mm Z-Axis Travel (Ram Vertical) - 900mm Vertical Travel of Cross Rail - 700mm Maximum X / Z-Axis Cutting Feedrate - 7,500mm / Min X / Z-Axis Rapid Feedrate - 7,500mm / Min Cross Rail Rapid Traverse - 300mm / Min ATC Type of Tool Holder - MAS BT 50 12 Tool Magazine Capacity Maximum Tool weight - 50kg MOTOR Table Motor (Cont. / 30 min) - AC 37.0 / 45.0 kW X / Z-Axis Servo Motor AC - 7.0 kW POWER SOURCE Input Power Supply - 415V / 50Hz / 3PH Power Capacity - 80 kVA DIMENSIONS AND WEIGHT Height - 5,290 mm External Width (With Chip Conveyor) - 6,760mm External Depth - 4,565m Weight - 25,800 kg STANDARD SUPPLIED MACHINE FEATURES Fanuc 32i-A Control System Table, Servo Drives And Motors 4 Jaw Independent Chuck Automatic Tool Change System Lubrication Oil Cooler Itjdpfx Agsguq Txj Usb Hydraulic Power Unit Automatic Lubrication System For Guides Coolant System And Wash Gun Foundation Bolts And Nuts Tool Box Through Tool Coolant Operator And Programmer Manuals Splash Guard And Safety Guard Rail X-Axis Slideway Protect Steel Cover Work Light Patrol Lamp (Red, Yellow And Green) NC Power Off Chip Pan Levelling Blocks Electrical And Mechanical Manuals FANUC 32I CNC

Condition: excellent (used), Year of construction: 2005, FOR SALE - Emcomat 17D Lathe Year 2005 Travel in X/Z 220 / 710 mm Distance between centers - 700 mm Distance above centers - 170 mm Max. speed - 3000 rpm Spindle nose - DIN 55029 Max. drive power - 5.3 kW Quill diameter 50 mm Inner cone MT3 Quill travel 120 mm Dimensions (LxWxH) 1650 x 1060 x 1635 mm Machine weight 755 kg Iodpfx Ajxyzikjg Ujtb 3 & 4 Jaw Chuck

Condition: excellent (used), Year of construction: 2010, The XYZ 200TC is a CNC lathe known for its precision and versatility. It features a Siemens 810D Shopturn control system, a 12-station VDI turret. Key Features and Specifications: Control System: Siemens 810D Shopturn. Turret: 12-station VDI turret. Chuck: Hydraulic 200mm 3-jaw chuck. Bar Capacity: 52mm. Ijdpfx Ajxrvcvsg Uetb Swing Over Bed: 420mm. Maximum Machining Diameter: 200mm. Maximum Machining Length: 550mm. Spindle Speed: 4800 rpm. Spindle Bore: 62mm. Spindle Motor Power: 14.9kW. Other Features: Automatic tool setting arm, swarf conveyor, parts catcher, hydraulic tailstock, remote electronic handwheel, and through-tool and flood coolant. Weight: 4100kg. The XYZ 200TC is a slant-bed CNC lathe, which means the lathe bed is angled, allowing for better chip evacuation and access to the workpiece. It can be equipped with a multi-feed barfeed for automated feeding of bar stock. The machine is typically used in small to medium-sized workshops and production environments. Complete with bar feed, swarf conveyor and tooling.

Condition: excellent (used), Dugard Eagle BNC2680X CNC Lathe CNC Fagor 8055 Control Year 2007 Swing in gap 870mm Between centres 2000mm With Steady and boring attachment 15" Chuck 3.5" Spindle bore Itsdpfx Agswwlakj Uob

Condition: excellent (used), Hardinge HXL-S CNC Lathe Fagor Control Year 1998 Manuals Itsdpfx Agoxrvdge Ueb Great Condition - Fully Working with no faults. We welcome any inspections

Condition: excellent (used), Year of construction: 2020, Swing over bed 720mm, Swing over cross-slide 590mm, maximum machining diameter 481mm, maximum machining length 1275mm, bar capacity 102 mm, 12 station turret, spindle speed 2,800 rpm, Fanuc I series control, tool setter, swarf conveyor, 3 jaw chuck, Ijdpfx Agsx Uy Haj Ujtb

Condition: new, Year of construction: 2024, functionality: fully functional, HYUNDAI-WIA SE2200M CNC LATHE WITH FANUC 0IT PLUS CONTROL AND C-AXIS MACHINE CONSTRUCTION & FEATURES  8” STANDARD CHUCK SIZE.  30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY.  HIGH PERFORMANCE ROLLER LM GUIDEWAYS.  12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET - BMT45. [24 POSITION INCLUDED]  4,500 RPM HIGH POWER MAIN SPINDLE.  30 X 36 M/MIN RAPID TRAVERSE RATES - X & Z AXES.  C-AXIS MAIN SPINDLE.  ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. MACHINE CAPACITIES Swing Over the Bed Ø 600 MM Swing Over the Carriage Ø 390 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 288 MM Bar Capacity - Main Ø 65 MM MAIN SPINDLE Chuck Size 8” Ø 203 MM Spindle Bore Ø 75 MM Spindle Speed (Rpm) 4,500 RPM Motor (Max / Cont.) 15.0 / 11.0 KW Torque (Max.) 167 NM Spindle Type BELT Spindle Nose A2-6 C-Axis Indexing 360° (0.001°) FEED Travel X 210 MM Travel Z 340 MM Rapid Speed X 30 M / MIN Rapid Speed Z 36 M / MIN Slide Type ROLLER LM GUIDE TURRET Number of Tools 12 [24 POSITION INDEX] Tool Size - OD 20 MM² Tool Size - ID Ø 32 MM Indexing Time 0.15 SEC / STEP LIVE TOOL Motor (Max / Cont.) 2.75 / 1.85 KW Milling Tool Speed 6,000 RPM Torque (Max.) 26.2 NM Collet Size ER 20 - Ø 13 Type BMT45 TAILSTOCK HYDRAULIC NC TAILSTOCK (STD LIVE CENTRE) Taper MT 4 Quill Diameter Ø 56 MM Tailstock Travel 580 MM TANK CAPACITY Coolant Tank 150 L Lubricating Tank 0.7 L POWER SUPPLY Electric Power Supply 18 KVA Thickness of Power Cable OVER 16 MM² Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 2,220 X 1,610 MM Height 1,700 MM Weight 3,250 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO (RENISHAW) HYDRAULIC TYPE NC TAILSTOCK TURRET UPGRADE - 12 STATION 24 POSITION BMT45, LIVE TOOLS 6K RPM, 2.75 KW STANDARD FACTORY FITTED MACHINE OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE Iodsx Trgcepfx Ag Ustb CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) MANUAL VIEWER OPERATION MEMO PREMIUM TOOL OPERATION SCHEDULING SMART GUIDE-i (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 150 LITRES FRONT DOOR INTERLOCK FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) BACK SPIN TORQUE LIMITER TOOLBOX STANDARD TOOLING PACKAGE

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD2200 FANUC 0IT PLUS CNC LATHE MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 45° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET. ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. ▪ 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ▪ ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. Swing Over the Bed Ø 550 MM Swing Over the Carriage Ø 390 MM Maximum Turning Diameter Ø 380 MM Maximum Turning Length 565 MM Bar Capacity Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” – 203 MM 10” - [254] MM Spindle Bore Ø 76 MM Itodpfx Ajx Tqppsg Uob Spindle Speed (rpm) 4,500 RPM Motor (Max/Cont.) 18.5 / 15.0 KW Torque (Max/Cont.) 206 / 125.3 NM Spindle Type BELT Spindle Nose A2-6 FEED Travel X 215 MM Travel Z 580 MM Rapid Speed X 24 M/MIN Rapid Speed Z 30 M/MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.12 SEC / STEP TAILSTOCK Taper MT 4 Quill Diameter Ø 65 MM Quill Travel 80 MM Travel 513.7 MM TANK CAPACITY Coolant Tank 150 L Lubricating Tank 1.8 L POWER SUPPLY Electric Power Supply 23 KVA Thickness of Power Cable Over 16 MM² Voltage 415V / 50Hz / 3Ph MACHINE Floor Space (L x W) 2,925 x 1,650 MM Height 1,820 MM Weight 4,100 KGS INCLUDED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX COOLANT GUN HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD OIL SKIMMER BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD STANDARD FACTORY FITTED MACHINE OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 150 LITRES FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) MACHINE MANUALS & OPERATOR HANDBOOKS TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK - 4MT WITH STD LIVE CENTER

Condition: good (used), Year of construction: 1996, Victor Vturn-20 CNC turning centre, 10 Itedpfsyahz Iox Ag Ueb station tool holder, Fanuc Series 0-T CNC, swarf conveyor, fitted air bench, with Hydrafeed Multifeed MLI bar feeder, serial no. 2766 (1996)

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100L FANUC 0IT PLUS CNC LATHE MACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 10 STATION HIGH SPEED RIGID SERVO TURRET. 2,800 RPM 26.0 /18.5 KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. MACHINE CAPACITIES Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 500 MM Itedpfsx Tiggjx Ag Ujb Maximum Turning Length 1,300 MM Bar Capacity Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (rpm) 2,800 RPM Motor (Max/Cont.) 26.0 / 18.5 KW Torque (Max/Cont.) 1,123 / 657 NM Spindle Nose A2-11 FEED Travel X 265 MM Travel Z 1,350 MM Rapid Speed X 24 M/MIN Rapid Speed Z 30 M/MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 10 Tool Size - OD 25 MM² Tool Size - ID Ø 50 MM Indexing Time 0.15 SEC / STEP TAILSTOCK Type QUILL TYPE TAILSTOCK [PROGRAMMABLE TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM TANK CAPACITY Coolant Tank 220 L Lubricating Tank 1.8 L POWER SUPPLY Electric Power Supply 27 KVA Thickness of Power Cable Over 16 MM² Voltage 415V / 50Hz / 3Ph MACHINE Floor Space (L x W)4,405 x 1,978 MM Height 1,850 MM Weight 7,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT GUN HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO STEADY REST PREPARATION - PROGRAMMABLE CLAMPING & TRAVEL PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV STANDARD FACTORY FITTED OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE STANDARD LIVE CENTER

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100M FANUC 0IT PLUS CNC HIGH POWER TURNING CENTRE WITH HARDENED & GROUND BOX GUIDEWAYS, HIGH SPEED SERVO TURRET, C-AXIS & DRIVEN TOOLS & 12" STD CHUCK Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 740 MM Bar Capacity - Main Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (Rpm) 2,800 RPM Motor (Max. / Cont.) 26.0 / 18.5 KW Torque (Max. / Cont.) 1,123 / 657 NM Spindle Type BELT [GEARLESS] Spindle Nose A2-11 C-Axis Indexing 360° (0.001°) Travel X 265 MM Travel Z 830 MM Rapid Speed X 24 M / MIN Rapid Speed Z 30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.15 SEC / STEP LIVE TOOLS Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max. / Cont.) 70.0 / 35.4 NM Collet Size ER32 - Ø 25 Type BMT65P QUILL TYPE TAILSTOCK [PROGRAMMABLE BUILT IN TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM Tailstock Travel 830 MM TANK CAPACITY Coolant Tank200 L Lubricating Tank 1.8 L POWER SUPPLY Electrical Power Supply 27 [30 GEARLESS] KVA Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 3,885 x 1,800 MM Height 1,850 MM Weight 6,050 KGS STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) Itjdpfxex Thzvs Ag Ueb STANDARD COOLANT SYSTEM 0.5 BAR FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX MAIN SPINDLE - 2,800 RPM, 26.0 / 18.5 KW, 1123 NM BELT DRIVEN TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM FACTORY FITTED MACHINE OPTIONS CHIP BUCKET STANDARD CHIP CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD (RATED AT 60HZ SUPPLY) BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - MANUAL PROGRAMMABLE TAILSTOCK IN LIEU OF STDMACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET – BMT65P. 2,800 RPM 26.0 / 18.5 [35.0 / 25.0 GEARLESS] KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. C-AXIS MAIN SPINDLE. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET.
