Used Burkhardt for sale (11)

Condition: ready for operation (used), Year of construction: 2016, A Burkhardt + Weber heavy-duty CNC large-format machining center is available. Axis travel X/Y/Z: 1600mm/1250mm/1250mm, tool interface: SK50, pallet dimensions X/Y: 800mm/1000mm, 125mm tool pockets: 95, 225mm tool pockets: 7, 350mm tool pockets: 5, 420mm beam tool pockets: 5, coolant system capacity: 1900l, control: Siemens 840D with ShopMill, operating hours: approx. 20000h. Including coolant system with paper band filter, machine enclosure, through-spindle coolant, external coolant nozzles, chip conveyor, dual-gripper tool changer and HV-NC swivel head. Documentation available. An on-site inspection is possible. Lhjdpfxszp Rgqe Afkjk

Condition: good (used), Year of construction: 2011, functionality: fully functional, Technical details x-travel 1600 mm y-travel 1250 mm z-travel 1600 mm B-axis (table) 360.000 x 0,001° deg milling-head swivable +/- (HV) 360.000° deg pallet size: 1000 x 800 mm table load 3000 kg tool taper SK 50-B Plananlage 125 spindle turning speed range max. 8000 U/min transmission ratio 2 spindle drive (100/40 % ED) 37/50 kW feeds x/y/z -stepless 30000 mm/min max. torque on the spindle 1410/2000 (100/40 % ED) Nm total power requirement 100 kVA dimensions of the machine ca. 11555 x 7998 x 5050 mm Additional information Universal machining center 5 axes simultaneously Original purchase price: EUR 1.295.000,- First machine installation in September 2011. A geometry measurement report (dated 30. August 2025) is available. Equipment: CNC-control Siemens 840D Solution Line Separate handheld control unit, wired, Siemens HT-2 2-station pallet changer with safety light barrier 110-position tool changer (max. tool length 600 mm) with 2nd Siemens 840 D control panel Tool taper cleaning system Special cabin with oil mist extraction system Coolant tank 3.300 liters, pump pressure 4 bar/50 bar (Q1/Q2) Lodpfjzvm Hysx Afkshk Chip conveyor Workpiece measuring probe Manual books Spare part: New ball screw. Note: The machine will be sold without tool holders, tools, and clamping devices.

Condition: ready for operation (used), Year of construction: 2011, travel distance X-axis: 1,100 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 1,250 mm, controller manufacturer: SIEMENS, controller model: 840D, total height: 4,000 mm, total width: 6,000 mm, table load: 1,500 kg, spindle speed (max.): 5,500 rpm, number of slots in tool magazine: 240, tool weight: 60,000 g, product length (max.): 6,000 mm, number of axes: 4, This 4-axis Burkhardt-Weber MCX750 M2 was manufactured in 2011. It features a substantial X-axis travel of 1100 mm, Y-axis travel of 900 mm, and Z-axis travel of 1250 mm. The machine has a maximum pallet load of 1500 kg and a magazine capacity of 240 positions. The machine is linked to a Burkhardt-Weber MCX750 M2 (2011) and a pallet magazine and set-up station (12 positions + 2 positions per machine + 2 set-up stations) Lsdpfx Aezl S Uhofkohk Contact us for further details. • Maintenance contract: Yes • Utilization: 70% • Shifts: 2 • Number of revolvers/magazines: 1 • Magazine capacity: 240 positions • Pallet size: 800 x 800 mm • Drive power: 50 kW • Maximum torque: 1650 Nm • Maximum tool length: 750 mm • Maximum tool diameter: 350 mm • Rated voltage 3x 400 V • Frequency 50 1/s • Full load current 150 A • Rated current main drive 85 A • Connected load 80 kW 100 kVA • Operating voltage 400 V • Control voltage 24 DC • Frequency 50 Hz • Power 2.9 kW • Current 11.0 A • Refrigerant R134a • Filling quantity 3.0 kg Additional equipment • OPTIONAL: Tooling package (approx.): • Group 1: 700–750 tools (Ø up to 124.9 mm) • Group 2: 100–150 tools (Ø 125–224.9 mm) • Group 3: 50 tools (Ø 225–350 mm)Geometry readjusted (done by official Burkhardt-Weber)The machine is linked to a Burkhardt-Weber MCX750 M2 (2011) and a pallet magazine and set-up station (12 positions + 2 positions per machine + 2 set-up stations) Technical Specification Taper Size SK 50

Condition: used, Year of construction: 2010, x-travel 1.100 mm y-travel 900 mm z-travel 1.250 mm control SIN 840 D spindle turning speed - gearbox stage 1 20 - 1.333 1/min. spindle turning speed - gearbox stage 2 1.333 - 8.000 1/min. power capacity at 60% / 100 % load 50 / 37 KW tool taper SK50 B - axis 360 x 0,001 ° rotary table speeds infinitely variable 1 - 500 U/min feed X/Y/Z/-axis 1 - 60.000 mm/min Lhjdoymfzrepfx Afkek rapid traverse 60 m/min feed capacity X/Y/Z 17 kN numbers of pallets 2 pallet size 800 x 800 mm table load 1,50 t tool magacine with 120 Plätzen tool length - max. 600 mm tool diameter 135 mm wotkpiece diameter with 2 vacant positions 350 mm weight of tools max. 60 kg total power requirement 150,00 kW weight of the machine ca. 35,00 t dimensions of the machine ca. 11,50 x 7,40 x H4,25 m Machining center with control SIEMENS SIN840D, H/V-head and turning-operation; Pallett-changer with 2 palletts and hydr. chuck Forkardt 3KS1000, Coolant unit KNOLL; Coolant through spindle (30 l/min 50bar);

Condition: ready for operation (used), Year of construction: 2006, operating hours: 27,713 h, travel distance X-axis: 1,100 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 1,250 mm, controller manufacturer: SIEMENS, controller model: 840D, total height: 4,000 mm, total width: 6,000 mm, table load: 1,500 kg, overall weight: 12,000 kg, spindle speed (max.): 7,500 rpm, spindle motor power: 50,000 W, number of slots in tool magazine: 144, tool weight: 60,000 g, product length (max.): 6,000 mm, number of axes: 4, This 4-axis Burkhardt-Weber MCX750 M1 was manufactured in 2006. It features an impressive X-axis travel of 1100 mm, Y-axis travel of 900 mm, and Z-axis travel of 1250 mm. The machine has a maximum pallet load of 1500 kg and a magazine capacity of 144 positions. The machine is linked to a Burkhardt-Weber MCX750 M2 (2011) and a pallet magazine and set-up station (12 positions + 2 positions per machine + 2 set-up stations) Contact us for further details. • Maintenance contract: Yes • Utilization: 70% • Shifts: 2 • Pallet size: 800 x 800 mm • Drive power: 50 kW • Maximum torque: 1650 Nm • Number of revolvers/magazines: 1 • Magazine capacity: 144 positions • Maximum tool length: 750 mm • Maximum tool diameter: 350 mm • Operating hours: 27713 h Additional equipment • OPTIONAL: Tooling package • Group 1: approx. 700–750 tools (Ø up to 124.9 mm) • Group 2: approx. 100–150 tools (Ø 125–224.9 mm) • Group 3: approx. 50 tools (Ø 225–350 mm)Recent replacement of the X-spindle and the rotary seal on the IKZ (internal cooling through spindle)Geometry readjusted(done by official Burkhardt-Weber)The machine is linked to a Burkhardt-Weber MCX750 M2 (2011) and a pallet magazine and set-up station (12 positions + 2 positions per machine + 2 set-up stations) Technical Specification Lsdjzl S T Depfx Afkohk Taper Size SK 50

Condition: ready for operation (used), Year of construction: 1998, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,500 mm, table load: 20,000 kg, spindle speed (max.): 3,500 rpm, number of axes: 3, This 4-axis Burkhardt-Weber MC100 was manufactured in 1998. It features a working range with an X-axis travel of 3,000 mm, Y-axis travel of 2,500 mm, and Z-axis travel of 1,500 mm. The machine has a maximum table load capacity of 20,000 kg and a spindle speed of 3,500 RPM. If you are looking to get high-quality milling capabilities, consider the Burkhardt-Weber MC100 horizontal machining centre we have for sale. Contact us for further details. • B-axis (NC rotary table): 360° continuous • Tooling standard: High-torque configuration for large-scale milling Lhodpfjzg Il Esx Afkek • Additional notes: • Retrofitted in 2008 Technical Specification Taper Size BT 50

Condition: good (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 281008, A fully automatic round capper from ALWID is offered of the type FAVORIT 12SK The details of the machine: - Stainless steel design (frame, paneling, etc.) Lhedpfxstlrlxj Afksk - Fully automatic cap sorting and cap feed - 12 screw heads with magnetic coupling and torque setting - The machine is suitable for line integration - Output: 2,000 - 24,000 bottles / h - Bottle height: 90 - 300mm - Suitable for plastic screw caps (only one format available) Only plastic bottles with plastic screw caps were processed on the machine. The machine is currently not in use and can be viewed by arrangement at the production site in Thuringia. The machine layout including dimensions is attached as a PDF document.

Condition: good (used), Year of construction: 2008, functionality: fully functional, A fully automatic round capper from ALWID is offered of the type FAVORIT 4SK The details of the machine: Lhedpfxstlttfo Afkjk - Stainless steel design (frame, paneling, etc.) - Fully automatic cap sorting and cap feed - 4 screwing heads with magnetic coupling and torque setting - The machine is suitable for line integration - Output: 2,000 - 8,000 bottles / h - Bottle height: 90 - 300mm - Suitable for plastic screw caps (three formats available) The machine was used to process glass and plastic bottles with plastic screw caps. The machine is currently not in use and can be viewed at the production site in Thuringia by arrangement. The machine layout including dimensions is attached as a PDF document.

Year of construction: 1995, condition: good (used), functionality: fully functional, For sale is a bottle erecting machine made by Engler including a stainless steel bottle bunker. There are also various format parts and a blower. The machine is currently not in use and can be viewed by arrangement at the production site in Thuringia. Formats: 300ml, 400ml, 500ml, 875ml for PE or PET bottles. Diameter: 2.10m; Outlet height: approx. 0.98m; Lhjdpfx Afotmqafjkek Bunker height: 1.12m to 1.75m

Condition: used, Year of construction: 2008, functionality: fully functional, machine/vehicle number: 261007, For sale is a fully automatic lid pressing machine from ALWID, model ADR. Machine details: - Stainless steel design (frame, covers, etc.) - Fully automatic closure sorting (disc sorter) - Closure feeding via adjustable chute (spindle) - Suitable for integration into automated lines (infeed and accumulation sensors available) - Output: 2,000 - 9,000 jars/hour - Jar height: 80 - 280 mm Ledpotltp Aofx Afkjhk - Suitable for plastic snap-on lids (press-on closure) and tin snap-on lids (Pano closure) Please note: There is a crack in the housing of the disc sorter, as shown in the attached photo. The machine is currently not in operation and can be inspected by arrangement at the production site in Thuringia. The machine layout, including dimensions, is attached as a PDF document.

Condition: used, Load resistance -Load resistance for: bridge cranes -Serial number/picking number: 2089442-1 Lsdpfxedpatle Afkshk -Weight: 340 kg
