Horizontal machining center

Makino A99

Condition: used, Year of construction: 2000, x-travel 1000 mm y-travel 1000 mm z-travel 950 mm Control FANUC Pro-3 feed X/Y/Z/-axis 1 - 50.000 mm/min rapid traverse X/Y/Z 50,00 m/min tool taper HSK-A 100 Lsdpfxsydflxs Afksaf turning speeds 20 - 12.000 U/min spindle drive 25 / 30 kW torque milling spindle 420 Nm spindle diameter in front bearing 110 mm B - axis 360 x 0,001 ° size of pallet 2x 800 x 800 mm table load capacity 1.800 kg dimension of workpiece 1.000 x 950 mm workpiece height max. 1.000 mm tool piece magazine with 188 tool length - max. 475 mm tool diameter 320 mm weight of tools max. 20,00 kg total power requirement 65,00 kW weight of the machine ca. 30,00 t dimensions of the machine ca. 8,00 x 5,30 x H3,50 m Horizontal machining center with FANUC Porfessional 3 control, NC rotary table, el. handwheel, chip conveyor, coolant filter KNOLL VRF 450/2300, through-spindle coolant, 188-station tool magazine. New spindle in 2023 Machine can be inspected under power.

Condition: used, Technical details: x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm turning speeds: 35-10.000 1/min spindle: 37 / 30 kW Ljdpfswix Hhox Afksaf max. torque on the spindle: 525 / 206 Nm Tool bore: BT 50 rapid traverse: 60 m/min tool change unit: 160 Pos. size of pallet: 500 X 500 mm control: MAZATROL 640M Nexus c-axis: 0,001° x 360.000 workpiece weight: 1.000 kg workpiece height max.: 1.000 mm interference area: 900 mm 2 pcs. horizontal machining centers (HCN 6000-II + HCN 6000, 2005), interlinked with pallet pool (16 pallets) MAZAK FMS, 2 pallet changer, chipconveyor, coolant device with internal coolant supply, *

Condition: used, Year of construction: 2005, functionality: fully functional, machine/vehicle number: 175849, travel distance X-axis: 1,740 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 840 mm, controller model: PC Fusion 640 M, total height: 4,450 mm, total length: 3,300 mm, total width: 2,900 mm, overall weight: 11,500 kg, spindle speed (max.): 12,000 rpm, 3-Axis Machining Center MAZAK - VTC 300C-II Manufacturer: MAZAK Model: VTC 300C-II Control: PC Fusion 640M Year of manufacture: 2005 Internal coolant supply (IKZ): 15 bar Table length: 2000 mm Table width: 760 mm Feed rate X-axis: 36,000 mm/min Feed rate Y-axis: 36,000 mm/min Feed rate Z-axis: 36,000 mm/min Tool holder: SK 40 Spindle power: 15 kW Spindle speed: 12,000 rpm Tool changer: 30 positions Lsdeyanuhspfx Afkjaf Internal coolant: Yes Number of controlled axes: 3 Chip conveyor: Yes Cooling unit: Yes Length: 4450 mm Width: 3300 mm Height: 2900 mm Can be inspected under power.

Condition: used, Year of construction: 2023, controller manufacturer: Siemens, controller model: 840Dsl, _____ Description: Year of manuf. : 2023 Control : Siemens 840Dsl Speed : 24000 rpm Movement X/Y/Z : 2600/1700/950 mm Tool holder : HSK-A63 Spindle: Technology:Swivelhead with Motospindle Speed:24.000 rpm Power (max.):15 kW Torque (max.):14,3 Nm Laedpfxey E Ebqs Afkof Taper:HSK-A63 A-Axis:+/- 120° C-Axis:270° In general: Toolmagazine:18 stations Clampingsurface:2.350 x 1.700 mm Rapid travers in X/Y/Z:80/80/60 m/min Equipment/Accessory: Workpiecemeasurement:Touch probe, m&h RWP 20.50 Toolmeasurement:Laser, Hexagon Toolbreakagecontrol:Probe, m&h TS 35.20 Setup operations:Electronic Handwheel 3D-Extruder:CEAD S25 Granulatedryer-/conveyor:Vismec Further Accessory:Spindlechiller

Condition: good (used), Year of construction: 2012, 750mm Swing, 500mm max. machining diameter, 1300mm max turning length, 3000rpm main spindle, 65mm bar capacity, 8,000rpm milling 20kW, C axis 0.001 degrees, Y axis - 90/+120mm, 40 station ATC, , milling speed 4,000rpm, 30kW spindle motors, FANUC 31i control, 3 Jaw Power Chuck, Swarf Conveyor, Coolant, tool setter, parts catcher, barfeed unit. Ljdjxqyg Nepfx Afkoaf

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 900 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 980 mm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 50 m/min, rotational speed (max.): 8,000 rpm, spindle nose: ISO 50, number of spindles: 240, CNC MSX 701 III Travels (X/Y/Z axes): 900 / 800 / 980 mm Pallet working surface: 630 x 630 mm Pallet load capacity: 1,200 kg High-torque spindle max speed: 8,000 rpm Rapid traverse rate (X, Y, Z): 50 m/min Tool magazine capacity: 240 tools Spindle motor power (30 min / continuous): 37 / 30 kW Machine Configuration: 240-position RACK tool magazine Spindle taper DIN 69871 – ISO 50 Tool breakage detection in magazine Index table with 1° indexing FASTEMS interface, model MLS-MD Spindle speed 8,000 rpm – 37/30 kW TOOL IC SYSTEM BALLUFF interface No. 600 macro variables No. 1 load monitor No. 200 storable programs No. 512 tool life management No. 999 tool offsets Lasdpfjykpg Hjx Afkjf No. 48 workpiece coordinate systems Data server + ATA card Mori Seiki scraper-type chip conveyor with drum filter MARPOSS application, model MIDA T25G, with E86N radio transmission system META pumping unit, model M 50/50, partial filtration system, 50 bar high pressure COMET drilled pallet Instruction manuals and CE Declaration of Conformity

Condition: good (used), Year of construction: 2012, Ref. -No.: 10558 Manufacturer: YOU JI Type: HMC 1200 BP Year of construction: 2012 Type of control: CNC-Steuerung Control: FANUC Series 18i-MB Storage location: Halberstadt Country of origin: Taiwan X-Travel: 1800 mm Y-Travel: 1500 mm Z-Travel: 1360 + 990 mm B-Axis: 360 ° W-Axis: 700 mm Table Dimensions (Lengthxwidth): 1200 x 1400 mm Table Load: 5.000 kg Max. Tool Weight: 25 kg Max. Tool Length: 400 mm Max. Tool Diameter: 125 mm Spindle Speed: 30 - 3.500 RPM Numbers Of Pallets: 2 Lasdsxxpbxopfx Afkjf Further information: 4-axis simultaneous machining IKZ (internal spindle cooling) AKZ (external spindle cooling) Synchronized walking (rigid thread cutting) Renishaw RMP60 workpiece probe (radio) Number of pallet changers for automatic pallet change: 2 Size: 1200 x 1400 mm Tool magazine, number of tools: 60 The machine is currently in production and can be viewed by appointment.

Condition: new, Year of construction: 2025, control type: CNC control, degree of automation: automatic, pipe diameter (max.): 51 mm, pipe length (max.): 3,000 mm, tube wall thickness (max.): 3 mm, bending angle (max.): 190 °, bending radius (max.): 250 mm, number of axes: 5, Equipment: CE marking, emergency stop, foot remote control, STANDARD EQUIPMENT • 3 Sets of Dies (1 set of rolling die and 2 sets of bending dies, or 3 sets of bending dies, as per required dimensions) • 5-axis servo control (Y, B, C, H, V) • Servo Motorized Feed Axis • Servo Motorized Rotation Axis • Servo Motorized Bending Axis • Servo Motorized H and V Axes • 21” TFT Touchscreen Mobile CNC Control Unit • Rolling capability • 3D Bending Simulation • Collision Simulation • Daily, Weekly, and Monthly Total Operating Status Reports • Calculation of Workpiece Material Length • Calculation of Estimated Bending Time • X-Y-Z to Y-B-C Conversion • Emergency Stop Foot Pedal with Mobile Function • Remote Assistance • Mandrel Bending and Mandrel-less Bending • Safety Plate behind Bending Head • Hydraulic Clamping • Hydraulic Mandrel • Hydraulic Support • Hydraulic Linear Guide System • Hydraulic Chuck Clamp • Safety Lock on Electrical Cabinet and Keyed Panel Lock • Electrical System Cooling Unit • Overload Protection • Detailed Operation Report Automatically Sent OPTIONAL EQUIPMENT (Not Included in Price) • Additional Sets of Dies • Safety Mat (750 x 1000 mm) Ledpfexircajx Afkoaf • Safety Mat (1000 x 1500 mm) • Hydraulic Oil Heater • Additional Mandrel Length (up to 6 m) – per meter • Ball Mandrel and Wiper Die • Automatic Mandrel Lubrication System (for suitable tube diameters) • Hydraulic Oil Cooler CAPACITY MB-51 CNC/5 AXIS Maximum Capacity mm Ø51x3 mm Maximum Bending Radius mm 250 mm Maximum Bending Angle ° 190° Hydraulic Pressure bar 50–200 Working Length mm 3000 Rotation Tolerances ±0.1 Bending Speed kW Variable LxWxH mm 6350x1400x1600 Weight kg 3750

Condition: reconditioned (used), Year of construction: 2011, functionality: fully functional, travel distance X-axis: 2,100 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 24 m/min, rapid traverse Y-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, controller manufacturer: FANUC, controller model: FANUC 31i-A, workpiece height (max.): 1,725 mm, workpiece diameter (max.): 2,300 mm, workpiece weight (max.): 3,000 kg, rotary table diameter: 1,250 mm, spindle speed (min.): 20 rpm, spindle speed (max.): 6,000 rpm, coolant supply: 70 bar, spindle motor power: 26 W, spindle nose: ISO 50, number of slots in tool magazine: 120, tool length: 650 mm, tool diameter: 300 mm, tool weight: 25,000 g, input voltage: 400 V, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, USED ​​horizontal machining center with pallet changer and 120 tools. Ledpexlcivsfx Afkjaf

Condition: good (used), Year of construction: 2000, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 880 mm, nominal power (apparent): 61 kVA, controller manufacturer: Mazatrol, controller model: 640M, workpiece height (max.): 1,000 mm, workpiece diameter (max.): 900 mm, workpiece weight (max.): 1,000 kg, total height: 3,200 mm, total length: 6,100 mm, total width: 3,500 mm, table width: 500 mm, table length: 500 mm, overall weight: 18,000 kg, spindle speed (min.): 35 rpm, spindle speed (max.): 7,000 rpm, spindle motor power: 26,000 W, Equipment: chip conveyor, Dear Sir or Madam, Ledpfx Ajxf T Txefksaf we are offering you a used CNC horizontal machining center "MAZAK" in good condition. Please refer to the attached file for details.
