Mesh welders for sale
Identified location: Ashburn (US) (Edit)
|
1
The line is dedicated to produce mesh sheets.
Line wire feeding off spools.
Cross wire feeding pre-cut.
F9tepr9gw more
|
|
3
VM-2400/4-8 BB-Basic wire mesh machine is ideal solution for rebar shops and factory of reinforcing mesh with not large capacity. In addition to the low price, the advantageof this machine is inexpensive and easy maintenance, as well as the possibility of designing a machine according to your technical characteristics.
TECHNICAL DATA:
• Line wire diameter: Ø 4 ÷ 8 mm
• Cross wire diameter: Ø 4 ÷ 8 mm
• Line wire pitch: 150, 200 mm
• Cross wire pitch: 150, 200 mm (fixed)
• No. of electrodes: 16... more
|
|
Mesh welding line EVG
It is possible to produce grid maps with virtually any geometry, apertures and holes, as well as combinations of armature diameters. The equipment is equipped with a control that optimizes welding points.
Diameter of longitudinal bars of a mesh from coil with a measured rod: 6÷16 мм - 18÷20 мм.
Diameter of transverse grid rods from coils: 6÷16 мм.
Length of the longitudinal bars of the mesh: 300÷12000 мм.
Length of transverse rods: 300÷4000 мм.
Mesh settings Dimensi... more
|
|
Machine is designed for making panel welded meshes, width
2150 mm, length 6000 mm with distance between line wires 150
mm, with distance of cross wire from 25 to 300 mm and wire
diameter from 4 to 8 mm.
Basic parts of the machine:
1. Pay-off for line wire.
2. Straitening unit.
3. Line wire pooling unit with loop.
4. Welding unit.
5. Shear.
6. Turner with panel’s stacker.
Nm9fn
7. Energy electrical cabinet.
8. Control cabinet.
Machine is new ! more
|
|
1
Working width: max. 2.438,4 mm
Jcdbqzn
Wire diameter range: 3,0 - 6,35 mm
Welding capacity: 7 x 200 kVA = 1400 kVA total
Line wire pitches: 50,200,300 mm (2", 4", 6")
Cross wire pitch: variable from 50 mm
Cross wire length: max. 2438 mm, min. 1219 mm
Number of wleding presses: 25 (6kN)
Panel width: max. 2.438,4 mm (8ft)
Panel length: max. 6.096 mm (20 ft)
Line wires: off coil
Cross wires: off coil
Wire coil max. weight: 2.000 Kg. more
|
|
3
MESH WELDING MACHINE SCHLATTER MG 208 - 2900 mm
Wire mesh width: max. 2900 mm / min. 1000 mm
Wire mesh length: max. 6000 mm / min. 2500 mm
Line wire spacing: 100, 150, 200 mm
Cross wire spacing: 50 - 300 mm
Line wire diamter: 4 - 10 mm
Cross wire diamter: 4 - 10 mm
Number of presses: 24 pieces
Number of line wires: max. 24 pieces
- manual line wire feeding unit
- MG 24.4/8C welding portal
K7snkb89
- Cross wire feeder QF8
- Control Cabinet MP SIEMENS SIMATIC S7 more
|
|
Ideal PGS 140/12
Mesh Welder, Grid welder
Year of manufacture 1995
Max. Usable width 1 = 1400mm
Cross wire diameter: 2.00-8.00 mm
Line wire diameter: 2.00-8.00 mm
Rated power at 50% ED 63kVa
Bvp82uda
Connection power kVa165
Photoelectric sensor
Mounted In Enclosed Wire Cage Safety Structure, Grid housing more
|
|
Wire mesh welding line VM 2400-BB/3-8 has advanced technology for production welded wire mesh working with pre-cut wire. Working range Ø 3 to Ø 8 mm. Mesh welding line VM 2400-BB/3-8 is ideal for the production of reinforcement mesh panels.
TECHNICAL DATA:
Tkhevpk
• Line wire diameter: Ø 3 ÷ 8 mm
• Cross wire diameter: Ø 3 ÷ 8 mm
• Line wire pitch: 100, 150 mm
• Cross wire pitch: 100, 150 mm (software regulation)
• Mesh panel width: 2400 mm
• Mesh panel length (min-max): 2 ÷ 6 m
• Stroke (weldi... more
|
|
Mesh welding line EVG model QC7
Construction year - 1998.
Partially refurbished in 2014.
Technical details -
line wire Ø pre-cut min: 5 mm
line wire Ø pre-cut max: 14 mm
cross wire Ø from spool min: 5 mm
cross wire Ø from spool max: 14 mm
strokes (cross wire) min / max: 100
mesh width min: 950 mm
mesh width max: 2500 mm
no. of line wires max: 49
line wire feeding: prestraightened bars
cross wire feeding: prestraightened bars
line wire distance min: 50 mm
cross wire distance mi... more
|
|
5
Technical Details :
– Year – 1990/2012
– Model – 8/SR12
Bfjkt70nzb
– Speed – max. 70 tact/min.
– range of opening mesh space – 25×25 – 100×100 mm
– Wire range – 1,5 – 5 mm
– Number of transformers – 4 x 100 kw
– Mesh width – max. 1200 m
– Mesh lenght – 1000 – 3000 mm
On line was made new control panel and transformers in 2012 more
|
|
|
|
1
Working width: max. 1.200 mm
Xsersmbp
Wire diameter range: 3,0 - 6,0 mm
Consist of:
Line wire feeder: LV 2 Schlatter
Cross wire feeder: QFE
6 Transformers: 2 new
9 line wires: new
9 Electrodes: new
PLC-Controller: SIEMENS S 5 more
|
|
1
EVG TS 10-30 TL/5 Lattice Girder Line
Manufacturer: EVG
Pay-off Model: TL/5
Welder Model: TS 10-30
Technical Data:
Height 70 - 300 mm
Bct7gwqa7h
Lower Chords: 4 - 12 mm
Upper Chords: 5 - 12 mm
Truss Wires 3.5 - 6 mm (smooth wire)
Lengths: 12 m, automatic stacking Max
Max. Speed: 18 m/min (90 welds/min)
Pay-off wire coil weight max: 2000 KG
Power: 455 KVA
Motor: 41.9 Kw, 380 v, 50 Hz
Size: 6500 mm X 1500 mm X 2400 mm; 9,000 kg
The machine is in a very good condition. Las... more
|
|
1
Continous feeding of the line and cross wires from spools for the production of mesh sheets and/or rolls.
Pcskofxd2 more
|
|
5
Truss welding machine PBM-2000 for the production of single lattice girders and mesh spacer.
PBM-2000 machine working with coils wires. Machine are driven by servo electro motor.
-Automatic bending unit
-Automatic packing unit
• Wire diameter range: 3-5 mm
• Spacer height: 50-200 mm
• Angle of bending: 30-80°
• Number of electrodes: 2
• Machine control: PLC
• Transformer power: 35 kVA
• Transformer number: 2
• Working mode: One by one/Group/All at once
• Adding line wire: Coil feeder
• Adding ... more
|
|
1. Schlatter model MG303
2. Construction year – 1997.
3. LINE wires - Min/Max wire diam. - 4,0 – 10mm
4. Number of line wires - 34
5. CROSS wires - Min/Max wire diam. - 4,0 - 10mm
6. Max. width of mesh panels 3.400mm
Ndaxd
Please contact us for more details.... Thank you! more
|
|
8
Technical Details :
- Mesh width - up to 2400 mm
- Mesh length - 3000 - 6000 mm
- Line wire diameter - 4-10 mm
- Cross wire diameter - 4-10 mm
Nnzyl
- Line wire spacing - 100mm/150mm/200mm/250mm
- Cross wire spacing - 50mm - 250mm
- Max. line wires - 24
- Speed - up tp 80 strokes/min.
- Total installed power - 1200 kva ( transformers )
- Other motors - 90 kw
- The line can be renewed at customer's request more
|
|
STARWELD GR is a high performance mesh welding plant for the production of electro-fused grating. A big product range can be achieved through its easy adjustments. Special designs can be adopted according to the customer needs (special technical specifications or special products).
Products can be used for stairs, floorings, catwalks, platforms, fencing, etc.
Features:
Feeding from coil or pre-straightened and cut bearing bars
Bfbhxy8mqm
Automatic or manual feeding of flat steel bearing bars
A... more
|
|
6
IDEAL VPS 646 Double & flat bar meshes
Mesh welding line
Mesh type: double bar length max. 2500 mm
flat bar max. length 2450 mm
Mesh length: double bar lebgth 800-2400 mm
flat bar length 800-2400 mm
Bctsnjnina
Diameter: ø 5-6 mm
More information? Please contact us sales team!
spare parts: weparto more
|
|
1
Works from cold rolled low-carbon steel wires, wires ribbed or smooth, truss wires smooth
Tu9o7jdys more
|
|
9
VMP-2500 welded mesh machine is designed to produce a welded mesh for fence panel.
Line wire diameter: Ø 3 ÷ 5 mm
Cross wire diameter: Ø 3 ÷ 5 mm
Wire type: galwanized or black wire
Line wire pitch: 50 mm (fixed)
Cross wire pitch: 25-400 mm (software regulation)
Mesh panel width: 2500 mm
Mesh panel length (min-max): 800-2500 mm
Stg9yw
Feeding of line wires: Bar (Feeding in with automatic loading magazine for longitudinal wires)
Feeding of cross wires: Bar (Feeding with cross wire magazine)
Rem... more
|
|
EVG Mesh Welding Line; Model GRS
currently producing 3D fence mesh
welding width: 3760mm
welding length: max. 3000mm (adjustable)
cross wire spacing: min. 12.5mm steplessly adjustable
line wire spacing: min. 25mm steplessly adjustable
cross wire dia. min. 2mm – max. 6mm
Icjzqilx
line wire dia. min. 2mm
max. 8mm
speed: 120 SPM – cross wire; payoff turntable; cross wire payoff system; line wire guide/pull unit; line wire straighteners; welder; mesh shear; (2) Japan Robot mesh turner-stacker ... more
|
|
Machine is designed to produce two spacers in the same time,
with double stroke (pitch) of 150 mm, with heights from 70 to
220 mm, diameter of line wires from 3.5 to 5 mm and diagonal
wire diameter from 3.5 to 4 mm.
The main parts of machine:
1. Pay-off
2. Straightening system
3. Line wire pooling unit with loop.
4. The system of diagonal wire bending
5. Welding unit
6. Output table with bending unit
Jvbnry
7. Energy electrical cabinet
8. Control cabinet more
|
|
STARWELD PC is a high performance mesh welding line for the production of medium & heavy weight wire or reinforcing mesh panels from pre-straightened and pre-cut bars. It is a more compact-sized and thus lower cost welding line compared to the lines processing wires from coils; this makes STARWELD PC a suitable line when there is smaller space available. Design is made in accordance to the specific project & mesh type parameters. PRATTO can supply all the necessary auxiliary equipment. Products ... more
|
|
2
Construction year – 1992
Bkkukekb
Technical Details :
Weld width / mesh width: 2400 / 3050mm
Number of transformers / electrodes: 12/48
Power per transformer: 100KVA
Min.electrode distance 50mm
Cross wire ø: 5-10mm
Longitudinal wire ø: 5-10mm
Mesh length: 2500 - 8100mm depending on the turner
max. width / length of turner: 2500 / 6200mm (turn) / 8100mm stacking
Note:
System complete with vibrating table, threader, roller feed, mat extractor and turner
Control type:
S5-115U (threader and... more
|
|
1
Schlatter Fully automatic Roll Take-up Machine,
Tu9ivant7
Type MP24A8, with a complete new control cabinet more
|
|
Wire mesh welding line VM 2400-CC/3-8 has advanced technology for production welded wire mesh working with line & cross wires from coils. Working range Ø 3 to Ø 8 mm. Mesh welding line VM 2400-CC/3-8 is ideal for the production of mesh panels, mesh in rolls or both.
TECHNICAL DATA:
Line wire diameter: Ø 3 ÷ 8 mm
Cross wire diameter: Ø 3 ÷ 8 mm
Line wire pitch: 100, 150 mm
Cross wire pitch: 100, 150 mm (software regulation)
Mesh panel width: 2400 mm
Mesh panel length (min-max): 2 ÷ 6 m
Mesh ... more
|
|
10
Electrowelded mesh welding line AWM Italy
COMPLETELLY AUTOMATIC ( Line and Cross wires from coils )
Brand - AWM Italy
Year - 2004.
Max. length of panels - 6.000 mm
Min. length of panels - 2.000 mm
Max. width of panels - 2.400 mm
Mix. width of panels - 1.000 mm
Max. number of longitudial wires - 24
Diam. of longitudinal wires - 4 - 8mm
Diam. of cross wires - 4 - 8mm
Min. distance between longitudinal wires - 100mm
B7qmjgo
Min. distance between cross wires - 50mm
Max. distance b... more
|
|
9
Technical Details :
1. Mesh welding line EVG GE 12/102
- Max. Width mesh - 2.400 mm
- Max. Length mesh - 6.000 ( 10.0000 )
- Wire diameter range - 4 - 12 mm
Beedskwg3r
- Power - 850 KW
- Max. speed - 120 strokes / min.
2. Straightening and cutting machine EVG
- Run out table - 6 m
- Wire diameter range - 4 - 8 mm
- Speed - up to 2,7 m/sec.
- Power - 58 KW
3. Straightening and cutting machine EVG
- Run out table - 6 m
- Wire diameter range - 6 - 12 mm
- Speed - up to 2 m/sec.
- Power - 78 K... more
|
|
STARWELD PO is a high performance mesh welding line for the production of medium & heavy weight wire or reinforcing mesh panels. It is a line appropriate for big production needs. Design is made in accordance to the specific project & mesh type parameters – e.g. there can be a rolling mechanism for the machine to produce rolls too if so desired. PRATTO can supply all the necessary auxiliary equipment. Products can be used in the construction industry. They are also used for shelves, grids, cages... more
|
|
5
SPECIAL Mesh welding line type EVG HFBE
Beqzh7xmzy
With this special mesh welding line it is possible to produce grid maps with virtually any geometry, apertures and holes, as well as combinations of armature diameters. The equipment is equipped with a control that optimizes welding points.
- Diameter of longitudinal bars of a mesh from coil with a measured rod:
6 x 16 mm - 18x20 mm.
- Diameter of transverse grid rods from coils: 6 x 16 mm
- Length of the longitudinal bars of the mesh... more
|
|
6
1 production line for welded mesh ViDa (Italy) - 1995 - mesh panel width : max. 2400mm - mesh panel length max. 6000mm - wire dia. range approx. 5 - 12mm - 6 transformers - Line wires from coils and cross wires from pre-cut bars - with stacker
Gydv2utf more
|
|
7
Technical details :
Lattice gireder line
Manufacturer: VIDA
Pay-off Model: Mechanical
Sv2wxdgd
Year Manufactured: 1992
Height 70 - 200 mm
Lower Chords: 4 - 8 mm
Upper Chords: 5 - 9 mm
Truss Wires 3.5 - 6 mm (smooth wire)
Lengths: 12 m
Max. Speed: 8 m/min
Pay-off wire coil weight max: 2000 KG
Welding Power: 300 KVA more
|
|
Starweld PE
STARWELD PE is a high performance mesh welding line for the production of fine & light mesh in rolls or rolls & sheets. The mechanisms are designed in a way that the produced mesh is of high quality, even when the wire processed is of a very small diameter. Products can be used for cages, fencing, etc.
Features:
Line & cross wire feeding from coil
Edge trimming
Mesh fabric slitting
Vczmtqmh
Fully or semi automatic system for mesh cutting, rolling & ejecting
Excellent mesh accura... more
|
|
6
Welding line of purely mechanical design for processing fine wires for cage mesh, protective screens, wire plaster netting, screed mesh, etc. The wire mesh welder runs with wires which are fed from spools. Within a certain diameter range it is possible to weld two cross wires simultaneously. For processing bright, annealed or galvanised wire. The serrated feed roller ensures maximum precision during mesh production.
Oinbp32o more
|
|
15
Lattice girder line made by AWM (Italy)
Construction year - 2004.
Diameter of UPPER longitudinal wires - 6-12mm, smooth or ribbed
Diameter of LOWER longitudinal wires - 6-12mm, smooth or ribbed
Diameter of cross (zig-zag) wires - 4-6 mm, smooth
Cross wire pitch - 20mm fixed
Lattice girder height - variable form 100 to 250mm
Lower rods distance - 100mm
Lattice girder cut - 200 mm (step)
Nnhkb
Length of finished lattice girder - 12 meters more
|
|
7
Girder Welder
Manufacturer: DATZ
Pay-off Model: Mechanical
Year Manufactured: 1980
2q290a
Height: 70 - 250 mm
Lower Chords: 4 - 8 mm
Upper Chords: 5 - 8 mm
Truss Wires : 3.5 - 5 mm (smooth wire)
Lengths: 12 m
Max. Speed: 12 m/min (60 welds/min)
Pay-off wire coil weight max: 2000 KG
Welding Power: 420 KVA more
|
|
1
Welding transformer 140 KVA - SCHLATTER
Field of application Einsatz in Gitterschweissmaschinen Marke SCHLATTER
Type: SCHLATTER TEW 140 /10,5 -7,1
Voltage 400 V /10,5 -7,1 V
Frequency 50-60 Hz
Xnvpx3ip
Vergleichsartikel SCHLATTER 11.01.777
More products in our B2B e-Shop weparto.com more
|
|
14
Mesh welding line for 3D fence panels
Mul728
Brand - BUCH (Spain)
Model- SM 2500
Can produce 3D fence 0,6m to 2,5m height, 2m to 2,5m length, max wire diameter 5 mm.
Please contact us for more info. Thank you! more
|
|
6
Techical Details :
- Working Speed - 80 cycles
- Total Power for welding - 1200 kw
- Total Power for motors - 15 kw
- Transformer power - 400 kw
- Width of panels - 1000 - 2500 mm
- Length of panels - 3000 - 6000 mm
Beygrr9cwa
- longitudinal wire dia. - 4 - 10 mm
- Cross wire dia - 4 - 10 mm
- Pitch of the variable mesh - from 100x100 till 250x250
- Number of longitudinal wire - 4 - 24 more
|
|
8
Mesh welding line EVG model KFR
Construction year – 2006.
Detailed description:
Longitudinal and transverse pitch: 6.35 mm; 12.7 mm; 19.05 mm; 25.4 mm; 31.75 mm; 38.1 mm; 44.45 mm; 50.8 mm
Square and rectangular cells.
The maximum width of the grid 2120.9 mm
The minimum width of the grid is 1016 mm
Maximum roll diameter 600 mm
Maximum roll weight 400 kg Wire diameter (both longitudinal and transverse) 0.5 ... 1.4 mm Wire quality - black baked or clean galvanized
Working speed - 160 t... more
|
|
10
- Year of construction 1983 (overhauled on 2006)
- Max working width 2750 mm (=max. length of cross wire)
- Max welding width 2700 mm (max. distance between
Nh9v9
outside line wires)
- Line wire spacing 50 mm and multiples
- Cross wire spacing Min 50 m. - Max 300 mm.
- Line wire diameters 4.0 - 12.0 mm. pulled from spools
- Cross wire diameter 3.0 - 10.0 mm. pulled from spool
- Max welding capacity 26 (total of wire diameters at line
wire spacing 100mm)
- Voltage (three... more
|
|
10
Mesh line EVG model GZF
Construction year – 2009.
Technical specifications:
Maximum mesh width: 2100 mm
Maximum welding width: 2000 mm
80cwdh
Longitudinal wire pitch: 25 mm and multiple
Maximum number of longitudinal rods: 81
Transverse wire pitch: 12.5 - 100 mm with an interval of 12.5 mm and 18.75 mm; 100 -200 mm with an interval of 12.5 mm
Diameter of longitudinal wire: 1.0 - 3.0 mm
The diameter of the transverse wire: 1.0 - 3.0 mm
Maximum working speed: 160 transverse rods per mi... more
|
|
7
Technical Details :
Weld width / mesh width: 2400 / 3050mm
Number of transformers / electrodes: 12/48
Power per transformer: 100KVA
Min.electrode distance 50mm
Cross wire ø: 5-10mm
Longitudinal wire ø: 5-10mm
Mesh length: 2500 - 8100mm depending on the turner
max. width / length of turner: 2500 / 6200mm (turn) / 8100mm stacking
Accessories: div specific E-parts
Note: System complete with vibrating table, threader, roller feed, mat extractor and turner
Control type: S5-115U (threader and inverter... more
|
|
8
Mesh welding line EVG model G45/102
Year - 1967.
Kxey2wmn
Line and cross wires from spools
Min/max wire diam. - 4-10 mm
Min Line and cross wire spacing - 50 mm
Without payoff more
|
|
14
Mes wedling line EVG (Austria)
Model G45/102
max. working width: 2750mm
max. welding width: 2600mm
cross + longitudinal wire dia. range: 3 to 9/10mm
line wire + cross wire from coils (auto cross wire)
Bcri7jnygm
cross wire spacings: 50 to 400mm steplessly adjustable
line wire spacings: 50 to 300mm; max. welding cap.: 19mm
strokes per min: 75 to 90
6 x 100 KVA transformers; 380V-3-50cycle power; 100kw power; line consists of: LAR power loop feed, wire tangle unit, line wire straighteners, me... more
|
|
6
Welding mesh line PITTINI (complete)
Specification:
The line have the longitudinal and transverse wires power to coil
Wire diameter is 4mm to 10mm
Maximum number of longitudinal wire is 24
Distance between longitudinal wires is 100mm-200mm
Distance between the crossing wires is 50mm- 250mm
Mesh width max is 2500 mm
The maximum number of welds per minute 130
Mlu3z
Rated power for each transformer 100 Kva( 12 pcs transformer)
Total nominal power kW 1200 kVA + 30
Year of construction i... more
|
|
5
AWM Welded Wire Mesh Plant:
8zqcnoyzq
AWM (Italy) Semi-Automatic Welded Wire Mesh Line; Model Easynet S; max. width: 2400mm, min.-max. wire dia. long + cross: 5 to 12mm, long-cross wire straightened + pre-cut, max # of long. wires: 24, pitch between long + cross wires: 100-150-200mm, 12 x 150KVA transformers, stacker & turner; Fully Automatic Special Welded Wire Mesh Line:max. width: 630mm (24"), min.-max. wire dia. 3-5mm, cross + long. fed from coil, max. long. wires: 12, (6) six AC 50KVA tra... more
|
|
6
Mesh welding line SCHLATTER PG28
Tech details -
1. Schlatter model MG28
2. Construction year – 1997 but FULLY refurbished in 2007.
3. LINE wires (FROM PRECUT BARS) - Min/Max wire diam. - 4,0 – 10mm
4. The line wire feeding system is LVB1/32
9qgysrap3
5. CROSS wires (FROM COIL) - Min/Max wire diam. - 4,0 - 10mm
6. Max. width of mesh panels 2.700mm
7. Max. length of mesh panels 6.000mm
8. Mesh pull-out device - MAZ4
9. Machine is dismantled
10. Machine WAS in working condition prior to disman... more
|
|
6
Mesh welding line SUPERFLEX 4
Min max wire diam. - 6-25mm
Max mesh panel width - 3650 mm
Max mesh panel ,length - 1,5 - 14 meters
Line wire spacing - 75mm - 150mm
Electrical drive features - 2400 KVA
Line wire feed - 8 spools ( with guide rack )
Cross wire feed - 2 spools with payoff station
Ebevs0j
- Line wire straightener
- Edge trim and slittingt shear
- mesh cuttof shear
- Sheet stacker more
|
|
4
Lattice girder line SMEI (Italy) made in 2004. and completelly refurbished.
Please see attached document or contact us for more details.
Bbe32ahe7n more
|
|
|
Didn't find what you were looking for? Please contact our partners for this category :
Dealer for Mesh welders
Dealer for Mesh welders
