Cylindrical grinder

Okamoto OGM 350 UNC

Year of construction: 2007, condition: ready for operation (used), - USED - 8-AXIS CNC LATHE WITH MILLING HEAD, DOWN TURRET HEAD AND COUNTER SPINDLE Njdpfx Aheyy Thzsuecw MAX ROTATING DIAMETER: 660 mm MAX TURNING LENGTH: 1495 mm MAX TURNING DIAMETER: 660 mm BAR CAPACITY: 65 - 65 mm SPINDLE: 35-5000 rpm; 22 kW; 254 mm COUNTER SPINDLE: 35-5000 rpm; 18,5 kW; 254 mm HEAD: CAPTO C6 ; -30°+195° ; 15-12000 rpm; 18,5 kW X-AXIS TRAVEL: 580 mm X2-AXIS TRAVEL: 150 mm Y-AXIS TRAVEL: 160 mm Z-AXIS TRAVEL: 1545 mm Z2-AXIS TRAVEL: 1490 mm B-AXIS TRAVEL: 1550 mm RAPID FEEDS X-Y-Z: 38 - 26 - 38 m/min TURRET HEAD: 9 POS TOOL MAGAZINE: CHAIN-TYPE ; 80 POS HIGH PRESSURE COOLANT: 18 Bar CONTROL UNIT: MAZATROL MATRIX WEIGHT: 11800 Kg OVERALL DIMENSIONS: 5090 x 3270 x 2830 mm ACCESSORIES: SWARF CONVEYOR ; PAPER FILTER ; TOOL SETTER

Condition: good (used), Magnetic table 455 x 170 mm digital display water tank Ncjdjtu Il Tjpfx Ahuow Honing device Wet sanding device

Condition: good (used), Year of construction: 2008, travel distance X-axis: 4,230 mm, travel distance Y-axis: 1,950 mm, travel distance Z-axis: 750 mm, table length: 4,000 mm, table width: 1,250 mm, table load: 11,000 kg, Portal milling machine KAO MING - KMC 4000 SV-H Double guideway two box way construction Head changer for Multi-Face machining off larger compontents ATC tool changer for Horizontal and vertical milling head swivabel Distance table spindle nose    213 - 1093 mm Distance table spindle center  130 -.mm Indexing Horizontal head 5 Degrees x 72 positions HeidenHain iTNC530 with HR410 handwheel Spindle torq 1018 Nm ISO50 Universal Huron type milling head X - Travel: 4230mm Y - Travel: 1950mm Z - Travel: 750mm Distance between column:1500mm Table Length: 4000mm Table Width: 1250mm Table load: 11000 Feed rate X-Axis: 12000mm/min. Feed rate Y-Axis: 15000mm/min. Feed rate Z-Axis: 12000mm/min. Spindle Taper: 50ISO/Bt/Mk Power on spindle: 26kW Speeds / ranges: 4400Rpm ATC / revolver: 30 Ncedpfx Ahsxf E Tweusw Chip conveyor: Yes Coolantsystem: Yes Length: 10100mm Width: 4500mm Height: 4250mm Weight: 30000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 30214501, turning length: 2,000 mm, total length: 12,000 mm, WFL Millturn M60/2000 WORKING RANGE center distance mm 2000 swing over bed, turning diameter mm 690 MAIN DRIVE AC-drive with 2 gear steps drive power 100% duty cycle kW 40 max. speed min-1 3300 max. torque at the spindle 100% duty cycle Nm 1830 TAILSTOCK quill diameter mm 140 quill travel mm 160 quill force (adjustable) N 3500-31000 quill with installed live center MK 5 TOOL HOLDER (single tool holder, turning-boring-milling unit) AC-drive drive power 100% duty cycle kW 30 speed range max. min-1 6000 max. torque at the spindle 100% duty cycle Nm 315 Ncedou Hl R Tepfx Ahujw travel vertical to the X/Z-plane (Y-axis) mm 300[-125/+175] pivot capability of the milling spindle (B-axis) ° -110/+90 spindle head acc. DIN 69893 HSK-A100 spindle diameter in front bearing mm 100 DIMENSIONS length (max. tool magazine) m 11 width/height m 3,9/3,3

Condition: good (used), Year of construction: 2018, operating hours: 7,819 h, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 720 mm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 50 m/min, STANDARD TECHNICAL SPECIFICATION – MAZAK CAPABILITIES Table work surface (length): 2,500 mm Table work surface (width): 820 mm Longitudinal (crosswise) X-axis travel: 2,000 mm Column (crosswise) Y-axis travel: 800 mm Spindle head (vertical movement) Z-axis: 720 mm Minimum distance from spindle nose to top of table: 140 mm Maximum distance from spindle nose to top of table: 860 mm Table load capacity (uniform load): 1,700 kgf Spindle head rotation (B-axis): ± 110° SPINDLE HEAD Spindle taper: 7/24 taper, No. 40 Maximum spindle speed (standard): 18,000 min⁻¹ Minimum spindle speed (standard): 35 min⁻¹ Main spindle motor output (continuous rating): 26.0 kW FEED RATES Rapid traverse (X-axis): 50 m/min Rapid traverse (Y-axis): 50 m/min Rapid traverse (Z-axis): 50 m/min TABLE Table length: 2,500 mm Table width: 820 mm T-slot width: 18 mm Number of T-slots: 7 Distance between T-slot centers: 100 mm Height from machine base to table surface: 870 mm AUTOMATIC TOOL CHANGER Tool storage capacity (standard): 30 Tool storage capacity (optional): 48 Tool selection: Mazatrol memory random access type Tool shank: CAT-40 / MAS BT-40 Max. tool diameter with adjacent tools: 80 mm Max. tool diameter without adjacent tools: 130 mm Max. tool weight (with holder & taper pin): 8 kgf Max. total tool magazine weight: 150 kgf Max. tool length (from gauge line): 350 mm Tool change time (chip-to-chip): 4.7 s MACHINE DIMENSIONS Machine height (from floor): 3,355 mm Machine width: 4,250 mm Machine depth: 4,046 mm Machine weight: 14,000 kg OTHER Power supply voltage: AC380/400/415V ±10% Power supply frequency: 50/60 Hz ±1 Compressed air pressure: 0.5–0.9 MPa Compressed air capacity: 260 l/min Coolant tank capacity: 450 L STANDARD MACHINE EQUIPMENT – MAZAK GENERAL MACHINE OPTIONS Foundation kit (base bolts & plates) One set of adjusting tools Work area lighting Power transformer for European market USB I/F (1 port) MANUALS, DOCUMENTATION One set of documentation (CD) SPINDLE SPEED Spindle speed: 18,000 rpm (#40) MACHINE FRAME COLOR Mazak standard color (F white / S black) Nsdpfx Aoya Hngehujcw SAFETY, HEALTH Global safety measures Work area door interlock with locking switch Full machine enclosure Full-cover chip and coolant protection TOOL MAGAZINE 30-position tool magazine COOLING SYSTEMS Complete cooling system HIGH PERFORMANCE/HIGH PRESSURE COOLANT Through-spindle coolant (5 bar, 71 PSI) PRODUCTION AUTOMATION SYSTEMS Automatic ON/OFF + warm-up MEASURING SYSTEMS Automatic tool length measurement & tool breakage detection POSITIONING SYSTEM Absolute positioning system CHIP CONVEYOR Preparation for chip conveyor (left side) NC CONTROL UNIT – 15 Functions 19" color LCD (touch screen) 3-D coordinate conversion Position sensor B) Shape compensation for rotary axes EIA/ISO code input function (standard) Background tool path check LAN connection High smoothing control Mazak 2D software (shape compensation) Mazak 3D high-speed software package Mazak thread tapping / pre-tapping Tornado (Mazatrol) Mazatrol SmoothX CNC Movable control panel SD memory I/F (1 slot) + USB I/F (1 slot) Smooth standard software

Condition: used, Year of construction: 2004, grinding diameter 250 mm grinding length 650 mm centre height 125 mm Maschine wird mit Wartung und neuer Geometrie verkauft Betriebsstunden bisher 12260 Reitstock mit Feinverstellung Ncjdpfxoywntyj Ahujw Schleifspindelstock schwenkbar mit 5° Hirtverzahnung Papierbandfilter Marposs Messeinrichtung Innenschleifeinrichtung

Condition: used, Year of construction: 2008, max. wheel diameter 700 mm max. module 10 (18) min. module 1 table diameter 530 mm Table speed max. 350 1/min Distance of shafts 50 - 680 0 workpiece weight 4.000 kg Axial travel 1.000 mm tangential adjustment 300 mm Njdeyv Ipfepfx Ahuscw pivoting angle + / - 45 Grad power capacity 32 kW spindle turning speed range 3.500 - 12.000 U/min tool diameter 320 mm total power requirement 80 kW weight of the machine ca. 25,00 t

Condition: used, Year of construction: 2000, grinding diameter 360 mm grinding length 1600 mm centre height 180 mm internal diameter 0 mm grinding depth 0 mm swing diameter 0 mm total power requirement 40 kW weight of the machine ca. 10000 kg dimensions of the machine ca. m K A R S T E N S (Germany) Universal “CNC” - Cylindrical Internal and Face Grinding Machine also for grinding excentric and cam profiles and polygons and even suitable for Threadgrinding Model K 51 – 1500 Year 2000 Serial No. 99 093 Height of centres 180 mm Distance between centres / grinding length 1,700/1.600 mm Cylindrical Grinding: Grinding Ø, approx. 5 - 360 mm Grinding wheel: Ø x width x bore 500 x 100 x 127 mm Grinding spindle speeds (35 m/s / 50 m/s) 1.900 / 2.200 rpm Drives of cyl./int/face spindle units 7.5/4,0/7,5 kW Grinding Wheelhead: 3 Positions = B-Axis Head swivels in 3 positions = 240 ° / 17,5 degree X-axis adjustment in total 360 mm Increments for infeed 0,001 – 125 mm Workpiece wheelhead = C-Axis Spindle speeds steplessly adjustable 10 – 1.000 rpm Spindle taper / Spindle bore MK 4 / 24 mm Table speeds 0,01 – 10.000 mm/min Total electrical load 40 kW - 400 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features: * Very versatile CNC Grinding Machine for almost all grinding purposes like External/Internal and Face grinding as well as for Excentric- / Cam- / Polygone Grinding and even for Thread Grinding * Free programmable CNC System make BWO Model 900 C with many grinding cycles and for easy input of the work-parameters. Graphic support, any many more features. Ncodpfx Ahot Hw Rdeusw * 3 position wheelhead with 3 Grinding spindles as B-Axis, one with measuring feeler (Z - Position) * MOVOMATIC Measuring Device Model ES 400 for diameter control, Probe head CR 60, to be mounted on table. * MPM Automatic Grinding wheel balancing Device, Dressing devices with diamantflees mounted on table surface and also motorized Diamantroll Profile dresser on table (for thread profiles, etc.) * Workhead and tailstock can be easily moved on table by air cushion. Hydraulic quill on tailstock. * No Coolant Device available ! Condition : Good to very good. Machine can be inspected under power. Delivery : Ex stock as inspected. Payment : Net, after conclusion of contract.

Condition: like new (used), Year of construction: 2022, OEM – laser marker / engraving laser (diode pumped YAG-laser) The laser beam source was used for some time to generate plasma as part of a scientific project. Overall, however, it only has few operation time. Due to the short pulse length, this laser is also very suitable as an engraving laser Ncedpfspyg N Aex Ahujw Laser source of the complete system is a 10 Watt diode-pumped YAG-laser with 1064 nm wavelength. The working area is 100 x 100 mm, up to 300 x 300 mm is available as an option. No external cooling is necessary. Input-voltage: 110...240 VAC / 50 Hz. Applications are laser engraving and material ablation. The control software is installed on a PC, optionally also a Laptop can be used. The language of the software can be choosen (German, English). The laser is prepared for an integration into a ‘higher level system’, but can also be used as a 'stand alone' system. In this case interfaces for Interlock, emergency stop, laser control etc. are available. We are happy to support the customer according to his requirements.

Condition: good (used), Year of construction: 2008, functionality: fully functional, Okuma Multus B300-W 6-axis turning and milling center - Okuma OSP P200L - Year 2008 - Cutting time: 10,500 h - H1 milling spindle: 6,000 rpm - Main spindle: 3,800 rpm, Rota NC 315-86 - Counter spindle: 5,000 rpm - ATC 60 system HSKA-63 (60 tools) - Geometry: very good - Marpos tool sensor Nodpfxsyg Rf No Ahujcw
