Used Guideway Grinding Machine for sale (83,970)

Condition: ready for operation (used), Year of construction: 1989, CNC Universal Cylindrical Grinding Machine TOS Model: BUA 25 x 1000 Year of manufacture: 1989 Completely overhauled and equipped with a new control in 2007, has only been operated occasionally since then Swing diameter: 280 mm Maximum grinding diameter: 250 mm Grinding length: 1000 mm Fitted with a new 2-axis CNC Teach-In control KAVALIR K 51/2 Ball screw spindles, axis drives, and measuring systems on both axes Grinding wheel: 400 x 40 x 127 mm Workpiece spindle speed steplessly adjustable from 30 to 150 rpm Grinding wheel speed: 2036 – 2556 rpm Workpiece spindle head swivels 90 degrees Table swivels plus/minus 9 degrees Internal grinding device Flanges Belt filter system Nwjdsx Icb Tjpfx Aa Eer Weight: 5 tons Complete set of accessories Price: EUR 7,500.— plus VAT, ex location

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 1315/451, Completely overhauled: Mechanics, geometry, hydraulics, and electrical parts (checked and/or replaced) Wheelhead: Disassembled, parts cleaned, worn or defective components replaced, motor overhauled, bearings replaced, belts replaced, spindle disassembled, seals and O-rings replaced, adjustments made. Newly painted. Workhead: Disassembled, parts cleaned, worn or defective components replaced, motor overhauled, belts replaced. New spindle bearings. Newly painted. Tailstock: Disassembled, inspected, overhauled. Hydraulics: Disassembled, motor checked, hoses replaced, defective and worn parts replaced. Hydraulic block checked. X-axis: Disassembled, all worn parts such as O-rings, seals, segments, etc. replaced, hydraulic piston overhauled, table ground. Z-axis: Disassembled, table ground, worn or defective parts replaced, hydraulic piston overhauled, newly painted. Electrical cabinet: Completely checked, various relays replaced. Paintwork: Colors: White RAL 9003 and Grey RAL 7011 Geometry according to manufacturer's protocol. Various accessories checked and cleaned. Origin: CH Voltage: 380 / 50 / 3 Net weight: approx. 2,200 kg Customs tariff number: 8460.2920 TECHNICAL SPECIFICATIONS Nominal distance between centers: 600 mm Max. distance between centers (with extended headstock): 750 mm Center height, standard: 125 mm Center height with interchangeable pads for heads: 175–250 mm Max. workpiece diameter (125 mm center height): 250 mm Max. workpiece diameter with interchangeable pads: 350–500 mm Swiveling range of table in each direction: 10° Max. grinding length for flat surfaces (max. width = 200 mm): 900 mm Continuously variable hydraulic table speed: up to approx. 6 m/min Nwedpfx Aaow U Ry Nj Eer Table reversal delay: 0–5 sec Grinding wheel for external grinding, diameter - width - bore: 400x50x127 mm Grinding wheel for flat surface grinding: 250x13x76 mm Wheelhead spindle speed: 1,500/1,700/2,200/3,600 rpm Wheelhead swiveling range: 270°, with indexing every 90° Vertical travel of wheelhead, center height: 125–350 mm Transverse travel of wheelhead: 285 mm Hydraulic rapid traverse stroke: 40 mm Intermittent infeed of wheel by table reversal: 0.001–0.03 mm/dia Continuous infeed for plunge grinding: 0–0.9 mm/dia Micrometric infeed stop, by division: 0.001 mm/dia Workhead swiveling range: 360° Workhead spindle speed, stepless: normal/special: 20–400 / 10–400 rpm Internal taper of workhead/tailstock: Morse 5/3 Wheelhead motor: approx. 4 HP All technical specifications are given without obligation and subject to errors or omissions.

Condition: used, Grinding wheel diameter max.: 225 mm grinding wheel diameter max.: 225 mm Largest tool diameter: 300 mm Smallest tool diameter: 80 mm Tool width max.: 230 mm tool width max.: 230 mm Nwedpfjlf H Tgsx Aa Ejr Weinig Rondamat 929 knife grinding machine for producing profile knives. Production from a straight blank or regrinding of used knives using a template. * Incl. new coolant pump.

Condition: excellent (used), Year of construction: 1996, grinding length 600 mm Nodsx Haryepfx Aa Eswr grinding width 350 mm total power requirement 7,5 kW

Condition: good (used), For sale is an external cylindrical grinding machine of the brand VEB Werkzeugmaschinenbau and of the type SU 200/1x800 Nsdpfxjrdf Hge Aa Ejwr The machine is fully functional and ready for immediate use Technical data Grinding diameter: 200 mm Sanding length: 800 mm orbital diameter: approx. 160 mm Headstock speed: 200-1000 1/min Headstock: MK2 Grinding wheel diameter: approx 330 mm Table size: 900 x 200 mm Dimension: 3050x1300x1430 Weight: 4.6 tons On request, loading and transport (Europe-wide) can be organized for an extra charge. Prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website

Condition: good (used), Year of construction: 1984, Used TOS KAMENICEK model BUC63A x 3000 Universal cylindrical grinding machine. YEAR OF MANUFACTURE: 1984. MACHINE FORMERLY INSTALLED AT ROLLS ROYCE PLC IN DERBY UK. IMMEDIATELY FOR SALE AND NOW LOCATED IN BELGUIM WHERE IT CAN BE INSPECTED. SPECIFICATION Max Swing 630 mm Distance between centres 3000 mm Workhead swivel – towards wheelhead only 90 deg. mm Work spindle bored taper No. 6 M.T. Length of stroke of tailstock barrel 70 mm Tailstock barrel taper No. 6 M.T. Spindle nose clamping Din 55021 Swivelling of wheelhead + 30 deg – 10 deg Length of adjustment by re-circulating ball screw 290 mm Additional length of adjustment 250 mm Length of rapid feed 90 mm Length of infeed setting per each rev. of handwheel, measured on work diameter 0.5 mm Nwodpfoh U Rznsx Aa Ejr Grinding wheel dia. X width X bore 750 x 80 x 305 mm Min. dia. of worn grinding wheel 570 mm Max. face width of grinding wheel 125 mm Rate of table traverse – steplessly variable 0.5-0.6 m/min Table traverse per 1 rev of handwheel 8 mm Swivelling of table +/- 5 deg. Max. permissible weight of work between centres 2500 kg Max. permissible weight of workpiece in chuck with overhang. (including weight of chuck) 150 kg Wheel spindle speeds (2) 840,970 rpm Grinding wheel surface speed 33 m/sec Work spindle speeds – int. var. in 2 ranges 8-50, 50-315 rpm Drive – total power required rated 31 kva Output of workhead motor 3 kw Output of wheelhead motor Electrics 15 kw 415V ,3Ph,50Hz Equipped with:- Additional wheel flanges, coolant system with clarifier and splash guards. FEATURES AND EQUIPMENT – Swivel Round Internal Grinding Attachment

Condition: ready for operation (used), Year of construction: 2000, Immediately available ex location: Horizontal Surface Grinding Machine ABA Type ECOLINE L 1006 Year of manufacture: 2000 Control: Abamatic – 1 Operator Table: 1000 x 600 mm Table load capacity: 1000 kg Grinding length: 1000 mm Grinding width: 700 mm Installation height: 700 mm Grinding wheel: 400 x 100 x 127 mm Grinding wheel speed steplessly adjustable up to 2600 rpm Nsdpfjx Iccwsx Aa Ejwr Drive power: 11 kW Grinding wheel speed steplessly adjustable up to 2600 rpm Feed rates, X axis: steplessly adjustable up to 10,000 mm/min Feed rates, Z axis: steplessly adjustable up to 10,000 mm/min Feed rates, Y axis: steplessly adjustable up to 10,000 mm/min Magnetic chuck Belt filter system Weight: 6 t Price: EUR 9,500 – plus VAT, ex foundation

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 6360.16.65, Country of manufacture: Switzerland Nedpew Ucxqsfx Aa Ejwr Voltage: 380/400/50/3 Net weight: 1350 kg Customs tariff number: 8460.1920 Dimensions: 200/120/160 cm TECHNICAL SPECIFICATIONS Maximum saddle travel: 530 x 220 mm Maximum grinding surface: 520 x 230 mm Table clamping surface: 600 x 200 mm Table speeds Longitudinal, standard operation: 0-25 m/min With slow feed: 5/10 mm - 8 m/min Cross feed: 0-6 m/min Vertical travel by hand: 330 mm Rapid travel by motor: 290 mm Rapid feed rate: 460 mm/min Max. distance between table and spindle axis: 412 mm Vertical feed movement Handwheel, 1 division: 0.01 mm Micrometric device, 1 division: 0.001 mm Automatic: 0.001-0.099 mm With pulse button: 0.001 mm Cross feed movement Handwheel, 1 division: 0.01 mm Micrometric device: 0.001 mm Grinding wheel Diameter x width x bore: 225x25x50/51 mm Standard RPM: 2700 rpm With variable speed drive: 3700-1300 rpm All technical data are provided without guarantee and are subject to possible errors or omissions.

Condition: used, Manual planer knife sharpener Weinig Rondamat 931 for sharpening and grinding profile knives and straight planer knives in the planer head using templates. Nsdpsw Au Rcofx Aa Eswr Max. tool width: about 230 mm Grinding speed: infinitely adjustable Mandrel: 30 / 35 / 40 / 50 / 60 mm

Condition: excellent (used), Description to follow! Nsdpfxox Harto Aa Eowr

Condition: used, Year of construction: 1999, grinding diameter 300 mm grinding length 500 mm centre height 150 mm Nodexzu Aaspfx Aa Ejwr digital readout 2 Achs Mitutoyo Ka Counte Knoll PF 70 magnetic chuck ja type Schild nicht auffindbar

Condition: excellent (used), machine/vehicle number: 31.207.011, Manufacturing origin Swiss Voltage 380/50/3 Netweight 3150 kg Dimensions 400x185x175cm Custom position 8460 TECHNICAL DATA Distance between centres 1000 mm Centres height 175 mm Wheelhead Wheel : diameter/width/bore 500 / 80 (100) / 203.0 mm Max width of wheel 80(100) mm Spindle speeds 1220,1360,1530 min-1 Table maximal travel 1100 mm Table, speed (variator, progressively adjustable) 0.02 to 6.0 m/min Workpiece headstock Swivel 360° speed (variator,progressive adjust) 20 min-1 to 400 min-1 Wheelhead motor 6 HP Nwjdoiwtm Sepfx Aa Ejr Total power 7 HP Max diameter of workpiece 249 mm Tailstock internal taper Morse 3 errors and omissions excepted-data given without obligation

Condition: used, 2 belt cross sander Heesemann MFA 8 for intermediate sanding of varnish and sanding of wood panels and other workpieces. working width: 1300 mm Clearance height: max. approx. 140 mm Njdpfxoxr N I Es Aa Ejwr clearance height: max. approx. 140 mm Aggregate 1: cross-section Unit 1: Electronic print bar Aggregate 2: longitudinal grinding Unit 2: Cross-section Unit 3: longitudinal grind Unit 4: cleaning brush

Condition: good (used), Year of construction: 1999, operating hours: 16,000 h, functionality: fully functional, machine/vehicle number: 650341, Year 1999 with Fanuc 18 TB – 3 axes XZB Marposs E30/E20 Country of manufacture: Switzerland Voltage: 400V/50Hz/3ph Dimensions: 410 x 220 x 190 cm Net machine weight: 5,000 kg TECHNICAL SPECIFICATIONS CNC control: Fanuc 18TB Intermediate Section Fixed intermediate section: grinding head R Swiveling section with manual indexing 2.5°: R / RS / UR / URS -210° to +30° Swiveling section with automatic indexing 2.5°: R / RS / UR / URS -210° to +30° B axis, resolution 0.1'': R / RS / UR / URS -210° to +30° Standard workhead Swivel range: -10° to (+100°) Spindle speed (continuous): 6 – 600 rpm Internal taper: MT5 Reducing sleeve: MT5/MT4 Short external taper fitting: DIN 55026 / Size 5 Permissible torque: 160 Nm Guaranteed roundness for chuck work Standard: 0.5 µm Option: 0.2 µm Workpiece weight between centers: 150 kg Tailstock Taper fitting: MT4 Quill stroke: 50 mm / 2° Option: fine adjustment with correction (Ø +/- 150 µm) Grinding wheel data (max. speed) Diameter 300: 27 m/s Diameter 400: 35 m/s Diameter 500: 45 m/s UR Grinding Head Power: 9.2 kW / 12.5 HP Wheel mounting, left max.: Ø 500 x 80 mm Right, additional max.: Ø 400 x 63 mm Internal grinding device: spindle HJN 828 Lower table (Z axis) Distance between centers: 1000 mm Max. travel: 1150 mm Max. speed: 15 m/min Max. resolution: 0.1 µm Upper table Distance between centers: 1000 mm / swivel 0° to 9° Grinding carriage (X axis) Max. travel: 320 mm Max. speed: 7.5 m/min Max. resolution: 0.1 µm Nedpfx Aow T Tb Hea Eewr Pneumatics Min. connection: 6 bar Air consumption: approx. 0.6 m³/h Coolant Max. connection pressure: 3 bar Required space (version 1000): 3600 x 2000 mm Unless otherwise stated, technical data is provided without engagement and may be subject to errors or omissions.

Condition: used, engine: 2,2 kW Spindle length per side: 175 mm · Spindle diameter max.: 35 mm spindle diameter: 35 mm Nodpelfdxusfx Aa Ejwr Carstens bench grinder for grinding and polishing wood and other materials with two spindles. · Dimensions LxWxH approx.: 1,750 x 700 x 1,100 mm · Further technical data on request

Condition: refurbished (used), Year of construction: 2025, operating hours: 36 h, functionality: fully functional, machine/vehicle number: 1024-54, Country of Manufacture: Switzerland Voltage: 380/50/3 Net weight: approx. 1600 kg Customs tariff: 8460.2920 Dimensions: 235 x 155 x 145 cm TECHNICAL FEATURES: MAIN DIMENSIONS: Centre height: 100 mm Distance between centres: 400 mm LONGITUDINAL SLIDE: Max travel: 420 mm Minimum automatic travel: 1 mm Table feed speed: 100–3500 mm/min Overtravel delay: 0–5 sec. Maximum table swivel (400/650 mm): 30°/15° CROSS SLIDE: Max travel: 170 mm Rapid traverse: 30 mm Plunge depth (diameter): 1.9 mm Feed rate 1: 0.03–1.5 mm/min Feed rate 2: 0.02–0.3 mm/min Plunge feed per impulse: 0.0005–0.025 mm WHEELHEAD: Grinding wheel (diameter x width x bore): 350 x 32 x 127 mm Nwsdpfx Aow T Sc Nea Esr Drive power: 3 kW Peripheral speed: 30 m/s Spindle speeds: 1600/1975/2200 rpm Manual stroke: 120 mm Swivel to right: 15°/30° Optional wheel guard for wheel set max width: 50 mm WORKHEAD: Swivel range: 0°–90° Spindle speeds: 80/175/380/800 rpm Internal taper: Morse 4 Collet type: W-20 Drive power: 0.5 kW Maximum workpiece weight: 20 kg Load for in-the-air grinding: 12 Nm Optional stepless drive speed range I: 30–300 rpm Optional stepless drive speed range II: 120–1200 rpm TAILSTOCK: Internal taper: Morse 2 Quill travel: 20 mm GUARANTEED WORKING ACCURACY: Generator straightness: Between centres: 400 mm Measured over 400 mm: 0.002 mm Between centres: 650 mm Measured over 650 mm: 0.003 mm Roundness accuracy for in-the-air grinding: 0.0004 mm CONNECTION VALUES: Power consumption: max. 8 kVA Permissible voltage variation: –15% / +10% Permissible frequency variation: ±3% Compressed air: 5 bar All technical specifications are given without obligation and subject to errors or omissions.

Condition: used, sanding belt: 300 x 1010 mm engine: 2,2 kW Drum sander or belt sander KED II HDZ for sanding wood and other materials. · Dimensions LxWxH approx.: 1,050 x 600 x 1,000 mm Nwedpfx Aaslfdxxj Ejr

Condition: refurbished (used), Year of construction: 2025, operating hours: 50 h, machine/vehicle number: 3018-04, Country of manufacture: Switzerland Voltage: 380/50/3 Net weight: 3100 kg Overall dimensions: 230x155x170 cm Installed power: 13 kVA Customs tariff position: 8460.2920 TECHNICAL SPECIFICATIONS MAIN DIMENSIONS Distance between centers: 650 mm Grinding capacity SpW+bs: -80 Stroke: 700 LONGITUDINAL SLIDE Max stroke: SpW+50 mm Minimum automatic feed: 1.5 mm Speed: 50-5500 mm/min Reversal delay: 0-6 sec Maximum table swivel: 12°/10°/8.5°/6° Pneumatic relief for table and workhead CROSS SLIDE Max stroke: 300 mm Rapid traverse: 60 mm Plunge grinding depth in diameter: 3.4 mm Feed 1: 0.012-6 mm/min Feed 2: 0.012-1.2 mm/min Feed per pulse: 0.001-0.05 mm GRINDING WHEEL HEADSTOCK Left-side wheel, external grinding: 400x80x127 mm Drive power: 5.5 kW Peripheral speed: 35 m/s RPM: 1670/2110 min-1 Internal grinding device for belt-driven spindles, including drive unit: 1.5 kW WORKHEAD Swivel range: 0-90° Continuously variable RPM: 30-1000 min-1 Internal taper: Morse 5 Collets: W-25 Drive power: 0.55 kW Maximum workpiece weight between centers: 130 kg Grinding load between centers: 100 Nm TAILSTOCK Internal taper: Morse 3 Quill stroke: 35 mm Fine adjustment for cylindricity correction: ± 40 μm Nwodpfx Aajw T Sd Te Esr TECHNICAL CHARACTERISTICS: GUARANTEED WORKING ACCURACY Straightness of the generator over 630 mm: 0.003 mm Roundness during chuck grinding: 0.0003 mm CONNECTION VALUES Maximum absorbed power: 13 kVA Maximum permitted voltage fluctuation: -15%/+10% Maximum permitted frequency variation: ± 3% Required compressed air pressure: 5 bar Unless otherwise stated or in case of error or omission, these technical details are provided without engagement.

Condition: used, Year of construction: 2017, Double-sided (top/bottom) grinding machine Stähle Hess Saturn Roto Finish for fine grinding of window scantlings or other woods. Two units, each with several surface-grinding, rotating tools, which also rotate around their own axis with the grinding unit and thus achieve cutting of the wood fibers with easy adjustment of the wood type. Application e.g. as a grinding machine after a planing machine in a window production facility. Nwodpfjxwtwusx Aa Ejr Technical specifications: see PDF Working width max.: 240 mm Max. wood height: 140 mm Wood height max.: 140 mm

Condition: refurbished (used), machine/vehicle number: 2257, Manufacturing origin France Voltage 380/50/3 Netweight 3000 kg Custom position 8460.29 20 Dimensions 2400x1550 mm TECHNICAL DATA Diameter capacity 80 mm Type 2HA : 120 mm Maximum infeed grinding length 200 mm Maximum throughfeed grinding length (with normal-type guides) 300 mm Grinding wheel : -diameter 400 mm -maximum width 200 mm -bore 203.2 mm Driving wheel : -diameter 254 mm -width 200 mm -bore 127 mm Main drive motor 11-22 kW Driving wheel motor 1,1 kW Driving wheel speed 10 – 200 U/Min Standard accessories : 1 flange with grinding wheel 1 flange with driving wheel Nwedjfnm Iiepfx Aa Esr 1 workpiece support bridge 1 set of shims for workpiece support -Hydraulic dressing and trueing device for grinding and driving wheels -Variable speed drive of driving wheel -Electrical equipment for 3x380 v, 50 Hz -Main drive motor, 11 kW -Ammeter for main drive motor Starter keys and operating manual errors and omissions excepted data given without obligation.

Condition: used, · Spindle diameter: 45/35mm Clamping length per side approx.: 450 mm Double sanding block Langbein with left/right mode for woodworking. Nwedpfxelfdxms Aa Esr

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 1845/455, Completely refurbished: Mechanics, geometry, hydraulics, and electrical components Wheelhead Disassembly, cleaning of parts, replacement of worn and defective components, motor overhaul, replacement of bearings, replacement of belts, spindle disassembly, replacement of seals and O-rings, plus adjustment. New paintwork. Workhead Disassembly, cleaning of parts, replacement of worn and defective components, motor replacement, replacement of belts. New spindle bearings. New paintwork. Tailstock Disassembly, cleaning of parts, replacement of worn and defective components, motor replacement, replacement of belts. New spindle bearings. New paintwork. Internal grinding attachment Disassembly, cleaning of parts, replacement of worn and defective components, installation of the support and geometry alignment. New paintwork. Hydraulics Disassembly, motor replacement, hose replacement, defective and worn parts replaced. Hydraulic block checked. X-Axis Nwedpfx Aajxt Ilfo Ejr Disassembly, replacement of worn items such as O-rings, seals, rings, etc., overhaul of hydraulic piston, regrinding of tables. Z-Axis Disassembly, regrinding of tables, replacement of worn and defective parts, overhaul of hydraulic piston, scraping of V and flat guides. New paintwork. Measuring system Digital 2-axis display included. Electrical cabinet Replacement of motor contactors and relay controls. New wiring. New variable speed drive (frequency inverter) for the workhead. TECHNICAL SPECIFICATIONS Distance between centers: 1500 mm Distance between centers (workhead to tailstock overhang): 1650 mm Center height, standard: 125 mm Center height with riser blocks: 225/250 mm Maximum grinding diameter: Ø 250 mm Maximum grinding diameter with riser blocks: 450/500 mm Table Usable surface: 2060 x 140 mm Max. length and width for surface grinding: 1750 x 200 mm Longitudinal travel, manual or hydraulic: 1750 mm Manual table movement, 1 handwheel revolution – coarse: 20.006 mm Manual table movement, 1 handwheel revolution – fine: 2.457 mm Table speed, continuously via hydraulics: up to 6 m/min Table swivelling: 6° Stop and return: 0–5 sec. Workspindle Workpiece speeds, continuously variable (electric): 20–400 rpm Swivelling: 360° Workspindle taper (internal): MT5 Tailstock Internal taper, tailstock spindle: MT3 Spindle retraction, manual or hydraulic: 30 mm Diamond dresser taper (internal): MT0 Universal grinding head Cross slide travel for wheel: 285 mm Rapid traverse for wheel slide, front and rear: 40 mm Grinding spindle speeds: 1500 – 1700 – 2200 – 3600 rpm Vertical grinding spindle movement, center heights: 125–330 mm Max. wheel for cylindrical grinding: 400 x 50 x 127 mm Max. wheel for surface grinding: 250 x 20 x 76 mm Head swivelling with locking at every 90°: 270° Wheel feed 1 division of the micrometer drum: 0.005 mm/Ø Automatic wheel feed, max.: 0.9 mm/Ø Motors Grinding spindle motor: 2,900 rpm / 4.0 hp Workspindle motor: 3,000 rpm / 2.0 hp Coolant pump motor: 2,850 rpm / 0.12 hp Internal grinding attachment Bore: 70 mm Internal grinding spindle speed Ø70 mm: 14,000 rpm Internal grinding spindle speed Ø50 mm: 21,000 rpm Subject to error or omission, the technical information is provided without obligation.

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 027.0400/067, CNC CYLINDRICAL GRINDER STUDER S-33 CNC Year: 2007 - Fanuc 21i-TB 1 External Grinding Spindle Country of Origin: Switzerland Voltage: 380/50/3 Net machine weight: 4,000 kg TECHNICAL SPECIFICATIONS Distance between centers: 600 mm Center height: 175 mm Maximum workpiece weight: 80 kg Longitudinal Slide Z Max. travel: 800 – 1,150 mm Travel speed: 0.001 to 10,000 mm/min (early 2000’s model: 0.001-5,000 mm/min) Resolution: 0.0001 mm Cross Slide X Max. travel: 285 mm Travel speed: 0.001 to 20,000 mm/min (early 2000’s model: 0.001-10,000 mm/min) Resolution: 0.0001 mm Nedpow T Sh Esfx Aa Eowr Wheelhead (universal version) Swiveling range: -15° to 225° (early 2000’s model: -15° to 195°) Swivel axis: 2.5 / 1 ° Hirth Drive power: 7.5 or 9 kW or 11 kW Grinding wheel: 500x63 (80/110F5) x203 mm Workhead Rotational speed: 1 – 1,500 min-1 Mount taper: MT4 or MT5 / ISO 50 Drive power: 1.6 or 3.0 or 4.0 kW Tailstock Mount taper: MT3 or MT4 Quill stroke: 35 / 50 mm (early 2000’s model: 35 mm) Quill diameter: Ø 50 mm Fine adjustment: +/- 40 µm Control system: Fanuc 21i-TB All technical details are provided in good faith but subject to errors or omissions.

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 510-1986, CYLINDRICAL GRINDER JOTES SCHAUDT A440X1500 Specifications Nwedjw T Ti Depfx Aa Eer Maximum longitudinal travel: 1500 mm Grinding diameter: 298 mm External grinding: Yes Internal grinding: Yes Dimensions (L x W x H): 5400 × 2400 × 1600 mm Weight: 4800 kg Operating hours: — Power-on hours: — Condition: Rebuilt Compliant with local standards: — Status: Under power Technical features - Grinding length [mm]: 1500 - Grinding diameter [mm]: 300 - Manual table displacement [mm/rev]: 10 - Table speed range [mm/s]: 0.01–5 - Smallest table stroke [mm]: 3 - Wheelhead swivel [°]: ±90 - Centre sleeve taper [Morse No.]: 4 - Grinding wheel dimensions [mm]: 500 x 63 x 203 - Spindle speed [rpm]: 32–500 - Grinding wheel drive motor power [kW]: 5.5 - Workpiece drive motor power [kW]: 0.75 - Hydraulic pump motor power [kW]: 1.5 - Grinding attachment drive motor power [kW]: 0.75 - Machine dimensions [mm]: L=5400 / W=2400 / H=1580 / Machine weight [kg]: 4800

Condition: refurbished (used), functionality: fully functional, machine/vehicle number: 32461/2384, Manufacturing origin Swiss Voltage 380 / 50 / 3 Netweight 4900 lbs Dimensions 121 x 69 inches TECHNICAL DATA Nominal distance between centre 600 mm Max. distance between centres, headstock and tailstock projecting 750 mm Nodpfod Amifjx Aa Ejwr Height of centres, standard 125 mm Height of centres by means of raising blocks for work head-and tailstock 175 =ᐳ 250 mm Max. swing diameter with 125 mm height of centres 250 mm Max. swing diameter with raising blocks 350 =ᐳ 500 mm Table swivels each side 10° Max. lenght for surface grinding (width=200 mm) 900 mm Table speed infinitely viable by hydraulic drive, approx. .. 6 m/min Dwell of table reversal 0 - 5 sec. Grinding wheel for cylinrical grinding (diameter x width x hole) 350/400x50x127mm Grinding wheel for surface grinding diameter x width x hole 250 x 13 x 76 Speeds of grinding wheel spindle 1500/1700/2200/3600 Grinding wheel head swivels 270° with indexed stop each 90° Vertical movement of grinding wheel head, height of centres -350 mm Cross movement of grinding wheel head 285 mm Rapid advance and withdrawal of wheelhead 40 mm Intermittent infeed per reversal of table 0,001-0,03 mm/dia Infeed for plunge grinding 0-0,9 mm/dia Micro-corrector of infeed, 1 division of dial 0,001 mm/dia Swivel of work headstock 360° work speeds infinetely viable, normal/special 20-400/10-400 Internal taper of headstock/tailstock 5/3 Morse Grinding wheel motor, approx. 4 HP errors and omissions excepted data given without obligation Inventory Nr.2170089, machine equipped with : 1 Workpiece headstock MT5 1 sinus rule without comparator 1 Wheel headstock with 4 pulleys 1 Tailstock MT3 1 Collet clamping device with drawbar and reduction sleeve B32 1 Internal grinding device with quill Fischer UJ50x250 – pulley Ø 48 for 14000 min-1 1 Pivoting wheel trueing-up device with sole 50 mm 1 Table’s pivoting stop without comparator 1 Cooling device through decantation 1 extractor 1 balancing stake
