Used Electrospindle for sale (210)

Condition: used, Year of construction: 2007, Travel range: X=4400 Y=2195 Z=440 mm Working area in X=3650 mm Y=1560 mm Clearance: 330 mm Electrospindle SCM Power 2000, high speed milling spindle with 13 kW power Rotary axis Vector (C-axis) Cleaning blower for tool on the milling unit Tool holder HSK 63 F Speed range 600 - 24,000 rpm, stepless via inverter Motor power 8.5 kW Tool holders: 6 pcs Tool changer: Rapid 12 (12 positions) Vacuum pump 250 m³/h / 5.5 kW Max. vacuum: 0.9 bar Reference stop at the sides of the table Drilling unit with 11 spindles (7 vertical / 4 horizontal) Control: NUM Series 1000 User interface: XILOG Plus PC Office hardware WINDOWS XP Professional Total connected load: max. 27.5 kW Weight: 5200 kg Storage location: Nattheim Dksdpsw Dcb Ssfx Aqvsn

Condition: used, Year of construction: 2016, Used machine Year of manufacture: 2016 Equipment and technical data: - Electrical connection: 3x400V 50 / 60Hz - Cardanic 5-axis electrospindle 12 kW (S6) HSK F63 - 24,000 rpm - Ceramic bearings including liquid cooling with infinitely variable, height-adjustable dust extraction hood – controlled by electric motor - Full rated power at approximately 12,000 rpm - Speed range: 1,000 – 24,000 rpm - Drive: 3-phase high-frequency motor controlled via inverter - Rotational direction: right/left - 2 controlled compressed air connections - Interface for aggregates - Tool weight (rotating): 6 kg - Maximum saw blade diameter: 350 mm - Spindle cooling: liquid cooling - Continuously adjustable extraction hood - Profit H350 16.30: CNC machining center in gantry design (without tools) with digital drives (driven on both sides). The machine frame of the Profit H350 16.30 is made from thick-walled, electro-welded box sections. The internal steel ribbing in the frame ensures high stability. - Machining area H350 16.30: Axis travel: X = 4,000 mm Y = 1,970 mm Z = 455 mm Working area: X = 3,000 mm Y = 1,500 mm Z = 150 mm clearance height Axis positioning speeds: Depend on the selected safety system (can be taken from the layout). - Gantry drive on both sides Dkjdey Ih Rgspfx Aqvon - X-axis guidance system: The carriage of the X-axis is driven by a rack and pinion with helical, crowned teeth—this ensures maximum precision. The reduction gear guarantees the highest machining quality and repeat accuracy. The slideways use recirculating ball carriages running on encapsulated, hardened and ground linear guides. - Y-axis guidance system: Slideways use recirculating ball carriages running on encapsulated, hardened and ground linear guides. The Y-axis is positioned by a ground ball screw. - Z-axis guidance system: Slideways use recirculating ball carriages running on encapsulated, hardened and ground linear guides. The Z-axis is positioned by a ground ball screw. - Automatic central lubrication: Grease is supplied under control to the guide carriages of the X, Y, and Z axes as well as to the recirculating ball screws on Y and Z. Lubrication is performed automatically after a preset interval. - 12-position linear tool changer mounted on the left side of the machine frame, including one pickup station for aggregates: The 12-position linear changer ensures minimal changeover times and offers ample space for milling tools. One station for aggregates (see layout for configuration options). Maximum tool diameter: 250 mm Maximum tool length: 240 mm - Drill head DH 18 6H 1S: Vertical: 12 spindles—7 in X-direction and 5 in Y-direction. Horizontal: 6 spindles—4 in X-direction and 2 in Y-direction. Stroke = 70 mm; max. drill length = 70 mm; shank diameter = 10 mm. All spindles individually driven and selectable. 1 grooving saw in X-direction; maximum saw blade diameter 120 mm.

Condition: ready for operation (used), Year of construction: 2006, table width: 1,520 mm, table length: 6,200 mm, travel distance X-axis: 6,821 mm, travel distance Y-axis: 1,963 mm, travel distance Z-axis: 663 mm, controller manufacturer: BIESSE, controller model: XP600 PC-based control with Windows XP WRT, spindle motor power: 9,000 W, spindle speed (max.): 22,000 rpm, number of slots in tool magazine: 22, number of axes: 5, This 5-axis BIESSE Rover C 9.65 was manufactured in 2006. It features a working area of 6200 mm in X and up to 1935 mm in Y, with a Z-axis travel of 663 mm. The machine is equipped with a powerful 8 kW spindle and a tool changer with 22 positions. If you are looking to get high-quality CNC routing capabilities, consider the BIESSE Rover C 9.65 machine we have for sale. Contact us for further details. • Drive system X-axis: rack and pinion • Drive system Y-axis: ball screw • Drive system Z-axis: ball screw • Guide system: linear guides with recirculating ball bearing blocks • Motors: brushless motors with digital drives • Programming formats: DXF and CID3 • Main spindle type: 5 interpolating axes machining unit • Spindle power S1: 8 kW at 12000 rpm • Spindle power S6: 9 kW at 12000 rpm • Maximum spindle speed: 22000 rpm • Tool interface: HSK F63 • C-axis rotation: 360° continuous • C-axis speed: 13.5 rpm • B-axis rotation: ±100° (positioning) / ±98° (interpolation) • B-axis speed: 13.5 rpm • Z-axis feed speed: 30 m/min • Vacuum system: multi-zone vacuum with connections on both sides • Vacuum pump capacity: 250 m³/h (50 Hz) / 300 m³/h (60 Hz) • Worktable: ATS system with modular supports • Number of workpiece supports: 10 • Number of module carriers: 40 • Module size: 132 x 132 x H41.5 mm • Vacuum module size: 132 x 146 x H74 mm / 132 x 54 x H74 mm • Total module height: 115.5 mm • Clamping system: vacuum and pneumatic (Uniclamp optional) • Clamping force Uniclamp: 220 kg at 7 bar • Minimum workpiece length (Uniclamp): 140 mm • Drilling unit: BH 42 L • Vertical drilling spindles: 29 • Horizontal drilling spindles: 6 (double output) • Grooving saw diameter: 120 mm • Drilling spindle speed: up to 6000 rpm • Tool changer: chain type • Tool changer capacity: 22 positions Dkodsy Sgmujpfx Aqvon • Tool spacing: 180 mm • Max tool diameter (full load): 175 mm • Max tool diameter (single): 250 mm • Max tool length: 268 mm • Max tool weight: 7.5 kg • Total tool weight: 100 kg • Pick-up tool changer: 1 position • Max tool weight pick-up: 8 kg • Electrical supply: 380/400/415 V 50/60 Hz • Inverter for spindle: up to 14 kW • Cooling system: liquid cooling unit for electrospindles (1600 W) • Lubrication system: automatic centralized lubrication • Safety system: CE compliant with safety mats, guards and emergency stops • Chip removal: integrated chip conveyorIn 2023, the machine received a new 5-axis spindle head HS552 A HD 0S2 + ES360 F63 9 kW

Condition: ready for operation (used), Year of construction: 2021, total width: 5,851 mm, travel distance X-axis: 3,140 mm, travel distance Y-axis: 1,260 mm, travel distance Z-axis: 245 mm, overall weight: 3,000 kg, controller manufacturer: BIESSE, controller model: HH660 PC-based control, spindle motor power: 13,200 W, product length (max.): 7,116 mm, spindle speed (max.): 24,000 rpm, number of axes: 4, This 4-axis BIESSE Rover A 1232 was manufactured in 2021. It features a working area of 3140 mm in the X-axis, 1260 mm in the Y-axis, and a Z-axis travel of 245 mm. The machine is equipped with an electrospindle power of 13.2 kW and a maximum tool diameter of 113 mm. If you are looking to get high-quality CNC routing capabilities, consider the BIESSE Rover A 1232 machine we have for sale. Contact us for further details. • Power supply voltage 400 VAC • Full load current 31.7 A • Number of power supply phases 3 • Installed power 18.66 kW • Frequency 50 Hz • Short circuit protection rating 10 kA RMS Sym • Working area X 3140 mm Dedpfxey Sglke Aqvjkn • Working area Y 1260 mm • Working area Z 245 mm • Max panel thickness: depends on vacuum module height (H74 / H29) and tooling • Workpiece support length 1200 mm • Vacuum pump capacity 90 m³/h • Vacuum pump capacity 108 m³/h at 60 Hz • Vacuum system dry pump • Electrospindle power 13.2 kW • Electrospindle speed 12000 to 15000 rpm S1 • Electrospindle speed 12000 to 24000 rpm programmable • Tool holder HSK F63 • Rotation clockwise and counterclockwise • Two separate magazines installed: • 8-position tool magazine (rear / Y-axis area) • 13-position tool magazine (main X-axis unit) • Maximum tool diameter 113 mm • Maximum tool length 110 mm • Maximum tool weight 7.5 kg • Maximum total magazine weight 32 kg • Vacuum system:Configurable vacuum pump system. Available configurations include:– 2 × 90 m³/h– 2 × 100 m³/h– 1 × 250 m³/h

Condition: ready for operation (used), Year of construction: 2009, travel distance X-axis: 4,250 mm, travel distance Y-axis: 2,280 mm, travel distance Z-axis: 150 mm, overall weight: 6,300 kg, spindle motor power: 18,000 W, spindle speed (max.): 24,000 rpm, number of axes: 3, This 3-axis SCM Accord 20 CNC router was manufactured in 2010. It features a working area with dimensions of 4250 mm in the X-axis and 2280 mm in the Y-axis, making it suitable for nesting production and wood processing. The machine includes a powerful electrospindle with a speed range of 600 to 24,000 rpm and a side tool magazine with 10 positions. If you are looking to get high-quality milling capabilities, consider the SCM Accord 20 CNC router we have for sale. Contact us for further details. • Typical applications: nesting production; windows and doors manufacturing; stair components production • Table size (L x W): 4200 x 2300 mm • Controlled axes: 3 (X, Y, Z) Dkodpfjyu Rbmsx Aqvon • Axis drives: Brushless motors • Rapid traverse: X 75 m/min; Y 75 m/min; Z 15 m/min • Lubrication: Automatic central lubrication system • Work table: Nesting table; large-format multifunctional aluminum matrix; pressed aluminum construction mounted directly to the base; designed for vacuum clamping of large panels • Main spindle: 1 electrospindle, HSK F63 tool holder; 600–24,000 rpm; 11 kW inverter; up to approx. 18 kW in working range (12,000–18,000 rpm); CW/CCW rotation; air cooling with fan; pneumatic tool clamping • Tool changer: Side tool magazine TR-10; 10 positions; 130 mm spacing; max 8 kg per position; automatic tool change • Workpiece clamping: Vacuum (nesting table); 2 vacuum pumps, 250 m³/h each • CNC control: SCM PC control • Software: Xilog Maestro; Xilog Plus; graphic programming editor; DXF import; subprogram and macro management • Electrical: 400 V; 50/60 Hz • Construction: Heavy welded gantry; high-rigidity industrial frame; aluminum matrix table mounted directly to the base • Safety: Fixed safety fencing on two sides; CE marking • History/condition: One owner since new; used continuously in one company; regularly serviced; technical condition very good Additional equipment • Automatic dust extraction hood

Condition: ready for operation (used), Year of construction: 2003, number of axes: 3, This 3-axis SCM PRATIX 48 NST was manufactured in 2003. It features a working area of approximately 1220 x 2440 mm and is equipped with a vacuum nesting table. The machine includes an HSK electrospindle with a power range of 7.5–9 kW and a tool changer, either linear or side-mounted. If you are looking to get high-quality CNC wood machining capabilities, consider the SCM PRATIX 48 NST machine we have for sale. Contact us for further details. • Working area: approx. 4' × 8' (1220 × 2440 mm) Dodsy R Rp Dspfx Aqvekn • Table: Vacuum nesting table • Spindle: HSK electrospindle, 7.5–9 kW • Tool changer: Linear or side-mounted ATC • Drilling block: Vertical drills (standard) • Controller: SCM Xilog

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,200 mm, travel distance Z-axis: 1,100 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 50 m/min, feed rate Z-axis: 50 m/min, table length: 4,000 mm, table width: 2,000 mm, spindle speed (max.): 22,000 rpm, torque: 128 Nm, spindle nose: 63, CNC Heidenhain iTNC 530 S.P. WORKING AREA Longitudinal X-axis travel: mm 4.000 Transversal Y-axis travel: mm 2.200 Vertical Z-axis travel: mm 1.100 Maximum speed with interpolating axes: m/min 50 WORKTABLE Dimensions: mm 4.000 x 2.000 Height: mm 300 Load capacity: T/m² 15 T-slots for workpiece clamping mm 28 DIN 650 (H12), complete with leveling elements. T-slot direction parallel to X-axis movement. AXIS CHARACTERISTICS Axis feed rate: mm/min 50.000 Acceleration: m/s² 4 WORKING AREA (CLEARANCES) Maximum horizontal clearance: mm 3.200 Maximum vertical clearance under crossbeam: mm 1.926 Height of worktable from floor: mm 330 CONTINUOUS POSITIONING UNIVERSAL HEAD WITH ELECTROSPINDLE Automatic universal head indexed to 360,000 positions (every 0.001°). Rotation is driven by direct drive motors and controlled by the CNC as a positioning axis. Automatic tool clamping. Allows 10° undercut machining. Internal cooling system for bearings and axis motors. B-axis rotation range: ± 185° A-axis rotation range: ± 185° Maximum axis rotation speed: rpm 30 Maximum torque available on A/C axes: Nm 450 Axis clamping torque: Nm 1.400 Spindle power (S1/S6): kW 22/33 Spindle torque (S1/S6): Nm 84/128 Maximum spindle speed: rpm 22.000 Tool interface: HSK-A63 DIN 69893 The head is supplied complete with a cradle for handling and storage. The cradle is used outside the working area and therefore does not reduce the machine’s actual working capacity. CHAIN TOOL MAGAZINE – 30 POSITIONS (HSK) 30-position automatic chain tool changer located at the rear side of the working area, fully protected from dust and chips. Tool type: HSK-A63 DIN 69893 Max tool diameter (adjacent pockets occupied): mm 90 Max tool length: mm 300 Max tool weight: kg 10 MEASURING SCALE PRESSURIZATION Pneumatic system complete with control unit for pressurizing the measuring scales. SPRAY-MIST TOOL LUBRICATION/COOLING Mist lubrication system. The mist is generated by mixing air and oil and is controlled via M-function. The spray-mist improves cutting quality, prevents built-up edge formation, keeps the cutting area clean, and provides cooling. Highly effective for improving surface finish quality. EXTERNAL TOOL COOLING Coolant distribution system controlled by the CNC, with nozzles positioned on the flange around the spindle. Complete with a tank (1,200-liter capacity) for coolant collection and filtration. Flow rate: 30 l/min, pressure: 4 bar. REQUIRED CONNECTIONS Maximum installed power: kW 150 Maximum current required: A 235 MACHINE EQUIPPED WITH: • Heidenhain HR550 remote electronic handwheel • Various tooling included with the machine • Renishaw probe • BLUM laser presetting system • AUTOCAL automatic head calibration system • Visormax subscription for remote monitoring Dodpfx Aqozb Evlsvskn • Electrical cabinet air conditioning unit • Cooling system for all axes and the electrospindle • No. 2 chip conveyors positioned on both sides of the worktable • User and maintenance manual and CE declaration of conformity

Condition: used, machine/vehicle number: 007734, X axis working area: 3050 mm Y axis working area: 850 mm Dedpsw Idb Hjfx Aqvokn Main Electrospindle power: 5 KW Total number of drilling spindles: 19

Condition: used, machine/vehicle number: 005836, X axis working area: 3000 mm Y axis working area: 1000 mm Djdjwuckuspfx Aqvokn Main Electrospindle power: 3.5 KW Number of controlled axes: 3 axes Total number of drilling spindles: 82

Condition: used, machine/vehicle number: 007289, X axis working area: 3200 mm Y axis working area: 900 mm Main Electrospindle power: 4.5 KW Number of controlled axes: 3 axes Dsdpewukyqjfx Aqvekn Total number of drilling spindles: 16

Condition: excellent (used), Year of construction: 2005, machine/vehicle number: 59978, functionality: fully functional, BIESSE SKIPPER 100 CNC Drilling and Machining Center For sale: BIESSE SKIPPER 100 high-performance CNC through-feed machining center designed for drilling, routing and grooving operations in furniture production and panel processing. The machine offers excellent productivity, high machining accuracy and compact industrial construction. Technical Specifications Manufacturer: BIESSE Model: SKIPPER 100 Axes X-axis travel: 3,000 mm Y-axis travel: 1,000 mm Z-axis travel: 60 mm Workpiece Dimensions Length: 90 – 3,000 mm Width: 70 – 1,000 mm Thickness: 8 – 60 mm Spindle Unit HSK electrospindle Spindle speed: 6,000 – 18,000 rpm Spindle power: 3.5 kW Total installed power: approx. 20 kW Drilling Units Per operating unit: 29 vertical drilling spindles 8 horizontal drilling spindles along X-axis 2 horizontal drilling spindles along Y-axis Total: Dkedpfxozatrrj Aqvjn 78 independent spindles Upper and lower machining units Equipment Automatic panel size detection Electronic thickness control Central automatic lubrication BiesseWorks software Roller loading table Unloading conveyor Dust extraction connections Safety enclosure Machine Dimensions Overall length: 7,290 mm Overall width: 4,400 mm Height: approx. 2,000 mm Weight: approx. 2,700 kg The machine is in good working condition and can be inspected under power by appointment. Photos, videos and additional technical information available upon request.

Condition: used, machine/vehicle number: 008169, X axis working area: 4500 mm Y axis working area: 1550 mm Dksdpfjxaud Ijx Aqvsn Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 4 axes Total number of drilling spindles: 31 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 008381, X axis working area: 4250 mm Y axis working area: 2280 mm Dodpfx Aqex Swc Hsvjkn Working Table: Flat table Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 11 Total number of tool changer positions: 24

Condition: used, machine/vehicle number: 008557, X axis working area: 3050 mm Y axis working area: 850 mm Main Electrospindle power: 5 KW Number of controlled axes: 3 axes Dsdpfxozcbhge Aqvokn Total number of drilling spindles: 19

Condition: used, machine/vehicle number: 008377, X axis working area: 3390 mm Y axis working area: 1570 mm Working Table: Pod and Rail Main Electrospindle power: 13 KW Number of controlled axes: 4 axes Total number of drilling spindles: 32 Dksdpfx Aqox Swb Ajvon Total number of tool changer positions: 10

Condition: used, machine/vehicle number: 008362, X axis working area: 3200 mm Y axis working area: 1600 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Dkodjx A Tl Aspfx Aqvon Total number of drilling spindles: 32 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 008370, X axis working area: 5055 mm Dkodpfjx A Tk Sox Aqven Y axis working area: 1930 mm Working Table: Pod and Rail Main Electrospindle power: 19 KW Number of controlled axes: 5 axes Maximum edge height: 60 mm Total number of drilling spindles: 28 Total number of tool changer positions: 31

Condition: used, machine/vehicle number: 008340, X axis working area: 4400 mm Y axis working area: 1300 mm Dkedpjy Nkpnsfx Aqvsn Working Table: Pod and Rail Main Electrospindle power: 11 KW Number of controlled axes: 5 axes Total number of drilling spindles: 36 Total number of tool changer positions: 30

Condition: used, machine/vehicle number: 008495, X axis working area: 3050 mm Dodpfx Ajy Edqqsqvokn Y axis working area: 1400 mm Working Table: Pod and Rail Main Electrospindle power: 11 KW Number of controlled axes: 4 axes Maximum edge height: 45 mm Total number of drilling spindles: 21 Total number of tool changer positions: 12

Condition: used, machine/vehicle number: 008480, X axis working area: 4600 mm Y axis working area: 1550 mm Working Table: Pod and Rail Main Electrospindle power: 18 KW Number of controlled axes: 5 axes Dkodsy Edqkopfx Aqvon Total number of drilling spindles: 31 Total number of tool changer positions: 58

Condition: used, machine/vehicle number: 008205, X axis working area: 4250 mm Y axis working area: 1320 mm Working Table: Pod and Rail Main Electrospindle power: 11 KW Number of controlled axes: 4 axes Dodpfsx A Th Rsx Aqvskn Total number of drilling spindles: 31 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 008198, X axis working area: 4200 mm Y axis working area: 1400 mm Working Table: Pod and Rail Main Electrospindle power: 18.5 KW Dedpfox A Hbkox Aqvjkn Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 35 Total number of tool changer positions: 26

Condition: used, machine/vehicle number: 008170, X axis working area: 4300 mm Y axis working area: 2250 mm Working Table: Flat table Main Electrospindle power: 9 KW Number of controlled axes: 4 axes Total number of drilling spindles: 12 Total number of tool changer positions: 14 Dksdpfx Asx A Tcusqvjn

Condition: used, machine/vehicle number: 008184, X axis working area: 8185 mm Y axis working area: 1550 mm Working Table: Pod and Rail Main Electrospindle power: 13 KW Number of controlled axes: 5 axes Djdeyxmv Nspfx Aqvokn Total number of tool changer positions: 22

Condition: new, Year of construction: 2023, The K’MX 920 CLEVER sliding headstock automatic lathe is designed for machining complex workpieces up to Ø 20 mm. The lathe is equipped as standard with two electrospindles with a maximum speed of 12.000 rpm each. With its nine axes, comb + turret on three axes and independent end unit, this machine is capable of having four tools in the material for an optimised cycle time. Dksdok Dz Dijpfx Aqvjn 9 linear axis 1 independent rack with 10 positions Cross-section of outer tools 12 x 12 mm Turret number of stations 12
