Used Cutting Device for sale (25,191)

Condition: new, Model Name Iodpfogvkctjx Ag Uotb Shark 282 SXI evo

Condition: new, Year of construction: 2024, table length 3048 mm Iedpfxjwp Thyo Ag Uetb table width 1524 mm burner heads 1 stroke 270 mm speed 100 m/min dimensions 8900 x 2260 x 2220 mm weight of the machine ca. 7.500 kg

Condition: new, Year of construction: 2024, thread dia. bis M 16 mm Iedpfju Ag Raex Ag Uotb turning speeds 0 - 600 U/min thread M5 - M16 working area 2050 Rmax. working area 500 Rmin. table surface area 900 mm engine output 3,0 kW weight ca. 250 kg

Condition: used, Year of construction: 2021, cutting range for steel to 50 mm Itjdpfx Asv Da Udeg Usb capacity at 100% 130 A weight of the machine ca. 130 kg dimensions of the machine ca. 650 x 400 x 900 mm ORIGINAL PRICE: ~6,000 EURO Very good condition Very little use Features: - Burner A151/6 - Ground cable 25 mm² Adjustment range, continuously variable [A] 25 - 150 Duty cycle at Imax. (10 min) at 20°C [%] 60 Mains connection [V] 3 x 400 V Fuse protection (slow-blow) [A] 35 Protection class IP 23 Cutting capacity max. [kw] 21 Current/voltage at 100% IDl [A/V] 130/130 Power consumption max. 24.5 Power factor [cos phi] 0.97 Max. cutting quality with REHM power torch 40 mm Max. cutting capacity for manual cutting with S 235/S355 [mm] 50

Condition: new, Year of construction: 2025, table length 3048 mm table width 1524 mm burner heads 1 Control CNC workpiece weight 1450 kg traversing speed 200 m/min weight 5010 kg dimensions of the machine ca. 9450 x 2240 x 2520 mm Laser cutting machine with automatic shuttle table Configuration 1. BodorPower laser source 12 kW 2. BodorGenius laser cutting head with autofocus 3. BodorThinker 3.0 control system 4. Bed made of tenon and mortise structure 5. Stretched aluminum portal 6. One-click fully automatic processing 7. Automatic layout of residual material 8. Edge detection and automatic zeroing of the focal length through intelligent detection 9. Bodor Lightning perforation technology 10. 21.5-inch monitor with touch function 11. Intelligent control of gas pressure 12. Automatic adjustment of cutting gas pressure 13. Bodor Mango® ergonomic remote control 14. Active anti-collision function Itjdjwmwwmspfx Ag Usb 15. Intelligent vibration protection 16. Intelligent adjustment to overheating 17. Gas-saving nozzles with stable flow 18. Intelligent maintenance reminder 19. WIFI internet connection 20. Water cooling 21. Dust removal function 22. Safety light curtains 23. Extraction 24. Wear parts set CUTTING CAPACITY: STRUCTURAL STEEL 35 mm STAINLESS STEEL 35 mm ALUMINUM 25 mm OPTIONAL: LANTEK EXPERT II CUT software incl. post-processor

Condition: used, Year of construction: 2017, table width 3000 mm table length 1500 mm burner heads 1 Plasma cutting system HEZINGER PlasmaLine EPJ / ECKERT with extraction system PFC-4 Plus 4kW F3800 Technical data HYPERTHERM Powermax 125 plasma cutting unit: Itodpjucpnlefx Ag Ujb Cutting capacity: Recommended: 38mm Maximum: 44mm Separating cut: 57mm Piercing: 25mm Output current: 30-125A Mains connection: 400v-36A Compressed air requirement: 260l/min Air pressure 5.9bar Dimensions: 592 x 274 x 508 mm Weight: 49kg

Condition: new, Year of construction: 2025, table length 3000 mm table width 1500 mm burner heads 1 Control CNC workpiece weight 900 kg Itjdpfx Agoxv D T Rj Uob traversing speed 91 m/min weight 4980 kg dimensions of the machine ca. 5562 x 2270 x 2388 mm Laser cutting machine with manual shuttle table Configuration 1. BodorPower laser source 12 kW 2. Bodor Genius laser cutting head with autofocus 3. Bodor Thinker 3.0 control system 4. Bed made of tenon and mortise structure 5. Bodor servo motor and driver 6. Nitrogen control valve 7. Bodor Lightning perforation technology 8. Automatic layout of residual material 9. 21.5-inch monitor with touch function 10. Automatic adjustment of cutting gas pressure 11. Active anti-collision function 12. Intelligent vibration protection 13. Anti-burn mineral casting 14. Bodor Mango® Ergonomic Remote Control 15. Gas-saving nozzles with stable flow 16. Intelligent maintenance reminder 17. WIFI internet connection 18. Water cooling 19. Extraction system 20. Wear parts set CUTTING CAPACITY: STRUCTURAL STEEL 35 mm STAINLESS STEEL 35 mm ALUMINUM 25 mm OPTIONAL: LANTEK EXPERT II CUT software incl. post-processor

Condition: new, thread dia. M6 - M36 mm turning speeds 156 U/min radius 1200 mm Ijdsg N Nl Iopfx Ag Ujtb angle adjustable from - to 0 - 90 Grad weight of the machine ca. 0,4 t dimensions of the machine ca. 1,4 x 0,1 x 0,7 m Electric tapping machine / 4450136SET Fast and precise thread cutting with freely positionable swivel arm - The machine head can be swiveled from 0 to 90 degrees - Quick change chuck with slip clutch for safe thread cutting without Risk of breakage - Right-left rotation can be selected on the machine head - Setting of thread size, speed, pitch and cutting depth via Touchscreen on the swivel arm - Manual mode: the stops after the set cutting depth is reached Spindle automatic, forward and reverse must be activated manually. - Automatic mode: changes after the set cutting depth is reached the machine automatically from the forward to the return - ideal for that Thread cutting of several blind holes Incl. 1 each GT12 M6, M8, M10, M12, M14, M16, M18, M20, M22-24, M27, M30, M33, M36 Substructure 900 x 600 x 875 mm

Condition: new, Year of construction: 2025, table length 3000 mm table width 1500 mm burner heads 1 Control CNC workpiece weight 800 kg traversing speed 140 m/min total power requirement 42,5 kW dimensions of the machine ca. 10050 x 4920 x 2200 mm CUTTING CAPACITY: STRUCTURAL STEEL 25 mm STAINLESS STEEL 15 mm ALUMINUM 12mm BRASS 8mm COPPER 8mm MACHINE AXES: 4 axes [X, Y, Z, U ] CUTTING HEAD: Precitec ProCutter CAD/CAM SOFTWARE: LANTEK EXPERT CUT *4 servo motors for all axial movements *CNC CONTROL PANEL 15 5” touch screen *IPG laser sources and coolers integrated *Precitec Procutter cutting head system *AIR FILTER (compressed air filter) *CONVEYOR BELT under cutting area Itedpfx Agsun Um Se Ujb *Closed housing and specially coated filter protection windows *LOADING / DISCHARGING SYSTEM *PROPORTIONAL GAS AND PIPE SYSTEM

Condition: new, table width 3000 mm table length 1500 mm burner heads 1 Control CNC feed 20.000 mm/min total power requirement 15 kVA dimensions of the machine ca. 4,5 x 2,5 m Itodpfxspm U U Ne Ag Usb * Heavy machine bed with precision guides for quiet movement machine * A ball bearing cross carriage for height adjustment with 400mm vertical Hub * Thermal separation of the drive and cutting areas ensures the highest precision * Automatic height finding and torch height control during cutting * Torch holder with collision protection and automatic shutdown in the event of a collision * Installation or implementation of the machine using the plug & play method with a forklift, Ant or crane possible * 3-sided accessibility to cutting area through boom design SATOTEC suction table: The SATOTEC table system is characterized by a stable table construction max. cutting thickness of 150 mm. For cutting a workpiece thickness of 150 mm, oxyfuel cutting technology is required. The workpiece support frame has interchangeable ones placed at a 45° angle and 3 mm thick flat iron slats. The distance between the slats is 50 mm. Power source Kjellberg Q1500: * Precise plasma cutting of all electrically conductive materials from 0.5 to 60 mm both dry and under water * Recommended cutting range from 0.5 to 40 mm * Maximum piercing thickness 30 mm, increase possible with ProPierce Technology * Marking, notching and punching, including coated metallic materials * Inverter power source with digitally controlled, fully electronic process flow * Integrated cooling with partially automated filling and emptying Gas control: Fully automatically controlled, processor-controlled plasma all-gas console Q- Gas for cutting all metals Lantek Expert Cut Inside: CAD/CAM module integrated in the machine control Extraction TEKA EcoCube 5.5 kW Medium to be filtered: dry, fat-free or oil-free dust/smoke Filter area: 100 m² (4 cartridges of 25 m²) Filter cartridge: BIA M, Type Nano Degree of separation: 99% (according to BGIA test certificate) Filter control: automatic filter cleaning, PLC Fan performance: 4500 m³/h Motor power: 5.5 kW Connection voltage: 400V/50 Hz or 480V 60Hz. Current consumption: 11.5 A Current type: 3Ph+N+PE Fan structure: on the system, including silencer duct bend, right side Motor control: frequency converter Noise level: 75dB(A) + max 10 dB(A) with cleaning pulse Intake port: NW 250 mm via intake duct, left side Exhaust: via silencer duct bend Dimensions (W x D): approx. 800 x 800 mm System color: - Fan housing: Light gray - Cartridge housing: RAL 5007 brilliant blue Special equipment: - Locking hooks and toggle locks - Compressed air connection and condensate drain each mounted with one Bulkhead fitting - Compressed air connection with hose nozzle d=8mm - Provide the system with grounding bolts - Cable in UL version - EATON frequency converter on the left in the attached control cabinet

Condition: new, Year of construction: 2025, table length 3000 mm table width 1500 mm burner heads 1 Control CNC workpiece weight 900 kg Itsdjwh Ulqjpfx Ag Usb traversing speed 91 m/min dimensions of the machine ca. 5562 x 2270 x 2388 mm Laser cutting machine with manual shuttle table Configuration 1. BodorPower laser source 6 kW 2. Bodor Genius laser cutting head with autofocus 3. Bodor Thinker 3.0 control system 4. Bed made of tenon and mortise structure 5. Bodor servo motor and driver 6. Nitrogen control valve 7. Bodor Lightning perforation technology 8. Automatic layout of residual material 9. 21.5-inch monitor with touch function 10. Automatic adjustment of cutting gas pressure 11. Active anti-collision function 12. Intelligent vibration protection 13. Anti-burn mineral casting 14. Bodor Mango® Ergonomic Remote Control 15. Gas-saving nozzles with stable flow 16. Intelligent maintenance reminder 17. WIFI internet connection 18. Water cooling 19. Extraction system 20. Wear parts set CUTTING CAPACITY: STRUCTURAL STEEL 20 mm STAINLESS STEEL 18 mm ALUMINUM 14 mm OPTIONAL: LANTEK EXPERT II CUT software incl. post-processor

Condition: new, table width 1500 mm table length 3000 mm burner heads 1 Control CNC CNC plasma cutting system *NEW - AVAILABLE FROM STOCK* Itodpfjiid Hwox Ag Ujb Furnishing: Cutting area 1,525 x 3,050mm Consisting of guiding machine, CNC control Plasma torch holder incl. torch height control, incl. Radio remote control and cross-laser for positioning, 1 license FastCAM programming software with Auto Nest Function and DXF,DWG import. Autogen set consisting of gas control solenoid valve, injector Machine torch torch holder, capacitive Height control, cutting range 10 - 50 mm plasma system Hypertherm Powermax 85 Sync CPC System Cutting range 1 - 20mm, cutting gas air Machine torch Smartsync 180° - 15.2 meters Machine is offered ex works. Without accessories (dye, anti-rust, aint mushroom, etc.) - further costs on request!

Condition: new, table length 3000 mm table width 1500 mm burner heads Precitec ProCutter laser capacity in Watt 6000 x-axis 3050 mm z-axis 150 mm y-axis 1550 mm total power requirement 21 kW dimensions 9190 x 3710 x 2200 mm weight of the machine ca. 11200 kg Furnishing: - Resonator Ytterbium YLS 4000 compact - Beckhoff controller - Precitec ProCutter Automatic cutting head - autom. Lubrication system - CAD / CAM software LANTEK EXPERT CUT - 17 "touchscreen, keyboard, control panel - Collective conveyor under the cutting table - additional loading unit Cutting capacities: - normal steel 25 mm - stainless steel 15 mm - aluminum 12 mm - brass 8 mm - copper 8 mm Axes: - Machine axes: 4 axes (X, Y, Z, U) - s speed: 100 m / min (simulated) - Axis speed X / Y: 100 m / min (single) - Positioning accuracy: + - 0.03 mm / min - Burning height: 125 - 200 mm Loading table: - Number of pieces 2 (35 seconds for changing) - automatic change of tables - d 2,500 kg. assisting gases: - mild steel - oxygen (0.5 - 25 bar) - stainless steel - nitrogen (0.5 - 25 bar) - Aluminum - compressed air or nitrogen (0.5 - 25 bar) including: - Compatible suction system - Sick light barrier safety device - Spare part basic supply package Why Fibermak? - Up to 3 times faster cutting compared to other laser technologies Isdpfx Agjgvq D Uo Uetb - Machines for cutting thin sheets - axes equipped with linear motors / Servo motors reach up to 141 m / min. - Accelerations up to 2G - Fiber laser is the green laser technology (Saving of at least 50% energy costs) - There is no need for laser gas mixing - There is no need for optical Components / therefore very low-maintenance - Save up to 50% per part through more efficient production - Extended options: cutting from reflective materials like aluminum, copper, brass etc., - In addition, precise cuts and smooth surface quality - Heavy-duty constructed frame, equipped with world-famous, durable, high-quality components - ERMAK passes the price advantage on to its customers thanks to its fast and high quality production - Creative design, constant, highest technology and quality - High reliability - High efficiency - High quality - CE declaration

Condition: new, Year of construction: 2024, table length 3000 mm table width 1500 mm burner heads 1 Control CNC workpiece weight 1500 kg traversing speed 200 m/min total power requirement 55 kW dimensions of the machine ca. 10050 x 4920 x 2200 mm CUTTING CAPACITY: STRUCTURAL STEEL 40 mm STAINLESS STEEL 40 mm Iedpfx Agsu Dpb Rj Ustb ALUMINUM 40 mm BRASS 16 mm

Condition: new, table length 3000 mm table width 1500 mm burner heads 1 Control CNC workpiece weight 1500 kg total power requirement 21 kW weight of the machine ca. 10,4 t dimensions of the machine ca. 5,2 x 4,2 x 2,62 m CUTTING CAPACITY: STRUCTURAL STEEL 25 mm STAINLESS STEEL 15 mm ALUMINUM 12mm BRASS 8mm COPPER 8mm MACHINE AXES: 4 axes [X, Y, Z, U ] CUTTING HEAD: Precitec ProCutter CAD/CAM SOFTWARE: LANTEK EXPERT CUT Itedpjvuz I Hsfx Ag Ujb *4 servo motors for all axial movements *CNC CONTROL PANEL 15 5” touch screen *IPG laser sources and coolers integrated *Precitec Procutter cutting head system *AIR FILTER (compressed air filter) *CONVEYOR BELT under cutting area *Closed housing and specially coated filter protection windows *LOADING / DISCHARGING SYSTEM *PROPORTIONAL GAS AND PIPE SYSTEM

Condition: new, Year of construction: 2025, table length 3048 mm table width 1524 mm burner heads 1 Control CNC Itedpownt Eijfx Ag Usb workpiece weight 911 kg traversing speed 180 m/min weight 4150 kg dimensions of the machine ca. 9392 x 2232 x 2307 mm Laser cutting machine with automatic shuttle table Configuration 1. Bodor Power 3kW laser source 2. Bodor Genius laser cutting head with autofocus 3. Bodor Thinker 3.0 control system 4. Mortise-and-tenon type plate welded segmented bed 5. Stretched aluminum gantry 6. Bodor servo motor and driver 7. Bodor rack and pinion 8. One-click processing 9. Bodor Lightning perforation technology 10. Expert database for high-speed cutting 11. Automatic cutting gas pressure adjustment 12. Open door protection 13. Cutting malfunction alarm function 14. Ergonomic remote control (Bodor Mango®) 15. Active anti-collision function 16. Intelligent anti-shake 17. Gas-saving continuous flow nozzle 18. Intelligent maintenance reminder 19. WIFI internet connection 20. Water cooler 21. Extraction system 22. Wear parts set CUTTING CAPACITY: STRUCTURAL STEEL 14 mm STAINLESS STEEL 10 mm ALUMINUM 6 mm OPTIONAL: LANTEK EXPERT II CUT software incl. postprocessor Translated with (free version)

Condition: new, thread dia. M6 - M24 mm turning speeds 200 U/min radius 1200 mm angle adjustable from - to 0 - 90 Grad weight of the machine ca. 0,4 t dimensions of the machine ca. 1,4 x 0,1 x 0,7 m Electric tapping machine / 4450124SET Fast and precise thread cutting with freely positionable swivel arm Itjdpfx Agsg N Nl Dj Ueb - The machine head can be swiveled from 0 to 90 degrees - Quick change chuck with slip clutch for safe thread cutting without Risk of breakage - Right-left rotation can be selected on the machine head - Setting the parameters via touch display on the swivel arm - Both manual and automatic switching from forward to backward to reaching the entered Incl. 1 each GT24 M6, M8, M10, M12, M14, M16, M18, M20, M22-24 tapping chuck Substructure 900 x 600 x 875 mm

Condition: new, Year of construction: 2025, table length 4000 mm table width 2000 mm burner heads 1 Control CNC workpiece weight 2510 kg traversing speed 200 m/min dimensions of the machine ca. 11599 x 3380 x 2718 mm Laser cutting machine with automatic shuttle table Configuration 1. BodorPower laser source 12 kW 2. BodorGenius laser cutting head with autofocus 3. BodorThinker 3.0 control system 4. Bed made of tenon and mortise structure 5. Stretched aluminum portal 6. One-click fully automatic processing 7. Automatic layout of residual material 8. Edge detection and automatic zeroing of the focal length through intelligent detection 9. Bodor Lightning perforation technology 10. 21.5-inch monitor with touch function 11. Intelligent control of gas pressure 12. Automatic adjustment of cutting gas pressure 13. Bodor Mango® ergonomic remote control 14. Active anti-collision function 15. Intelligent vibration protection 16. Intelligent adjustment to overheating 17. Gas-saving nozzles with stable flow 18. Intelligent maintenance reminder 19. WIFI internet connection 20. Water cooling 21. Dust removal function 22. Safety light curtains 23. Extraction 24. Wear parts set CUTTING CAPACITY: STRUCTURAL STEEL 35 mm Iodpfx Aswh Ukyeg Ustb STAINLESS STEEL 35 mm ALUMINUM 20 mm

Condition: new, Year of construction: 2025, table length Rohmateriallänge 6500 mm table width Rohrdurchmesser max. 230 mm burner heads 1 Control CNC workpiece weight 300 kg traversing speed 91 m/min weight 5750 kg dimensions of the machine ca. 12900 x 2370 x 2650 mm Tube laser with T-loader Configuration 1. Bodor Power laser source 6 KW 2. Bodor Genius laser cutting head with autofocus 3. Bodor Thinker 3.0 control system 4. Pneumatic chuck 5. Adaptive adjustment of jaw clamping force 6. Follow-up servo blanking clamp 7. Support for composite clamping rollers 8. Active collision avoidance 9. Automatic tube inspection 10. Automatic tube edge detection and positioning 11. Automatic adjustment of cutting gas 12. Laser cutting process database 13. Air-saving continuous jet nozzle 14. Intelligent maintenance reminder 15. WIFI internet connection 16. Water cooler 17. Extraction system 18. Wear parts set 19. Auxiliary feeding device T-Loader: - One-click adjustment - Material shortage alarm - Automatic loading - Scratch-resistant tube - Host safety lock - Tube size range: Round tube 20 - 220 mm Square tube 20 - 220 mm Rectangular tube 220 mm = side length = 20 mm - Maximum tube weight: 300 kg - Pipe loading length range: 4500 mm-6500 mm - Maximum loading weight: 1800 kg CUTTING CAPACITY: STRUCTURAL STEEL 16 mm STAINLESS STEEL 12 mm ALUMINUM 10 mm WALL THICKNESS STRUCTURAL STEEL* (mm) If DM < 50: WS = 1.2 If DM = 50: WS = 2.5% × DM Itsdpfx Aowh Uldsg Ueb Max. finished part length 4500 mm OPTIONAL: LANTEK FLEX3D TUBES PLUS

Condition: new, thread dia. M5 - M24 turning speeds 70 - 200 U/min working area max. 1200 R angle adjustable from - to 0 - 90 Grad voltage 230 V engine output 1200 W weight 65,0 kg - with micro spray system for constant cooling & minimal Cooling lubricant consumption - Includes blow-out device to remove chips, ensuring optimal visibility on the borehole - Includes quick-change chuck for using taps for Through and blind holes - Swivel motor unit for thread cutting at any desired angle between 0° and 90° - Higher accuracy compared to manual thread cutting, thread is guaranteed right angle (90°) - high productivity, significant time savings compared to manual Threading - Quick-change chuck with integrated slip clutch prevents breaking of the tap - Includes large radius swivel arm for easy positioning tap on the workpiece Ijdsxaaybjpfx Ag Uetb - For thread cutting in steel, stainless steel, aluminum and non-ferrous metals scope of delivery - Operation via touchscreen - Digital drilling depth display - Micro spray system - Blow-out device - Quick change mount - Quick-change chuck according to DIN - Electric motor - 90° angle adjustment - Mounting flange Special accessories included: - BERNARDO base frame 900 x 600 mm (Art. No.: Mounts: DIN 376: M5-6 / M8 / M10 / M12 / M14 / M16 / M18 / M20 / M22-24

Condition: new, length 1500 x 740 x 780 innen mm weight of the machine ca. ca. 200 kg. For collecting and disposing of bulk goods and industrial waste Furnishing : - Tipping containers - forklift attachments - for in-house storage of bulk goods - powder-coated in standard color - RAL 5010 blue, RAL 6011 green or RAL 7016 anthracite gray Itsdpfx Agjxab Iyj Uob - Tilting device with base plates for swivel and fixed castors - Drainage device - Stable base frame with drive-in pockets - Favorable load center - Robust sheet steel construction with reinforced edges - Container volume: approx. 600 l available for a surcharge: - 2x fixed castors / 1x swivel castor .. 80.00 euros

Condition: new, thread dia. 12 M max. turning speeds 400 U/min thread M 3 - M 12 M working area 1600 R max. working range 500 Rmin. weight 16 kg Description: The AT II models have a radius of up to 1600 mm and thanks Iedoxabbmspfx Ag Uetb to their construction a flexible workspace. For professional use. Easy to mount on a worktop. Furnishing: - Tool holder with 6 cutter holders • M3 20111812 DIN 371 19 • M4 20111814 DIN 371 19 • M6 20111816 DIN 371 19 • M8 20111817 DIN 371 19 • M10 20111818 DIN 376 19 • M12 20111820 DIN 376 19 - with slip clutch - Control valve with lubrication - Including compressed air motor / maintenance unit - Adapter connection size 1

Condition: new, thread dia. bis M 24 turning speeds U/min thread M5 - M24 working area 2050 Rmax. working range 500 Rmin. work height max. 900 mm table surface area 700 x 900 mm oil volume 100 l engine output 3,0 kW weight - pallet system ca. 300 kg Furnishing: - electro-hydraulic thread cutting machine - large working area (radius max. 2050 mm) * including table clamping disk * Swivel movement is smooth thanks to built-in gas pressure dampers - mobile machine base * Oil tank + hydraulic unit integrated in the base frame * hydraulic pressure gauge - continuous speed adjustment - vertical/horizontal thread cutting possible - Lateral sorting of the quick-change inserts possible - Connection cable with 16A plug Itedpoxab Iasfx Ag Usb Special accessories included / quick-change inserts: M05 / M06 / M08 / M10 / M12 / M14 / M16 / M18 / M20 / M22

Condition: new, length 1500 x 740 x 780 innen mm weight of the machine ca. ca. 200 kg. For collecting and disposing of bulk goods and industrial waste Itjdpfx Agsxab Itj Ujb Furnishing : - Tipping containers - forklift attachments - for in-house storage of bulk goods - powder-coated in standard color - RAL 5010 blue, RAL 6011 green or RAL 7016 anthracite gray - Tilting device with base plates for swivel and fixed castors - Drainage device - Stable base frame with drive-in pockets - Favorable load center - Robust sheet steel construction with reinforced edges - Container volume: approx. 600 l available for a surcharge: - 2x fixed castors / 1x swivel castor .. 80.00 euros

Condition: new, thread dia. 20 M turning speeds 400 U/min thread M 4 - M 20 M working area 1900 Rmax. Iodpfx Aoxaaa Iog Uetb working range 200 Rmin. Description: The AT models have a radius of up to 1900 mm and their construction a flexible workspace. For professional use. Easy to mount on a worktop. Furnishing: - including 7 thread cutting inserts • M3 20111812 DIN 371 19 • M6 20111823 DIN 371 31 • M8 20111824 DIN 371 31 • M10 20111826 DIN 371 31 • M12 20111827 DIN 376 31 • M16 20111829 DIN 376 31 • M20 20111831 DIN 376 31 - Control valve with lubrication - Including air motor - Adapter connection size 2 - The cutting head can be pivoted vertically downwards by 90 ° - The cutting head is pivoted and rotatable through 360 ° - Operating instructions in German * without the perforated table as per Fig.
