Brochure production system

Watkiss Nearline Powersquare 224

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, Very well-maintained machine. Only 130,000 cuts. Predpezlr Nxefx Adzsa

Year of construction: 1994, condition: excellent (used), machine/vehicle number: 04.2398, Manufacturer: Arthur Klink Type: RIW 10 x 1500 x 500 Machine No.: 04.2398 Year of construction: overhauled by manufacturer 1994 weight: 3700kg tractive force: 10.000kg (100kN) max. stroke: 1500mm max. workpiece diameter: Ø 500mm Pedpfjgyd T Eex Adzsra clearing speed: infinitely variable from 1m/min to 6m/min return speed: stepless adjustable up to 20m/min power supply: 400V / 50Hz

Condition: used, functionality: fully functional, machine/vehicle number: 7085, Used universal cylindrical grinding machine Manufacturer: WMW Model: SU 315 x 1000 mm Equipped with internal grinding attachment Maximum workpiece diameter: 315 mm Maximum grinding length: 1000 mm Grinding spindle speed: 1340 rpm Workpiece speed: 22–500 rpm Longitudinal table travel: 5–1680 mm Table feed rate: 0.05–5 m/min Prodpfx Adswl A H Dezsa Maximum workpiece weight: 300 kg Connected load: 12.5 kW Machine weight approx.: 5.8 t

Condition: excellent (used), COLLATING MACHINE BOURG: 2xTOWERS BST10 & BDF Counter: number sets: 2092702 // sheets: 2102565 // stapling: 1807398 // folds: 2022952 // cuts: 1763900 Equipment: Prodpfx Asir U Rtsdzsa 2xTOWER BST10 / BST 10 (each 10 stations) M.No.: 02 01 4 1834 M.No.: 02 11 4 1769 BDF M.No.: 40 12 4 1046 Two spare wire stitching heads included

Condition: ready for operation (used), Year of construction: 1988, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,250 mm, table load: 6,300 kg, spindle diameter: 120 mm, spindle speed (min.): 2,000 rpm, quill travel distance: 600 mm, quill stroke: 600 mm, quill diameter: 120 mm, Control: Wotan 1500 Dialog, SK50 DIN 69871, complete documentation available, table size 1600 x 1250, T-slot width 22 H7, Heidenhain linear scales/measurement systems, Siemens feed drive. Pjdpjyxwwwjfx Adzsra

Condition: used, machine/vehicle number: 13071420, Business card cutter, Uchida Yoko, machine number 13071420, the machine is in good condition and available immediately. Prjdpfx Adsxvxl Uszsa

Condition: excellent (used), Year of construction: 1972, functionality: fully functional, press force: max. 1.250 to. daylight: max. 480 mm width: 585 mm stroke: max. 355 mm weight: 9.000 Kg. Note: the press is been partly reconditioned by SACK & KIESSELBACH Pedowuutbepfx Adzjra and the control system is been repalced.

Condition: used, Minolta c1060L, LU202, FS612, standard controller, approx. 392,000 copies Prjdpfx Adopvi A Aezea

Year of construction: 1963, condition: used, machine/vehicle number: 18135, Broaching Machine – Horizontal Manufacturer: Forst Typ: RIW 100/2200 Force: 100 Tons Stroke: 2.200 mm It is possible to buy the Crane - see offer no Y941 Psdpfebrcy Njx Adzjra

Condition: new, Year of construction: 2025, operating hours: 60 h, functionality: fully functional, workpiece weight (max.): 40,000 kg, wheel width: 3,700 mm, feed length X-axis: 2,000 mm, feed length Y-axis: 1,300 mm, feed length Z-axis: 500 mm, rotary table diameter: 3,700 mm, position of the milling head: 0,025, table diameter: 2,000 mm, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 6 m/min, total length: 12,000 mm, gear diameter: 400 mm, total height: 5,000 mm, total width: 4,000 mm, Equipment: CE marking, documentation/manual, rotational speed infinitely variable, TECHNICAL REQUIREMENTS GEAR HOBBING MACHINE GHM 2500 CNC Description of the main components of the GHM 2500 machine The GHM 2500 CNC gearing milling machine is a machine tool intended for processing by milling toothed wheels and toothed crowns. The machine is equipped with an external teeth milling head - which can process the teeth with an inclination angle from 0 to +/- 45 degrees - and an internal teeth milling head. The machine is composed of a milling unit, a unit for clamping and rotating the workpiece and the pinion axis centering tip. The milling/gearing unit is provided with three translation axes and two rotation axes, as follows: -X axis: longitudinal/radial movement towards the workpiece axis -Y axis: vertical movement of the gearing head -Aza Z: tangential movement of the gearing head Prodpfxjy A Ngle Adzja -Axis: inclination +/-45 degrees of the gearing head -Axis C: rotation of the main axis of the gearing head The part fixing unit (the machine plate) has a rotation axis, axis B, for rotating the part. 1. External Gearing head – the housing of the tooth milling head is a GG300 gray cast iron cast piece. On the front side there are the counter guides of the Y axis (vertical movement of the head). Inside are the main tool actuation mechanisms, the mechanism for the horizontal movement of the gearing head axis and the mechanism for tilting the gearing head. The main actuation mechanism of the gearing shaft is composed of a 55 kW – S1 motor, a ZF angular reducer and a gearing shaft, mounted in the housing of the toothing horse. 2. Internal Gearing head – the housing of the tooth milling head is a GG300 gray cast iron cast piece. On the front side there are the counter guides of the Y axis (vertical movement of the head). Inside are the main tool actuation mechanisms, the mechanism for the horizontal movement of the gearing head axis and the mechanism for tilting the gearing head. The main actuation mechanism of the gearing shaft is composed of a 55 kW – S1 motor, a ZF angular reducer and a gearing shaft, mounted in the housing of the toothing horse. 3. The Quill - has the role of fixing the high parts, having a vertical displacement stroke. 4. The longitudinal advance mechanism of the upright, X axis – is made by a servo motor 30 Nm_ 3000 rpm, a Gressner worm reducer and a ball screw diam. 80 x 10, accuracy class IT 3. 5. The vertical advance mechanism of the toothing head, Y axis – consisting of a 30 Nm_ 3000 rpm servo motor, a Gressner worm reducer and a ball screw diam 80 x 10, precision class IT3. 6. Plate advance mechanism / plate rotation, C axis – is made with two 50 Nm_ 2000 rpm servo motor, a Gressner worm reducer and a duplex worm that meshes with the worm crown located on the plate. 7. The gearing head tilting mechanism, axis B – is made by a / 20 Nm_3000 rpm servo motor, a Gressner worm reducer and a worm gear-segment worm gear transmission. 8. The axial displacement mechanism of the gear head, Z axis – is made by a 20 Nm_3000 rpm servomotor, an Alpha Getriebe planetary reducer and a ball screw diam. 63 x 10, accuracy class IT3. 9. Top horizontal positioning mechanism, auxiliary axis X1 – a 20 Nm_ 2000 rpm servo motor, an Alpha Getriebe planetary reducer and a ball screw diam 63 x 10, precision class IT5.
