Used Studer S 30 for sale (65)

Condition: used, TECHNICAL DETAILS - distance between centers : 200 [mm] - centers height : 100 [mm] - strokes (X/Z) : 130 / 170 [mm] WHEELHEAD - grinding wheels dimensions : 400 x 63 x 127 [mm] - peripheral speed : 45 [m/sec] - power : 3 [kW] - positioned at : 30 [°] WORKPIECEHEAD - type of cone: MT4 - speeds : 600 - 3000 [rpm] - power : 0,5 [kW] - C axis indexing precision : +/- 0,5 [°] TAILSTOCK - type of cone : CM2 - quill stroke : 30 [mm] ELECTRICAL SUPPLY - voltage : 400 [V] - frequency : 50 [Hz] - installed power : 19 [kVA] DIMENSIONS - floor space : 1760 x 2180 [mm] - height : 2630 [mm] - weight : 4.000 [kg] HOURS - under power : 46.943 [h] - working hours : 21.529 [h] EQUIPMENT - CNC FANUC 16TB - soft options : Studer Release B, Pictogramming - interface : RS232C Hfedpfx Aouhbxmofhsk - electronic deported handwheel - direct measuring rules on axes X/Z - tailstock with fine concentricity adjustment - tailstock pinole hydraulic recoil - swiveling dressing wheel upon table : FISCHER AES-72x230/3 - dynamic wheel balancing device : DITTEL HBA 4000 - prepared for diameter sensor : MOVOMATIC ES400 - prepared for parts loading/unloading robot : FELSOMAT - automatic front door - prepared for cooling - electrostatic aspiration : ELOSTA BF2000 - pneumatic collets chuck - 1 wheel-holder - 1 grinding wheel - support arm for zero gravity wheel change - 1 balancing shaft

Condition: used, TECHNICAL DETAILS - Centers height : 125 [mm] - Distance between centers : 400 [mm] - Grinding wheels dimensions : 400 x 127 x 50 [mm] - Power : 4 [kW] - Max. part weight : 30 [kg] - Floor space : 3000 x 3520 [mm] - Weight : 4000 [kg] EQUIPMENT - CN FANUC 21i-T - B axis with 1° precision - Chuck 3 jaws - Tool-holder flanges - 1 external grinding wheel Hjdsuhbxtspfx Afhefk - 1 diamond grinder - Tail stock with fine adjustment - 1 internal grinding devices with spindle 42000 rpm - Coolant tank with paper filter - Part probe

Condition: used, TECHNICAL DETAILS - Number of axes : 5 - Distance between tips : 400 [mm] - Effective diameter : 180 [mm] LINEAR AXES - X1 and X2 x Z travel : 220 [mm] - Z travel : 850 [mm] - X x Z resolution : 0.0001 [mm] TURRET : - Number of fixed positions : 12 - Tool holders : VDI30 WHEEL CARRIER Hsdpfx Afovxw A Uohefk - Right-hand external grinding : * Grinding wheel dimensions (Ø x width x bore) : 400 x 50 x 127 [mm] * Drive power : 6.8 [kW] WORKPIECE CARRIER - Max. speed : 7500 [rpm] - Speeds (synchronous operation) : 1 - 5000 [rpm] - Taper type : CM4 - Drive power : 10.5 [kW] - C axis : 0.001 [°] SYNCHRONIZED COUNTER SPINDLE - Max. speed : 7500 [rpm] - Rotational speeds (synchronous operation) : 1 - 5000 [rpm] - C axis : 0.001 [°] - Inner cone : MK4 - Micrometric adjustment : +/- 40 [microns] - Drive power : 10.5 [kW] POWER SUPPLY - Power rating : 45 [KVA] DIMENSIONS - Floor dimensions : 2800 x 3960 [mm] - Machine weight : 7600 [kg] MACHINE HOURS - Powered hours : 57000 [h] EQUIPMENT - NC FANUC 310i-modelA - Software Studer WIN - RS232 / USB interface - Remote electronic handwheel - Turret with Renishaw LP2 length self-calibration device - Marposs feelers for diameters (multirange) + Z4 axes for positioning - Semi-automatic wheel balancing MPM.3 BMT100 M.24 - 480 L coolant tank * with paper filter * with magnetic filter - Chip conveyor - Fog extraction - Cooling unit for grinding wheel motor cooling - Electronic contact detection Dittel AE6000 - Fixed dressing device on workhead - Electrical cabinet air conditioning - Balancing shaft - Interface for automatic loading system

Condition: used, TECHNICAL DETAILS - Axes number : 6 - Centers height : 175 [mm] - Distance between centers : 650[mm] LINEAR AXES - Grinding length : 800 mm - Strokes X x Z: 310 X 850 [mm] GRINDING WHEEL HOLDERS HEADSTOCK - Taper type : - Continuous orientation ( B axe) : +/- 9 [°] - C Axis indexing precision ( High speed machining): 0.001 [°] - External grinding wheel dimensions : 500 x 80 x 20 [mm] - Grinding wheel holder headstock power : 12.5.5 [kW] - Rotation speed : 1400-3200 [Rpm] PART HOLDER HEADSTOCK - Taper type : ISO50 - Axis C indexing precision : 0.001 [°] - Power : 4[kW] - Rotation speed : 1-1000 [Rpm] SYNCHRONIZED COUNTER SPINDLE - Taper type : CM4 - Quill stroke (w axe) : 90 [mm] - Quill diameter : 50 [mm] - Power :1.6[kW] - Max. part weight between centers :50 [Kg] ELECTRICAL SUPPLY - Supply tension : 400 [V] 50[Hz] MACHINE HOURS - Number of working hours : 36000 Hfodpfx Aeu Haf Ejfhsk EQUIPMENT - CNC FANUC 31i-A control - Sofwares * StuderWIN * Pictogramming * StuderThread only cycles * StuderTechnilogy - Remote control with electronic handle - Measuring rules on axes X and Z - Automatic length probe arm MOVOMATIC C25 - In-process external diameter probe arm MOVOMATIC DM205 - Coolant tank 375 liters - Paper filter - Oil mist aspiration - Grinding wheel loading arm - Dressing wheel diamond device ( Dia 100mm) - SENSITRON - Automotic dynamic balancing DittelM6000 - Grinding wheel holder flanges - Interface for AROBOTECH steady - Interface B3 PROFIBUS for automatic loading

Condition: used, TECHNICAL DETAILS - Number of axes : 3 - Centers height : 175 [mm] - Distance between centers : 1000 [mm] LINEAR AXES - Grinding length : 500 [mm] - Travels X x Z : 267 X 650 [mm] GRINDING WHEEL HOLDER HEADSTOCK - Continuous orientation : +/-8,5 [°] - External wheel dimensions : 500 x 80 x 203 [mm] - Grinding wheel holder headstock power : 7,5 [kW] - Cutting speed : 44 [m/s] PART HOLDER HEADSTOCK - Taper type : CM5 - Axis C : +/-0.5[°] - Power : 1 [kW] - Rotation speed : 30-1000 [Rpm] TAILSTOCK - Taper type : CM3 - Quill travel : 35 [mm] - Quill diameter : 50 [mm] - Max. part weight between centers : 130 [kg] ELECTRIC SUPPLY - Supply voltage : 400V 50 Hz - Machine dimensions : 2700 x 2350 x H. 2100 [mm] - Weight : 4 000 [kg] HOURS - Working hours : 17.775 [h] EQUIPMENT - CNC FANUC 16i-TA control - Pictogramming - Studer RELEASE C - Electronic handwheel - SENSITRON - Dynamic balancing device : Hydrobalance HBA 40000-1 - Automatic length probe arm MOVOMATIC C25 - Automatic outer diameter probe arm in-process MOVOMATIC - Grinding wheel safety guard with automatic toppling - Fixed grinding device upon part-holder headstock Hfedpfsuhbydex Afhok - Coolant tank : 375 [l] - Paper filtering unit - Oil mist extractor - Wheel-holders flanges

Condition: used, TECHNICAL DETAILS - Distance between centers : 1000 [mm] - center height : 175 [mm] - X/Z stroke : 285/1150 [mm] - Axis X programmable feed speed : [mm/min] - Resolution : 0.0001 [mm] - Axis Z programmable feed speed : [mm/min] - Resolution : 0.0001 [mm] Hedpsxt U Rhefx Afhofk GRINDING WHEEL HOLDER HEADSTOCK - Orientation : 0/30 [°] * Grinding wheel dimensions : 500x63 [mm] PART-HOLDER HEADSTOCK - Type of cone : ISO50 - TAILSTOCK POWER SUPPLY - Supply voltage : 400 [V] MACHINE HOURS - Number of hours under power : 30064 [h] EQUIPMENT - CNC : FANUC Oi-TD - Electronic handwheel - Automatic diamond device - Coolant tank * with paper filtering unit

Condition: like new (used), Year of construction: 1995, functionality: fully functional, center height: 225 mm, workpiece weight (max.): 100 kg, grinding length: 1,600 mm, CNC cylindrical grinding machine STUDER S40, year of manufacture 1995. The machine is in good used condition. Technical data: • Control: Fanuc Series 16-GC • Required space approx. (Height/Length/Width): 250 cm / 650 cm / 320 cm Axes: • Distance between centers: 1,600 mm • Center height: 225 mm • 4 axes (X, Z, B, C) • Max. workpiece weight approx.: 100 kg Equipment: • 2 grinding wheels + 1 internal grinding stone (selectable via control) • Face, plunge, internal, and cylindrical grinding • Magnetic chuck, three-jaw chuck, collets, between-centers grinding • Automatic dressing device • Steady rest • Resolution: 0.0001 mm • Polygon grinding • Static balancing unit • Grinding wheels available in corundum, diamond, and CBN • Cycle control Hedpjt N Ivcjfx Afhjfk • DXF import possible

Condition: refurbished (used), functionality: fully functional, Studer S20 Favorit (latest version with updated PLC/automation) High-precision cylindrical grinding machine for external and internal grinding. - Distance between centers: 400 mm - Height between centers: 100 mm - Currently undergoing a complete reconstruction (retrofit) to deliver performance and precision comparable to a new machine. - Equipped with renewed components and adjusted to ensure maximum reliability and precision. - A wide range of accessories is available upon request. - Delivery time: please inquire Hsdpfxjzcytbs Afhofk - The photographs show a reference machine of the same model, which was reconditioned by us. Project reference: OP26-003

Condition: excellent (used), Year of construction: 2008, operating hours: 32,109 h, functionality: fully functional, center height in crank: 170 mm, center height: 175 mm, workpiece weight (max.): 80 kg, grinding length: 600 mm, center width: 350 mm, grinding wheel diameter: 500 mm, grinding diameter: 300 mm, distance between centers: 600 mm, workpiece diameter between centers: 300 mm, workpiece length between centers: 600 mm, grinding wheel width: 100 mm, feed rate X-axis: 285 m/min, input voltage: 380 V, TECHNICAL DATA: - Table tilt +8.5° - X-axis travel 285 mm - B-axis travel 800 mm - Angular grinding at 1° at –15° + 195 - Grinding wheel 500x63, 50 m/s - Distance between centres 600 mm, max 80 kg - Chuck B32 - Tailstock quill stroke 63 mm - Fine adjustment of tailstock 0.04 mm - FANUC 21-TB control, 10.4'' - Memory 64 KB - Coolant tank 375l with automatic filter paper feed Hedpfx Asy E N Iuofhjfk ADDITIONAL EQUIPMENT: - Steady rest ARBOTECH – GR – 055V - MARPOSS measuring device UNIMAR S30 - MARPOSS measuring device P4 - MPM wheel balancing system This S33 grinding machine is additionally equipped with a MARPOSS device for fast and precise measurement of workpieces, an ARBOTECH auxiliary unit for grinding workpieces in a single setup, and a grinding wheel balancing system. The machine has been serviced annually by the manufacturer STUDER. It is highly precise and in excellent condition. It has been used for tooling jobs in batches of up to a maximum of 50 pieces. The machine is connected to the electrical network and ready for operation.

Condition: reconditioned (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 055 - 030.0221, Complete overhaul Year 2003 - Fanuc 16i-T Center height 175 mm and distance between centers 650 mm 2 external grinding wheels + B-axis fine adjustment Country of origin: CH Voltage: 3x400V Dimensions: 3680x2165x2100 mm Net machine weight: 5500 kg TECHNICAL SPECIFICATIONS Center height: 175 mm Distance between centers: 650 mm LONGITUDINAL SLIDE (Z) Maximum travel: 800 mm Speed: 0.001 – 10,000 mm/min Hodpozbaz Aofx Afhjfk Resolution: 0.0001 mm TRANSVERSE SLIDE (X) Maximum travel: 254 mm / SPW 650 Speed: 0.001 – 5,000 mm/min Resolution: 0.0001 mm Maximum weight of workpiece clamped between centers: 80 kg TAILSTOCK Taper: Morse 3 Sleeve: Ø 50 mm Sleeve travel: 35 mm UNIVERSAL GRINDING WHEEL HEAD Left wheel dimension: 500 x 80 x 203 mm Right wheel dimension: 400 x 80 x 203 mm Grinding wheel head power: 12.5 kW Rotation speed: 3,200 min-1 Programmable cutting speed up to: 50 m/s B-axis travel: -15 to +195° B-axis indexing accuracy: 0.0001 ° LEFT WORKPIECE HEAD Taper: CM3 Power: 4 kW Rotation speed: 1-1000 min-1 C-axis indexing accuracy: 0.001 ° RIGHT WORKPIECE HEAD Taper: CM3 Power: 4 kW Rotation speed: 1-1000 min-1 C-axis indexing accuracy: 0.001° Hydraulic feed with pressure control Subject to errors and omissions, the technical specifications are provided without commitment. Inventory No. 2250029: STUDER S31 CNC, S/No. 055 - 030.0221 Completely overhauled: Mechanical, geometry, hydraulics, and electrical components (checked and/or replaced) Grinding wheel head Disassembly, cleaning of parts, replacement of worn and defective parts, overhaul of the motor, replacement of bearings, replacement of belts, spindle disassembly, replacement of seals and O-rings + adjustment. New paint. Workpiece head Disassembly, cleaning of parts, replacement of worn and defective parts, overhaul of the motor, replacement of belts. New spindle bearings. New paint. Tailstock Disassembled, inspected, overhauled Hydraulics Disassembly, motor check, replacement of pipes, defective and worn parts. Check the hydraulic block. X-axis Disassembly, replacement of worn parts such as O-rings, seals, segments, etc., overhaul of the hydraulic piston, re-grinding of the tables. Z-axis Disassembly, re-grinding of the tables, replacement of worn and defective parts, overhaul of the hydraulic piston, new paint. Electrical cabinet Complete check, replacement of various relays. Paint Colors: White RAL 9003 and gray RAL 7011 Geometry according to manufacturer's protocol. Inspection and cleaning of various accessories.

Condition: refurbished (used), Year of construction: 2025, IMMEDIATELY AVAILABLE Studer S20-2 – Mechanically Reconditioned Grinding length: 400 mm Center height: 100 mm Table swivel: 30° Bore diameter: 127 mm Grinding wheel dimensions: 350 x 32 mm Tool holder taper WSS: MK4 (stationary and rotating center) Hsdjfg Tbrspfx Afhefk Tool holder taper RST: MK2 Tailstock quill travel: 20 mm Workpiece weight: 20 kg Tailstock with manual runout compensation Further optional features: - Glass scale in X and Z axes - Internal grinding device - Grinding wheel flange - LED spotlight with flexible arm - Coolant system - Safety device

Condition: as good as new (ex-display), Year of construction: 2025, Studer S40 1000/1600 Grinding length: 1,000/1,600 mm Center height: 175 mm (optionally more) Workpiece weight: 120 kg Hfjdpfxofg S Uae Afhek Additional freely selectable options: - Completely new control cabinet with Siemens Sinumerik One or Fanuc 0iTF-Plus control - Quick setup via GSN user interface - B-axis freely positionable - Second external grinding wheel - Internal grinding unit - Center height adjustment - Dressing spindle for diamond dressing roll - Balancing and finishing sensor - Hydraulic clamping/releasing of the tailstock - Automatic Siemens door drive - 19" / 22" screen - Remote maintenance - Conversion to needle nozzles - Matching coolant/extraction system - Automation preparation - and much more We would also be happy to overhaul your existing machine! Schaudt / Studer / Kellenberger / Bahmüller / Voumard / Overbeck / Fortuna / Tacchella and others.

Condition: refurbished (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 027.0149, CNC internal and external cylindrical grinding machine S33 CNC – undergoing refurbishment. Delivery time: approximately 14 weeks. Technical data and accessories as per the attached PDF. Photo = sample photo only. Hfsdpfx Ajzcuwbofhok

Condition: used, Year of construction: 1982, grinding diameter:250 mm grinding length:650 mm centre height:125 mm internal grinding spindle rev.-stepless:9500-50000 U/min workpiece speeds -stepless:50-10000 mm/min grinding head swivelling:90 Grad max. dia. of grinding wheel:400 mm spindle bore:30 mm grinding length - plunge feed:80 (100) mm max. grinding depth by internal grinding:ca. 170 mm max. bore diameter to be ground:90 mm feed speeds:240 mm/min max. workpiece weight:80 kg required cooling water:36 l/min centre distance:650 mm distance of workpiece spindle-taper cone:960 mm drive capacity - spindle motor:6,25 kW connected load:ca. 10 kW Hsdpfxecxxubs Afhefk total power requirement:8,5 kW weight of the machine ca.:3,4 t dimensions of the machine ca.:3,9 x 2,5 x 1,85 m with Studer control, electric/hydraulic drive, variable speed, tailstock with fine adjustment and hydraulic back feed, work piece headstock with increased precision, table air , hydraulic removable dressing device, radius-dressing device, Hydro-Cyclone filter, automatic grinding wheel-balancing device, automatic dressing cycle with speed compensation

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 011.257.90.043, center height: 175 mm, center width: 1,000 mm, controller manufacturer: Fanuc, TECHNICAL DETAILS Maximum turning height: 175 mm Maximum turning diameter: 1,000 mm Longitudinal slide Maximum longitudinal slide travel: 1,050 mm Cutting speed (vt): 0.0001–10,000 mm/min Hfjdpfxozb Hxne Afhsk Resolution: 0.0001 mm Table tilt: max. 8.5° Cross slide Maximum cross slide travel: 275 mm Cutting speed (vt): 0.0001–10,000 mm/min Resolution: 0.0001 mm MACHINE DETAILS Control system manufacturer: Fanuc EQUIPMENT - Internal grinding attachment

Condition: good (used), cylindrical grinding machine Hjdpfxstrgndo Afhsfk

Condition: refurbished (used), functionality: fully functional, equipped with a FANUC 16-T CNC control system. Hjdpfx Aey Txk Uofhjfk Technical data and accessories are provided in a separate PDF. The machine has been completely mechanically overhauled.

Condition: refurbished (used), Year of construction: 2025, operating hours: 36 h, functionality: fully functional, machine/vehicle number: 1024-54, Country of Manufacture: Switzerland Voltage: 380/50/3 Net weight: approx. 1600 kg Customs tariff: 8460.2920 Dimensions: 235 x 155 x 145 cm TECHNICAL FEATURES: MAIN DIMENSIONS: Centre height: 100 mm Distance between centres: 400 mm LONGITUDINAL SLIDE: Max travel: 420 mm Minimum automatic travel: 1 mm Table feed speed: 100–3500 mm/min Overtravel delay: 0–5 sec. Maximum table swivel (400/650 mm): 30°/15° CROSS SLIDE: Max travel: 170 mm Rapid traverse: 30 mm Plunge depth (diameter): 1.9 mm Feed rate 1: 0.03–1.5 mm/min Feed rate 2: 0.02–0.3 mm/min Plunge feed per impulse: 0.0005–0.025 mm WHEELHEAD: Grinding wheel (diameter x width x bore): 350 x 32 x 127 mm Drive power: 3 kW Peripheral speed: 30 m/s Spindle speeds: 1600/1975/2200 rpm Manual stroke: 120 mm Swivel to right: 15°/30° Optional wheel guard for wheel set max width: 50 mm WORKHEAD: Swivel range: 0°–90° Spindle speeds: 80/175/380/800 rpm Internal taper: Morse 4 Collet type: W-20 Drive power: 0.5 kW Maximum workpiece weight: 20 kg Load for in-the-air grinding: 12 Nm Optional stepless drive speed range I: 30–300 rpm Optional stepless drive speed range II: 120–1200 rpm TAILSTOCK: Internal taper: Morse 2 Quill travel: 20 mm GUARANTEED WORKING ACCURACY: Generator straightness: Between centres: 400 mm Measured over 400 mm: 0.002 mm Between centres: 650 mm Measured over 650 mm: 0.003 mm Roundness accuracy for in-the-air grinding: 0.0004 mm Hodpfx Afjw T Sc Njhefk CONNECTION VALUES: Power consumption: max. 8 kVA Permissible voltage variation: –15% / +10% Permissible frequency variation: ±3% Compressed air: 5 bar All technical specifications are given without obligation and subject to errors or omissions.

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 027.0400/067, CNC CYLINDRICAL GRINDER STUDER S-33 CNC Year: 2007 - Fanuc 21i-TB 1 External Grinding Spindle Country of Origin: Switzerland Hjdpfx Afew T Sh Ejhjfk Voltage: 380/50/3 Net machine weight: 4,000 kg TECHNICAL SPECIFICATIONS Distance between centers: 600 mm Center height: 175 mm Maximum workpiece weight: 80 kg Longitudinal Slide Z Max. travel: 800 – 1,150 mm Travel speed: 0.001 to 10,000 mm/min (early 2000’s model: 0.001-5,000 mm/min) Resolution: 0.0001 mm Cross Slide X Max. travel: 285 mm Travel speed: 0.001 to 20,000 mm/min (early 2000’s model: 0.001-10,000 mm/min) Resolution: 0.0001 mm Wheelhead (universal version) Swiveling range: -15° to 225° (early 2000’s model: -15° to 195°) Swivel axis: 2.5 / 1 ° Hirth Drive power: 7.5 or 9 kW or 11 kW Grinding wheel: 500x63 (80/110F5) x203 mm Workhead Rotational speed: 1 – 1,500 min-1 Mount taper: MT4 or MT5 / ISO 50 Drive power: 1.6 or 3.0 or 4.0 kW Tailstock Mount taper: MT3 or MT4 Quill stroke: 35 / 50 mm (early 2000’s model: 35 mm) Quill diameter: Ø 50 mm Fine adjustment: +/- 40 µm Control system: Fanuc 21i-TB All technical details are provided in good faith but subject to errors or omissions.

Condition: refurbished (used), machine/vehicle number: 1015.54, Completely overhauled cylindrical grinding machine. Centre distance 400 mm, centre height 100 mm. Technical data and accessories as per separate PDF. Hfsdpfx Ajy Hhk Defhsk

Condition: excellent (used), FANUC 21i-T Control Center Height 175 mm Distance between centers 1000 mm Grinding head B-axis 1° Hsdpfx Asyabt Djfhjfk Grinding wheel 500 x 63 x 203 mm Grinding wheel speeds -1'500 rpm Internal grinding attachement 60'000 rpm Work piece spindle head C-axis 0.001 ° Measuring probe Automatic balancing attachement Wheel dresser Misc. accessories MARCELS MASCHINEN AG

Condition: used, Year of construction: 2002, Studer S60 CNC – Very well-maintained machine Hjdpfoh Aykijx Afhsfk Operated solely with oil Year of manufacture: 2002 Center height: 225 mm Control system: Fanuc 16T

Condition: good (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 018.0179.90.035, (Please tell us your offer price) Sale only within Europe, incl. Turkey Price without packaging; delivery condition: FCA (machine location) ===== Technical data see handout. All warranty rights are excluded. For the correctness of the technical data and year of construction, for the completeness of accessories and tool equipment, and for compliance with all safety and environmental protection requirements specified in the accident prevention regulations. No sale to private individuals. Sales only within Europe, incl. Turkey Price without packaging; Delivery condition: FCA (machine location) Hfodpfx Afeyh R Uwshsk ===== Technical data please see handout in attachment. German text leading language. Without any guaranty and warranty, including completeness of tools & accessories as well as environmental and safety regulations. No private sales.

Condition: good (used), Distance between centers: 1000 mm Height of centers: 175 mm Grinding length: 500 mm Maximum grinding diameter: 300 mm Working wheel dimensions (OD x ID x W): 500 x 203 x 80/100 mm Internal Morse taper: 5 Working wheel motor power: 7.5 kW Total power: 17 kW Longitudinal travel of the carriage (X-axis): 267 mm Transverse travel of the carriage (Z-axis): 650 mm CNC brand: FANUC Hodjtt Rawepfx Afhofk CNC model: 16-T Rotating range: +/- 8.5º Dimensions: 2600 mm x 2300 mm x 2100 mm Approximate weight: 4200 kg

Condition: used, Year of construction: 2003, internal diameter 99999 mm grinding depth 99999 mm Hfjdpfx Afsuxft Sohek swing diameter 99999 mm grinding diameter 99999 mm grinding length 200 mm centre height 175 mm CNC internal grinding machine B-axis 4 x 90° Q-axis for adjusting tapers Used with minor maintenance 2 HF internal grinding spindles: -Fischer MFM 1090 90,000 rpm -Fischer MFM 1242/60 42,000-60,000 rpm 1 external grinding motor spindle Fischer MFVS1407 7,000 rpm -Pneumatic power clamping device with 20mm stroke -Dressing device with 2 swivelling arms, hydraulically foldable back -Grinding detection ring sensor Dittel on the workpiece headstock -Passive grinding detection with magnetic base -Paper belt filter 375 l
