Used Milling Copier Deckel for sale (701)

Condition: like new (used), Year of construction: 1985, functionality: fully functional, travel distance X-axis: 580 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 450 mm, rotational speed (max.): 4,000 rpm, controller model: Contour 1, NC Milling Machine Deckel FP4A We are offering for sale a perfectly maintained Deckel FP4A CNC milling machine (very low operating hours, in as-new condition)! Hedpfx Afsxzpwfsnjfc Technical Details: - Travel (X): 580 mm - Travel (Y): 400 mm - Travel (Z): 450 mm (390 mm*) - Table size: 460 x 800 mm - Spindle speed range: 40 – 4000 rpm - Feed rate: 2 – 3600 mm/min - Rapid traverse: 4.0 m/min - Spindle taper: SK 40 - Machine dimensions (LxWxH): approx. 3.0 x 2.10 x 2.10 m - Spindle drive power: 4.0 kW - Control: Contour 1 Description: CNC-controlled tool milling machine, equipped with Contour 2 control. Features include a vertical head rotatable +/- 90° with quill travel of 80 mm, horizontal spindle, power feeds & rapid traverse on all 3 axes, hydraulic tool clamping, flying desk, electronic handwheel, automatic central lubrication, coolant system, safety emergency stop, chip tray, and separate electrical cabinet. The machine is in top working condition. Note: This additional information is standard for this model. Please always verify the exact configuration during inspection. The DECKEL FP4A Universal Tool Milling Machine, built in 1985, is a classic and highly versatile metalworking machine renowned for its precision and flexibility – testament to Deckel’s strong tradition of engineering quality. The FP4A features a robust bed-type construction, delivering the necessary stability for precise milling tasks. Its universal tool milling head is a highlight, enabling a wide spectrum of operations—from basic drilling to complex contouring and profiling. This versatility makes it a valuable asset in tool and die manufacturing, as well as mold making. Key technical features of the 1985 DECKEL FP4A include a generously sized worktable, infinitely variable spindle speed adjustment, and an intuitive control interface for efficient programming and machine operation. The advanced CNC technology contributes to exceptional accuracy and operator convenience. Despite its age, the DECKEL FP4A continues to be a trusted solution for applications requiring flexible tool milling. Its reputation for reliability and precision makes it an essential tool for modern metalworking and manufacturing operations. Deckel’s legacy of quality and innovation in the field of metal machining is clearly evident in this model.

Condition: used, total height: 16,000 mm, total width: 1,100 mm, total length: 1,500 mm, Empty weight: 1.000 kg Milling machine miller, mill Model: Conventional Manufacturer: Deckel Type: FP2 Travel: 400x270x400mm Spindle-speed: 40-2000 pm Table: 700x330mm Spindle-take: ISO40 Motorpower: 2,2kW Machine-dimensions: 1500x1100x1600 Machine-weight: 1000kg. - Documentation available: No Hsdpfox S Eaysx Afnofc - CE certificate present: No - Drive system: Conventional - Power [kW]: 2.2 - X-axis travel [mm]: 400 - Y-axis travel [mm]: 270 - Z-axis travel [mm]: 400 - Table length [mm]: 700 - Table width [mm]: 330 - Min. spindle speed [rpm]: 40 - Max. spindle speed [rpm]: 2000 - Transport dimensions: 1500mm x 1100mm x 16000mm (l x w x h) - Transport weight [kg]: 1000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Year of construction: 1997, condition: used, Price: On request - Year: 1997 - Documentation available: Yes - CE marking present: Yes Hedpfx Aewh Shvefnefc - CE certificate present: No - Drive system: CNC - Control system brand: Heidenhain - Number of axes [pcs]: 5 - X-axis travel [mm]: 1200 - Y-axis travel [mm]: 880 - Z-axis travel [mm]: 800 - Table length [mm]: 5000 - Tool holder: SK40 - Max. spindle speed [rpm]: 18000 - Options: Digital readout - └ Type of digital readout: Heidenhain Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, total height: 2,000 mm, total width: 2,300 mm, total length: 3,000 mm, Empty weight: 3.200 kg - Documentation available: No - CE certificate present: No - Drive system: Conventional - Number of axes [pcs]: 3 - X-axis travel [mm]: 800 - Y-axis travel [mm]: 450 - Z-axis travel [mm]: 500 - Table length [mm]: 1050 - Table width [mm]: 625 Hfedownif Sopfx Afnjc - Tool holder: ISO40 - Min. spindle speed [rpm]: 32 - Max. spindle speed [rpm]: 1600 - Options: Digital readout - └ Type of digital readout: Heidenhain - Transport dimensions: 3000mm x 2300mm x 2000mm (l x w x h) - Transport weight [kg]: 3200kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: reconditioned (used), Year of construction: 1988, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 50 rpm, quill stroke: 60 mm, total height: 1,935 mm, total length: 2,000 mm, total width: 200 mm, rotational speed (max.): 2,500 rpm, rotational speed (min.): 50 rpm, type of input current: three-phase, overall weight: 1,445 kg, table length: 460 mm, workpiece weight (max.): 400 kg, table load: 400 kg, table width: 800 mm, year of last overhaul: 2013, warranty duration: 6 months, The machine was completely and professionally overhauled by us in 2013. We were able to repurchase the machine from a customer who had used it very little, and we fully serviced and inspected it. Control 3-axis - Active - Digital display HEIDENHAIN TNC 113 Speed 50 - 2500 rpm, geometrically stepped direct drive with 18 speed stages for maximum torque / milling performance Feed 6.3 to 630 mm/min, steplessly adjustable Rapid Traverse 1.3 m/min Quill Extendable quill, vertical 60 mm, SK40 with M16 drawbar thread, optionally: with DECKEL - saw thread S20 x 2 Extendable quill, horizontal approx. 100 mm Axes X/Y/Z 500/400/400 mm Table Hfsdpfjyitxqjx Afnoc Rigid angle table 800x460 mm Equipment • Vertical and horizontal spindle • Milling head manually swivels +/- 90° • Central lubrication Options • Z-axis bellows • Chip tray • Machine lamp • Universal table • Rotary table • Slotting head • Dividing attachment • Counter-holder • etc.

Condition: new, Year of construction: 2026, Completely refurbished machine, as new, modernized to the legally prescribed "state of the art" safety standard in accordance with the safety regulations of the employers' liability insurance associations. Switch cabinet electronics Installation of a new CE - control cabinet according to the current legal regulations of the professional associations BGVA 3 / DIN-EN 60204-1 new machine standard. Optionally complete machine in CE execution. A CE declaration of conformity is issued for the machine. With this FPS Werkzeugmaschinen GmbH acts as manufacturer. The machine fulfills the requirements of the BETRIEBS-SICHERHEITSVERORDNUNG- Betr.SichV. The year of manufacture corresponds to the date of delivery of the machine. EN ISO 12100, EN ISO 13857, DIN EN 13128:2009-09, EN ISO 13850, EN ISO 13849, EN 60204-1 Control system 3-axis - FPS Active - digital display Speed 25 - 2500 rpm geometrically stepped direct gear with 18 speed steps for maximum torque / milling power Feed rate 5 to 500 mm/min, infinitely variable rapid traverse 1,2 m/min quill Extendable quill, vertical 100 mm SK40 with M16 tightening thread optional: with DECKEL - saw thread S20 x 2 Extendable quill, horizontal approx. 100mm Axes X/Y/Z 800/300/400 mm Table rigid angular table 1000x440mm, load 2000kg Equipment - Vertical and horizontal spindle - Milling head manually tiltable +/- 90 °. Hedpfjh Sptnox Afnjfc Options - Z-axis bellows - chip tray - machine light - central lubrication - universal table - rotary table - Shaper head - dividing head - counterholder - etc.

Condition: good (used), TOOL MILLING MACHINE - Deckel FP 3 incl. Heidenhain 3-axis digital readout - Machine with spindle brake motor - Travel X/Y/Z 500x300x400 mm - Automatic feeds on all 3 axes - Rapid traverse on all 3 axes - Heidenhain 3-axis digital readout - Speed range 40-2000 rpm - Swivelling vertical head with quill - Vertical-horizontal milling device - Tool holder ISO 40 - Drive power 3 kW - Rotary/tilt/swivel table Hodox Nh D Ajpfx Afnjfc - Coolant system - Machine feet - Machine documentation Dimensions: LxWxH 1.6x1.2x1.8 meters / Weight: 1500 kg Errors and input mistakes excepted.

Condition: excellent (used), Tool Milling Machine DECKEL FP 2 with new 3-axis digital readout from laboratory operation - Well-maintained original condition - Travel X/Y/Z 400x200x400mm - Digital readout 3 axes "NEW" - Swivel table – clamping surface 700x350mm - Spindle speed range 40 – 2000 rpm - Automatic feed / rapid traverse on all three axes - Tool holder ISO 40 - Vertical - horizontal milling device - Vertical head swiveling with quill - Coolant system - Documentation Hjdpjx Hahujfx Afnofc Dimensions: LxWxH 1.5x1.7x1.8 meters / Weight 1500Kg Subject to errors and input mistakes.

Condition: excellent (used), DECKEL FP 2 LB Tool Milling Machine from University in Well-Maintained Original Condition Hodpfex Da Erox Afnefc - 3-axis digital readout "ACURITE" - Travel (X/Y/Z): 795x300x400mm - Automatic feeds / rapid traverse on all 3 axes (18 settings) - Spindle speeds 40-2000 rpm (18 steps) - Horizontal and vertical milling attachments - ISO 40 tool holders - Table clamping surface: 1000x440mm - Table clamping surface with auxiliary table: 1000x700mm - Swivelling vertical head with quill - Coolant system - Various tool holders - Machine light - Documentation Dimensions: LxWxH: 2.5x2.4x1.8 meters / Weight: 2200 kg Errors and omissions excepted.

Condition: good (used), TOOL MILLING MACHINE DECKEL FP 1 - Travel X/Y/Z: 245-150-340 mm Hfodpfx Afjx A D Nfsnsc - Without vertical head / Machine was used exclusively for horizontal milling operations - Speed range: 95 - 1900 rpm - Dividing head - Automatic feeds on X & Y axes - Various collets and tool holders - Documentation included Dimensions: LxWxH 1.1x0.9x1.6 meters / Weight: 600 kg Errors and omissions excepted

Condition: good (used), Tool Milling Machine / DECKEL FP 2E – from training facility - Travel paths X/Y/Z 400x200x400mm - Automatic feeds + rapid traverse on X/Z axis - Speed range 40-2000 rpm - Tool holder ISO 40 - Vertical/horizontal milling attachment - Swiveling vertical head with quill - Machine with sliding head / extended Y-axis travel - New control cabinet - Coolant system - Chip tray - Documentation Dimensions: LxWxH 1.5x1.6x1.8 meters / Weight 1500 kg Hodpfjxga Tuex Afnsfc Errors and omissions excepted.

Condition: used, Universal swivel-tilt-rotary table DECKEL type FVW, suitable for FP 2 or FP 3 (Deckel no. 62473). Table size: 700 x 240 mm. Swivel range: +/- 30° in all directions. Weight: approx. 90 kg. Hfjdpfx Afoxcilrensc

Condition: good (used), Tool Milling Machine DECKEL FP 1 with 3-Axis Active Digital Readout TNC 113 from educational institution - Travel X/Y/Z 300x160x340 mm - Speed range 40-2000 rpm - Infinitely variable feed on all three axes - Rapid traverse on all three axes - Vertical head adjustable by 100 mm - Vertical and horizontal milling setup - Tool holder ISO 40 - Drive power 1.5 / 1.9 kW - Fixed angle table - Chip tray - Coolant system - Work light - Documentation Hjdpfx Afow Rbxnjnefc Dimensions: LxWxH 1.3x1.2x1.7 meters / Weight 900 kg Errors and omissions excepted.

Condition: excellent (used), Year of construction: 1994, functionality: fully functional, Deckel KF 3 S type Copy Milling Machine Hfjdpsv E Rw Ssfx Afnsc Very good condition

Condition: ready for operation (used), functionality: fully functional, With many tools Hodpfx Asyh Nafsfnsfc

Condition: good (used), functionality: fully functional, With many tools. Hodjyh I T Rspfx Afnsfc

Condition: like new (used), Year of construction: 2010, operating hours: 32,498 h, travel distance X-axis: 500 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 400 mm, nominal power (apparent): 35 kVA, controller manufacturer: Heidenhain iTNC 530, workpiece width (max.): 500 mm, workpiece diameter (max.): 630 mm, workpiece weight (max.): 200 kg, total height: 2,590 mm, total length: 4,780 mm, total width: 4,410 mm, overall weight: 5,900 kg, spindle speed (min.): 18,000 rpm, spindle motor power: 35,000 W, Year of construction: 2010 CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 500 Y-axis travel mm: 450 Z-axis travel mm: 400 C-axis degrees: 360º (0,001) B-axis degrees: 0º/108º (0,001) Feed rates m/min: 80/50/50 Milling/turning table nc: Number of pallets: 1 Table dimensions mm: Ø500x380 Maximum workpiece size (D x H) mm: Ø630x500 Max. workpiece weight kg: 200 Spindle Spindle speed rpm: 18000 Spindle drive power kW: 35/25 (40%ED/cont) Spindle torque Nm: 130/87 Cooling Cooling through the Spindle Center bar: 40 Tool system Tool holder: HSK-A63 Tool magazine slots: 30 With free neighboring places mm: 130 With occupied neighboring places mm: 80 Max. Tool Length mm: 300 Chip-to-chip time s: 5 Equipment Chip conveyor Infrared probe blowing air through spindle center selectable via M-function Laser tool measurement for measuring tool length and diameter Programmable coolant nozzles Oil skimmer Ready for internal cooling (40/80 bar) RENISHAW Measuring probe Machine running times Under power: 54257 Spindle Working: 32498 Rated power kVA: 48 Basic machine dimensions / weight Hfodpfx Asyi Dnijfnoc Length mm: 4780 Width mm: 4410 Height mm: 2590 Weight kg: 5900

Condition: excellent (used), Year of construction: 2002, Deckel Maho DMU 80 P-Hi Dyn 5-Axis CNC Machining Center Year of manufacture: 2002 Control: Heidenhain 430 Hjdpfx Aox Dlf Rsfnofc X-axis travel: 800 mm Y-axis travel: 700 mm Z-axis travel: 600 mm B-Axis: Automatic swivel milling head C-Axis: NC rotary table: 900x630 mm Workpiece weight: 800 kg Tool holder: SK40 Tool changer: 60 positions Accessories: Chip conveyor High-pressure coolant 40 bar (IKZ) Handwheel Heidenhain TS 642 probe

Condition: like new (used), Year of construction: 2015, operating hours: 26,156 h, travel distance X-axis: 600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller manufacturer: Siemens 840D, workpiece length (max.): 850 mm, workpiece diameter (max.): 630 mm, workpiece weight (max.): 500 kg, total height: 3,100 mm, total length: 4,150 mm, rotational speed (min.): 1,200 rpm, spindle speed (min.): 12,000 rpm, Year of construction: 2012 CNC controller: Siemens 840D Axes X-axis travel mm: 600 Y-axis travel mm: 700 Z-axis travel mm: 600 C-axis degrees: 360º (0,001) B-axis degrees: -30º/180º (0,001) Feed rates m/min: 60 Rapid traverse m/min: 60 Hjdpfxsxuiibj Afnsfc Acceleration in the axes m/s2: 6/6/5 Milling/turning table nc: Number of pallets: 2 Table dimensions mm: Ø630 Maximum workpiece size (D x H) mm: Ø630x850 Max. workpiece weight kg: 500 Table rotation speed rpm: 1200 Spindle Spindle speed rpm: 12000 Spindle drive power kW: 35/24 (40%ED/cont) Spindle torque Nm: 111/77 Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 980 Tool system Tool holder: HSK-A 63 Tool magazine slots: 60 Tool changer: Double gripper With free neighboring places mm: 120 With occupied neighboring places mm: 80 Max. Tool Length mm: 450 Max tool weight kg: 15 Chip-to-chip time s: 4 Equipment Electronic Handwheel Chip conveyor Infrared probe Rotating inspection windows Rinsing gun Operating mode 4 blowing air through spindle center selectable via M-function NC swivel rotary table 3D quickSET MPC – Machine Protection Control Machine running times Under power: 26156 Spindle Working: 16472 Basic machine dimensions / weight Length mm: 4150 Height mm: 3100 Weight kg: 10000

Condition: excellent (used), Year of construction: 2012, operating hours: 18,648 h, CNC controller: Heidenhain ITCN 530 ERGOline Axes X-axis travel mm: 500 Y-axis travel mm: 450 Z-axis travel mm: 400 C-axis degrees: 360° (0,001º) B-axis degrees: –5° a +110° (0,001º) Rapid traverse m/min: 24 Worktable Table dimensions mm: 630 x 500 Maximum workpiece size (D x H) mm: 500 x 400 Max. workpiece weight kg: 200 Spindle Spindle speed rpm: 18.000 Spindle drive power kW: 13 / 9 KW (40 / 100% ED) Tool system Tool holder: SK 40 Tool magazine slots: 30 Hsdpfx Afew Rnxzsnefc Max. Tool Length mm: 300 Max tool weight kg: 6 Equipment Chip conveyor Workarea light Paper band filter Rotating viewing window with laminated glass Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 600 L Machine running times Under power: 18.648 Rated power kVA: 34 Operating Time: 6.226 Basic machine dimensions / weight Length mm: 2.800 Width mm: 2.800 Height mm: 2.600 Weight kg: 4.450

Condition: like new (used), Year of construction: 2000, operating hours: 33,831 h, travel distance X-axis: 1,250 mm, travel distance Y-axis: 880 mm, travel distance Z-axis: 800 mm, controller model: '3D contouring control Millplus, workpiece weight (max.): 1,000 kg, total length: 7,000 mm, total width: 3,500 mm, overall weight: 3,902 kg, spindle speed (min.): 18,000 rpm, spindle motor power: 15,000 W, Year of construction: 2000 CNC controller: '3D contouring control Millplus Axes X-axis travel mm: 1250 Y-axis travel mm: 880 Z-axis travel mm: 800 C-axis degrees: 360º (0,001) Feed rates m/min: 40 Rapid traverse m/min: 40 Milling/turning table nc: Number of pallets: 1 Hfsdexvrbispfx Afnsc Table dimensions mm: Ø1000 Max. workpiece weight kg: 1000 max. torque Nm: 7900 Spindle Spindle speed rpm: 18000 Spindle drive power kW: 15/10 (40%ED/cont) Cooling Tank capacity: 600 Tool system Tool holder: CAT 40 Tool magazine slots: 60 Tool changer: Doeble gripper Equipment Electronic Handwheel Chip conveyor Internal cooling lubricant supply Rotating inspection windows Rinsing gun Preapared for RENISHAW sonde Accuracy package Ready for internal cooling (40/80 bar) Paper band filter Machine running times Under power: 33831 Spindle Working: 6328 Rated power kVA: 55 Basic machine dimensions / weight Length mm: 7000 Width mm: 3500 Height mm: 3902

Condition: excellent (used), Year of construction: 2004, operating hours: 60,477 h, travel distance X-axis: 1,050 mm, travel distance Y-axis: 710 mm, travel distance Z-axis: 710 mm, controller manufacturer: Heidenhain iTNC 530, controller model: iTNC 530, workpiece weight (max.): 800 kg, total height: 3,000 mm, total length: 3,500 mm, total width: 2,500 mm, table width: 800 mm, table length: 800 mm, overall weight: 9,600 kg, spindle speed (min.): 18,000 rpm, Year of construction: 2005 CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 1050 Y-axis travel mm: 710 Z-axis travel mm: 710 B-axis degrees: 103º Feed rates m/min: 30 Rapid traverse m/min: 30 Milling/turning table nc: Number of pallets: 1 Table dimensions mm: Ø800 Max. workpiece weight kg: 800 Spindle Spindle speed rpm: 18000 Spindle drive power kW: 28 (40%) Spindle torque Nm: 121 Tool system Tool holder: SK 40 Tool magazine slots: 32 Tool changer: Pick-up Chip-to-chip time s: 14 Equipment Rigid table with integrated rotary table Swivel head Hjdpfx Afox Arcajnofc Infrared probe Rinsing gun blowing air through spindle center selectable via M-function Tool measuring arm Internal coolant supply Machine running times Under power: 151446 Spindle Working: 60477 Basic machine dimensions / weight Length mm: 3500 Width mm: 2500 Height mm: 3000 Weight kg: 9600

Condition: like new (used), Year of construction: 2013, operating hours: 39,945 h, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 580 mm, travel distance Z-axis: 400 mm, controller manufacturer: Heidenhain iTNC 530, total height: 2,900 mm, total length: 5,500 mm, total width: 2,650 mm, spindle speed (min.): 28,000 rpm, coolant supply: 40 bar, Year of construction: 2013 CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 450 Y-axis travel mm: 580 Z-axis travel mm: 400 C-axis degrees: 360º (0,0001) A-axis degrees: +10 / -110º Feed rates m/min: 80 Rapid traverse m/min: 80 Acceleration in the axes m/s2: 13 Milling/turning table nc: Number of pallets: System 3R (21 pallets type GPS 240, 30pallets type GPS 120 and 24 pallets type ITS50) Table dimensions mm: baseplate for root pallet Maximum workpiece size (D x H) mm: for pallet GPS 240 (275x275x200mm); for pallet GPS 120 (150x150x200mm) and for pallet ITS50 (ø70x200mm) Max. workpiece weight kg: 150 (pallet + workpiece) Spindle Spindle speed rpm: 28000 Spindle drive power kW: 35/25 (40%ED/cont) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 600 Tool system Tool holder: HSK-A 63 Tool magazine slots: 120 Tool changer: Double gripper Equipment Electronic Handwheel Chip conveyor Infrared probe Internal cooling lubricant supply Rotating inspection windows Rinsing gun blowing air through spindle center selectable via M-function Laser tool measurement for measuring tool length and diameter 3D quickSET Arrangement for external pallet management Accuracy package Internal coolant supply Electrical cabinet active cooling unit Spindle active cooling unit Toolholders are not included Tools are not included Paper band filter Machine running times Under power: 62983 Hfjdpsxv Av Rofx Afnec Spindle Working: 39945 Rated power kVA: 60 Basic machine dimensions / weight Length mm: 5500 Width mm: 2650 Height mm: 2900 Weight kg: 9500 + system 3R

Condition: like new (used), Year of construction: 2013, operating hours: 46,048 h, travel distance X-axis: 630 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 850 mm, controller manufacturer: SIEMENS 840D, workpiece weight (max.): 600 kg, table height: 500 mm, table length: 500 mm, rotational speed (min.): 18,000 rpm, CNC controller: SIEMENS 840D solutionline Operate Axes X-axis travel mm: 630 Y-axis travel mm: 800 Z-axis travel mm: 850 Worktable Number of pallets: 12 Table dimensions mm: 500x500 Max. workpiece weight kg: 600 Spindle Spindle speed rpm: 18000 Tool system Hfodpfx Afjyh Niaonec Tool holder: HSK-A63 Tool magazine slots: 303 Equipment Chip conveyor Rotating inspection windows Rinsing gun Blowing air through spindle center selectable via M-function High pressure pump Tool breakage probe Coolant gun MPC – Machine Protection Control Infrared probe CE Round pallet storage Cooling Cooling through the Spindle Center bar: 80 Tank capacity: 980 Machine running times Under power: 46048 Spindle Working: 29258

Condition: like new (used), Year of construction: 2009, operating hours: 47,443 h, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, number of slots in tool magazine: 180, controller manufacturer: Siemens, total height: 2,900 mm, total length: 4,950 mm, total width: 5,060 mm, overall weight: 14,000 kg, table length: 630 mm, table width: 800 mm, controller model: 840D-Powerline, torque: 980 Nm, coolant supply: 40 bar, feed length X-axis: 800 mm, feed length Y-axis: 800 mm, feed length Z-axis: 800 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 60 m/min, feed rate Z-axis: 60 m/min, spindle motor power: 32,000 W, rapid traverse Z-axis: 60 m/min, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rotational speed (max.): 8,000 rpm, spindle speed (max.): 10,000 rpm, table load: 1,000 kg, operating hours of spindle: 22,963 h, CNC controller: Siemens 840D-Powerline Axes X-axis travel mm: 800 Y-axis travel mm: 800 Z-axis travel mm: 800 C-axis degrees: 360º (0,001) B-axis degrees: 0-190º Feed rates m/min: 60 Rapid traverse m/min: 60 Milling/turning table nc: Number of pallets: 2 Table dimensions mm: Ø800x630 Max. workpiece weight kg: 1000 Table rotation speed rpm: 8000 max. torque Nm: 980 Spindle Spindle speed rpm: 10000 Hfsdpfsui Np Rjx Afnoc Spindle drive power kW: 44/32(40%ED/cont) Spindle torque Nm: 288/187 Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 980 Tool system Tool holder: HSK-A 100 Tool magazine slots: 180 Chip-to-chip time s: 4.5 Equipment Electronic Handwheel Chip conveyor Infrared probe Rinsing gun Operating mode 4 blowing air through spindle center selectable via M-function Signal lamp 3D quickSET Machine interface for FASTEMS system Paper band filter Machine running times Under power: 47443 Spindle Working: 22963 Basic machine dimensions / weight Length mm: 4956 Width mm: 5064 Height mm: 2900 Weight kg: 14000
