Used Gdw Guidance And Lathe for sale (11,505)

Condition: ready for operation (used), Year of construction: 1985, Immediately available, free of encumbrances: L & Z lathe, Elliott Bedpfx Adsz Huymo Iowu Type Concord 460 Year of manufacture 1985 Swing over bed 550 mm Swing over cross slide 310 mm Turning length 1000 mm Spindle bore 71 mm Drive power 7.5 kW Spindle speeds 10 – 1000 rpm Coolant system Chuck Tool holder with inserts Weight 2.5 tons Price: EUR 1,750.00 plus VAT, ex works.

Condition: used, Year of construction: 2016, controller manufacturer: Siemens, controller model: Sinumerik, _____ Description: Year of manuf. : 2016 Control : Siemens Sinumerik General: Year of construction:2016 Control:Siemens Sinumerik Chuck diameter:170 mm Swing diameter:240 mm Travel X/Z:720 / 300 mm Spindle: Speed:6,000 rpm Chuck:3-jaw chuck SMW Autoblok KNCS-N 170-43 Bwodpfez Htpgjx Ad Iju Tool carrier: Technology:Turret, 12 stations Tool holder:VDI 42 Driven tool holders:Yes Automation: Technology:Integrated workpiece storage Features / Accessories: Chip disposal:Chip conveyor Coolant filtration:KNOLL band filter system (type 240 S-1) Fire protection:Kraft & Bauer argon extinguishing system

Condition: new, turning diameter 420 mm turning length 1500 mm swing diameter over bed slide 250 mm Swingdiameter in the bed bridge 590 mm centre height 210 mm Turning length in the bed bridge 260 mm reus 16 (45-1800) U/min tail stock MK 4 quill stroke 120 mm diameter of quill 50 mm spindle taper DIN ISO 702-2 Nr. 6 spindle bore 52 mm spindle cone MK 6 feed längs 17 / 0,05 - 1,7 m/min feed plan 17 / 0,025 - 0,85 m/min total power requirement 4,6 kW weight of the machine ca. 1340 kg dimensions of the machine ca. 2440 x 915 x 1375 mm Fully equipped master and feed spindle lathes. TH 4215 with digital position indicator DPA 21 / 3462070 - Hardened and ground Z-axis guideway - Spindle mount Camlock DIN ISO 702-2 No. 6 - Precisely crafted slide - Hand wheels with adjustable fine scaling 0.04 / 0.02 mm - Quadruple steel holder - All guides can be adjusted using V-ledges - Adjustment range top slide ± 90° - Guaranteed concentricity of the spindle nose better than 0.015 mm - Main spindle running in oil bath - Smooth-running gear wheels, hardened and ground with 2 adjustable Precision tapered roller bearings - Hand wheels decoupled and tested according to EN 23125 - Two-channel right-left switch tested according to EN 23125 - Switch with life cycle calculation, tested according to EN ISO 13849 Bsdpfx Adsk Egrps Iswu - All metric pitches in the range 0.2 to 14mm/rev and all Inch threads in the range of 72 - 2 threads per inch without changing the Change gears adjustable by shift lever in the control panel - Clockwise/counterclockwise rotation can be switched on the bed slide via the switching spindle - Central lubrication in bed slide - Meehanite cast base and machine bed in one piece - Lead screw cover - Emergency stop device with foot control - Safety handwheels with snap-out function in the X and Z axes - Tailstock for taper turning adjustable ± 10 mm - Tailstock quill and hand wheel with adjustable fine scaling 0.025 mm - Quick, easy and tool-free adjustment using a clamping lever - Heavily ribbed prism bed, induction hardened and precision ground cast iron - Coolant device with separate coolant tank with level indicator and oil separator; easy and complete emptying and cleaning according to DIN - LED machine lamp in the chip guard Models TH 4210D and TH 4215D with digital readout DPA21 - User-friendly membrane keyboard, splash-proof, closed andglare-free - Glass scales scope of delivery - Fixed bezel passage Ø 15 - 145 mm - Revolving bezel passage Ø 10 - 75 mm - LED machine light - Reducing sleeve MT 6 / MT 4 - Fixed center MK 4 - Change gear set - Position stop with fine adjustment - Initial filling of the machine with quality oil - Operating tool Incl. special accessory OPTIMUM three-jaw lathe chuck centrically clamping Ø 250 mm Quick change holder SWH5-B set

Condition: new, turning length 1500 mm turning diameter 410 mm swing diameter over bed slide 255 mm turning dia. in gap 580 mm spindle bore 52,0 mm turning speeds 30 - 3000 U/min bed width 250 mm spindle taper 55029 D 1-6 taper in tailstock 4 MK quill travel 120 mm total power requirement 5,5 kW weight of the machine ca. 1400 kg. range L-W-H 2530 x 1000 x 1450 mm Scope of delivery - 3-axis digital display ES-12 V with LCD display - 3-jaw steel chuck PO3-200 mm / D6 - Clamping disk 350 mm - Fixed steady rest - passage diameter max. 135 mm - Follow-on steady rest - passage diameter max. 65 mm - Foot pedal with brake function according to CE - Quadruple tool holder - Protective device for quadruple tool holder - Micrometer longitudinal stop - Turret stop with fine adjustment - Frequency converter - Initial filling with Shell Tellus 46 - Coolant system - Slip clutch - Thread gauge - LED machine light - Change gears - Reducing sleeve - 2 centering points - Chip back wall Bsdpfx Asxaaldjd Iswu - Operating tool * Images show identical machine

Condition: new, turning length 1000 mm turning diameter 350 mm turning dia. in gap 450 mm spindle bore 40,0 mm turning speeds 70 - 2000 U/min bed width 180 mm spindle taper 55029 D 1-4 taper in tailstock 3 MK quill travel 110 mm total power requirement 1,5 kW weight of the machine ca. 529 kg. range L-W-H 1730x700x1340 mm Scope of delivery: - 3-axis digital display i200 with LCD display - 3-jaw chuck DK11-160 mm / D4 - Face plate 200 mm / D4, according to DIN 55029 - Fixed steady rest - passage diameter max. 60 mm - Follow-on steady rest - passage diameter max. 60 mm - Clamping plate 250 mm - Quadruple tool holder - Shaft fixing device - Protection device for tool holder - Slip clutch - Micrometer longitudinal stop - Coolant device - Extendable chip tray - Frequency converter - Foot pedal with brake function according to CE - Splash guard - Thread gauge - LED machine light - Digital speed display Bedpfxow U U R Se Ad Iewu - Reducing sleeve - Change gears - 2 centering points - Base frame - Operating tool

Condition: new, turning diameter 560 mm turning length 1910 mm swing diameter over bed slide 355 mm Swingdiameter in the bed bridge 790 mm centre height 280 mm Turning length in the bed bridge 170 mm reus 12 (25-1600) U/min tail stock MK 5 Bwjdpfx Asucgr Ied Iju quill stroke 180 mm diameter of quill 75 mm spindle taper DIN ISO 702-2 Nr. 8 spindle bore 80 mm spindle cone MK 7 feed längs 35 / 0,059 - 1,646 m/min feed plan 35 / 0,020 - 0,573 m/min total power requirement 8,5 kW weight of the machine ca. 2560 kg dimensions of the machine ca. 3450 x 1150 x 1650 mm Fully equipped master and feed spindle lathes. TH 4215 with digital position indicator DPA 21 / 3462070 - Hardened and ground Z-axis guideway - Spindle mount Camlock DIN ISO 702-2 No. 6 - Precisely crafted slide - Hand wheels with adjustable fine scaling 0.04 / 0.02 mm - Quadruple steel holder - All guides can be adjusted using V-ledges - Adjustment range top slide ± 90° - Guaranteed concentricity of the spindle nose better than 0.015 mm - Main spindle running in oil bath - Smooth-running gear wheels, hardened and ground with 2 adjustable Precision tapered roller bearings - Hand wheels decoupled and tested according to EN 23125 - Two-channel right-left switch tested according to EN 23125 - Switch with life cycle calculation, tested according to EN ISO 13849 - All metric pitches in the range 0.2 to 14mm/rev and all Inch threads in the range of 72 - 2 threads per inch without changing the Change gears adjustable by shift lever in the control panel - Clockwise/counterclockwise rotation can be switched on the bed slide via the switching spindle - Central lubrication in bed slide - Meehanite cast base and machine bed in one piece - Lead screw cover - Emergency stop device with foot control - Safety handwheels with snap-out function in the X and Z axes - Tailstock for taper turning adjustable ± 10 mm - Tailstock quill and hand wheel with adjustable fine scaling 0.025 mm - Quick, easy and tool-free adjustment using a clamping lever - Heavily ribbed prism bed, induction hardened and precision ground cast iron - Coolant device with separate coolant tank with level indicator and oil separator; easy and complete emptying and cleaning according to DIN - LED machine lamp in the chip guard Models TH 4210D and TH 4215D with digital readout DPA21 - User-friendly membrane keyboard, splash-proof, closed andglare-free - Glass scales scope of delivery - Fixed bezel passage Ø 15 - 145 mm - Revolving bezel passage Ø 10 - 75 mm - LED machine light - Reducing sleeve MT 6 / MT 4 - Fixed center MK 4 - Change gear set - Position stop with fine adjustment - Initial filling of the machine with quality oil - Operating tool Incl. special accessory OPTIMUM three-jaw lathe chuck centrically clamping Ø 250 mm Quick change holder SWH5-B set

Condition: new, turning diameter 760 mm turning length 3000 mm swing diameter over bed slide 520 mm centre height 380 mm reus 17 (7,5 - 1015) U/min tail stock MK6 quill stroke 225 mm diameter of quill 105 mm spindle bore 132 mm feed längs 0,039 - mm/min feed quer 0,02 - 9 mm/min total power requirement 15 kW weight of the machine ca. 4700 kg dimensions of the machine ca. 4900 x 1650 x 1650 mm - Coolant device - Machine light - Chip back wall - Spindle protection - Lathe chuck protection - Tool holder protection - Interchangeable gears *Special equipment - 3-jaw chuck Ø 250 mm type 3204/ DIN6350, BISON - MULTIFIX quick-change holder type B, including 4 tool holders - 3-axis digital display DRO Newall Bwedpfoqv Iw Tox Ad Iou - Foot pedal with brake function CE

Condition: ready for operation (used), turning length 450 mm turning diameter over bed 245 mm turning diameter over slide rest 135 mm Bwjdpfx Adjzbc Dts Iju spindle bore 23.0 mm tool adaptor DIN 55021-4 quill: 2 MK quill travel 80.0 mm turning speeds 60 - 3000 U/min bed width 155 mm total power requirement 1.2 / 1.5 kW voltage 380 V weight of the machine ca. 340 kg. range L-W-H 1200 x 650 x 1330 mm from a vocational school (!) particularly suitable for precision turned parts The Primus series is the most compact precision sliding headstock and sliding headstock lathe (LZ) from WEILER. It is used in toolmaking, laboratories and training workshops as an absolute machine for precise work in the tightest of spaces. The machine is built for extremely tight tolerances. The hardened and ground machine bed ensures maximum for maximum vibration damping and durability. Features: - Robust lead/traction spindle lathe - 2-axis digital readout "D60-2V" - three-jaw chuck - Folding lathe chuck guard - chuck key - MULTIFIX steel holder with 3x inserts - Sliding tailstock - Control panel, front left - infinitely adjustable feeds for flat and top support - Pole-changing drive motor - machine base frame - Chip guard rear panel - Additional accessories such as collet holder Collets etc. - EMERGENCY OFF button at the front

Condition: used, Year of construction: 1985, turning diameter over bed 340 mm turning diameter over slide rest 260 mm turning length 700 mm spindle bore 48 mm spindle turning speed range 25 - 2000 U/min spindle nose DIN 55027 KK 5 voltage 380 Volt total power requirement 2,2 / 4,4 kW weight of the machine ca. 1000 kg dimensions of the machine ca. 1.800 x 700 x 1.500 mm NARDINI MS 175E â?? Robust Lead and Feed Spindle Lathe A solid and proven conventional lathe for workshops, maintenance, mechanical engineering, and demanding machining tasks. The machine impresses with its robust construction, intuitive operation, and versatile applications. It is ideal for turning, thread cutting, face and longitudinal turning, as well as for machining a wide variety of workpieces. Advantages of the NARDINI MS 175E: â? Robust, durable machine construction â? Proven conventional technologyâ??ideal for workshops and training â? Lead and feed spindles for versatile machining capabilities â? Wide speed range â? Feed and thread tables for quick and convenient setup â? Extensive options for metric and other thread types â? Well-organized control panel with clearly arranged switches and adjustment controls â? Powerful and precise machining thanks to the machineâ??s sturdy construction â? Solid machine bed for excellent stability and low-vibration operation â? Protective cover over the spindle area for additional operator safety â? Ideal for one-off production, repairs, maintenance, and small-batch production â? A machine for users who value mechanical, reliable technology over unnecessary complexity Equipment: - 3-jaw lathe chuck - Various jaws - Lathe chuck guard - Collet chuck adapter Bjdpfxjzlkwbo Ad Iewu - Various collets - Multifix tool holders - Multifix adapters - Vibration-damping feet

Condition: used, turning length 1000 mm turning diameter 330 mm turning dia. over face-slide 198 mm turning dia. in gap 476 mm spindle bore 38.0 mm turning speeds 70 - 2000 U/min bed width 180 mm spindle taper DIN ISO 702-2 Nr. 4 taper in tailstock 3 MK quill travel 110 mm total power requirement 1.5 kW weight of the machine ca. ca. 610 kg. range L-W-H 1930 x 755 x 1300 mm Features - Ideal for technical schools, repair shops, and training workshops - Modern main spindle bearing assembly with precision-grade angular contact ball bearings - Single-lever chuck for the tailstock, adjustable for taper turning - Hardened and ground gears and shafts in the gearhead - Optimally suited for machining steel, non-ferrous materials, and plastics - Removable bridge for machining workpieces with large . diameters - To minimize the effects of vibration, the solid prismatic bed . is additionally equipped with ribs - The speed and feed rate adjustment is simple in design, smooth-operating, and . can be shifted precisely Scope of delivery: - 3-jaw chuck - MULTI-FIX tool holder with insert - Safety guard for the 3-jaw chuck - Slip clutch - Coolant system - Foot pedal with brake function, CE-compliant - Rear splash guard - Machine light - Base frame Bodpfx Aezlukxsd Iowu

Condition: excellent (used), Year of construction: 2014, operating hours: 367 h, functionality: fully functional, turning length: 2,845 mm, turning diameter: 1,150 mm, total height: 1,890 mm, total length: 6,740 mm, total width: 2,205 mm, workpiece weight (max.): 5,000 kg, overall weight: 9,170 kg, Equipment: documentation/manual, Hankook Protec 9NC 3000 Flat Bed CNC Lathe — 2014 Year: 2014 Machine: Hankook Protec 9NC 3000 Type: Flat Bed CNC Lathe Running Hours: 367 hours Available for sale is a 2014 Hankook Protec 9NC 3000 Flat Bed CNC Lathe, showing just 367 hours. The machine is supplied with all three steady rests, making this a very well-equipped machine and an excellent opportunity for anyone looking for a heavy-duty CNC turning centre with very low hours. Key Features Hankook Protec 9NC 3000 2014 model Only 367 hours ! Flat bed CNC lathe 3 x steady rests included 3 Jaw and 4 Jaw Chucks Heavy-duty construction Suitable for a wide range of turning applications Low-hour machine Safety platform included Bjdpfjzvgayox Ad Iewu Turning diameter over bed: Ø1150 mm Turning diameter over carriage: Ø830 mm Maximum turning length: 2845 mm Spindle bore: Ø105 mm Maximum turning weight: 5000 kg A very clean, low-hour example of a Hankook Protec 9NC 3000, complete with all three steady rests. Contact us for further information, photographs, specifications or to arrange an inspection.

Condition: good (used), Year of construction: 2010, functionality: fully functional, Technical details turning diameter 475 mm turning length 830 mm control HEIDENHAIN MANUALplus 620 swing diameter over slide rest 260 mm centre distance 1000 mm spindle bore 70 mm spindle turning speed range 1 - 3000 U/min feeds - cross 0,001 - 1000 mm/U feeds - longitudinal 0,001 - 2000 mm/U rapid travel - longitudinal/face 10 / 5 m/min tailstock quill diameter 70 mm tailstock quill stroke 120 mm tailstock quill taper MT 5 main drive (40 % ED) 25 kW weight of the machine ca. 2,9 t Additional information Bwsdpfxezzwi Ne Ad Ieu * Control HEIDENHAIN MANUALplus 620 * DXF conversion software (processing of contours in DXF format from CAD drawings) * Ethernet and USB interfaces inside the control cabinet * Coolant system (frequency-controlled), 1–4 bar * Glass scale for direct position measurement on the X and Z axes * 4-position PARAT quick-change tool holder, size 2, with several inserts * 3-jaw-chuck RÖHM ZS 200 * Roller guide for easier movement of the tailstock * 2 movable safety doors * Main motor fan control, temperature-controlled, for particularly quiet environments such as laboratory workshops and schools

Condition: like new (used), Year of construction: 2010, operating hours: 14,010 h, turning length: 800 mm, turning diameter: 430 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 455 mm, travel distance Z-axis: 800 mm, rotational speed (max.): 6,000 rpm, feed length X-axis: 455 mm, feed length Z-axis: 430 mm, workpiece weight (max.): 5 kg, total height: 8,500 mm, total length: 2,500 mm, total width: 2,495 mm, overall weight: 8,500 kg, CNC controller: Fanuc FS31IA5 (MAPPS 4) Capacity Turning length mm: 800 Max. turning diameter mm: ø: Ø430 Turn-mill spindle X-axis travel mm: 455 Z-axis travel mm: 800 B-axis degree: ±120 (0.001º) Speed spindle rpm: 12000 Drive power kW: 9/5.5 Bsdpoy Rpq Tjfx Ad Iewu Y-axis travel mm: ±105 Tool magazine Magazine places: 76 Tool holder: Capto C5 Tool length max. mm: 250 Tool diameter max. mm: 70/130 Tool weight max kg: 5 Lower turret X-axis travel mm: 160 Z-axis travel mm: 730 Number of tool slots St .: 10 Main spindle Speed spindle rpm: 6000 Spindle bore mm: 73 Chuck type: Hollow Chuck (8") Manufacturer: KITAGAWA Counter spindle Speed spindle rpm: 6.000 Drive power spindle kW: 7.5/5.5 Chuck type: Solid Chuck (8") Manufacturer: KITAGAWA Equipment Chip conveyor Signal lamp High pressure pump Chuck foot switch (double) for main and counter spindle Coolant gun Working time hours Under power: 76482 Spindle 1: 14010 Spindle 2: 4306 Potencial nominal kVA: 48 Basic machine dimensions / weight Length mm: 2500 Width mm: 2495 Height mm: 8500 Weight kg: 8500

Condition: used, Year of construction: 1975, Technical details: turning diameter over bed: 400 mm turning diameter over support: 220 mm turning length: 1100 mm centre height: 180 mm spindle passage: Ø 45 mm range of revolution per miute: 31,5 - 1.400 / 12 step U/min range of feed in x - axis: längs: 0,08 - 1,10 m/min range of feed in y - axis: quer: 0,028 - 0,40 m/min tailstock quill taper MT: MK4 tailstock quill adjustment: 200 mm total power requirement: 4,0 kW Bwodpfxeu Ix E Hj Ad Isu weight of the machine ca.: 1,7 t dimension machine xH: 2,5 x 1,1 x 1,4 m Equipment: -Three-jaw chuck Ø 250mm manufacturer Forkardt with interchangeable jaws -Multifix steel holder -Cooling water device with pump -chuck guard -chip collecting tray -chip guard Accessories: -chuck spanner -tool holder -2 pieces gears *

Condition: used, Year of construction: 1951, Technical details: turning diameter over bed: 400 mm turning diameter over support: 240 mm turning length: 1100 mm centre height: im Bett gemessen: 190 mm spindle passage: 40 mm range of revolution per miute: 37,5 - 950 U/min total power requirement: 3,5 kW tailstock quill taper MT: MK 4 tailstock quill: 180 mm weight of the machine ca.: 1,6 t dimension machine xH: 2,6 x 1,4 x 1,3 m Bwjdpfx Aeu Ix Hdjd Isu The lathe is equipped with threading device. It is rewired and a new control cabinet is made. Emergency stop switch and chuck protection 3-jaw chuck Ø 250mm rotating tip Tool support quadruple steel holder tool support approx. 30° right/left swiveling 4 Stück Wechselräder Copying device (taper 15° right/left) *

Condition: used, Year of construction: 1986, Technical details: turning diameter over bed: 315 mm turning diameter over support: 200 mm turning length: 500 mm turning diameter over bed: 315 mm swing diameter over face slide: 200 mm center height measured in bed: 180 mm spindle passage: Ø 32 mm range of revolution per miute: 56...2.800 / nur only 6 step links-rechts U/min Bwsdpfsu Ix Hqox Ad Iou range of feed in x - axis: längs: 0,02..0,8 m/min range of feed in y - axis: plan: 0,01..0,4 m/min tailstock quill taper MT: MK 4 tailstock quill adjustment:: 140 mm total power requirement: 5,5 kW weight of the machine ca.: 2,0 t dimension machine xH: 2,1x 1,1 x 1,4 m -Workpiece pick-up via collet chuck -travels longitudinal slide= 580mm and cross slide=170mm -incl. tooling device lathe support -incl. change gears -steady rest Ø 100mm -fourfold tool holder The machines functionality is limited ! 6 speeds are currently selectable! (224/1800 ; 280/2240; 355/2800 rpm.) i.D. *

Condition: used, Year of construction: 2004, Technical details: turning diameter over bed: 610 mm Bodpfsu Ix I Ujx Ad Iewu turning dia. over face-slide: 350 mm swing diameter over bed: 610 mm centre distance: 1390 mm control: Fanuc 0i-Mate TC x-axis: plan: ca. 305 mm z-axis: längs: ca. 1350 mm revolution per minute: 22 - 2200 U/min feed:: X + Z-Achse: 5 / 10 m/min. spindle bore: Ø 70 mm tool turret - number of stations: 6 tailstock quill taper MT: MK5 tailstock quill stroke: 150 mm Weight approx.: 2,7 t total power requirement: 15 kW dimension machine xH: 3,7 x 1,7 x 1,7 m dimensions of hydaulic: 630 x 460 x 900 mm other features: -hydr. chuck TONFAU Ø 300mm -hydraulics -Coolant system -control panel -double foot switch accessories: -div. mold jaws -div. soft jaws -6 footrests *

Condition: used, Year of construction: 1987, Technical details: Bedpfxou Ix N Sj Ad Iowu turning diameter over bed: 180 mm turning length: 490 mm swing diameter: 450 mm cross travel: Z-Weg: 168 mm control: Traub TX8D revolution per minute: 20 - 4000 U/min spindle passage: Ø 60 mm operating hours - idle run: 23.495 h tool turret: 12 tools total power requirement: 38 kW Weight approx.: 4,2 t dimension machine xH: 3,6 x 2,5 x 2,2 m Tool holder straight shank DIN 69880 (VDI 3425) Ø 40x63 Röhm lathe chuck Ø 200mm hydraulic clamping Operation via double foot switch and control panel/operating panel. Coolant device The Traub carries an integrated chip conveyor with an ejection height of 1,100mm (currently without function). Accessories: multiple small parts 8 x machine feet without tailstock i.D. *

Condition: used, Year of construction: 1976, Technical details: turning diameter over bed: 340 mm turning diameter over support: 190 mm turning length: 800 mm turning length: plan =140 / quer =120 mm center height over bed: 170 mm spindle bore of work spindle: Ø 40 mm range of revolution per miute: 25 - 2000 / 20 step U/min feeds:: längs: 0,028 - 1,0 / quer: 0,012 - 0,44 mm tailstock quill taper MT: MK3 tailstock quill adjustment:: 120 mm total power requirement: 3,0 kW weight of the machine ca.: 1,1 t dimension machine xH: 2,0 x 0,8 x 1,4 m Threading possible: Metric, Withwort and modular thread Equipment: - 2-way measuring device VISUCONT - 3-jaw chuck Ø 205mm with internal clamping jaws - quick-change steel holder Multifix - foot brake Bedeva Ertepfx Ad Ijwu - cooling water pump (exclusive supply) *

Condition: used, Year of construction: 1979, Technical details: turning diameter over bed: 540 mm turning length: 630 mm centre distance: 900 mm center height over bed: 270 mm center height: über Hinterschlitten: 138 mm Turning diameter: über Hinterschlitten: 250 mm longitudinal feed: 700 mm facing movement : 80 / 75 mm revolution per minute: 1,8 - 450 bei 8x steples U/min clamping diameter: 26 mm range of feed in x - axis: 12 step / 0,063 - 0,63 mm/U range of feed in y - axis: 36 step / 0,070 - 1,11 mm/U tailstock quill: MK5 mm tailstock quill stroke: 250 mm Total power requirement: 7,0 kW machine weight approx.: 3,76 t dimension machine xH: 3,2 x 1,2 x 1,8 m Application: Mainly for relief turning and relief grinding of cutting tools (especially hobs with and without thread pitch). Back turning and relief grinding is possible from the front, the rear and in the axial direction of the machine. Bedpfxevbhv Rs Ad Ijwu Main drive via 8-stage manual gearbox. Feed gearbox is designed as a 12-stage manual gearbox. Swivel range of the rear slide = 360deg. Swivel range of cross slide = 360deg. Lathe chuck is cone disc Ø 200mm with MK5 Equipment: turning mandrel Ø 49,5 x 400mm Measuring system ARBAH-L 3+1 Inverter FRENIC 5000G11 i.D. *

Condition: used, Year of construction: 2008, Technical details: turning diameter over bed: 600 mm turning dia. over face-slide: 540 mm turning length: 550 mm longitudinal traverse (z-axis): 800 mm facing movement (x-axis): 260 mm control: Fanuc 18i-TB spindle bore: Ø 73 mm bar material dia.: Ø 65 mm revolution per minute: 0 ... 5000 steples U/min max. torque on the spindle: max. 250 Nm rapid traverse in x-y-z axis: X/Z: 30 m/min. / Y: 12 m/min. rapid traverse c-axis: 1000 U/min. tool turret - number of stations: 12 (Sauter) operating pressure: 6,0 bar Bwodpfx Ajvvtpxjd Iou electrics - voltage/frequency: 3 x 400 / 50-60 V/Hz operating pressure: 6 bar total power requirement: 40 kVA Weight approx.: 5,7 t dimension machine xH: 2,2 x 3,4 x 2,4 m dimension swarf conveyor LxWxH: ca. 2,9 x 0,6 x 0,55 (0,38 to) m dimensions LxWxH: Spänewanne: ca. 1,6 x 1,3 x 0,25 (0,2 to) m transport measurements machine: ca. 3,3 x 1,9 x 2,2 m The machine has a C-axis, E-axis, Y-axis, and W-axis. Powered tools can be used in all positions. Distance between spindle and counter spindle = 1050 mm. Counter spindle: A2-6, travel distance 800 mm, spindle diameter 105 mm, torque 250 Nm. Control cabinet equipped with Rittal cooler With hinged chip conveyor Chip tray Compressed air gun The machine has NO lathe chucks on sale as is! *

Condition: used, Year of construction: 2007, Technical details: turning diameter over bed: 762 mm turning length: 850 mm facing movement (x-axis): 287 mm longitudinal traverse (z-axis): 864 mm control: CNC Haas spindle passage: 76 mm revolution per minute: max. 3400 steples U/min tailstock taper ISO: Ø 290 tailstock quill stroke: ja mm tool turret - number of stations: 12 electrics - voltage/frequency: 360/ 400 V - 50-60 Hz V/Hz Weight approx.: 6,3 t transport measurements machine: ca. 3,4 x 2,1 x 2,4 m Equipment: 3-jaw power chuck KITAKAWA Ø 250 mm (without jaws) 4200 rpm. Operable via 2-position foot switch. Tool turret with powered tools available. Electric coolant system provided. Bedpfxevvt Eme Ad Ijwu Tool measuring system available. I.D. *

Condition: used, Technical details: number of spindles: 9 Stück total power requirement: 83,0 kW weight of the machine ca.: 17,0 t Bsdpeu Idvkefx Ad Iewu TRANSFERAUTOMAT with 9x drill-and mill spindles - right 3x drill-& mill spindle, 9 stages, driven, fixed and left 3x drill-& mill spindle 9 stages, driven, fixed such as radial 3x drill-& mill spindle with 9 stages, driven, fixed i.D. *

Condition: used, Technical details: spindle taper: 40 number of spindles: 9 Stück weight of the machine ca.: 10,0 t total power requirement: 13 (17,5 PS) kW dimensions of machine: LxBxH: 4100x3400x3200 mm dimensions electric cabinet: LxBxH: 2100x350x1900 mm TRANSFER MACHINE DRILL AND THREADCUTTING MACHINE - ROTARY TRANSFER MACHINE with 9x Drill-& Mill Spindles - right 2x Drill-&Mill Spindle from that 1x with U-axis flexible and 1x thread cutting unit with 9 stages flexible - left 2x Drill-&Mill Spindle from that 1x with U-axis flexible and 1x thread cutting unit with 9 stages flexible, such as radial 2x Drill-&Mill spindle and 1x thread cutting unit 9 stages, flexible - workpiece carrier with 8 clamping stations: workpiece holding barrel Ø 1000 mm (oil-pneumatic cycle), clamping station self-centering clamping jaws - Drilling: SK 40 intake; spindle stroke 125 mm; standard feed rate 0 - 2 m/min; RPM at 12 stages with 164-1005 rpm - Drill- and facing unit; SK 40 intake; spindle stroke 90 mm; standard feed rate 0 - 2 m/min; rapid traverse feed rate 7.5 m/min; RPM at 12 stages with 166 - 1020 rpm - 3 piece thread-cutting units: SK 40 Intake; Working stroke 125 mm; RPM at 12 stages with 31.5 - 194 rpm; clockwise and counterclockwise - 6 piece opposing drill units: SK 40 intake Equipment: - coolant system with feed - operation through control panel - chip box - counting mechanism - elevated platform with stairs Bwedpsu Idwbefx Ad Ieu i.D. *

Condition: used, Technical details: number of spindles: 9 Stück weight of the machine ca.: 10,2 t Transfer machine with 9 Drill-& Mill spindles - right 2x drill -& mill spindle and 1x thread cutting spindle with 9 stages - left 2x drill -& mill spindle and 1x thread cutting spindle with 9 stages such as radial 2x drill-& mill spinlde flexible and 1x thread cutting spindle 9 stages, flexible Bwsdpfsu Idwnox Ad Iou i.D. *
