Friedel Bertram GmbH

Condition: good (used), Year of construction: 1999, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,150 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 10 m/min, Control: Siemens 840 D Powerline Tool holder: HSK-A63 Max. rpm: 16,000 X-travel: 3,000 mm Y-travel: 2,500 mm Z-travel: 1,150 mm A-axis: +/- 100 mm C-axis: +/- 181.5 mm Table size: 3,000 mm x 2,500 mm Lsdpfsymnrtjx Ad Ejhc Option: External blowing air Kinematics: Fork head

Condition: good (used), Year of construction: 2022, CNC Heidenhain TNC640, table 2,500 x 4,000 mm, X/Y/Z 4,000/2,500/1,300 mm, 5-axis universal milling head 18,000 rpm, tool holder HSK-A63 DIN 69893, 120 tools, internal coolant supply (IKZ). Ledpfx Aoymm Eljd Eshc

Condition: good (used), Year of construction: 2010, functionality: fully functional, Unisign Uniport 6000 Year of manufacture: 2010 / Commissioned: 2011 Control: Siemens 840 D Travel ranges: X = 10,000 mm, Y = 1,500 mm Enlarged spindle ram stroke: Z = 1,000 mm Enlarged clearance height: 1,000 mm Clearance width: 1,500 mm Main drive: 36 kW, n = 6,000 rpm, 720 Nm 2-speed gearbox, 1:4 Taper: SK 50 Machining capacity in C45: - Solid drilling D=120mm - Tapping M55 - Milling 100 cm³/min Gantry design with traversing portal bridge and stationary clamping table. Clamping table equipped with transverse clamping beams at 750 mm intervals; standard plate sections eliminated. Hydraulic clamping device with clamping bridges for axle machining, including hydraulic unit Angle drilling and milling head, n = 4,000 rpm, SK 50 High accuracy and stability thanks to Hirth coupling Automatic tool change into the angle head Measuring probe RWP20.50-M Pendulum operation Safety fence with light curtains, Sick brand Clamping table with transverse clamping beams at 750 mm spacing Tool chain magazine on portal column with 30 stations Machine cooling unit Water-air heat exchanger integrated in the control cabinet Unisign remote diagnostics for Siemens Sinumerik 840 D Lhodpfjymb Eaex Ad Eec Makrolon curtains on both sides of the portal bridge, motorized height adjustment Partition wall with viewing window Chip conveyor with hinged belt design Mounting and alignment elements included

Condition: excellent (used), Year of construction: 1990, functionality: fully functional, machine/vehicle number: 3.8203, travel distance X-axis: 7,570 mm, travel distance Y-axis: 4,900 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 10 m/min, total length: 18,700 mm, table length: 6,850 mm, table width: 2,250 mm, total width: 8,500 mm, spindle speed (min.): 5 rpm, spindle speed (max.): 2,000 rpm, total height: 7,050 mm, table height: 300 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 10 m/min, distance between stands: 2,750 mm, type of input current: AC, table load: 60,000 kg, workpiece weight (max.): 60,000 kg, distance table to spindle center: 2,500 mm, overall weight: 145,000 kg, spindle motor power: 63,000 W, feed length W-axis: 2,000 mm, MODEL: Portal Type AGE: 1990 S/N #: 3.8203 CATEGORY: Mills, Planer Type, CNC CAPACITY: X-Axis Travel: 7570 mm Y-Axis Head Travel: 4900 mm Z-Axis Ram Stroke: 1000 mm, W-axis traverse movement: 2000 mm Ram Cross Section: 500 mm x 500 mm Distance Between Columns: 2600-2750 mm Distance Table To Ram Face: 2500 mm Table Size: 2x3000+850 mm x 2250 mm, two tables for split or integral operation Spindle (Quill) Diameter: 225 mm Spindle Taper: ISO #50 Spindle Speeds: 0-2000 RPM Spindle Motor: 63 KW EQUIPPED WITH: SIEMENS System 840D CNC Control, new in 2008 CNC biaxial continous milling head Universal Milling Head with Auto Indexing Lodpfx Adsyl S Ngo Eohc Right Angle Head with Auto Indexing Straight Milling Head Wagons for Head Change and Tool Pick-up Change Hydrostatic Bearings Coolant System Full Length Chip Conveyors Way Covers 63 KW Spindle Motor Rapid movements: W-2000 mm/min, Z-10.000 mm/min, X and Y-15.000 mm/min Table loads: 30.000 kg+30.000 kg, max 60.000 kg Weight of the machine: 143.000 kg Outside dimensions: 18.700 x 8.500 x 7050 mm

Condition: good (used), Machine is in good working condition. Parts shown by hand not come. Lhodpfxoylxg Ee Ad Ejc

Condition: ready for operation (used), Year of construction: 2004, number of axes: 3, This 3s Datron Cat3D-M8 XLB gantry milling machine manufactured in 2004 features a 2 kW water-cooled spindle with an included cooling unit and a 30-position tool changing system. Consider the opportunity to buy this Datron Cat3D-M8 XLB gantry milling machine. Contact us for further details. • Table dimensions: 1000 x 1500 mm Ljdeyia Hxopfx Ad Eehc • Spindle: 2 kW, water-cooled • Tool changer: 30 positions • Known defect: valve on the spindle is leaking Additional equipment • Spindle cooling unit (included)

Condition: excellent (used), Year of construction: 1999, travel distance X-axis: 1,500 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 500 mm, total length: 5,179 mm, table length: 1,800 mm, table width: 650 mm, total width: 3,345 mm, rapid traverse X-axis: 28,000 m/min, rapid traverse Y-axis: 28,000 m/min, rapid traverse Z-axis: 28,000 m/min, table load: 1,500 kg, overall weight: 7,500 kg, X - Travel: 1500mm Y - Travel: 800mm Z - Travel: 500mm Table Length: 1800mm Table Width: 650mm Table load: 1500 Feed rate X-Axis: 28000mm/min. Feed rate Y-Axis: 28000mm/min. Feed rate Z-Axis: 28000mm/min. Spindle Taper: 40ISO/Bt/Mk Power on spindle: 13.5kW Speeds / ranges: 8000Rpm Ledpfx Adoyhph Eo Eshc ATC / revolver: 24 Coolant through spindle / Bar:10 Number of controlled axis: 3 Chip conveyor: yes Coolantsystem: yes Length: 5179mm Width: 3345mm Height: 2595mm Weight: 7500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: like new (used), Year of construction: 2004, Retrofitted: 2026 Numerical control: NUEVO/NEW HEIDENHAIN TNC-i640 Technical features Dimensions Table dimensions: 5600 x 2000 mmNumber of T slots: 13T slots dimensions: 22 mm Traverses of axis X axis traverse: 5000 mmY axis traverse: 3250 mmZ axis traverse: 1000 mmVertical capacity (VC): 450 / 1450 mmDistance between columns: 2700 mm Milling head Auto-indexing differential head (UAD - 0,1º)Tool clamping system: HydraulicTaper nose: ISO50 (DIN69871)  /  Pull stud: DIN69872Speed range: 6000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 7200 / 12000 mm/min Weight and dimensions Maximum weight on table: 25000 kgMachine weight approximate: 56000 KgMachine dimensions approximate: 13200 x 5425 x 5350 mm Accesories Guarding: 2 sliding doors and new perimetral wire-mesh security omatic tool changer: OptionalChip conveyor: 1 transversal hinge typeElectronic handwheel: New HR-510Coolant: External internal high pressure through spindle Sales conditions Guarantee: 6 months mechanical spare partsPrice and sale conditions: On request View all technical features Lodpfoyf Rq Nsx Ad Eohc

Condition: like new (used), Year of construction: 1998, Retrofitted: 2024 Lhsdpeyf Rq Aofx Ad Ejc Numerical control: SIEMENS 840D Technical features Dimensions Table dimensions: 5000 x 2000 mmNumber of T slots: 13T slots dimensions: 22 mm Traverses of axis X axis traverse: 5000 mmY axis traverse: 3250 mmZ axis traverse: 1000 mmDistance between columns: 2500 mm Milling head Head type: C5E- 2 axis continuous headTool clamping system: HydraulicTaper nose: BT 50Speed range: 40 - 4000 rpmSpindle power: 37 kW / 372 Nm Feedrates Feedrate: 2 - 5000 mm/minX-Y,Z Rapid feedrate: 7200 / 12000 mm/min Weight and dimensions Max Weight on table: 25000 kgMachine weight: 40500 kgMachine dimensions: 12700 x 5070  x 4900 mm Accesories Guarding   Automatic tool changer: ATC-60Electronic handwheel: New SIEMENS 6FX2007-1AC04 Sales conditions Warranty: 6 months mechanical partsSale price (Ex Work): On request   View all technical features

Condition: like new (used), Year of construction: 2004, Retrofitted: 2025 Numerical control: HEIDENHAIN TNC-530 Lhsdpfx Adsyf Rqvo Eec Technical features Dimensions Table dimensions: 4000 x 2000 mmNumber of T slots: 11T slots dimensions: 22 mm Traverses of axis X axis traverse: 4000 mmY axis traverse: 3000 mmZ axis traverse: 1000 mmVertical capacity (VC): 500 / 1500 mm  (in direct exit)Distance between columns: 2530 mm Milling head Universal manual UM40Tool clamping system: HydraulicTaper nose: ISO50Speed range: 20 - 3.000 r.p.m. (5.000 r.p.m. direct exit)Spindle power: 30 kW Feedrates Feedrate: 7000 mm/minRapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Maximum weight on table: 10000 KgMachine weight approximate: 45300 KgMachine dimensions approximate: 10926 x 4768 x 5110 mm Accesories Guarding: 2 sliding doors and new perimetral wire-mesh security ernal coolant. Electronic handwheel: New HR-510 Sales conditions Guarantee: 6 months mechanical partsSale price (Ex Work): On request View all technical features

Condition: like new (used), Year of construction: 2010, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-i530 Lhsdpjyf Rrmjfx Ad Ejc Technical features Dimensions Table dimensions: 8500 x 2500 mmNumber of T slots: 17T slots dimensions: 22 mm Traverses of axis X axis traverse: 8000 mmY axis traverse: 3800 mmZ axis traverse: 1500 mmVertical capacity (VC): 168 / 1668 mmDistance between columns: 3100 mm Milling head Auto-indexing differential head UAD (every 0,02º)Tool clamping system: HydraulicTaper nose: ISO50 (DIN69871) / Pull stud: DIN69872Speed range: 6000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 7200 / 12000 mm/min Weight and dimensions Maximum weight on table: 35000 kgMachine weight approximate: 79000 KgMachine dimensions approximate: 22700 x 7660 x 6800 mm Accesories Guarding: 2 sliding doors with a new perimetral wire-mesh safety fenceAutomatic tool changer: ATC-60Chip conveyor: 2longitudinal hinge typeElectronic handwheel: New HR-510Coolant: External internal high pressure through spindle Sales conditions Guarantee: 6 months mechanical spare partsPrice and sale conditions: On request View all technical features

Condition: like new (used), Year of construction: 2007, Retrofitted: 2026 Lsdpfx Aoyf Rrtod Eehc Numerical control: NUEVO/NEW HEIDENHAIN TNC-i640 Technical features Dimensions Table dimensions: 4500 x 2000 mmNumber of T slots: 11T slots dimensions: 22 mm Traverses of axis X axis traverse: 4000 mmY axis traverse: 3000 mmZ axis traverse: 1000 mmVertical capacity (VC): 240 - 1240 mmDistance between columns: 2500 mm Milling head Auto-indexing differential head (UAD - 0,1º)Tool clamping system: HydraulicTaper nose: ISO50Speed range: 6000 rpmSpindle power: 30 kW Feedrates Feedrate: 5000 mm/minRapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Maximum weight on table: 10000 KgMachine weight approximate: 35500 KgMachine dimensions approximate: 10975 x 4770 x 5345 mm Accesories Guarding with 2 doors and new perimetral safety fenceAutomatic tool changer: ATC-60 (sale option with no ATC)Chip conveyor: 1 transversalElectronic handwheel: New HR-510Coolant: External internal high pressure through spindle Sales conditions Guarantee: 6 months mechanical spare partsSale conditions: On request View all technical features

Condition: like new (used), Year of construction: 1996, Retrofitted: 2026 Lhjdpfxeyf Rr Te Ad Eoc Numerical control: NUEVO/NEW HEIDENHAIN TNC-320 Technical features Dimensions Table dimensions: 6000 x 2000 mmNumber of T slots: 13T slots dimensions: 22 mm Traverses of axis X axis traverse: 6000 mmY axis traverse: 3800 mmZ axis traverse: 1000 mmVertical capacity (VC): 500 / 1500 mm (direct exit)Distance between columns: 3100 mm Milling head Universal head UM40 (Body B: manual / Body C: 3º auto-indexing) Direct spindleTool clamping system: HydraulicTaper nose: ISO50 (DIN-69871)  /  Pull stud: DIN-96872Speed range: 3000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 7200 / 12000 mm/min Weight and dimensions Machine weight approximate: 50000 KgMaximum weight on table: 15000 kgMachine dimensions approximate: 14740 x 5330 x 5050 mm Accesories Guarding: 2 sliding doors with a new perimetral wire-mesh safety fenceHead changer: automatic with lateral hinge/support in columnChip conveyor: 2 longitudinal palletsElectronic handwheel: New HR-510Coolant: External Internal high pressure through spindle (internal only with direct exit head) Sales conditions Guarantee: 6 months mechanical spare partsSale conditions and price: On request View all technical features

Condition: like new (used), Year of construction: 1996, Retrofitted: 2023 Numerical control: HEIDENHAIN TNC-426 Lhedpfx Adoyf Rtdj Esc Technical features Dimensions Table dimensions: 3000 x 1250 mmNumber of T slots: 8T slots dimensions: 22 mm Traverses of axis X axis traverse: 2500 mmY axis traverse: 1800 mmDistance between columns: 1680 mmZ axis traverse: 800 mm Milling head Head type: Standard vertical spindleTool clamping system: HydraulicTaper nose: ISO 50Speed range: 20 - 2000 r.p.m.Spindle power: 22 kW Feedrates Feedrate: 2 - 5000 mm/minRapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Max Weight on table: 10000 kgMachine weight: 21500 kgMachine dimensions: 7300 x 2690 x 3400 mm Accesories Guarding: YesCoolant: ExternalElectronic handwheel: HR-330 Sales conditions Warranty: 6 months mechanical partsSale price (Ex Work): On request View all technical features

Condition: good (used), Year of construction: 1997, Manufacturer: Line Type: Seramill 240 Control: NUM 750 Travel X: 6000 mm Lhedjyf A H Nopfx Ad Eec Travel Y: 2500 mm Travel Z: 950 mm Column spacing: 2400 mm Table: 6000 x 2100 mm Automatic milling head: 2.5° Spindle speed: 3200 rpm Feed rate: 10 m/min Machine weight: approx. 35 tons

Condition: excellent (used), Year of construction: 2000, travel distance X-axis: 5,500 mm, travel distance Y-axis: 2,900 mm, travel distance Z-axis: 1,000 mm, table length: 5,000 mm, table width: 2,000 mm, CNC Gantry Milling Machine Forest Line Seramill 240T – Robust & Precise For sale: Forest Line Seramill 240T CNC gantry milling machine, year 2000 – used, in excellent condition. Perfect for machining large workpieces with high precision. Key Features: Robust gantry design for maximum stability Accurate Siemens 840D control Lsdpfx Aeyfpkbjd Eehc Large working area: 5,000 × 2,000 mm Travel: X 5,500 mm | Y 2,900 mm | Z 1,000 mm | A ±135° | C ±180° ISO 50 spindle, max. 6,000 rpm Ideal for series production and individual parts Perfect for carpenters, furniture manufacturers, and production workshops that want to machine large parts precisely. Available immediately! Contact us for details, photos, or a viewing.

Condition: excellent (used), travel distance X-axis: 11,000 mm, travel distance Y-axis: 4,500 mm, travel distance Z-axis: 1,250 mm, total length: 25,200 mm, table length: 10,000 mm, table width: 4,500 mm, total width: 11,200 mm, total height: 5,500 mm, table load: 30,000 kg, distance table center to spindle nose: 1,500 mm, WALDRICH COBURG MULTITECH 3500 FT GANTRY TYPE, MOVING CROSSRAIL MILLING MACHINE Equipped with Siemens Sinumerik 840 D CNC control. WORKTABLES (No. 2): - Mounting width: 3,000 mm Lhjdpfx Adeydmkvo Esc - Mounting length, front table: 4,500 mm - Mounting length, rear table: 4,500 mm - Mounting length, tables coupled: 10,000 mm - T-slots, longitudinal: 28 mm / H8 - T-slot spacing: 250 mm - Max. load, front table: 20,000 kg - Max. load, rear table: 20,000 kg - Max. load, tables coupled: 30,000 kg - Distance between columns: 3,500 mm - Clearance between table and spindle nose (vertical spindle unit VS 125 C/150): 1,500 mm TRAVELS: - Table, longitudinal (X-axis): - Table 1: 5,000 mm - Table 2: 5,000 mm - Coupled: 11,000 mm - Milling/drilling unit, horizontal (Y-axis): 4,500 mm - Vertical spindle slide (Z-axis): 1,250 mm - Crossrail (W-axis): 1,000 mm MILLING/DRILLING UNIT TYPE M4: - Drive power: 45 kW - Spindle speeds: - I range: 5 - 1,300 rpm - II range: 40 - 6,000 rpm - Automatic indexing of horizontal spindle units from 1° to 1° over 0–360° AUTOMATIC TOOL AND ATTACHMENT CHANGER SYSTEM ROBOT: - Double gripper for tool change on vertical and horizontal spindle units - Double gripper for attachment change on milling/drilling unit - Tool holder flange diameter: 97.5 - 125 mm - Max. tool weight: 50 kg - Max. attachment weight: 750 kg SHELF STORAGE SYSTEM: - Number of shelves: 4 - Total tool stations: 192 - Total attachment stations: 4 - Tool holders according to DIN 69871 ISO 50 - Station-to-station distance: 140 mm - Max. tool diameter with full occupancy: 135 mm - Max. tool diameter: - Standard: 250 mm - Direct access with shuttle trolley: 315 mm - Max. tool length: - Standard: 375 mm - In top row of the magazine: 600 mm OVERALL DIMENSIONS: - Total machine length: 25,200 mm - Total machine width: 11,200 mm - Total machine height from floor: 5,500 mm COMPLETE WITH: - 1x vertical spindle ISO 50, length 300 mm - 1x vertical spindle ISO 50, length 450 mm - 2x 90° heads - Workpiece inspection with Renishaw probe USED MACHINE

Condition: like new (used), Year of construction: 2019, travel distance X-axis: 6,300 mm, travel distance Y-axis: 3,600 mm, travel distance Z-axis: 1,800 mm, table length: 6,300 mm, table width: 3,600 mm, spindle speed (max.): 2,500 rpm, GANTRY MILLING MACHINE DYE CNC SIEMENS (RETROFIT 2019) TECHNICAL SPECIFICATIONS Lhodpfx Ajydbhpjd Esc Brand: Dye (Retrofit) CNC: Siemens 840D Year: Retrofit 2019 Table: 6300 x 3600 mm X-axis: 6300 mm Y-axis: 3600 mm Z-axis: 1800 mm W-axis (Quill): travel to be confirmed Head magazine: 4 positions Includes 1 automatic 360° angular head Tool magazine: 60 tools Spindle motor: 40 kW PRICE AND FURTHER INFORMATION ON REQUEST (CNC, SIEMENS, HASS, LAGUN, FAGOR, CINCINATI, HEIDENHAIN, MACHINING, PINACHO, MORISEIKI, MILLING MACHINE, LATHE, GRINDER, BORING MACHINE, PRESS, LASER, SHEAR, PRESS BRAKES)

Condition: used, Year of construction: 2005, x-axis 3000 mm y-axis 1200 mm z-axis 750 mm Control S 840 D working area 3600 x 1200 mm Lsdpfx Asycxc Ijd Eohc feed - longitudinal/cross 0- 75000 mm/min feeds vertical 0- 70000 mm/min spindle turning speed - stepless 100- 40000 U/min spindle motor 6 kW b-axis 285 ° c-axis 520 ° total power requirement 25 kW weight of the machine ca. 5 t dimensions of the machine ca. 5,2 x 2,3 x 2,5 m

Condition: used, Year of construction: 2002, functionality: fully functional, travel distance X-axis: 2,700 mm, travel distance Y-axis: 2,200 mm, travel distance Z-axis: 1,050 mm, feed rate X-axis: 20 m/min, feed rate Y-axis: 20 m/min, feed rate Z-axis: 15 m/min, total length: 8,500 mm, table length: 2,000 mm, table width: 1,250 mm, total width: 7,500 mm, spindle speed (max.): 6,000 rpm, total height: 5,020 mm, Equipment: rotational speed infinitely variable, CNC travelling column machining centre manufactured by MIKROMAT Werkzeugmaschinen GmbH & Co. KG, Dresden, designed for precise and heavy-duty machining of large-format workpieces. The machine features a classic travelling column design and is particularly suitable for tool, mould, and mechanical engineering. Equipped with a Heidenhain TNC 430 M CNC control. Distance spindle nose – table: Vertical: approx. 300 – 1,350 mm With universal milling head (UFK): vertical: approx. –290 to +760 mm horizontal: approx. –55 to +995 mm in table area: approx. 180 – 955 mm Spindle / Speeds: Spindle without extension: 10 – 6,000 rpm Spindle with extension: 10 – 6,000 rpm Lhedpfx Aoycw I Aod Esc Universal milling head (UFK): 10 – 4,000 rpm Universal milling head (UFK): Rotation about vertical axis: 360° (indexing 2.5°) Swivel about horizontal axis: ±110° (indexing 2.5°) Electrical data (nameplate): Connected load: approx. 68 kW Nominal voltage: 400 V / 50 Hz Control voltage: DC 24 V Auxiliary voltage: 230 V Total weight: approx. 57 t CE-compliant, Made in Germany

Condition: ready for operation (used), Year of construction: 1997, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 10,000 rpm, table load: 4,000 kg, overall weight: 13,000 kg, controller manufacturer: SIEMENS, controller model: 840D, number of axes: 3, This 3-axis Nicolas Correa Euro 2000 was manufactured in 1997. It features a Siemens 840 D control system and a Ganfior electro-spindle capable of reaching 10,000 rpm. The working envelope is 2000 × 1250 × 700 mm with a spindle taper of SK40. It supports a maximum table load of 4,000 kg and weighs 13,000 kg. If you are looking to get high quality milling capabilities consider the Nicolas Correa Euro 2000 machine we have for tact us for more information. • Spindle: Ganfior electro-spindle Lhedpfx Adeyctpij Esc Technical Specification Taper Size SK 40

Condition: used, Year of construction: 2017, x-travel 5850 mm y-travel 2500 mm z-travel 1000 mm Control 840D sl feeds x- + y-axis 20 m/min feeds z-axis 20 m/min acceleration 5 m/qs spindle drive - main spindle 60 kW spindle turning speed - stepless 24.000 U/min max. torque on the working spindle 87 Nm tool taper HSK-A63/F80 c-axis +/- 360 grad a- axis +/- 100 grad tool changer 20 stück coolant tank 2300 l surface area 6.000*2.500 mm number of T-slots 18 flute distance 125 mm dimensions of the machine ca. 14,8x7,3x5,8 m Machine table Lhjdeycln Dspfx Ad Eec Width 2,500 mm Length 6,000 mm Number of T-slots 20 Distance of T-slots 125 mm Dimensions of T-slots 18H8 mm Max. table load 8,000 kg Travels Cross rail: X axis 5,850 mm Cross slide: Y axis, horizontal 2,500 mm Z axis, vertical 1,000 mm Feeds X-, Y- and Z-axes Feed rate 20 m/min Rapid traverse rate 45 m/min Acceleration 5 m/s² Vertical Slide Cross section 560x420 mm Motor spindle Drive power S1 (100% ED) 60 kW Max. speed 24,000 rpm Max. torque 87 Nm Tool interface HSK-A63/F80 C-axis Swivel range ±360 degree Feed 50 min-1 Acceleration 50 rad/s² Holding torque 1,400 Nm Clamping torque 4,000 Nm A-axis Swivel range ±100 degree Feed 50 min-1 Acceleration 50 rad/s² Holding torque 1,400 Nm Clamping torque 4,000 Nm Total dimensions Length 14,800 mm Width 7,300 mm Height 5,800 mm

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,100 mm, CNC 5-axis Gantry Milling Machine BELOTTI Eureka 4014 (4000x1400mm) 5-axis milling machine / machining center Belotti Eureka 4014 Model 3414. Year of manufacture 2001. Machine in stock, in good condition, fully functional. Lodpfsycin Iex Ad Eshc Available immediately, including a refurbished spare 4kW spindle, software, and complete documentation. Primarily intended for trimming and milling 3D parts – plastic, carbon, laminate, MDF, wood, aluminium, etc. Spindle speeds: 18,000/600Hz – 24,000/800Hz Transport can be arranged. Axis travels:    • X-axis: 4,000 mm    • Y-axis: 1,400 mm    • Z-axis: approx. 1,100 – 1,200 mm

Condition: used, Year of construction: 2009, Year of manufacture: 08/2009 Commissioning: 03/2010 Control: Heidenhain iTNC 530 Technical Data: Tool holder: SK 50 Tool changer: 30 stations Spindle speed vertical, stepless: 4400 rpm Lhodpsya U Uusfx Ad Esc Spindle speed horizontal, stepless: 3500 rpm Cutting capacity: 440 cm³/min Positioning accuracy: +/- 0.005/300 mm Repeatability of the automatic swivel head: +/- 3' Machine table (LxW): 4000 x 2000 mm Travel paths X/Y/Z: 4230 x 2150 x 775 mm Max. workpiece weight: 11,000 kg Rapid traverse X/Y/Z: 12 / 15 / 12 m/min Motor power: 22 kW Dimensions (LxWxH): 10,130 x 4,510 x 4,250 mm Machine weight: 27,000 kg Scope of delivery: - Chip conveyor - Tool cabinet - Approx. 80 tool holders including tools

Condition: used, Year of construction: 2008, functionality: fully functional, machine/vehicle number: 23750, travel distance X-axis: 7,500 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 2,300 mm, spindle speed (max.): 24,000 rpm, overall weight: 120,000 kg, grinding spindle motor power: 32,000 W, We offer this used FOOKE Endura 905 Linear planer-type milling machine - double column, year of construction 2008. Lodpfsyazmkjx Ad Ejhc Machine type: Endura 905 Linear Year of manufacture: 2008 Voltage: 400/230 V Frequency: 50 Hz Power: 130 kW Electrical enclosure rating: IP54 Weight: 120000 kg If you have any questions or need more information, feel free to send us a message or give us a call.
