Superabrasivi

Condition: ready for operation (used), Year of construction: 1965, Functionality: fully functional, hone diameter: 750 mm, table width: 1,200 mm, table length: 1,900 mm, stroke distance: 2,000 mm, The machine is ideal for honing cylinder liners for marine diesel engines, for example. TECHNICAL DATA Table dimensions: 1900 x 1200 mm Spindle height: 3250 mm Stroke distance: 2,000 mm Distance from spindle center to column: 700 mm Honing diameter: 750 mm Number of T-slots: 4 Distance between T-slots: 300 mm MACHINE DATA Total length: 4,000 mm Cdw0Petsge Total width: 2,060 mm Total height: 5,500 mm Installation dimensions: 3,650 x 5,800 mm EQUIPMENT Honing tools for the following diameters (approx.): - 820mm (bar length 500mm) - 640mm (bar length 500mm) - 570mm (bar length 500mm) - 520mm (bar length 300mm, 7-bar tool) - 500mm (bar length 400mm, 7-bar tool) - 450mm (bar length 300mm 7-bar tool) - 360mm (bar length 300mm 7-shell tool) - 350mm (bar length 300mm 7-bar tool) - 270mm (bar length 200mm 7-bar tool) - 270mm (bar length 200mm 7-bar tool)

Condition: used, honing diameter 1,5 -160 mm stroke 400 mm centre height 200 mm total power requirement 0,37 kW weight of the machine ca. 0,750 t dimensions of the machine ca. 1,2 x 1,4 x 1,7 m WORKING RANGE -HONING- Stroke max. 170 mm Stroke min. 6 mm Stroke rate max. 60 /min Stroke rate min. 500 /min WORKING RANGE -INTERNAL HONING- Spindle speeds from 200 /min Drhgfn Spindle speeds up to 3000 /min ELECTRICAL CONNECTION DATA Power consumption (total) 4 kW Supply voltage 400 V Mains frequency 50 Hz DIMENSIONS / WEIGHTS Space requirement -left/right- 1200 mm Space requirement -front/rear- 1600 mm Total height 1900 mm Total weight approx. 750 kg

Condition: good (used), Table 800 x 120 mm B7Wnp9Useg Swivel and tilt head Stroke: 800 mm

Condition: good (used), Condition: Used B7Wkwst0Ti Minimum diameter of sharpening points: 6 mm Maximum diameter of sharpening points: 55 mm Spindle speed: 18-24-36 rpm Grinding wheel speed: 2800 rpm Power: 1.5 Kw Weight: 450 Kg Engagements: 1000 x 650 x 1250 mm

Condition: like new (used), Year of construction: 2016, Never used honing machine B7V8Te2J9G

Condition: ready for operation (used), Year of construction: 1965, Functionality: fully functional, hone diameter: 750 mm, table width: 1,200 mm, table length: 1,900 mm, stroke distance: 2,000 mm, The machine is ideal for honing cylinder liners for marine diesel engines, for example. TECHNICAL DATA Table dimensions: 1900 x 1200 mm Spindle height: 3250 mm Stroke distance: 2,000 mm Distance from spindle center to column: 700 mm Honing diameter: 750 mm Number of T-slots: 4 Distance between T-slots: 300 mm MACHINE DATA Total length: 4,000 mm Total width: 2,060 mm Total height: 5,500 mm Installation dimensions: 3,650 x 5,800 mm EQUIPMENT Drc7Sf Honing tools for the following diameters (approx.): - 820mm (bar length 500mm) - 640mm (bar length 500mm) - 570mm (bar length 500mm) - 520mm (bar length 300mm, 7-bar tool) - 500mm (bar length 400mm, 7-bar tool) - 450mm (bar length 300mm 7-bar tool) - 360mm (bar length 300mm 7-shell tool) - 350mm (bar length 300mm 7-bar tool) - 270mm (bar length 200mm 7-bar tool) - 270mm (bar length 200mm 7-bar tool)

Condition: used, Year of construction: 2011, Precision honing machine SUNNEN Eclipse EC-3500EM-27 Bmyv2Rxvlk S/N: 4S1-1123 1 shelf with partition 1 lighting structure

Condition: used, Year of construction: 2011, Precision honing machine SUNNEN KGM-5000TCG Machine data Year of manufacture: 2011 S/N: 1K1-1081 Spindle speed: 250 - 3,700 rpm Diameter: min./max. 3.81/32 mm 1 front light barrier 1 control unit, swiveling Loading/unloading device Linear travel: approx. 1,200 mm Separate cooling unit Bmyu7Ycc2A Make: PFANNENBERG 1 sheet steel cabinet Doors: 2 Contents: 1 set of analog/digital measuring instruments, general machine accessories

Condition: used, Honing machine DELAPENA #2 Dq9Bpr

Condition: used, Honing machine DELAPENA #1 Bjupkfbehm

Condition: refurbished (used), Single pass - progressive honing machine SUNNEN MHS 840 (like VSS 84) overhaul and electronic retrofit (see video and photos) 4 heads, 8-station rotary table This machine can be inspected under power in our warehouse Test run possible M i m u Machine Tools Gussago BS Italy Single-pass honing is a type of honing process used for finishing internal cylindrical surfaces, where a tool with a fixed set of abrasive stones passes through the bore only once to achieve the desired surface finish and dimensional accuracy. In this process, the tool is typically designed with a specific shape and size, allowing for precise material removal in a single stroke Dq8Plr

Condition: repair required (used), Year of construction: 2016, Functionality: limited functionality, machine/vehicle number: 1601-011, Equipment: type plate available, As Metal Tetragon 130/1 Press 1. Hot press type shelf press 2. 8-shelf press, heated with oil 3. 3 electric heaters 4. Table with pressure insert table with pressure per cm2 Dq3V97 5. Year of production 2016 Press for renovation: 1. For grinding the plate - no plate surface 2. Leaking plate actuators 3. Lack of even plate pressure

Condition: excellent (used), Year of construction: 1987, 1 x Horizontal Honing Machine Nagel HHM 90 A Year of manufacture: 1987 in very good condition. Wsm720Cqy Technical data to follow. Accessories: see photos

Condition: used, Year of construction: 2010, honing diameter 54 mm Krf8Kn9Iq stroke 99999 mm centre height 9999 mm Control FANUC total power requirement kW weight of the machine ca. t dimensions of the machine ca. m CNC Ball and spherical honing machine

Condition: used, Year of construction: 1980, Year 1980 Dqpijt Type Präzisionshonmaschine In our opinion, the machine is in good used condition Condition and can be viewed under power by appointment. Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well Subject to prior sale!

Condition: ready for operation (used), Year of construction: 1993, Functionality: fully functional, machine/vehicle number: 28-7032, spindle speed (min.): 80 rpm, spindle speed (max.): 1,500 rpm, travel distance Z-axis: 1,500 mm, travel distance milling slide Z-axis: 350 mm, TECHNICAL DETAILS Control system: SIEMENS NC Honing capacities Honing diameter: 10 - 120 mm Stroke: 350 mm Max. honing length: 700 mm Spindle speeds (infinitely variable): 80 - 1,500 rpm Cosogbz0Iu Travel distances Z-spindle stroke: 350 mm Z-slide stroke: 1,500 mm Cross slide travel: ± 60 mm Longitudinal travel: 1,800 mm Table and swivel Swivel table: fixed at 0°/30°/45° Other technical data Rotation speed: 80 - 1,500 rpm Variable rinsing rings: 60 - 105 mm Control unit: MS-U2 Programs: 99 programs available Tool control: hydraulic/EMZ/macroform Dimension control: via air measurement Note: Machine is set up but not connected & can be inspected under power on request

Condition: used, Horizontal honing machine (cross grinding machine) PEMAMO HONING (Switzerland) Type MDR 120 E No. 293 Year of construction 1996 Honing range Ø 1.5 - 70 mm Spindle speed 310 to 1860 rpm infinitely variable Motor power 0.37 kW Mains connection 400 Volt, 50 Hz - Expanding diameter infinitely adjustable via handwheel - Semi-automatic expanding unit AR 340 with a repeat accuracy of 1 µm Expansion speed continuously adjustable from 1 to 120 sec. Dwell time infinitely adjustable from 0-30 sec. Automatic switch-off when the desired diameter is reached Automatic return to the initial diameter Repeat accuracy within 1 µm Honing range switchable in 2 stages Ø1.5-20 mm + Ø21-70 mm - Stepless spindle speed via variator gearbox - Start/stop via foot switch - Built-in cooling and lubrication system with oil circulation, honing oil tank with 15 liter pump - Support arm as round rod Ø 15 mm, length 320 mm, with adjustable stop ring - 10 honing tools for nominal diameters 8 / 10 / 12 / 15 / 16 / 17 / 19 / 20 / 25.4 / 30.5 - 31.5 mm Machine dimensions L x W x H: 1000 x 700 x 520 mm weight: 160 kg good condition The machine is used for the specialized honing of bores, e.g. piston cylinders, in order to Dqmuxr to achieve the required dimensions, tolerance and high surface quality. Thanks to the honing machine, shape defects such as scratches, axis curvatures or waviness are eliminated.

Condition: used, Year of construction: 1993, Technical details: honing diameter: 10-120 mm stroke: 350 mm honing length max.: 700 mm spindle turning speed - stepless: 80-1500 1/min Used Honing Machine Make: Nagel Type: PV-150/VS8-35LA 287032 YOM: 1993 Technical data: Z-spindle stroke 350mm Z-slide stroke 1500mm Cross slide travel: ± 60mm Longitudinal travel 1800mm Swivel table at 0/30/45 spline fixed Rotating speed 80-1500 U/min Variable flushing ring of 60-105 mm Control MS-U2 99 diverse Programmes Tool control hydraulical/EMZ/ Makroform Dimensional control via air measurement Still under power, fully functional Cmj3M2Wzns *

Condition: used, Technical details: lapping tool diameter: Ø 1000 mm Ckes7Rervq material thickness: Auftrag ca. 8,0 mm Plate thickness: ca. 75 mm internal diameter: 400 mm Weight approx.: 0,37 t dimensions: 1,2 x 1,2 x 0,3 mm boring diameter: Ø 290 mm Flange mounting: Ø 320 mm This work wheel can be used, for example, on a disk sanding, fine sanding and/or lapping machine. Application: Material removal for “gentle” processing of the workpiece surface, as well as keeping the tools flat The pattern (honeycomb) improves stock removal due to the additional cutting edges. This results in a good surface finish and evenness. Diamond and CBN lapping wheel/lapping plate Die Mittenbohrung Ø 290 mm weist eine Senkung mit Bohrung Ø 400 mm x 47 mm Tiefe auf. Verpackt in Holzkiste 11500 x1150 x 166 mm. *

Condition: used, Technical details: honing diameter: Ø 400 mm stroke: 600 mm throat: 390 mm Ccnn0P3B table-size: 1.550 x 780 mm table surface area: 1.400 x 480 mm table:: fest total power requirement: 4,1 kW Weight approx.: 2,8 t dimension machine xH: 2,0 x 1,2 x 4,35 m Further technical details: - longitudinal travel of machine table approximately 500mm - cross travel of machine table approximately 200mm - working height 350mm (non-adjustable) - distance column / table 0 - 200mm Equipment: - oil tank Ø 300 x 600mm - control panel i.D. *

Condition: good (used), Year of construction: 2012, Functionality: unexamined, machine/vehicle number: 25001, "General specifications: Ciahy8If - Maximum grinding length: 150 mm - Axle height on the bench: 251 mm - Center height from the floor: 1190 mm - Maximum outer diameter of the workpiece: 360 mm - Maximum grindable workpiece length: 200 mm - Maximum loadable weight (at 100 mm): 150 daN - Total installable power: 55 kW - Machine weight: 7000 kg X-axis: - Maximum travel: 330 mm - Maximum speed: 12 m/min - Resolution: 0.0001 mm - Transducer: Linear decoder on axis (absolute) - Axis motor: 7.6 Nm / 3000 rpm Z-axis: - Maximum travel: 590 mm - Maximum speed: 12 m/min - Resolution: 0.0001 mm - Converter: Linear encoder on axis (absolute) - Axis motor: 7.6 Nm / 3000 rpm Internal electric motor spindle: - Maximum revolutions: 36000 rpm (S6) - Grinding wheel motor power: 22 kW (S6) - Model: FISCHER MFM-1418/36/1HJDN16 - Maximum theoretical peripheral speed of the wheel: 50 m/s Workpiece headstock: - Spindle taper: Morse taper 5 / Asa 8 - Bar capacity: 38 mm - Speed range: 10 - 800 rpm - Torque: 58 Nm - Motor: 20 Nm / 3000 rpm Internal grinding wheel: - Diameter: 138 mm - Thickness: 49 mm - Maximum permissible speed: 6000 rpm Additional information: - Available immediately - All UK duties paid - Sale loaded on low loader - Shipping quotes available on request - Full supporting documentation (electronic format) including: Owner's manuals, drawings, certificate of conformity, consumables lists, back up files etc. - Nissan Asset Ref: AF201526 - Acquisition cost €345k+ - Professionally dismantled, marked, packed and stored in Liverpool, UK"

Condition: ready for operation (used), Year of construction: 2004, Functionality: fully functional, spindle speed (min.): 120 rpm, spindle speed (max.): 1,275 rpm, lifting speed: 25 mm/s, feed length Z-axis: 500 mm, hone diameter: 56 mm, TECHNICAL DETAILS Control: Siemens PLC control S7, NAGEL honing spindle control MS-U3 Production capacity: 90 workpieces/h at 100 % capacity utilization Roundness: 0.006 mm / 0.012 mm Bore tolerance: 22.018 - 22.028 mm / 56.000 - 56.019 mm Surface roughness (Rz): 4 µm / 6.3 µm Honing time: 28 / 33 seconds Secondary time: 12 / 7 seconds Cycle time: 40 seconds Workpiece Type: Connecting rod, large and small eye Hardness: 100 - 130 HB Machining diameter: 22 - 26 mm Machining length: 20.8 - 20.23 mm Workpiece holder: clamped and held down Machining data Pre-machining: fine-turned Diameter: 21.99 - 22.01 mm / 55.95 - 55.99 mm Brseunytbdi Roundness: 0.007 mm / 0.01 mm Surface roughness (Ra): 6 - 8 / 8 - 12 µm Material allowance: 0.013 - 0.033 mm / 0.02 - 0.06 mm Tool type Tool type: Diamond, articulated rod Honing spindle Number of honing spindles: 2 Stroke length: 0 - 500 mm Stroke speed: 25 m/min (infinitely variable) Tool holder: top / bottom, infinitely adjustable Spindle speed: 425 - 1,275 rpm and 120 - 360 rpm Drive power Stroke drive power: 5.5 kW Spindle drive power: 3 kW / 4 kW Measuring technology Measuring system: electro-mechanical step expansion Air measuring device: 0.0005 - 0.08 mm MACHINE DETAILS Installation area / height: 6,200 x 3,900 / 4,300 mm Weight: approx. 8 t Color: machine light grey RAL 7035, control cabinet capri blue RAL 5019 Construction: Welded steel construction in panel construction. The uprights have been artificially aged to relieve stresses. Hydraulic equipment Hydraulic tank: 400 l Electrical equipment Operating voltage: 400 V, 50 Hz with neutral conductor Control voltage: DC 24 V Total connected load: 28 kW Standard: according to VDE 0113 Note: Machine is set up but not connected & can be inspected under power on request

Condition: ready for operation (used), Year of construction: 2014, General Data Measurements width 1900 mm Measurements depth 3400 mm Measurements height 2600 mm Machine weight 6500 kg Main Drive Spindle speed range 1,100-1,900 rpm Uwpwabhwj7 Spindle motor power 15 kW Additional Equipment Control cabinet Cable between control cabinet and machine CO2 extinguishing device (without CO2) This vertical honing machine was manufactured in 2014. The Lodi VHP 300 4T CN features a robust design with dimensions of 3400x1900x2600 mm and a net weight of 6500 kg. It supports a maximum workpiece diameter of 300 mm and height of 150 mm. Key capabilities include adjustable table speed from 10-500 rpm and a powerful grinding motor of 15 kW. Ideal for precision honing, the machine we have for sale includes essential accessories. Contact us for further details regarding this vertical honing machine. Application Types Honing

Condition: used, Sunnen EC3500 honing machine holes: 1,5 to 165mm dia. spindle motor 5.5HP auto stone compensation ASC auto sizing available as option More pics available Under power in our warehouse. Test run possible. C93G3Si Mimu Machine Tools (Italy) Sunnen EC3500 ml5000 ml3500 ml2000

Condition: good (used), Honing machine NAGEL HHM-90, No. 2233 Beiyvzq
