Schreiner Karl, Bagger- und Fuhrunternehmen

Condition: ready for operation (used), functionality: fully functional, working width: 1,500 mm, punching force: 28 t, workpiece weight (max.): 200 kg, sheet thickness (max.): 4 mm, working length: 3,000 mm, TECHNICAL DETAILS Gsdpfx Aszlivijmboiw Maximum punching force: 280 kN Working area: 1,500 x 3,000 mm Maximum sheet metal thickness: 4 mm Maximum workpiece weight: 200 kg MACHINE DETAILS Machine weight: 15,800 kg

Condition: ready for operation (used), Year of construction: 2016, operating hours: 46,061 h, punching force: 22 t, sheet thickness (max.): 8 mm, travel distance X-axis: 3,050 mm, travel distance Y-axis: 1,550 mm, CNC punching machine manufactured in 2016. This TRUMPF TruPunch 5000 S12 features a working range of 3050 x 1550 mm and a maximum material thickness of 8 mm. It has a maximum punching force of 220 kN and can handle workpieces weighing up to 280 kg. If you are looking to get high-quality punching capabilities, consider the TRUMPF TruPunch 5000 S12 machine we have for sale. Contact us for further details. • Max. workpiece weight: 280 kg • Max. stripper force: 20 kN • Programmable stripper force: approx. 4.5–20 kN • Active die (optional equipment) max. lifting force: 220 kN • Active die (optional equipment) Z2 acceleration: 14 m/s² • Active die (optional equipment) max. speed: 4 m/min • Max. stroke rate (punching, hole spacing 1 mm): 1350 1/min • Max. stroke rate (marking): 3000 1/min • Max. axis speed X axis: 100 m/min Gjdpfx Aszlgupembjiw • Max. axis speed Y axis: 60 m/min • Max. axis speed X/Y simultaneous: 116 m/min • Max. acceleration X axis: 22 m/s² • Max. acceleration Y axis: 10 m/s² • Rotation C axis, tapping/thread forming: 500 1/min • Number of slots in linear magazine: 25 • Number of tools/grippers: 21/4 • Number of MultiTool tools/grippers: 21–210/2 • Number of grippers, standard/maximum: 4/4 • Part removal max. part size – part chute, punching (standard): 500 x 500 mm • Part removal max. part size – fixed chute, punching with support table: 80 x 50 mm • Cycle times tool change time, standard tool (from station to station): 2.8 s • Cycle times MultiTool tool change time: 0.3 s • Accuracy position deviation Pa: ±0.1 mm • Accuracy mean position dispersion Ps: ±0.03 mm • Control color monitor, TFT: 17" • Control touchscreen: Yes Additional equipment • Storage system • Tooling set (details not specified)

Condition: used, Year of construction: 2005, Punching capacity 220 kN plate thickness 8 mm Gisdjzk Rfijpfx Ambjw working area 2535x1280 mm sheet thickness for stainless steel 4-6 mm

Condition: ready for operation (used), Year of construction: 1998, operating hours: 30,430 h, functionality: fully functional, punching force: 22 t, sheet thickness (max.): 6 mm, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, punching diameter: 76 mm, TECHNICAL DETAILS Pressing force: 220 kN Sheet metal thickness - max.: 6.4 mm Punching diameter: 76.2 mm Travel distance X-axis: 2,500 mm Travel distance Y-axis: 1,250 mm Positioning speed X-axis: 90 m/min Positioning speed Y-axis: 60 m/min Positioning speed (simulation): 108 m/min Positioning speed (rotary axis): 360 °/sec Workpiece weight: 150 kg Smallest programmable path dimension: 0.01 mm or 0.01° Gedezk A Ntepfx Ambeiw Tool stations: 15 Tool change time: 1.5 - 6.5 sec MACHINE DETAILS Dimensions: 6,400 x 5,800 x 2,100 mm Machine weight approx.: 11,050 kg Operating hours: 30,430 h

Condition: good (used), Year of construction: 2014, operating hours: 5,722 h, functionality: fully functional, machine/vehicle number: 379, punching force: 28 t, sheet thickness steel (max.): 6 mm, working range: 2,080 mm, punching diameter: 105 mm, workpiece weight (max.): 200 kg, overall weight: 9,200 kg, lifting height: 90 mm, input voltage: 400 V, repeat accuracy: 0.03 mm, For sale: a Boschert Compact 1000 Rotation, manufactured in 2014, serial number 379, located in Königsdorf/Bavaria (south of Munich). Gsdpszkviaofx Ambsiw CNC punching/nibbling machine for sheet metal processing: – Punching force 28 t (280 kN) – Trumpf tool system (sizes 1–3, up to Ø 105 mm) – Rotating head: all tools can be rotated 360° continuously – Boschert CNC 32050 control with TFT operating panel, DXF import – Working area 1060 × 2080 mm, repositioning for long sheets – Sheet metal thickness up to 6 mm steel Meter readings taken directly from the control panel (photo in the advertisement): – Machine running: 5,722 hours – Hydraulics running: only 1,285 hours – Stroke counter: 2.3 million strokes The machine has been used little and is currently operational – inspection with demonstration is possible on short notice after arranging an appointment. Video will be provided later. Tool inventory and documentation available upon request. Dismantling and loading will be carried out by the buyer or by arrangement. Payment must be made before collection. Sale as seen, excluding any warranty. Export possible. Quick and straightforward transaction – please include a callback number with your inquiry.

Condition: used, Year of construction: 2007, Control system, manufacturer: Boschert; quick-change tool system, manufacturer: Trumpf; punching force: 3 x 280 kN; Station 1: Trumpf system tool, size 3 (105 mm) with spray device; Station 2: Trumpf system tool, size 3 (105 mm), free-rotating and indexable; Station 3: Trumpf system tool/Boschert Revotool, size 3 (105 mm), including Revotool 8-position tool holder; travel distances: X – 3,000 mm (adjustable up to 9,999 mm), Y – 1,580 mm; punching arm overhang: 1,730 mm; sheet metal thickness max.: 6 mm (clamp opening); stroke height max.: 90 mm, programmable in infinitely variable steps upwards and downwards; punching slug extraction; ball bearings in the machine table; table width left + right: 3,200 mm each; table depth: 2,810 mm; table height: 900 mm; overall width: 6,482 mm; overall depth: 4,600 mm; overall height: 2,110 mm; with workshop trolley, manufacturer: KS Tools, 7 drawers, contents: various hand tools. +++ ATTENTION: This machine is part of an online auction! +++ Gijdpezkah Tofx Ambjw

Condition: good (used), Year of construction: 1999, functionality: fully functional, Pressing force: 220 kN Sheet metal thickness – max.: 8 mm Gisdpfx Ajzil Dkembjw Travel distance – x: 3000 mm Travel distance – y: 1500 mm Positioning speed, X-axis: 90 m/min Positioning speed, Y-axis: 60 m/min Positioning speed, simulation: 108 m/min Positioning speed, rotary axis: 360 °/sec Punching diameter: 76.2 mm Workpiece weight: 150 kg Smallest programmable path dimension: 0.01 mm or 0.01° Tool stations: 15 pieces Tool change time: 1.5 - 6.5 sec Machine weight, approx.: 11,050 kg Dimensions: 6400 x 5800 x 2100 mm including setup cassettes including tool cabinet with tools including Quick-Set

Condition: used, Year of construction: 2006, punching force: 30 t, overall weight: 18,000 kg, For sale is a Finn-Power LP 6 combined punching and laser cutting machine, manufactured in 2006. The machine is currently powered and ready for operation. An on-site inspection can be arranged at any time by appointment. We would be happy to demonstrate the machine in operation so that you can see its technical condition and functionality for yourself. The Finn-Power LP 6 combines punching and laser technology in one machine and is ideally suited for the efficient processing of sheet metal parts with high flexibility and productivity. The laser combination requires cleaning of the beam deflection mirrors; the laser source is operating cleanly. Manufacturer: Finn-Power Gjdpfxezb Rr Ej Ambsiw Model: LP 6 Tool stations: 21 Year of manufacture: 2006 Siemens Sinumerik 840D control system CO₂ laser 2.5 kW Hydraulic punching technology with 300 kN punching force Multi-tool system Forming functions Automatic clamping positioning CE-compliant safety equipment Cooling system Extraction system Part conveyor belt Machine is powered Inspection and demonstration possible Immediately available upon agreement For further information, technical data or to arrange an inspection, please do not hesitate to contact us. Available from week 30.

Condition: good (used), Year of construction: 2008, functionality: fully functional, X working area max.: 3000 mm Y working area max.: 1500 mm Control system: Sinumerik 840D Standard equipment: Giedpfxeza Elqj Ambjw - Sturdy C-frame - Coordinate guidance with integrated linear magazine, 25 positions for tools and clamping jaws - 4 clamping jaws - Automatic part slide 500 x 500 mm - Drives: Maintenance-free three-phase servo motors Punch head: - Hydraulic mono-tool holder - 360-degree rotation for all tools - Automatic tool length compensation - Tool spray lubrication - 2nd lubricant tank - Programmable wiper movement - Punch slug extraction - Programmable clamping device for re-clamping with pre-selectable clamping force - Bulge detection Control system: - 10.4-inch TFT display - Simple operation - Diagnostic function - Integrated 3.5-inch floppy disk drive - RJ45 network connection Safety: - CE marking - Multi-beam light barriers - Rapid shut-off of hydraulics + Multitool function + MultiBend function + Thread forming function + Marking/fast beading function + Deburring and rolling technology + Individually opening clamping jaw + Re-clamping cylinder + Sensor for part slide + Vibration-damped installation + Automatic shut-off + Chip conveyor + MDE interface + ToolMaster 70

Condition: ready for operation (used), Year of construction: 1995, operating hours: 51,658 h, functionality: fully functional, punching force: 22 t, sheet thickness (max.): 8 mm, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, TECHNICAL DETAILS Sheet width: 2,500 mm Sheet length: 1,250 mm Sheet thickness: 8 mm Gisdpsy U U Npjfx Ambew Punching force: 220 kN MACHINE DETAILS Operating hours: 51,658 h Machine weight: approx. 11,050 kg EQUIPMENT - TRUMPF Sheetmaster

Condition: ready for operation (used), Year of construction: 2014, operating hours: 65,000 h, functionality: fully functional, punching force: 22 t, sheet thickness (max.): 8 mm, travel distance X-axis: 3,050 mm, travel distance Y-axis: 1,550 mm, workpiece weight (max.): 200 kg, Machine with SheetMaster TECHNICAL DETAILS Travel range of the X-axis during punching: 3,050 mm Travel range of the Y-axis during punching: 1,550 mm Sheet thickness: max. 8 mm Workpiece weight: max. 200 kg Punching force: max. 220 kN Stroke rates Punching stroke rate at 1 mm: 1,350 min⁻¹ Marking stroke rate: 3,000 min⁻¹ Part removal Part size, part flap during punching: max. 500 x 500 mm Part size, fixed chute during punching with a moving table: max. 80 x 50 mm MACHINE DETAILS Operating hours: 65,000 h Space requirement: 7,395 x 6,540 x 2,072 mm Gedpfx Amjy U Ut Isbsiw Power consumption, auto-shutdown active: 0.5 kW Power consumption during production: 9.5 kW

Condition: ready for operation (used), Year of construction: 1980, functionality: fully functional, throat depth: 2,700 mm, sheet thickness (max.): 13 mm, sheet thickness steel (max.): 13 mm, overall weight: 2,120 kg, total width: 1,200 mm, total length: 4,500 mm, total height: 2,000 mm, space requirement height: 2,300 mm, space requirement length: 4,800 mm, input voltage: 400 V, Refurbished Pullmax Kumla F13C edge rolling machine in excellent condition for sale. Can edge roll steel sheets up to 13 mm thick and stainless steel sheets up to 10 mm thick! Gsdpfx Ajy Tni Tsmbjiw

Condition: new, Year of construction: 2026, functionality: fully functional, D-T50 – CNC Turret Punch Press | Heavy Duty CNC Turret Punch Press – D-T50 | 500 kN | Sheet size 2500×1250 mm Heavy-duty CNC turret punching machine engineered for high-volume sheet metal fabrication. With a punching force of 500 kN and a stroke rate of 160 hits per minute, the D-T50 guarantees excellent productivity and precision. Key Specifications: • Capacity: 500 kN • Hit Rate: 160 strokes/min • Sheet Size: 2500 × 1250 mm • Max. Sheet Size (with single reposition): 5000 × 1250 mm • Max. Sheet Thickness: ≤ 6.35 mm • Accuracy: ± 0.1 mm • Feeding Speed: 80 m/min • Turret Stations: 16 / 24 / 32 • Air Pressure: 0.65 MPa • Machine Dimensions: 5000 × 5200 × 2300 mm ✅ High hit rate – ideal for mass production ✅ Extended sheet capacity with repositioning up to 5000 mm ✅ CE certified | Warranty included | Spare parts & service available D-Y80 – CNC Turret Punch Press | Heavy Duty | Thick Plate CNC Turret Punch Press – D-Y80 | 800 kN | Thick Plate up to 15 mm Heavy-duty CNC turret punching machine designed for processing thick sheet metal. The D-Y80 accommodates material up to 15 mm thick, delivering 800 kN punching force — perfect for structural and heavy-gauge tasks. Key Specifications: • Capacity: 800 kN • Hit Rate: 100 strokes/min Giodpfxey Swn Ns Ambow • Sheet Size: 2000 × 800 mm • Max. Sheet Thickness: 6–15 mm • Accuracy: ± 0.15 mm • Feeding Speed: 60 m/min • Turret Stations: 6–12 • Air Pressure: 0.65 MPa • Machine Dimensions: 4100 × 4000 × 2400 mm ✅ Exceptional punching force – specialist for heavy-gauge sheet metal ✅ Robust design for demanding industrial applications ✅ CE certified | Warranty included | Spare parts & service available

Condition: good (used), Year of construction: 1999, operating hours: 52,324 h, functionality: fully functional, X working area max.: 1270 mm Y working area max.: 1270 mm Control: Bosch Type 3 Basic Standard equipment: - Robust C-frame - Safety light barriers - Coordinate guide with integrated linear magazine Gjdpfxoy Sat Us Ambeiw - 2 clamping claws - Automatic tool changer - Automatic repositioning - Tool length compensation - Forming capability - Mono tool holder with 360° rotation for all tools - Programmable hold-down device - Multitool drive - Punch slug extraction - Brush tables - Part chute 200 x 200 mm, sorting of parts into 2 containers - NC-controlled, digital, maintenance-free three-phase drives - Network interface RJ34 - 3.5" floppy disk drive - TOPS 2000 graphical programming - Online diagnostics via modem - Operating manual + Vibration-damped installation + Multitool + Thread forming + Start post

Condition: good (used), Year of construction: 2014, functionality: fully functional, Sheet width: 3000 mm Sheet length: 1500 mm Sheet thickness: 8 mm Workpiece weight: 200 kg Punching force max.: 220 kN Total power requirement: 9.5 kW Space requirement approx.: 7395 x 6540 x 2072 mm Equipment: Punch head: - Hydraulic single-tool chuck with 360° rotation - Manually adjustable clamping force - Programmable clamp (active/passive/re-positioning) - Spray lubrication for punch - Stroke counter for punch - Level monitoring for threading and tool lubrication Control system: - Open control system based on Sinumerik 840 D - 12" TFT color display - Teleservice via internet - Automatic shutdown Data transfer: - USB interface - RJ-45 network connection Safety: - CE marking - Dual light curtains - Rapid shutdown of hydraulics - Bulge detection Programming: - TruTops Punch via network access 1 x MultiTool function 1 x MultiShear function 1 x Thread forming function 1 x Deburring and rolling technology 1 x SoftPunch function 4 x individually openable clamping jaws 4 x height-adjustable clamping jaws 1 x Re-positioning cylinder 1 x Sensor for stripper (included in rest material-free processing) Gsdpfx Amjy Sak Tsbsiw - GripMaster - Rest material grippers with sensor technology - Shear lift table 400 mm - Tilting rest material pallet 3000 x 1500 mm - SheetMaster - Operating hours: 65,000 h

Condition: excellent (used), Year of construction: 2024, operating hours: 3,540 h, functionality: fully functional, punching force: 280 t, X working area max.: 3080 mm Y working area max.: 1540 mm Operating hours: 3540 hrs Control: CNC control LABOD with graphics Standard equipment Hydraulic punching machine - Punching force: approx. 280 kN (28 tons) - Throat depth: approx. 1750 mm - Max. punching diameter: 70.0 mm - Max. stroke height: 90 mm, steplessly programmable up and down via control - Table width left + right: 3430 mm each - Table depth: 3160 mm - Table height: 900 mm + 8 easily exchangeable cassette holders + Rotary drive, tool holders top and bottom continuously rotatable 360° + 1 piece, indexable Revotool tools + Programmable clamp positioning + Scrap slug extraction system + Spray device + Brush table + Brush table extension tables + Multitalk, USB, SD memory card and network connection + Digital stroke height adjustment + Three-sided safety light barrier Gsdpfx Amey N Dwrobjiw + Various intermediate matrix plates for Trumpf tooling sizes 1 and 2 + Tooling package + 1 set of keys and operating manuals + Boschert EasySharp tool grinding device

Condition: good (used), Year of construction: 2004, functionality: fully functional, Punching force: 220 kN Godpsyrcycsfx Ambsiw Sheet thickness: 8 mm Working area: 2535x1280 mm Sheet thickness for stainless steel: 4-6 mm Accessories: - Tool change cassettes - Table with ball rollers - Operating hours: 97,000

Condition: new, neu ca. 12 - 14 Wochen ab Auf Türkei 292500 € 30 to 3000x1500 mm 3000 mm 1500 mm 70 m/Min 60 m/Min 120 m/Min 40 mm 1200 1/Min 325 1/Min 2800 1/Min 6 mm 3 mm 3 mm 1.5 mm 28 0,1 mm 0,05 mm 22 U/Min 150 U/Min 200 kg 940 mm 6 bar 88.9 mm 15 kW 180 l 6650 mm 7650 mm 6300 mm 8300 mm 2310 mm 18250 kg Control unit, Siemens Sinumerik 840 D SL CAD-CAM software Programming on the control panel Remote diagnostic function Automatic clamp positioning Network Ethernet communication Automatic tool lubrication UPS for control panel Movable scrap box Brush table Oil Cooler USB Driver Command pedal Web cam for service Reposition on X axis Alignment Tools for Index Station D Manual nesting turret (27 stations without tool and holder): 11 x A-Station fix: 0,8-12,7 mm 11 x B-Station fix: 12,8 - 31,7 mm 2 x C-Station fix: 31,8 - 50,8 mm Gjdoynna Hopfx Ambjiw 1 x D-Station fix: 50,9 - 88,9 mm 3 x D-Station Index: 50,9 - 88,9 mm Infra-red light barriers according to CE rules PRICE FCA TÜRKIYE

Condition: new, neu ca. 12 - 14 Wochen ab Auf Türkei 249800 € 30 to 2500x1250 mm 2500 mm 1250 mm 116 m/Min 80 m/Min 140 m/Min 40 mm 1200 1/Min Giodpfx Ajynnayembsw 425 1/Min 3200 1/Min 6 mm 3 mm 3 mm 1.5 mm 27 0,1 mm 0,05 mm 22 U/Min 150 U/Min 120 kg 940 mm 6 bar 88.9 mm 15 kW 5750 mm 6800 mm 5360 mm 7360 mm 2310 mm 12960 kg Control unit, Siemens Sinumerik 840 D SL CAD-CAM software Programming on the control panel Remote diagnostic function Automatic clamp positioning Network Ethernet communication Automatic tool lubrication UPS for control panel Movable scrap box Brush table Oil Cooler USB Driver Command pedal Web cam for service Reposition on X axis Alignment Tools for Index Station D Manual nesting turret (27 stations without tool and holder): 11 x A-Station fix: 0,8-12,7 mm 11 x B-Station fix: 12,8 - 31,7 mm 2 x C-Station fix: 31,8 - 50,8 mm 1 x D-Station fix: 50,9 - 88,9 mm 3 x D-Station index: 50,9 - 88,9 mm Infra-red light barriers according to CE rules Price FCA Türkiye

Condition: used, Year of construction: 2001, punching force: 2,800 t, total length: 2,500 mm, sheet thickness (max.): 8 mm, overall weight: 11,500 kg, table length: 1,250 mm, Offered for sale. Nice Boschert punching nibbling machine. Comes with a large selection of tools. Giedsyiz I Tepfx Ambjw

Condition: used, Year of construction: 2011, Offer: High-Precision and Versatile Punching/Nibbling Machine Boschert Compact 500 CNC Z (Year 2011) – Ideal for Flexible Sheet Metal Processing! We are selling a powerful and reliable punching/nibbling machine from the renowned manufacturer Boschert, which impresses with its advanced features and precision. This machine is the ideal solution for a wide range of punching and nibbling tasks, from one-off pieces to large-scale production. Key Features: • Manufacturer: Boschert • Model: Compact 500 500 x 1000 CNC Z • Year of manufacture: 2011 • Intuitive CNC Control: Multi-axis Ladob controller with graphical user interface for easy programming and visualization of machining processes. • Extended work area for greater flexibility: o X-axis: 0–2000 mm (enables processing of long workpieces) o Y-axis: 0–750 mm (offers ample space for wide sheet metal) • Ultra-fast tool change: Trumpf quick-change tool system ensures minimal downtime and maximum productivity. • Universal tool compatibility: Compatible with the full range of Trumpf tools – reduce your tooling costs and expand your capabilities. • Secure and precise material handling: o Collet clamping: Ensures a firm grip of the workpiece during processing. o Non-contact repositioning up to 9999 mm: High-precision repositioning device with 2 sheet holders for efficient processing of even very long sheets without loss of position. • Dynamics and precision at their best: Gijdox Uxtfopfx Ambsw o Maximum positioning speed: 60 m/min for fast processing cycles. o Infinitely variable feed rates: Optimal adjustment of processing speed to the material and task. o Highest positioning accuracy: ± 0.05 mm for precise results on every workpiece. • Robust and durable construction: o Y-axis drive: Two ball screw-driven carriages located left and right beside the machine table ensure maximum stability and torsional stiffness. o X-axis drive: Ball screw and four recirculating ball guides guarantee precise and smooth movement. • Specialized equipment for small parts: Stop plate (L-bracket) for secure processing of small parts that can no longer be safely held by the collets – for maximum flexibility and minimal scrap. Condition: The machine is in very good, well-maintained condition and has been serviced regularly. It is immediately ready for operation and offers excellent performance for your sheet metal processing needs.

Condition: excellent (used), Year of construction: 2006, punching force: 28 t, sheet thickness (max.): 10 mm, sheet thickness steel (max.): 6 mm, punching diameter: 105 mm, throat depth: 1,500 mm, Boschert TWIN 1500x3000 Rota-Index Quick-change tool system TRUMPF Station 1: Rotating with indexing option for Boschert Multitool Max. punching diameter 105 mm, infinitely rotatable tool Station 2: Max. punching diameter 105 mm, with option for Boschert Multitool Revotool adapter incl. 8-position tool holder Punching force: 280 kN (28 tons) Travel range: x-axis 2050 mm (repositioning up to 9999 mm) y-axis 1580 mm Throat depth: 1750 mm Tool system: Trumpf Gr1-3 (105 mm) and Boschert Revotool Labod 32060 graphic control / workshop programmable Max. sheet thickness: 6 mm (clamp opening) Max. stroke height: 90 mm, infinitely programmable upwards and downwards Table width left + right: 2250 mm each Table depth: 3250 mm Table height: 900 mm Overall width: 4900 mm Giedpfx Ajx Tp Rfombjw Overall depth: 4800 mm Overall height: 2080 mm Drive power: 20 kVA Machine weight: 15,000 kg Hydraulic oil capacity: 160 l Color: Blue RAL5017 / Light Grey RAL7035 Year of manufacture: 2006 Ball transfer table Slug extraction system Fast hydraulic system Very well maintained condition Comes with accessories

Condition: ready for operation (used), functionality: fully functional, punching force: 22 t, sheet thickness (max.): 6 mm, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,270 mm, workpiece weight (max.): 150 kg, Punching and nibbling machine with TRUMALIFT Sheetmaster! TECHNICAL DETAILS Press force: 220 kN Max. sheet thickness: 6.4 mm Travel path X-axis: 2,500 mm Travel path Y-axis: 1,270 mm Positioning speed X-axis: 90 m/min Positioning speed Y-axis: 60 m/min Positioning speed simulation: 108 m/min Positioning speed rotary axis: 360°/sec Punching diameter: 76.2 mm Minimum programmable increment: 0.01 mm or 0.01° Workpiece weight: 150 kg Tool stations: 15 pcs Tool change time: 1.5 - 6.5 sec MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 6,400 x 5,800 x 2,100 mm Machine weight: approx. 11,050 kg EQUIPMENT Multitool control "Softpunch" function Pneumatic follow-up cylinders Small parts sensor for programmable part chute Parts box for finished parts Chip conveyor with container Scratch-reduced processing Air-cushioned mounting Gedpfxex I Hh Rj Ambjiw Additional clamping bridge Prepared for TRUMALIFT SheetMaster TRUMALIFT Sheetmaster for workpieces up to 2,500 x 1,250 mm Alignment system for loading stack with spreader magnets Manually movable scrap grid system

Condition: ready for operation (used), Year of construction: 2001, operating hours: 62,769 h, functionality: fully functional, punching force: 22 t, sheet thickness (max.): 8 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, TECHNICAL DETAILS Sheet thickness: 8 mm Punching force: 220 kN Travel X-axis: 3,000 mm Travel Y-axis: 1,500 mm MACHINE DETAILS Control: Siemens Machine weight: approx. 17,500 kg Operating hours: 62,769 h EQUIPMENT Gjdpfx Asx I E Ezsmbeiw Scraper position change monitoring Thread forming Marking – quick beading Slitting Multishear Multibend Backgauge repositioning Roller tools Setup cassettes Ball transfer table

Condition: ready for operation (used), Year of construction: 2011, punching force: 31 t, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,525 mm, overall weight: 21,000 kg, table load: 160 kg, controller manufacturer: FANUC, number of axes: 2, This AMADA EMZ 3610 NT CNC punching machine was manufactured in 2011. It features a Fanuc control system, a punching force of 300kN, and a working area of 2500 x 1525 mm, extendable to 5000 x 1525 mm with repositioning. The machine can handle sheet thicknesses up to 4.5 mm and supports a maximum table load of 160 kg. If you are looking to get high-quality punching capabilities, consider the AMADA EMZ 3610 NT machine we have for sale. Contact us for more information. • Working area with repositioning: 5000 x 1525 mm • Max. sheet thickness: 4,5 mm (mild steel) • Feed rate X/Y: 100 / 80 m/min (128 m/min simultaneous) • Positioning tolerance: +/- 0,1 mm • Z-turret stations: 45 • AutoIndex stations: 4 (2 x B, 2 x C) • Turret feed rate: 30 1/min • Max. number of hits: 1000/min • Machine frame: Bridge frame • Punching drive: Servo-electric Twin Drive • Drives (turret + table): AC-Servo motors • Clamps: Pneumatical • Electrical connection: 400V / 50Hz • Electrical consumption: 1 kW – 7 kW • Air consumption (machine): 250 l/min • Air consumption (Air Jet Vakuum): 250 l/min Additional equipment • Loading unit: Loader L III 300 • Sheet size min.: 1000 x 300 mm • Sheet size max.: 3000 x 1500 mm • Material thickness: 0,5 – 8,0 mm • Max. loading weight: 300 kg • Max. stack height: 300 mm • Max. pallet weight: 4000 kg (2x2000 kg) • Max. feed rate (traverse): 70 m/min • Number of suction cups: 34 pieces • Double sheet control: Yes, with sheet thickness detector • Air consumption: 510 l/min, 6 bar inlet pressure • Electrical connection: 400V • Unloading unit with Parts Remover: PR 3 UL 300 P • Part size min./max.: 150 x 150 mm / 2500 x 1000 mm Gedpfxex D Hpqj Amboiw • Sheet thickness: 0,5 – 3,0 mm (4 mm for EM-Serie) • Max. part weight: 50 kg • Storage table size: 3400 x 1400 mm • Max. part size for unloading clamps: 3000 x 1500 mm • Max. stack height skeleton table: 450 mm • Max. weight skeleton table: 2000 kg • Max. stack height storage table: 450 mm • Max. weight storage table: 4000 kg • Max. feed rate X-/Y-direction: 180 / 90 m/min • Air consumption: 1000 l/min, 6 bar inlet pressure • Electrical connection: 400V
