LERINC Werkzeugmaschinen & Automation GmbH

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, nominal power (apparent): 7 kVA, Number of controlled axes: 5 X-axis travel (longitudinal): 6650 mm Y-axis travel (transverse): 800 mm Z-axis travel (vertical): 525 mm B-axis rotation (vertical-horizontal): 0° to 90°, continuous C-axis rotation (perpendicular to the work plane): 0° to 360° Electric spindle power at 24,000 rpm: 7 kW Number of independent work areas: 2 Tool holder taper: HSK-E 40 Godpfx Acszz Stveiobt Tool magazine capacity: 9 + 1 Maximum dimensions of disc cutter: diameter/thickness: 300 / 5 mm Automatic positioning of vices

Condition: used, Year of construction: 2008, functionality: fully functional, travel distance X-axis: 1,200 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,200 mm, controller manufacturer: Siemens, spindle speed (max.): 6,000 rpm, coolant supply: 70 bar, spindle nose: SK50, number of spindles: 1, number of slots in tool magazine: 300, Equipment: chip conveyor, documentation/manual, Hüller Hille NBH230 Sale without multi-pallet storage system. The machine can be integrated into an existing automation system or converted for manual loading. The professional conversion is carried out by the experts at GSN Maschinen-Anlagen-Service GmbH to OEM standards. Spare parts, repairs, conversions, retrofits, relocation, commissioning, and much more – all from a single source. Technical data and highlights: Pallet size: 630x800 (Additional pallets available) Year of manufacture: 2008 Tool interface: SK50 Control system: Siemens 840D Powerline Gbsdpozzw Dtsfx Acijt Main axes: X/Y/Z/B Spindle type: Geared spindle, 2-stage (Extended spindle housing) Spindle speed: 6,000 rpm Tool magazine: 300-place cassette magazine (6 units) Axis travels (X/Y/Z): 1200/1000/1200mm Coolant: 1200 l coolant tank including chip conveyor Rotary table (B): NC type, 0.001mm Additional equipment / options: Rotating transparent screen Tool drawer Remote diagnostics Feedrate torque monitoring Drill breakage monitoring Renishaw OMP60 measuring probe

Condition: good (used), Year of construction: 2011, Equipment: chip conveyor, Tool holder: HSK 63 Turning spindle: 85 Spindle speeds: 20,000 rpm Chain magazine: 60 positions Gbedpozzmcrjfx Aciet Table size: 400 x 500 mm Table load: 500 kg Chip conveyor Pallet changer Coolant filtration system KS high-pressure system through the spindle

Condition: new, Year of construction: 2026, feed length X-axis: 80 mm, feed length Y-axis: 80 mm, feed length Z-axis: 60 mm, spindle speed (min.): 24,000 rpm, Perfect for: Applications in model and mold making, as well as for milling other materials – a universal powerhouse with a rapid traverse rate of 80 m/min. Materials: Plastics, composite materials such as CFRP/GFRP, model-making materials, aluminum. Industries: Automotive, aerospace, transportation & logistics, leisure industry, sanitary, boat building, automation. _____ Reference number: 1233 Availability from: approximately December 2026 / January 2027 CNC machine type: 5-axis CNC milling machine G-S-F/UNI (35-15) Spindle data: 13 kW / 10.3 Nm; 12000-24000 1/min; HSK F 63 Gedpfx Acjzy Updsiobt Rapid traverse rate X/Y/Z: 80/80/60 Part dimensions X/Y/Z: 3500 x 1500 x 700 Control system: SIEMENS – Sinumerik One with hand terminal HT 2 Tool changer: 10 tools Tables: 1 table Vacuum system: yes Tool breakage and length monitoring: Renishaw-TS 27 R Other: on request Year of manufacture: 2026 Condition: new

Condition: ready for operation (used), Year of construction: 2007, operating hours: 29,682 h, travel distance X-axis: 1,250 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, controller manufacturer: FANUC, controller model: 31i MA, total height: 3,330 mm, total width: 4,270 mm, table load: 1,600 kg, overall weight: 21,000 kg, spindle speed (max.): 6,000 rpm, spindle motor power: 30,000 W, number of slots in tool magazine: 90, tool weight: 25,000 g, product length (max.): 7,060 mm, number of axes: 3, This 4-axis DOOSAN HM 8000 was manufactured in 2007. It features an impressive X/Y/Z axis travel of 1250 x 1000 x 1000 mm and a maximum load capacity of 1600 kg. The machine includes a tool magazine capacity of 90 positions and operates with a spindle speed of 20 - 6,000 RPM. If you are looking to get high-quality machining capabilities, consider the DOOSAN HM 8000 horizontal machining centre we have for sale. Contact us for further details. • Secondary HMI panel: Pro-face (magazine rotation) • Rapid feedrate (X/Y/Z): 24 / 24 / 24 m/min • Pallet/table size: 800 × 800 mm Gjdpfx Aszyaa Iociobt • Number of pallets: 2 • Pallet indexing: 1° • Max. workpiece size: 1310 × H1200 mm • Tool magazine capacity: 90 positions (86 recorded on HMI tool search screen) • Max. tool diameter: 135 mm (with adjacent tool), 250 mm (without adjacent tool) • Max. tool length: 550 mm • Coolant through spindle: High-pressure • Operating hours (from CNC): Power on 70,190 h 16 m; Operating 29,682 h 18 m; Cutting 17,937 h 26 m • Recent maintenance/overhauls: Pallet changer, spindle line, tool changer, and auger motors recently overhauled Additional equipment • Chip conveyor • Coolant circuit filtration system with belt-type oil skimmer • BUTTI chip collection bin Technical Specification Taper Size ISO 50

Condition: refurbished (used), Machine is located at our premises in Burscough. We welcome any inspections prior to sale. Spindle Diameter 4" / 101.6mm Spindle Taper 50 INT Main spindle travel 30" / 762mm Spindle speeds 10 - 1300rpm Vertical Y Travel - 48" / 1219mm Main Motor 25 HP Equipment - Facing head, outer (tailstock) steady Gbodpfozwmrlox Acist Vast amount of tooling, rotary table, angle plates. DRO Pendant control This machine has undertaken a full machine rebuild and all slides re ground. Exceptional condition

Condition: ready for operation (used), Year of construction: 2012, operating hours: 25,960 h, functionality: fully functional, machine/vehicle number: 238911, travel distance X-axis: 1,400 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,325 mm, table length: 800 mm, spindle speed (max.): 8,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 1,400 mm Travel range, Y-axis: 1,200 mm Travel range, Z-axis: 1,325 mm Table area (L x W): 800 x 800 mm Spindle speed: 8,000 rpm Spindle torque: 1,218 Nm Tool changer positions: 80 MACHINE DETAILS Number of pallets: 2 Dimensions & Weight Dimensions (L x W x H): approx. 8,000 x 3,000 x 3,500 mm Weight: approx. 30,800 kg Operating Hours (according to image) Operating hours: 54,415 h Power-on hours: 30,498 h Cutting hours: 25,960 h EQUIPMENT Tool magazine for 80 tools, SK 50 DIN69871 Air blow-off device on the workpiece Interface for high-pressure cooling system 70 bar, Knoll Chip conveyor Preparation for Mazak Monitoring System B, optical probe type OMP60 Synchronized tapping Rapid traverse with constant pitch during angular movements 2-pallet changer Spindle with increased torque NC rotary table with 360,000 positions Gsdeztqg Sepfx Acisbt MAZAK Monitoring System B, optical probe type OMP60 Automatic tool length measurement

Condition: used, Year of construction: 2018, operating hours: 3,000 h, travel distance X-axis: 3,200 mm, travel distance Y-axis: 620 mm, travel distance Z-axis: 600 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 6 m/min, rapid traverse Z-axis: 6 m/min, table length: 3,000 mm, spindle speed (min.): 4,000 rpm, spindle motor power: 7,500 W, number of slots in tool magazine: 10, Equipment: rotational speed infinitely variable, CNC drilling/milling machine No CNC knowledge required, extremely easy to operate Tool holder: Laip Coolant system Automatic tool changer for 10 tools Automatic tool length measurement Data import: DXF Electronic handwheel Light curtain on the operator side Spindle motor: 7.5 kW Spindle speed: 200-2000 RPM Touchscreen: 21.5" Gbjdpezqvbpsfx Aciot Factory inspected

Condition: used, Year of construction: 1999, x-travel 1800 mm y-travel 1000 mm z-travel 1200 mm Control Siemens 840 C total power requirement 20 kW Gbsdpfozmy T Isx Acijt

Condition: used, Year of construction: 2000, x-travel 1800 mm y-travel 1000 mm z-travel 1200 mm Gsdpezmy Tnjfx Acijbt Control Siemens 840 C total power requirement 20 kW

Condition: good (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 1,400 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,350 mm, workpiece weight (max.): 3,000 kg, spindle speed (max.): 15,000 rpm, coolant supply: 40 bar, tool weight: 27,000 g, We offer in good condition DMG Mori NHX8000 from 2015 with following options: Gsdpfx Acozlqw Ioisbt 30/25 KW 15.000 RPM Spindle SK50 Mapps 4S Control 60 tool ATC 800x800 pallet 3.000 kg max table load Signal light 40 bar Internal coolant Touch probe Machine will be in stock in 2 weeks

Condition: ready for operation (used), Year of construction: 2012, operating hours: 25,960 h, functionality: fully functional, machine/vehicle number: 238911, travel distance X-axis: 1,400 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,325 mm, table length: 800 mm, spindle speed (max.): 8,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 1,400 mm Travel range, Y-axis: 1,200 mm Travel range, Z-axis: 1,325 mm Table area (L x W): 800 x 800 mm Spindle speed: 8,000 rpm Spindle torque: 1,218 Nm Tool changer positions: 80 MACHINE DETAILS Number of pallets: 2 Dimensions & Weight Dimensions (L x W x H): approx. 8,000 x 3,000 x 3,500 mm Weight: approx. 30,800 kg Operating Hours (according to image) Operating hours: 54,415 h Power-on hours: 30,498 h Cutting hours: 25,960 h EQUIPMENT Gjdezi Ai Rjpfx Aciobt Tool magazine for 80 tools, SK 50 DIN69871 Air blow-off device on the workpiece Interface for high-pressure cooling system 70 bar, Knoll Chip conveyor Preparation for Mazak Monitoring System B, optical probe type OMP60 Synchronized tapping Rapid traverse with constant pitch during angular movements 2-pallet changer Spindle with increased torque NC rotary table with 360,000 positions MAZAK Monitoring System B, optical probe type OMP60 Automatic tool length measurement

Condition: good (used), Year of construction: 2005, Horizontal machining center Machine type: Mori Seiki NH 8000 DCG Control: Fanuc 18 imb + Mapps 2 Year: 2005 Working hours: !!! 9.971 !!! h SPECIFICATIONS Travel X-Axis: 1.400 mm Y-Axis: 1.200 mm Z-Axis: 1.200 mm B-Axes: 0,001° Rapid motion: (X/Y/Z): 50 m/min. Spindle speeds: 10.000 rpm Gedpfjzizd Hsx Aciebt Spindle power: 30 / 25 kW Tool: BT 50 Toolchanger Tool capacity: 140 Palett system Amount of paletts: 2 Palett size: 800 x 800 mm Machine weight: 32.000 kg Req. space (LxBxH): 9,200 x 4,900 x 3,920 m Equipment Internal cooling: bar Chip conveyor High pressure pumps

Condition: used, 5-Axis CNC Machining Centre – EMMEGI SATELLITE TU/6.5 Manufacturer: Emmegi Model: Satellite TU/6.5 5-axis CNC machining centre designed for machining aluminium profiles and light alloys. Ideal for milling, drilling, tapping and complex multi-face machining operations in a single setup, ensuring high precision and productivity. The machine is equipped with a high-speed vertical electrospindle, automatic tool magazine, pneumatic profile clamps, and an Emmegi CNC control system, making it an ideal solution for the production of aluminium windows, doors, curtain walls and architectural aluminium structures. Main Features ✅ 5-axis CNC machining centre ✅ Suitable for aluminium profiles and light alloys ✅ Milling, drilling, tapping and multiple machining operations ✅ High-speed electrospindle ✅ Automatic tool magazine ✅ Pneumatic clamps for secure profile clamping ✅ Long worktable for machining long profiles ✅ CE marked Technical Specifications X-axis travel: 6,500 mm Y-axis travel: 800 mm Z-axis travel: 300 mm Gbedpfxjzhbg So Aciet Weight: 6,500 kg Installed power: 26 kW Rated current: 77 A Power supply: 400 V – 3 Phase – 50 Hz

Condition: ready for operation (used), Year of construction: 1998, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,500 mm, table load: 20,000 kg, spindle speed (max.): 3,500 rpm, number of axes: 3, This 4-axis Burkhardt-Weber MC100 was manufactured in 1998. It features a working range with an X-axis travel of 3,000 mm, Y-axis travel of 2,500 mm, and Z-axis travel of 1,500 mm. The machine has a maximum table load capacity of 20,000 kg and a spindle speed of 3,500 RPM. If you are looking to get high-quality milling capabilities, consider the Burkhardt-Weber MC100 horizontal machining centre we have for sale. Contact us for further details. • B-axis (NC rotary table): 360° continuous • Tooling standard: High-torque configuration for large-scale milling • Additional notes: • Retrofitted in 2008 Godpjzg Il Ejfx Acisbt Technical Specification Taper Size BT 50

Condition: ready for operation (used), Year of construction: 2022, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 750 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 355, table load: 4,000 kg, spindle speed (max.): 1,800 rpm, spindle motor power: 20,000 W, number of axes: 5, This 5-axis SHW PowerSpeed 4000 CNC horizontal machining center was manufactured in 2022. It features an impressive X-axis travel of 1,500 mm, Y-axis travel of 1,000 mm, and Z-axis travel of 750 mm. The machine includes a rotary table with a diameter of 1,400 mm and a maximum table load of 4,000 kg. If you are looking to get high-quality machining capabilities, consider the SHW PowerSpeed 4000 machine we have for sale. Contact us for further details. Gsdpfx Acozgd I Aoijbt • Bosch Servodyn servo drives; individual AC drives on X/Y/Z • Status / Condition: Machine connected and operational; very good technical condition; regularly maintained; available for inspection under power • Documentation: Complete technical, electrical, programming, transport and maintenance manuals; large documentation package included • W (quill) 115 mm • Rotary table: RT 5D, Ø 1,400 mm; controlled axes X, Y, Z, W, B (table); 7 T-slots + center slot; T-slot 22 mm (DIN 650); spacing 160 mm; center bore Ø 100 H6; max speed 2.5 rpm; table weight ~2,800 kg • Spindle: 95 mm front bearing diameter; horizontal and vertical milling spindle capability • Feed rates: Infinitely variable; 2–8,000 mm/min; rapid 8,000 mm/min • Tool clamping force: Horizontal 16,000 N; Vertical 10,000 N • Machine configuration and features: Horizontal machining center with automatic indexing rotary table; full enclosure; automatic lubrication system; Bosch Servodyn drive package; Heidenhain CNC control; large electrical cabinet with climate-controlled cooling units • Main capacities (summary): W 115 mm; rotary table Ø 1,400 mm Additional equipment • Vertical milling head (attachment) • Tool holders (as visible in photos) • Tool trolley (as visible in photos) Technical Specification Taper Size ISO 50

Condition: ready for operation (used), functionality: fully functional, Perfectly functional. Gbodpfx Aozfgiteciet

Condition: ready for operation (used), Year of construction: 2008, operating hours: 1,752 h, functionality: fully functional, machine/vehicle number: 2052592, travel distance X-axis: 1,626 mm, travel distance Y-axis: 1,270 mm, travel distance Z-axis: 813 mm, table load: 4,536 kg, spindle speed (max.): 6,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range X-axis: 1,626 mm Travel range Y-axis: 1,270 mm Travel range Z-axis: 813 mm Table length: 1,626 mm Table width: 914 mm Gedpfx Acozd Tcdjijbt Table load: max. 4,536 kg Spindle speed: 6,000 rpm Drive system: geared head Torque: max. 610 Nm at 500 rpm Power: max. 22.4 kW Thrust force X/Y axis: max. 24,910 N Thrust force Z axis: max. 33,362 N Rapid traverse: max. 13.7 m/min Cutting feed rate: max. 12.7 m/min Tool diameter with full tooling: max. 102 mm Tool diameter with free adjacent positions: max. 254 mm Tool-to-tool time: 10.3 s Chip-to-chip time: 12.6 s MACHINE DETAILS Dimensions (L x W x H): 3,660 x 3,880 x 3,190 mm Operating hours (see image) Spindle hours: 1,752 h Servo hours: 15,789 h

Condition: ready for operation (used), Year of construction: 2005, operating hours: 10,197 h, functionality: fully functional, travel distance X-axis: 1,300 mm, travel distance Y-axis: 710 mm, travel distance Z-axis: 710 mm, controller model: Fanuc 18i-MB, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Number of axes: 4 Travel in X-axis: 1,300 mm Travel in Y-axis: 710 mm Travel in Z-axis: 710 mm B-axis rotation: 360° Godpfozdfgpex Aciobt Table length: 1,500 mm Table width: 660 mm Tool holder: ISO40 Max. spindle speed: 10,000 rpm MACHINE DETAILS Control: Fanuc 18i-MB Power: 38.4 kW Dimensions & Weight Dimensions (L x W x H): 4,300 x 3,250 x 3,080 mm Shipping weight: 7,000 kg Shipping packages: 4 Operating hours: 10,197 h EQUIPMENT External cooling system Chip conveyor Tool magazine with 32 positions CE marking

Condition: good (used), Year of construction: 2014, Ref. -No.: 10553 Manufacturer: HANDTMANN / BAVIUS Type: HBZ Trunnion 120 Year of construction: 2014 Type of control: CNC-Steuerung Control: Heidenhain TNC 640 Storage location: Halberstadt Country of origin: Germany Machine-No.: 200XXXXX X-Travel: 1270 mm Y-Travel: 1100 mm Z-Travel: 900 mm Table Height: Ø 1200 mm Table Load: 2000 kg Max. Tool Weight: 20 kg Max. Tool Length: 90 x 200 / 24 x 400 mm Max. Tool Diameter: Ø 130 mm Tool Taper: HSK 100 Numbers Of Tools In Magazin: 40 Tool Piece Magazine With: 140 Pcs./pcs. Spindle Turning Speed - Stepless: 14.000 RPM Max. Torque: 15000 Nm Rapid Traverse X-Axis: max. 60 m / min Rapid Travel Y-Axis: max. 60 m / min Rapid Traverse Z-Axis: max. 60 m / min Machine length: 7500 mm Machine width: 5500 mm Machine Height: 3500 mm Weight Of The Machine Ca.: 26 t Rapid traverse C-axis: max. 25 RPM Rapid traverse A-axis: max. 20 RPM A-axis (swivel axis): - 30 / + 120 ° C-axis (rotary table axis): 360 ° Further information: - Horizontal machine, Y-axis arranged vertically - Machine stand designed as a welded construction - set up on height-adjustable precision wedge shoes, chip tray with cooling lubricant device, for external splash water cooling capacity: approx. 400 liters, with clean water pump, LP circuit, approx. 40 1/min at approx. 5 bar and rinsing nozzles on the Z-axis and/or the spindle - Complete safety housing - Stainless steel interior lining - Work area lighting - Manual loading door to the work area with polycarbonate safety window with glass front panel - Side viewing window to the work area with polycarbonate safety pane with glass front pane - Maintenance area freely accessible - HSK 100 hollow shank taper - Tool clamping via springs, tool release hydraulically - Tool clamping control - Cone cleaning - incl. spindle orientation Gedpfx Acszc D Aaeiebt The machine can be viewed under power by arrangement.

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 1,400 mm, travel distance Y-axis: 1,050 mm, travel distance Z-axis: 1,200 mm, controller manufacturer: FANUC, controller model: 31i CNC, total height: 3,760 mm, total width: 4,325 mm, overall weight: 26,000 kg, spindle speed (max.): 6,000 rpm, spindle motor power: 35,000 W, number of slots in tool magazine: 60, tool weight: 30,000 g, product length (max.): 8,150 mm, number of axes: 4, This 4-axis DOOSAN HM 8000 horizontal machining center was manufactured in 2014. Equipped with Fanuc 31i CNC control, it features a maximum workpiece diameter of 1450 mm and weight capacity of 2000 Kg. It includes a high-pressure through-spindle coolant system, chip conveyor, and both workpiece and tool probes. If you are looking to get high-quality milling capabilities consider the DOOSAN HM 8000 machine we have for sale. Contact us for more information about this machine. • Max. workpiece diameter: 1450 mm • Max. workpiece weight: 2000 kg • Travel (X/Y/Z): 1400 x 1050 x 1200 mm • Pallet size: 800 x 800 mm • Spindle motor power: 22/35 kW • Max. torque: 1732 N·m • B-axis: indexable by degree • Max. tool diameter: 130/320 mm • Max. tool length: 630 mm Additional equipment • Belt-type oil skimmer • Triple light tower • Pallet centering device • Shower coolant • Through-spindle coolant 70 bar, 7.5 kW, with cyclone filtration • Automatic shutdown • Tool load monitoring • Chip conveyor Gsdpfx Aozar Aiocisbt • Workpiece probe OMP60 • Tool probe TS27R Dimensions Machine Depth 8150 mm Technical Specification Taper Size BT 50

Condition: used, Year of construction: 2005, functionality: fully functional, Control HEIDENHAIN iTNC530 Table dimensions 1250 x 1600 mm Max. table load 15 tons X-axis travel 2500 mm Y-axis travel 2000 mm Z-axis travel 1500 mm W-axis 800 mm Table rotaion 360/1 degree Spindle speed range 4 - 3500 rpm Spindle taper SK50 Drive power 45 kW Gbsdpfxoy Snwuj Acijt Tool magazine 90 stations Machine weight 35000 kgs Floor space required 7000 x 14000 mm Accessories, features - Table rotaion 360/1 degree - W axis - Coolant unit with papirfilter - Chip conveyor - Fully covered working area - Portable MPG - Operation manual + wiring diagram, + mechanical drawings The machine is still under power in Hungary.

Condition: used, Year of construction: 2001, travel distance X-axis: 1,800 mm, travel distance Y-axis: 1,800 mm, travel distance Z-axis: 1,800 mm, controller manufacturer: Fanuc, overall weight: 75,000 kg, table length: 1,000 mm, table width: 1,000 mm, controller model: 160i-M, table load: 2,000 kg, CNC Precision Horizontal 5-axis Machining Centre Gbjdpfx Acey Nz Rvsiet CNC Control: Fanuc 160i-MA Table size 1000 x 1000 mm Table load 2000 kg Number of pallets 5 Max. workpiece diameter x height 1400x1200 mm Movement X-Y-Z-Axis: 1800 mm A-Axis (table tilt) +20 / -110 B-Axis travel 360° Spindle taper DIN 69871/50A Spindle speed 10.000 R/Min Tool store capacity 240 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: good (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 1,450 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 1,300 mm, table load: 2,000 kg, Travel Paths Travel path X: 1450 mm (longitudinal) Travel path Y: 1100 mm (vertical) Travel path Z: 1300 mm Pallet size: 800 x 1000 mm Table load capacity: 2000 kg Spindle & Drives NC rotary table with direct drive Positioning: 0.001° Max. rotary table speed: 60 rpm Rapid traverse: 60 m/min Spindle motor: 50 kW (25%) / 28 kW (100%) Spindle torque: 1210 Nm / 680 Nm Spindle speed: 6000 rpm Gbjdpjy Idykofx Acijt Spindle taper: HSK 100 Tool Changer: 80 positions Max. tool diameter: 325 mm Max. tool length: 800 mm Max. tool weight: 35 kg Workpiece diameter: 1600 mm Workpiece height: 1400 mm Workpiece weight: 2000 kg Accessories: - Coolant through spindle - Coolant shower - Tool breakage detection in tool changer - Spindle motor load monitoring - Spindle extension by 100 mm - Electronic handwheel - Various tools

Condition: ready for operation (used), Year of construction: 2012, operating hours: 24,101 h, functionality: fully functional, travel distance X-axis: 1,800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 600 mm, controller model: Siemens 840D Shopmill 3 D Formingstar, spindle speed (max.): 12,000 rpm, coolant tank capacity: 900 l, The machine is in very good used condition with no outstanding maintenance required! TECHNICAL DETAILS Travel distance in long-operation X-axis: 1,800 mm Travel distance swivel table X-axis: 1,020 mm Travel distance rotary table X-axis: 675 mm Travel distance in pendulum operation: 675/675 mm Travel distance Y-axis: 800 mm Travel distance Z-axis: 600 mm Spindle speed: 12,000 rpm Swivel range: +10° to -100° × ±360° Feed rates X/Y/Z: 40 m/min Rotary-swivel table Rotary table size: Ø 620 × 500 mm Interference circle diameter: Ø 700 mm T-slots: 18 mm T-slot spacing: 100 mm Number of T-slots: 5 Reference keyway: 18H8 Gbedpfsy A Rzdsx Aciot Centering bore: 30H7 × 10 mm Swivel range: +10° to -90° × ±360° Swivel speed 90°: 1.2 s Swivel accuracy: < ±10″ Rotary speed: 0–30 rpm Indexing accuracy: < ±6″ Axial runout: 0.015/Ø 300 mm Table load capacity: max. 375 kg Fixed machine table Clamping surface: 1,120 x 750 mm Max. tool weight: 10 kg Max. tool length: 330 mm Max. tool diameter: 80 mm (100 mm with adjacent pockets free) Chip-to-chip time approx.: 7.5 - 12 sec. Tool stations: 30 MACHINE DETAILS Internal coolant supply (IKZ): 40 bar Coolant tank capacity: 900 liters Tool holder: SK40 Control: Siemens 840D Shopmill 3D Formingstar Standby magazine Total positions: 190 Levels: 6 Tool length A: max. 240 mm Capacity A: 100 pcs Tool length B: max. 330 mm Capacity B: 90* pcs Tool change time: approx. 17–22 s Space required: 1,780 × 1,760 mm Height: 2,810 mm Weight: approx. 950 kg Spindle hours: 24,101 h Power-on hours: 62,438 h EQUIPMENT 3D touch probe Rotary-swivel table
