Condition: excellent (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 0509, Technical specifications Manufacturer: STAR Micronics Type: ECAS-20 Year of manufacture: 2011 CNC long-turn lathe Control system: Star Motion Control System Max. turning diameter: 20 mm Spindle stroke: 205 mm CNC axes: 10 Main spindle speed: 10,000 rpm Counter spindle speed: 10,000 rpm Spindle power: 2.2 kW / 3.7 kW each (30 min.) C-axis: main and counter spindle Powered tools up to 8,000 rpm Turning tools: 4 front, 2 rear Powered tool positions up to 6 (optional) Drilling diameter max. 10 mm Milling diameter max. 10 mm Itedpfo Aarq Nsx Akpen Thread cutting up to M8 Coolant tank: 120 liters Connected load: 8 kVA Weight: approx. 3,500 kg Dimensions: 2,588 x 1,150 x 1,765 mm

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 0398 (036), STAR Micronics ECAS-12 Manufacturer: STAR Micronics, Japan Year of manufacture: 2007 Control system: Siemens 840 Machine type: CNC long-bed turning center Technical data STAR Micronics ECAS-12, year of manufacture 2007 CNC long-bed turning center Control system: Siemens 840Di Max. turning diameter: 13 mm Spindle stroke: 205 mm CNC axes: 10 Main spindle speed: 12,000 rpm Itedpfx Ao Aarq Askpjn Counter spindle speed: 12,000 rpm Spindle power: approx. 3.7 kW each Driven tools up to 8,000 rpm Drilling diameter max. 10 mm Milling diameter max. 10 mm Thread cutting up to M8 Rapid traverse: 18 m/min Connection power: 8 kVA Weight: approx. 3,500 kg Dimensions: 2,590 x 1,140 x 1,830 mm

Condition: ready for operation (used), Year of construction: 2021, functionality: fully functional, ## 2021 Star SB-20R Type G – 20 mm CNC Sliding Head Lathe 7 axis | Twin spindles | Driven tooling | Guide-bush / non-guide-bush operation | FMB magazine bar feeder Available from Swiss CNC, this 2021 Star SB-20R Type G CNC sliding head lathe combines 20 mm bar capacity, twin-spindle machining and a versatile tooling platform for precision component production. Equipped with FANUC CNC control, it offers turning, milling, drilling, tapping and back-working capability within a compact machine layout. The 10,000 rpm main spindle and 9,000 rpm sub-spindle both feature C-axis control, supporting accurately positioned machining operations on the front and rear of the component. The fully independent sub-spindle allows front- and back-working operations to overlap where the component and programme permit, helping reduce cycle times and minimise additional handling. ### Guide-bush and non-guide-bush flexibility A key feature of the SB-20R Type G is its ability to switch between guide-bush and non-guide-bush operation. Guide-bush mode supports the material close to the cutting point, making it particularly suited to slender components and longer turned features. For shorter components, non-guide-bush operation can reduce bar remnant length and improve material utilisation. This flexibility allows manufacturers to adapt the machine to different component geometries and production requirements. ### Technical specification | Specification | Details | |---|---| | Manufacturer / model | Star SB-20R Type G | | Year of manufacture | 2021 | | Maximum machining diameter | 20 mm | | Controlled axes | Seven: X1, Y1, Z1, C1, X2, Z2 and C2 | | Maximum headstock stroke — guide-bush mode | 205 mm | | Headstock stroke — non-guide-bush mode | Up to 2.5 × bar diameter, maximum 50 mm | | Main spindle speed | Up to 10,000 rpm | | Sub-spindle speed | Up to 9,000 rpm | | Sub-spindle chucking capacity | 20 mm | | Spindle positioning | C-axis control on both spindles | | CNC control | FANUC CNC | | Rapid traverse | Up to 35 m/min | ### Tooling capability Itedpfoz U Acmox Akpen - Gang-type turning-tool arrangement, with six 12 mm or seven 10 mm square turning-tool positions, depending on the fitted tool block. - Four front-working sleeve positions for end-working operations. - Cross-drilling and milling capability, with modular cartridge tooling configurations available for different machining requirements. - Four-position back-working station, supporting static or driven tooling according to configuration. - Independent sub-spindle movement for component transfer and rear machining. ### Included equipment - FMB Turbo 2-20 automatic magazine bar feeder for 3.2 m bar stock. - Filtermist FX mist extraction system. - LNS MH500 Turbo swarf conveyor. - FireTrace fire suppression system. - Selection of tooling and workholding. The supplied bar feeder, extraction and swarf-handling equipment provide a practical package for manufacturers looking to add automated 20 mm bar-machining capacity. ### Machine hours and availability Power-on and cutting hours to be confirmed. 2021 machines available in the UK, offered individually. Price on application, plus VAT. Delivery, installation and training available. Contact Swiss CNC for pricing, machine videos, inspection arrangements and further information.

Condition: ready for operation (used), Year of construction: 2008, operating hours: 17,000 h, functionality: fully functional, ## 2008 Star SR-20RIII – 20 mm CNC Sliding Head Lathe Seven controlled axes | Twin spindles | Driven tooling | FMB magazine bar feeder | 140-bar coolant Available from Swiss CNC, this 2008 Star SR-20RIII CNC sliding head lathe combines 20 mm machining capacity, twin spindles and driven tooling for the production of precision components from bar. Equipped with FANUC Series 300iS-Model A CNC control, it offers versatile turning, milling, drilling, tapping and back-working capability. The sliding head and guide bush arrangement supports the material close to the cutting point, making the machine particularly suited to small-diameter and slender components. C-axis control on both spindles allows accurately positioned machining features, while the opposed sub-spindle enables rear-face finishing and secondary operations within the same machine cycle. Independent front- and back-working capability allows operations to overlap where the component and programme permit, helping reduce cycle times and the need for additional handling between machines. ### Technical specification | Specification | Details | |---|---| | Manufacturer / model | Star SR-20RIII | | Year of manufacture | 2008 | | Maximum machining diameter | 20 mm | | Maximum headstock stroke | 205 mm | | Controlled axes | Seven: X, Y, Z, XB and ZB, plus C-axis control on both spindles | | Main spindle speed | Up to 10,000 rpm | | Sub-spindle speed | Up to 8,000 rpm | | CNC control | FANUC Series 300iS-Model A | | Rapid traverse | Up to 35 m/min | | Approximate machine weight | 2,200 kg, excluding bar feeder and ancillary equipment | ### Standard tooling layout - Six turning-tool positions for external turning, profiling, grooving and parting. - Five radial driven-tool positions for cross-drilling, milling and tapping applications. - Four front-working sleeve positions for end-working operations. - Four-position back-working station for machining components held in the sub-spindle. ### Included equipment - FMB Turbo 3-36 automatic magazine bar feeder for 3.2 m bar stock. - 140-bar high-pressure coolant system — approximately 2,000 psi. - LNS MH500 swarf conveyor, compatible with long-parts ejection. - JBS guide bush system. - TriMist Extraction - Noble fire suppression system. The combination of magazine bar feeding, high-pressure coolant and swarf handling provides a useful equipment package for repeat batch production and components requiring several machining operations. Itodoz Uxmbspfx Akpjn ### Machine hours Approximately 56,000 power-on hours. Cutting hours - 17,000 Available in the UK. Price on application, plus VAT. Contact Swiss CNC for pricing, machine videos, inspection arrangements and delivery or installation requirements. *Tooling layout describes the standard model configuration; the supplied toolholder package is subject to confirmation.*

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, turning length: 500 mm, spindle speed (max.): 8,000 rpm, spindle speed (min.): 50 rpm, spindle bore: 26 mm, bar diameter (max.): 26 mm, operating pressure: 60 bar, Machine in production under power, no defects, can be inspected in production. Equipement: - 2x spindle - 2x C axsis - live tools for main and sub spindle - swarf coveyour - Iemca bar feeder - high pressure pump Ijdpfoz Smfusx Akpotn - Siemens controller - all books and manuals

Condition: used, STAR SW 20 is a CNC automatic (Swiss-type) lathe offering high precision, strong accuracy and reliable performance. Capacities: 11 axes, 2 spindles, max machining Ø 20 mm, back spindle up to 10,000 t/min. Specs: spindle 3.7 kW, driven tools 1.2 kW (8,000 t/min), carriages with 7 and 5 positions, counter-operation 8 tools (6 driven), rapid traverse 35 m/min, 50 Hz 3x380 V, ~3400 kg, L2600×W1150×H1765 mm. Accessories: bar loader, lamp, 150 l coolant system, ELBARON oil-mist extractor, interface for bar loader. Achieves tight tolerances; typical uses: automotive, watchmaking, tooling, aerospace, medical. Iedpfx Akoz R Nqkjpjtn

Condition: ready for operation (used), Year of construction: 2019, operating hours: 20,672 h, spindle motor power: 7,500 W, spindle speed (max.): 8,000 rpm, overall weight: 4,200 kg, total width: 1,550 mm, total height: 2,160 mm, bar diameter (max.): 26 mm, product length (max.): 2,350 mm, number of axes: 8, This 8-axis Maier ML26 C5Y were manufactured in 2019. It features a spindle capacity of 26 mm and a rapid carriage speed of 32 m/min. The machine includes a robust coolant capacity of 260 l and is equipped with a bar feeder and extensive tooling package. Three machines available! If you are looking to get high-quality turning capabilities, consider the Maier ML26 C5Y swiss type turning machine we have for sale. Contact us for further details. - Carriage / Rapid Speed: 32 m/min - Main Spindle Capacity: 26 mm - Main Spindle Indexing: Mechanical indexing 5° - Main Spindle Headstock Stroke: 320 mm (Options: 220 mm, 450 mm) - Main Spindle Power Rating (100% / 60%): 5.5 kW / 7.5 kW - Main Spindle Collet: 161E - Counter Spindle Capacity: 26 mm - Counter Spindle Indexing: Mechanical indexing 5° - Counter Spindle Max. Travel (Z2): 220 mm (340 mm option) - Counter Spindle Speed: 0 - 8000 rpm - Counter Spindle Power Rating (100% / 60%): 5.5 kW / 7.5 kW - Counter Spindle Collet: 161E - Guide Bush Model: 451.001 - Coolant Capacity: 260 l / 1.5 bar - Cross Machining Lathe Tool Holders: 5 pcs. (12x12) - Driven Tools: 4 pcs. - Back Machining Tools: 4 pcs. Ø34mm (driven) - Back Machining Y2 (Option): 4 pcs. Ø34mm (fixed), 4 pcs. Ø34mm (driven) - Front Machining Tools: 5 pcs. (fixed) - Power On Time: 31,849 h 23 min - Cutting Time: 13519 h - Part Total Count: 1,052,178 pcs - Accessories: Bar feeder / loading magazine (FMB), oil mist extractor (LTA), 2 x live tools, extensive tooling package included - Total Power: 17.3 kW - Voltage: 400 / 230 / 24 V Technical Specification Itodpfjz R A Uuex Akpon Counter Spindle Yes

Condition: good (used), Year of construction: 2011, functionality: fully functional, Mitsubishi controller, tapping spindle, loading magazine. Iodpfx Akjz Ryz Eepotn

Condition: good (used), Year of construction: 2015, functionality: fully functional, Fanuc control system, Turning and milling lathe, Itjdoz Ryynjpfx Akpjn Pick-up spindle, Tool magazine.

Condition: good (used), Year of construction: 2003, functionality: fully functional, Fanuc control system, Itodpfx Aoz Ryulokpen extraction spindle, FMB loading magazine.

Condition: ready for operation (used), Year of construction: 2022, spindle speed (max.): 8,000 rpm, overall weight: 3,750 kg, total width: 2,100 mm, total height: 2,245 mm, bar diameter (max.): 32 mm, product length (max.): 2,289 mm, number of axes: 10, This 10-axis TORNOS EvoDECO 32 was manufactured in 2022. It features a main spindle and counter spindle with a maximum speed of 8,000 RPM, and a bar capacity of up to 32 mm. The machine includes a robust tooling system with multiple rotating tools and a high-pressure coolant system. If you are looking to get high-quality turning capabilities, consider the TORNOS EvoDECO 32 swiss type turning machine we have for sale. Contact us for further details. Technical Specification Itedpfez I Sxvsx Akpsn Counter Spindle Yes

Condition: used, Year of construction: 2000, operating hours: 43,000 h, machine/vehicle number: IntNr231493, STAR SA 16-12 CNC sliding headstock lathe, year of manufacture 2000 CNC control: FANUC 18i-T Operating hours: 43,000 Technical specifications: - Number of axes: 5 - Number of spindles: 2 Itodoz Iruwspfx Akpsn MAIN SPINDLE - Maximum bar diameter: 12 mm - Z-axis travel: 140 mm - Spindle speed: 8,000 rpm - Spindle drive power: 2.2 kW - Number of tool stations: 13 SUB SPINDLE - Maximum bar diameter: 10 mm - Spindle speed: 8,000 rpm - Number of tool stations: 4 FMB Minimag bar feeder The machine can be inspected under power by appointment. Subject to prior sale. Technical data and specifications subject to change and correction.

Condition: used, Year of construction: 2003, operating hours: 86,000 h, machine/vehicle number: IntNr231169, STAR CNC Swiss-type lathe SB 16, Year 2003 CNC control: FANUC 18i-TB Technical Data - Number of axes: 6 - Number of spindles: 2 MAIN SPINDLE - Max. bar diameter: 16 mm - Z-axis stroke: 205 mm - Spindle speed: 10,000 rpm - Spindle drive power: 3.7 kW - C-axis minimum resolution: 0.001 SUB SPINDLE - Max. bar diameter: 16 mm Itodpoz Irttjfx Akpen - Spindle speed: 8,000 rpm - C-axis minimum resolution: 0.001 Bar feeder: FMB Minimag 3200/A Bar diameter: 2–16 mm Bar length: 3,200 mm Kraft & Bauer fire suppression system Mayfran chip conveyor Operating manual included The machine can be powered up and inspected by appointment. Technical data and specifications subject to change and prior sale; errors excepted!

Condition: good (used), Year of construction: 2013, operating hours: 33,100 h, functionality: fully functional, Equipment: documentation/manual, CNC long-turn lathe Manufacturer: STAR Itedpoz Ipryefx Akpsn Type: SR-32J Year of manufacture: 2013 FANUC 32i control system Rear-end machining Synchronous spindle Powered tools C-axis Parts conveyor Chip conveyor Oil mist extraction system Tool monitoring Bar loader magazine FMB TURBO 3-36

Condition: excellent (used), Year of construction: 2016, 2016 Tornos DT 26 Swiss Type CNC Sliding Head Lathe With Fanuc Series 31i-Model B Control & SBF326-3.2M Bar Feeder Itjdpfez H U I Rsx Akpjn Maximum Bar Ø25.4mm. Rapid Traverse 32m/min. Standard Workpiece Length With Guide Bush 225mm. Standard Workpiece Length Bushless 50mm. Main Spindle- Spindle Speed Range 0-10,000rpm (10.5kW Motor). Maximum Turning Tools 6 (Shank 12 x 12mm.). Number Of Frontal Tools (Main-Operation/Counter-Operation) 4/4. Max Front Drilling Ø12mm, Max Front Tapping M10 x 1.5.Cross Drilling/Milling Tools 6 (ER20), Max Rotating Tool Speed 6,000rpm (1kW Motor), Max Front Drilling Rotating Tools Ø10/Ø10mm, Max Front Tapping Rotating Tools M5 x 0.8. Counter Spindle-Maximum Bar Ø25.4mm. Main Spindle- Spindle Speed Range 0-15,000rpm (5kW Motor). Max Insertion Length Of Workpiece Into Counter Spindle 100mm. Max Standard Length Of Workpiece 120mm. Max Back Drilling Ø10mm, Max Back Tapping M6 x 1. Cross Drilling/Milling Tools 6 (ER20), Max Rotating Tool Speed 6,000rpm (1kW Motor), Max Front Drilling Rotating Tools Ø10/Ø10mm, Max Front Tapping Rotating Tools M5 x 0.8. Counter-Operation-Max Number Of Tool Positions 8, Max Rotating Tool Speed 7,200rpm (1kW Motor). S/No. 2581050017 (2016). Please note a loading charge of £200 + VAT to be added to buyer's invoice. With Coolant System, Hennig Chip Conveyor, Krauft Bauer Fire Suppressor Unit, SEI Mist Extraction Unit, Parts Catcher, Parts Conveyor, Signal Tower, Tool Kit, Cromar Swarf Bin & Manuals. Overall Dimensions L2,230 x W1,250 x H1,730mm. Weight 2,400kg.

Condition: good (used), Year of construction: 1997, functionality: fully functional, 1 x CNC long-turn lathe Star SA 12/16 Year of manufacture: 1997 Control system: Fanuc 18 i-T with loading magazine Iemca CH 220/32 Year of manufacture: 1998 Technical data: Spindle bore: 16 mm Spindle travel: 140 mm Main spindle speed: 500 - 12,000 rpm Counter spindle speed: 500 - 8,000 rpm Speed: driven tools: 0 - 4,000 rpm (remaining data see photos) Iodpfx Asz Hccijkpstn Approximately 6 months ago, the counter spindle was fitted with new bearings. The machine can be inspected while in operation and under power.

Condition: good (used), Year of construction: 2006, functionality: fully functional, Fanuc control system, Ijdpjz E Ayfsfx Akpjtn 11 axes, powered tools, tool changer spindle, Iemca tool magazine.

Condition: like new (used), Year of construction: 2019, operating hours: 7,300 h, machine/vehicle number: IntNr231648, For sale is a very well-maintained TORNOS Swiss GT 13-8 CNC Swiss-type automatic lathe, manufactured in 2019, with only approximately 7,300 operating hours. Technical data – TORNOS Swiss GT 13-8 Manufacturer: TORNOS Model: Swiss GT 13-8 Machine type: CNC Swiss-type automatic lathe Year of manufacture: 2019 Control system: FANUC 31i-B Number of CNC axes: 8 Number of spindles: 2 Operating hours: approx. 7,300 h Condition: very good Main spindle Max. bar diameter: 13 mm Max. machining length: approx. 190 mm Max. spindle speed: 15,000 min⁻¹ Spindle drive power: approx. 4 kW C-axis Counter spindle Max. machining/clamping diameter: 13 mm Max. speed: 15,000 min⁻¹ Drive power: approx. 4 kW C-axis resolution: 0.001° Tool turret 1 8 tool positions Speed of driven tools: up to 6,000 min⁻¹ Drive power: approx. 1 kW Tool turret 2 8 tool positions Speed of driven tools: up to 6,000 min⁻¹ Drive power: approx. 1 kW Front machining up to 4 tool positions Rear/opposite-side machining Up to 8 tool positions Itedpfx Akez Er Tnepjn Of which up to 4 are driven positions Speed of driven tools: up to 6,000 min⁻¹ Drive power: approx. 0.75 kW Tool holder package is charged separately! TORNOS Robobar SBF 213 bar feeder High-pressure coolant system, type: HP-20-140 Kraft & Bauer fire extinguishing system ELBARON oil mist separator Supply voltage: 400 V The machine can be inspected while powered on by prior arrangement. Subject to changes, errors and prior sale!

Condition: like new (used), Year of construction: 2016, operating hours: 9,300 h, machine/vehicle number: IntNr231649, For sale is a very well-maintained TORNOS Swiss GT 13-8 CNC Swiss-type automatic lathe, manufactured in 2016, with only approximately 9,300 operating hours. Technical Data – TORNOS Swiss GT 13-8 Manufacturer: TORNOS Model: Swiss GT 13-8 Machine Type: CNC Swiss-type automatic lathe Year of Manufacture: 2016 Control System: FANUC 31i-B Number of CNC Axes: 8 Number of Spindles: 2 Operating Hours: approx. 9,300 h Condition: very good Main Spindle Max. bar diameter: 13 mm Isdpfx Aoz Er A Njkpotn Max. machining length: approx. 190 mm Max. spindle speed: 15,000 rpm Spindle drive power: approx. 4 kW C-axis Counter-Spindle Max. machining/clamping diameter: 13 mm Max. speed: 15,000 rpm Drive power: approx. 4 kW C-axis resolution: 0.001° Tool Carrier 1 8 tool positions Speed of driven tools: up to 6,000 rpm Drive power: approx. 1 kW Tool Carrier 2 8 tool positions Speed of driven tools: up to 6,000 rpm Drive power: approx. 1 kW Front machining Up to 4 tool positions Rear/Opposite-side machining Up to 8 tool positions Of which, up to 4 are driven positions Speed of driven tools: up to 6,000 rpm Drive power: approx. 0.75 kW Tool holder package is charged separately! TORNOS Robobar SBF 213 bar feeder High-pressure coolant system, type: HP-20-140 Kraft & Bauer fire extinguishing system ELBARON oil mist separator Supply voltage: 400 V The machine can be inspected under power by prior appointment. Subject to changes and errors in technical data and specifications, as well as prior sale!

Condition: good (used), Year of construction: 2002, functionality: fully functional, Control system: Traub TX 8i Main spindle Iodpfxjz Erdto Akpjtn Max. bar diameter: 26 mm Max. speed: 8,000 rpm Counter spindle Max. bar diameter: 26 mm Max. speed: 8,000 rpm Tooling system Number of turrets: 2 (upper and lower turret) Tool positions per turret: 12 stations, without drive Front tool holder, 5-position, with Z3 slide, without drive Rear machining station (5 tools), without drive Bar loader: IEMCA BOSS 432/44

Condition: like new (used), Year of construction: 2023, operating hours: 12,147 h, functionality: fully functional, spindle motor power: 3,700 W, spindle speed (max.): 10,000 rpm, type of input current: three-phase, input voltage: 380 V, Equipment: documentation/manual, Citizen A20-3F7 + FMB Minimag 20 bar FEEDER Year: 2023 7 axes: X1, X2, Y1, Z1, Z2, C1, C2 Removable guide bushing: can be used in both Swiss-type (sliding headstock) and fixed-headstock configurations. Maximum main spindle speed: 10,000 rpm Itjdpfxsz D Tx Ns Akpsn Machining length: 200 mm X2 axis with linear guides Simultaneous C-axis control on both the main and sub-spindle, with back-working driven tools Short cycle times thanks to the advanced CNC control (Fanuc FS32i) Maximum machining diameter: 20 mm (standard) Machining length per chucking: 200 mm, or 2.5 × D in fixed-headstock mode Main spindle: 10,000 rpm, 3.7 kW Sub-spindle: 8,000 rpm, 1.5 kW Gang-type driven tools: 6,000 rpm, 0.75 kW Back-working driven tools: 6,000 rpm, 0.75 kW Compact footprint: approx. 2.5 m² Polygon turning function Equipped with an FMB Minimag 20 bar feeder.

Condition: used, Year of construction: 2011, STAR ECAS-20 — CNC SWISS-TYPE AUTOMATIC LATHE MACHINE IDENTIFICATION — VERIFIED FROM NAMEPLATE Manufacturer: Star Micronics Co., Ltd., Japan Model: ECAS-20 Type: 570 Manufacturing date: March 2011 Serial number: 0509 Lot number: 047 Supply voltage: AC 200 V, three-phase Frequency: 50/60 Hz Rated apparent power: 8.0 kVA Machine weight: 3,500 kg CE marking: Present MODEL SPECIFICATIONS — MANUFACTURER DATA Configuration: 10 axes; independent front/back machining; simultaneous two-tool turning Control system: Star Motion Control System Maximum machining diameter: 20 mm Headstock stroke: 205 mm MAIN AND SUB-SPINDLES Maximum speed: 10,000 rpm each Motor output each: 2.2 kW continuous / 3.7 kW for 30 minutes C-axis indexing: 0.01° each Sub-spindle chucking diameter: 20 mm Front-ejection length: 80 mm Workpiece projection: 30 mm TOOLING Turning positions: 4 front, 2 rear Tool shank: 12 mm; optional 16 mm Sleeve-holder positions: 4; optional 2 rear-end stationary tools Stationary drilling: Ø10 mm Tapping/die-cutting: M8 × 1.25 Optional driven positions: 3 front, 3 rear Driven-tool speed: 8,000 rpm Driven-tool motor: 0.75 kW Driven drilling: Ø8 mm Driven tapping: M6 × 1.0 Milling: Ø10 mm Slotting: 1.5 mm wide × 4 mm deep BACKWORKING Tool positions: 4 Drilling, stationary/driven: Ø10/Ø8 mm Tapping, stationary/driven: M8 × 1.25 / M6 × 1.0 CAPACITY AND DIMENSIONS Itsdpoz D Ezvefx Akpjn Coolant tank: 120 litres Machine dimensions (W × D × H): 2,588 × 1,150 × 1,765 mm Overall installation dimensions with peripherals: Unconfirmed EQUIPMENT VISIBLE IN PHOTOGRAPHS Bar-feeding equipment with pendant control Fire-suppression cylinder and automatic CO₂ warning label CNC operator panel

Condition: used, TSUGAMI HS 207-5AX is a CNC automatic lathe / Swiss-type lathe with high precision, excellent accuracy and reliability. 5 axes, 2 spindles; turning diameter 3–20 mm; max turning length 250 mm; internal spindle diameter 20 mm. Spindle speeds 200–10,000 t/min; spindle power 3.7 kW; back spindle 2.2 kW; 35 tools; rapid traverse 32 m/min; power 50 Hz 3x400 V; total installed 14.6 kVA; weight ~3300 kg; footprint 2110×1200×1885 mm. Bar feeder LNS EXPRESS 320. Built to achieve tight tolerances on precision components. Iedpfxjz Dv Efe Akpotn

Condition: used, STAR SR-16 R is a CNC automatic lathe / CNC Swiss type lathe offering high precision, accuracy and reliable performance. Capacities: 7 axes, 2 spindles, max turning length 205 mm, spindle bore 16 mm, max drilling Ø10 mm; travels X1 16 mm, X2 40 mm, Y1 89 mm, Z1 205 mm, Z2 80 mm, C‑axis spindle resolution 0.01°. Specs: main spindle up to 12,000 rpm, back spindle up to 8,000 rpm, driven tool speeds 8,000 rpm, rapid traverse 20 m/min; supply 3x400 V 50 Hz, total power 6 kVA; weight ~2200 kg, footprint 2207×1080×1700 mm. Accessories: LNS SUPER HYDROBAR bar feeder, ELBARON oil‑mist extractor, transformer. Achieves tight tolerances; suited for automotive, watchmaking, machine tools, aerospace and medical sectors Itjdsz Dvz Tjpfx Akpen

Condition: used, TORNOS DECO 2000/13 is a CNC automatic lathe engineered for precision machining, high accuracy and dependable reliability. Key capacities: 10 axes; max workpiece length 180 mm; internal spindle diameter 13 mm; spindle speeds 100-12000 t/min; back spindle 100-8000 t/min. Main specs: 50 Hz 3x400 V supply; spindle motor 2.2 kW; total power 11 kVA; weight approx. 2550 kg; footprint L2000×W1260×H1950 mm. Equipment: bar feeder IEMCA GENIUS 226/32, chip conveyor, coolant system, oil mist extractor. Achieves tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical. Itsdpfsz Dvztjx Akpon
