Yilmaz Gear Company Ltd.

Condition: refurbished (used), Year of construction: 1987, operating hours: 200 h, functionality: fully functional, Please make your inquiry by email. Fpsdpfsxmiqcex Aacen

Condition: good (used), Year of construction: 1970, functionality: fully functional, grinding length: 500 mm, Grinding length: 500 mm Centre height: 150 mm Fedpfx Aexmgdtoacjpn Grinding wheel diameter: 350/400 mm Spindle diameter: 60 mm Workpiece headstock: MK4 Tailstock: MK4 Wet grinding device Internal grinding device Grinding spindle Quick-clamping device Includes many grinding wheels and accessories

Condition: good (used), Internal item no.: 25079 No VAT can be stated, as margin scheme applies. Cylindrical grinding machine Overbeck 250R + Operating manual + Three-jaw chuck (workpiece clamping) + Collet set (workpiece clamping) Technical specifications: Max. grinding diameter: 100 mm Max. clamping length: 280 mm Fpjdpoxl S Tdjfx Aacen Max. grinding length: 250 mm Workpiece spindle speed: 150 - 1350 rpm (infinitely variable) Centre height: 100 mm Swing diameter: 180 mm Grinding spindle speed: 2250 / 2750 rpm Grinding wheel diameter: 300 mm Grinding wheel width: 60 mm Workpiece spindle taper: MT4 Tailstock taper: MT2 Power requirement: 4.5 kW Dimensions (LxW): 2.5 x 2.9 m Weight: 1700 kg The machine comes from a training workshop at a rehabilitation clinic and is in very well-maintained condition.

Condition: used, Year of construction: 1991, operating hours: 2,000 h, Name: Used injection molding machine Manufacturer: Ferromatik Milacron (Klöcker) Fsdpfxsxl R Sxs Aacjpn Type: FX50 R 35 Year built: 1991 Hours of operation: 2000 h Driving force: 15 kW Dimensions: L 4300 x W 1400 x H 2200 mm Empty weight: 3400 kg Technical doc.: Yes Message: General Data: Dry cycle rate: 40 min, Pump drive: 15 kW, Total connected load: 25.7, Oil tank capacity: 180 L Injection unit: Screw diameter: 35 mm, Injection pressure: 1730 bar, Displacement: 116 cm3, Screw stroke: 120 mm, Maximum part weight: 99 g, Maximum injection flow: 505 g/s, Calculated injection capacity: 15 kW, Plasticizing flow: 29 g/s, Screw length: 22 LID, Maximum screw speed: 430 min, Maximum screw torque: 360 Nm, Installed heating capacity: 10.7 kW, Number of heating zones: 5, Nozzle compression force: 65 kN Clamping unit: Clamping force: 500 kN, Mold opening stroke: 350 mm, tool installation height min.: 200 mm, platen distance max.: 550 mm, ejector force: 34 kN, ejector stroke: 150 mm, clear distance between columns max.: 355×355 mm, clamping plate max.: 540×540 mm. Accessories: With two tool tempering devices. Condition: Second hand Price: By request

Condition: used, Year of construction: 1979, functionality: fully functional, Floor-standing arm stapling machine for 2 to 3-ply corrugated cardboard. Bahmüller quality!! Unfortunately, machines like this are no longer available for purchase today... Fpodjxlix Rjpfx Aacsn

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, center height: 225 mm, controller model: Fanuc 16T, TECHNICAL DETAILS Fodsxlix Dopfx Aacspn Centre height: 225 mm MACHINE DETAILS Control: Fanuc 16T

Condition: excellent (used), Machine is in very good, full working condition (VAT not included) Fpedpfx Aajxiq S Hecjn

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 64122, A well-maintained external cylindrical grinding machine Make: STUDER Type: S20-12 Machine No.: 64122 Fpedpfxsxfvxdj Aacen

Condition: good (used), Cylindrical Grinding Machine Stock number: 3043 Manufacturer: Fortuna Year of manufacture: Machine number: 6034 Model: USE 500/II Grinding length: 500 mm Centre height: 125 mm Grinding diameter: 250 mm Grinding wheel diameter: 450 x Spindle speed: 1,270 and 1,520 rpm Accessories/Equipment: Coolant system, steady rest, diamond dresser, chuck, magnetic chuck, etc. (see pictures) Fsdpfoxfgv Tjx Aacspn Connection: kW Weight: 2.8 t Dimensions: 2,000 x 1,600 x 1,700 mm

Condition: good (used), Universal Cylindrical Grinding Machine Manufacturer: Jotes Poland Year of manufacture: 1968 Machine number: 364 Model: SWA 10 Grinding length: 400 mm Centre height: 100 mm Grinding diameter: 200 mm Internal grinding diameter: 8 to 80 mm Grinding wheel diameter: 300 x 127 x 40 mm (or 300 x 76 x 40 mm) Accessories/Equipment: Internal grinding attachment Fjdpfxoxfgvgs Aacjpn Power connection: 5 kW Weight: 2.0 t Dimensions: 2,000 x 1,600 x 1,400 mm

Condition: good (used), Year of construction: 2002, operating hours: 9,999 h, functionality: fully functional, machine/vehicle number: 120231, Cylindrical Grinding Machine SCHAUDT / Mikrosa PS 51 N 600 Technical Data – Schaudt / Mikrosa PS 51 N 600 Fpedpfx Asxdb R Nsacen Machine type: Universal / External Cylindrical Grinding Machine Year of manufacture: 2002 Control: Siemens 840D Grinding length (between centers): 600 mm Center height / Height over bed: 180 mm Maximum grinding diameter over bed: approx. 300–360 mm Max. workpiece weight (between centers): approx. 150–200 kg, depending on configuration Grinding spindle power: approx. 22 kW Grinding wheel width: e.g., 220 mm on premium versions; diameter depending on equipment approx. 400–500 mm Grinding wheel speed / surface speed: On some versions approx. 45 m/s; variable depending on equipment Total weight: approx. 10 t

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, External Grinding Machine Manufacturer: NAXOS-UNION (Germany) Model: W500 500 x 2500 mm Year: Overhaul in 2017 Technical Data: • Max. distance between centers: 2500 mm • Center height: 250 mm Fpodpfxoxcvr Ss Aacsn • Grinding wheel diameter: 600 mm • Grinding support traverse: 320 mm • Max. workpiece weight between centers: 1500 kg • Grinding spindle speed, steplessly adjustable: 900 – 1600 RPM • Workpiece spindle speed: 50 – 450 RPM • Workpiece spindle mounting: Morse 5 (MK 5) • Motor power: 2.2 kW • Dimensions (L x W x H): approx. 7800 x 3300 x 1750 mm • Weight: approx. 13 tons Accessories: • 1 pc. machine enclosure incl. front sliding door with safety switch • 2 pcs. glass scales for X- and Z-axes incl. digital display Z300 from RSF-Elektrik, MSA measuring system • 1 pc. new belt filter unit by SEITZ, type PFA 100 with pump (100 l/min) incl. control unit • 1 pc. electromechanical balancing system by MPM, balancing head mounted on spindle, sensor on grinding spindle bearing • 1 pc. live center by RÖHM MK 5 • 6 pcs. grinding wheel flanges • 7 pcs. steadies (Lynetten) • 14 pcs. leveling feet Condition: Fully overhauled in 2017, very little use since revision Asking price (negotiable): €79,000 Price basis: ex works, loaded on truck Collection/shipping: after payment receipt and by appointment Disclaimer: The seller accepts no liability for errors in writing or data transmission. The condition of the machine, both visually and technically, as well as wear, is consistent with its age; used machines are sold without any guarantee. All prices are net.

Condition: good (used), grinding diameter 450 mm grinding length 600 mm centre height 140 mm workpiece dia. 280 mm number of turns of spindle head 63 - 400 U/min Fsdpfx Aajxcblqocepn grinding wheel speeds 20-35 m/s dimensions of the machine ca. 2,4 x 1,9 x 2,1 m

Condition: used, Cylindrical grinder SCHAUDT RFH500 Fsdpfxsxbt Hke Aacspn

Condition: good (used), Year of construction: 1970, functionality: fully functional, Data : Tip width 300 mm Tip height 150 mm External grinding spindle 4.0 kW Grinding wheel max. 400 x 80 x 127 mm Spindle cone MK4 Workpiece headstock 0.55 kW Fpedpoxbnlnjfx Aacsn Workpiece speeds 30 - 450 rpm Internal grinding spindle 1.5 kW

Condition: good (used), Manufacturer: Beling & Lubke Model: cylindrical grinder Condition: Used Fpodpfxoxal Iwj Aacon

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 027.0400/067, CNC CYLINDRICAL GRINDER STUDER S-33 CNC Year: 2007 - Fanuc 21i-TB 1 External Grinding Spindle Country of Origin: Switzerland Voltage: 380/50/3 Net machine weight: 4,000 kg TECHNICAL SPECIFICATIONS Distance between centers: 600 mm Center height: 175 mm Maximum workpiece weight: 80 kg Longitudinal Slide Z Fpodpjw T Sh Eefx Aacjn Max. travel: 800 – 1,150 mm Travel speed: 0.001 to 10,000 mm/min (early 2000’s model: 0.001-5,000 mm/min) Resolution: 0.0001 mm Cross Slide X Max. travel: 285 mm Travel speed: 0.001 to 20,000 mm/min (early 2000’s model: 0.001-10,000 mm/min) Resolution: 0.0001 mm Wheelhead (universal version) Swiveling range: -15° to 225° (early 2000’s model: -15° to 195°) Swivel axis: 2.5 / 1 ° Hirth Drive power: 7.5 or 9 kW or 11 kW Grinding wheel: 500x63 (80/110F5) x203 mm Workhead Rotational speed: 1 – 1,500 min-1 Mount taper: MT4 or MT5 / ISO 50 Drive power: 1.6 or 3.0 or 4.0 kW Tailstock Mount taper: MT3 or MT4 Quill stroke: 35 / 50 mm (early 2000’s model: 35 mm) Quill diameter: Ø 50 mm Fine adjustment: +/- 40 µm Control system: Fanuc 21i-TB All technical details are provided in good faith but subject to errors or omissions.

Condition: refurbished (used), Year of construction: 2025, operating hours: 50 h, machine/vehicle number: 3018-04, Country of manufacture: Switzerland Voltage: 380/50/3 Net weight: 3100 kg Overall dimensions: 230x155x170 cm Installed power: 13 kVA Customs tariff position: 8460.2920 TECHNICAL SPECIFICATIONS MAIN DIMENSIONS Distance between centers: 650 mm Grinding capacity SpW+bs: -80 Stroke: 700 LONGITUDINAL SLIDE Max stroke: SpW+50 mm Minimum automatic feed: 1.5 mm Speed: 50-5500 mm/min Reversal delay: 0-6 sec Maximum table swivel: 12°/10°/8.5°/6° Pneumatic relief for table and workhead CROSS SLIDE Max stroke: 300 mm Rapid traverse: 60 mm Plunge grinding depth in diameter: 3.4 mm Feed 1: 0.012-6 mm/min Feed 2: 0.012-1.2 mm/min Feed per pulse: 0.001-0.05 mm Fpsdpfsw T Sd Tsx Aacsn GRINDING WHEEL HEADSTOCK Left-side wheel, external grinding: 400x80x127 mm Drive power: 5.5 kW Peripheral speed: 35 m/s RPM: 1670/2110 min-1 Internal grinding device for belt-driven spindles, including drive unit: 1.5 kW WORKHEAD Swivel range: 0-90° Continuously variable RPM: 30-1000 min-1 Internal taper: Morse 5 Collets: W-25 Drive power: 0.55 kW Maximum workpiece weight between centers: 130 kg Grinding load between centers: 100 Nm TAILSTOCK Internal taper: Morse 3 Quill stroke: 35 mm Fine adjustment for cylindricity correction: ± 40 μm TECHNICAL CHARACTERISTICS: GUARANTEED WORKING ACCURACY Straightness of the generator over 630 mm: 0.003 mm Roundness during chuck grinding: 0.0003 mm CONNECTION VALUES Maximum absorbed power: 13 kVA Maximum permitted voltage fluctuation: -15%/+10% Maximum permitted frequency variation: ± 3% Required compressed air pressure: 5 bar Unless otherwise stated or in case of error or omission, these technical details are provided without engagement.

Condition: refurbished (used), Year of construction: 2025, operating hours: 36 h, functionality: fully functional, machine/vehicle number: 1024-54, Country of Manufacture: Switzerland Voltage: 380/50/3 Net weight: approx. 1600 kg Customs tariff: 8460.2920 Dimensions: 235 x 155 x 145 cm TECHNICAL FEATURES: MAIN DIMENSIONS: Centre height: 100 mm Distance between centres: 400 mm LONGITUDINAL SLIDE: Max travel: 420 mm Minimum automatic travel: 1 mm Table feed speed: 100–3500 mm/min Overtravel delay: 0–5 sec. Maximum table swivel (400/650 mm): 30°/15° CROSS SLIDE: Max travel: 170 mm Rapid traverse: 30 mm Plunge depth (diameter): 1.9 mm Feed rate 1: 0.03–1.5 mm/min Feed rate 2: 0.02–0.3 mm/min Plunge feed per impulse: 0.0005–0.025 mm WHEELHEAD: Grinding wheel (diameter x width x bore): 350 x 32 x 127 mm Drive power: 3 kW Peripheral speed: 30 m/s Spindle speeds: 1600/1975/2200 rpm Manual stroke: 120 mm Swivel to right: 15°/30° Optional wheel guard for wheel set max width: 50 mm WORKHEAD: Swivel range: 0°–90° Spindle speeds: 80/175/380/800 rpm Internal taper: Morse 4 Fsdpfxow T Sc Ne Aacspn Collet type: W-20 Drive power: 0.5 kW Maximum workpiece weight: 20 kg Load for in-the-air grinding: 12 Nm Optional stepless drive speed range I: 30–300 rpm Optional stepless drive speed range II: 120–1200 rpm TAILSTOCK: Internal taper: Morse 2 Quill travel: 20 mm GUARANTEED WORKING ACCURACY: Generator straightness: Between centres: 400 mm Measured over 400 mm: 0.002 mm Between centres: 650 mm Measured over 650 mm: 0.003 mm Roundness accuracy for in-the-air grinding: 0.0004 mm CONNECTION VALUES: Power consumption: max. 8 kVA Permissible voltage variation: –15% / +10% Permissible frequency variation: ±3% Compressed air: 5 bar All technical specifications are given without obligation and subject to errors or omissions.

Condition: like new (used), Year of construction: 2013, Schaublin UG400 universal grinding machine Year: 2013 NEW, used only a few hours. Height of centers 100mm Distance between centers 400 mm Maximum table travel 425mm Travel speed (stepless) 0.05-5 m/min Minimum stroke 2 mm Table rotation - towards the spindle 30 degree - away from the spindle 3 degree Delay in reversal 0-10sec Handwheel movement of manual feed 15 mm Spindle rotation range 0-90 degree Spindle speed (stepless) 100-1000 rpm Spindle cone 4 Morse Collet chuck diameter 25 mm Engine power 0.2-0.37 kW Chuck diameter (standard) 125 mm Maximum workpiece weight without using tailstock 30 kg Maximum torque 300 kg/cm Maximum workpiece weight between centers 60 kg Grinding wheel size (outer diameter x width x inner diameter) 350x50x127 mm Fpsdpjw Tmidjfx Aacon Minimum grinding wheel diameter 280 mm Grinding wheel motor power 3.7 kW Insertion feed system Fast approach 40 mm Additional adjustment 200 mm Feed rate by diameter (roughing) 0.015-6 mm/min Feed rate (finishing) 0.015-3 mm/min Minimum increment of feed by diameter 0.001 mm Tailstock Quill cone 3 Morse Moving the quill 25 mm Fine tuning range 0-0.040 mm Internal grinding spindle Maximum speed of rotation of the spindle 28000rpm Maximum possible spindle size 100mm Accessories/options: Internal grinding spindle 28000 rpm, Fischer Coolant tank paper filter type Grinding wheels Grinding flanges Taolstock Digital readout system Balancing arbor Hand tools Etc... Under power in our warehouse, ready for inspection.

Condition: used, Year of construction: 1999, grinding diameter 120 mm Fedpfew Sybdsx Aacopn centre height 100 mm Stirnschleifeinrichtung Kein Typenschild auffindb

Condition: used, Year of construction: 1960, grinding diameter ca. 360 mm grinding length 1500 mm serial number 12013 Fjdpfx Aajw Sya Tocjpn

Condition: used, Year of construction: 1975, functionality: fully functional, 1 used: Universal cylindrical grinding machine Fpjdpfx Aajw R Ttqjcon • Manufacturer: RIBON, Italy • Model: RUR 500 • Year of manufacture: approx. 1975 • Centre height: 145 mm • Centre distance: 500 mm • Work spindle: 4-step speeds 35/70 100/200 125/250 155/310 rpm • Grinding spindle: 1700 / 2100 rpm,  24 mm through hole • Grinding wheel: 300 x 20 x 127 mm • Table, swivelling: 2 x 5°

Condition: used, Year of construction: 1991, Machine unit: MS 25/29 WM-03494 Stapling unit: HS 750 WH-03495 Maximum trimming width (folded): 2900 mm Minimum trimming width (folded): 340 mm Sheet height (WM) max.: 2500 mm Sheet height (WM) min.: 300 mm Fpedpfx Ajw Ra Nfsacen Stapling speed: 750 cycles/min Additionally included: hot melt glue unit from Bühnen, model 4100.

Condition: good (used), Year of construction: 1987, TSCHUDIN Type HTG-610 U660 TSCHUDIN Type HTG-610 U660 Cylindrical Grinding Machine, year of manufacture 1987, in very good original condition. The machine comes from the training workshop of a renowned German mechanical engineering company. Fpodpfew Iqr Sox Aacon TECHNICAL DATA MAIN DATA Centre distance: 600 mm Centre height: 100 mm Total power requirement: 4-8 HP MACHINE TABLE Table travel max.: 620 mm Table speed, stepless up to: 5 m/min Reversal delay up to: 4 sec Chuck base swivels: 7° GRINDING SPINDLE HEADSTOCK Wheel diameter: 300 mm Wheel bore (with 300 mm diameter): 127 mm Motor power with 300 mm wheel: 2.5 HP WORKPIECE SPINDLE HEADSTOCK Swivelling range: 360° Spindle taper: MT 4 Spindle speeds, stepless: 65-500 rpm Motor power: 0.5 HP TAILSTOCK Quill internal taper: MT 3 Quill stroke: 20 mm INTERNAL GRINDING ATTACHMENT Spindle diameter max.: 80 mm Motor power: 1.5 HP COOLANT TANK Capacity: 100 litres Dimensions (LxWxH): 2160 x 1200 x 1350 mm Weight: 2600 kg About the machine: We are offering a TSCHUDIN Type HTG-610 U660 cylindrical grinding machine with automatic cycle, year 1987, in very good condition. The machine is, of course, fully functional. All slides run very smoothly and evenly. The Tschudin also operates very quietly at high speeds. Take advantage of the opportunity to inspect this machine under power on-site and see its condition for yourself. You can find further cylindrical grinding machines from reputable manufacturers on our website.
