Gematec GmbH

Condition: excellent (used), Year of construction: 1998, Mazatrol T-Plus control Max. turning diameter: 470 mm Max. swing diameter: 575 mm Turning length: 1,500 mm Spindle speed: 3,000 rpm Magazine for 40 tools (KM 63/SK 40) B-axis Y-axis Kdelhcdwey Ehm Aswsk Steady rest Tailstock Chip conveyor

Condition: ready for operation (used), Year of construction: 2010, operating hours: 5,002 h, functionality: fully functional, turning length: 424 mm, turning diameter: 370 mm, travel distance X-axis: 380 mm, bar passage: 52 mm, controller model: FANUC FS-31iA5 (MAPPS 4), TECHNICAL DETAILS Turning length: 424 mm Maximum turning diameter: 370 mm (270 mm with turret 2) Bar capacity: 52 mm Turn-mill spindle Full indexing specifications: Yes X-axis travel: 380 mm Y-axis travel: ±105 mm Z-axis travel: 460 + 155 mm (ATC) B-axis: ±120º Spindle speed: 12,000 rpm Keljy Edc Hjhcdwwodk Drive power: 9/5.5 kW Tool magazine Magazine positions: 38 Tool holder: Capto C5 Maximum tool length: 250 mm (210 mm for tools under Ø70 mm) Maximum tool diameter: Ø70/Ø130 mm (with/without adjacent tools) Maximum tool weight: 5 kg Lower Turret X-axis travel: 155 mm Z-axis travel: 610 mm Number of tool stations: 10 Tool rotational speed: 6,000 min⁻¹ Driven tool power: 1.5/1.2 kW Main Spindle Spindle speed: 6,000 rpm Drive power: 11/7.5 kW Spindle bore: 73 mm Chuck type: Hollow chuck (8") Manufacturer: KITAGAWA Spindle nose: JIS A2-5 Maximum torque: 223 Nm Sub Spindle Spindle speed: 1,000 rpm BW axis: 4 fixed positions, 0º, -30º, -180º (-225º for overhang to conveyor, if equipped) MACHINE DETAILS Control: FANUC FS-31iA5 (MAPPS 4) Potential rated output: 39.24 kVA Dimensions & Weight Dimensions (L x W x H): 2,705 x 2,425 x 2,385 mm Weight: 8,800 kg Operating Hours Powered on: 54,061 hours Spindle 1 operating hours: 9,813 hours Spindle 2 operating hours: 5,002 hours EQUIPMENT Chip conveyor Signal lamp High-pressure pump Air blower outside the spindle Foot switch (double) for main and sub spindle

Condition: used, Year of construction: 2007, CNC Turning and Milling Center Machine type: DMG CTX 210 V3 Control: Heidenhain CNC Pilot 4290 Year of manufacture: 2007 Available from: immediately / now TECHNICAL DATA: Max. turning length: 365 mm Turning diameter: 290 mm Max. swing diameter over bed: 380 mm C-axis Spindle speed range: 20 - 6,000 rpm Bar capacity: 56 mm Travel distances: Kdjlhey Ecuhocdwwjk X-axis: 160 mm Z-axis: 339 mm Number of turrets: 1 Tool holder: VDI 30 Tool stations: 12 Driven tools: 12 Tailstock Space requirements (LxWxH): 2.88 m x 1.72 m x 1.67 m Machine weight: 4,200 kg Features: Operating manual / instruction manual

Condition: ready for operation (used), Year of construction: 2021, functionality: fully functional, A used CNC turning and milling center Main and counter spindle C axis Y axis Kslhcdsy D Tz Njwwodk Further technical data will be added.

Condition: good (used), Year of construction: 2008, functionality: fully functional, turning length: 1,240 mm, turning diameter: 380 mm, Machine Type: CNC Lathe Manufacturer: Hwacheon Model: Hi-Tech 300 Year of Manufacture: 2008 Control: Fanuc 18i-TB Country of Origin: Korea Delivery Time: available from stock >> Extended turning length configuration >> Driven tools >> Includes tailstock with quill >> Includes bar loading magazine >> Includes additional accessories This horizontal CNC lathe is in very good condition. The machine comes with a comprehensive equipment package, including a full-featured C-axis, touch setter, 3 spindle reduction sleeves, driven tools, tailstock with quill, 3-jaw hydraulic chuck, extended turning length (1240 mm), among others. The extensive features enhance machining capabilities and ensure tool break monitoring. The additional bar loading magazine further increases production productivity. Machine Equipment > Chip conveyor > Bar loading magazine > 3 spindle reduction sleeves > Turning and milling spindle > Driven tools (4 holders available) > Tailstock with quill > Boxways > 3-jaw hydraulic chuck 250 mm (Seoam ACE CAH-10) > Full-featured C-axis > Touch setter Technical Data Performance Swing diameter over bed: 600 mm Max. turning diameter: 380 mm Max. turning length: 1240 mm Spindle Main spindle power: 22 kW Main spindle torque: 1030 Nm Main spindle speed: 3200 rpm Main spindle chuck diameter: 254 mm Bar capacity: 76 mm Rapid traverse X/Z-axis travel speed: 20 / – / 20 m/min Turret Number of tool stations: 12 positions Driven tool speed: 3000 rpm Drive power: 3.7 kW Tool system (type): BMT Direct drive: 6 powered stations Kelhcdwsy D Tigswsdk C-axis: 0.001° Tailstock Quill diameter: 100 mm Quill stroke: 120 mm Taper: MT5 Bar feed magazine Type: Samsys Multisam 2000 Bar length: max. 1550 mm

Condition: used, Year of construction: 2007, operating hours: 67,434 h, functionality: fully functional, machine/vehicle number: PT18SY0210, turning length: 300 mm, turning diameter: 230 mm, spindle motor power: 18,500 W, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 205 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 350 mm, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 6,000 rpm, feed length Z-axis: 350 mm, feed rate Z-axis: 30 m/min, chuck outer diameter: 250 mm, bar diameter (max.): 65 mm, overall weight: 8,800 kg, We are offering a high-performance and reliable Doosan TT1800SY CNC turning center, ideal for demanding serial production as well as complex precision machining. Key Features: Dual spindle (main + sub spindle) Y-axis for off-center and complex machining Twin turret system (upper + lower turret) Live tooling capability Full spindle synchronization (simultaneous machining) High productivity with reduced cycle times Kolhcdwsy D Rypowjdk Technical Specifications: Max. turning diameter: approx. 230 mm Max. turning length: approx. 300 mm Bar capacity: approx. 65 mm Spindle speed (main/sub): up to 5,000 rpm Spindle motor power: ~18.5 kW Y-axis travel: ±50 mm X/Z axis travels: approx. 205 mm / 350 mm Rapid traverse rates: up to 30 m/min Turrets: 2 × 12 stations Live tooling speed: up to 6,000 rpm Tool holders: BMT55 Control system: FANUC 18iTB C-axis: both spindles

Condition: used, Year of construction: 2001, Technical details: turning diameter: 120 mm Kdslhcdwjy D Nxdowsk turning length: 100 mm control: Fanuc Spindle 1 power: 7,5 kW Spindle 1 RPM: 4500 1/min Spindle 2 power: 7,5 kW Spindle 2 RPM: 4500 1/min Distance between spindle noses: 600 mm Turret No.1 stations / rotary tools: 15/15 Power rotary tools turret 1: 2,7 kW RPM of rotary tools turret 1: 4000 1/min Turret No.2 stations / rotary tools: 15/15 Power rotary tools turret 2: 2,7 kW RPM of rotary tools turret 2: 4000 1/min Travel x/z turret 1: 250 / 300 mm Travel x/z turret 2: 250 / 920 mm Bar capacity spindle 1: 51 mm Bar capacity spindle 2: 51 mm power chuck: 165 mm Spindle bore sp. 1: 62 mm Spindle bore sp. 2: 62 mm dimensions of the machine ca.: 3700 x 2300 x 3000 mm weight of the machine ca.: 5600 kg Used CNC-2-spindle CNC turning and milling center with gantry loader - 2x 15 station turret -automatic gantry loader with turnaround station. 14 station-magazin right side Max. Parts size Ø 120 x 100 mm Doublegripper capacity 2 x 3 kg *

Condition: ready for operation (used), Year of construction: 2005, operating hours: 19,229 h, functionality: fully functional, machine/vehicle number: 8043943123C, turning length: 1,050 mm, turning diameter: 465 mm, travel distance X-axis: 300 mm, travel distance Z-axis: 1,050 mm, controller model: Siemens 840 D, TECHNICAL DETAILS Turning diameter: 465 mm Turning length: 1,050 mm Swing diameter: 680 mm Chuck diameter: 325 mm Kslhcdjy D I Ttswwodk X-axis travel: 300 mm Z-axis travel: 1,050 mm Spindle speed range: 3,500 rpm Rapid traverse X/Z: 30 m/min MACHINE DETAILS Control: Siemens 840 D Number of tool positions: 12 positions Tool holder: VDI 40 Weight: 7,500 kg Operating hours Spindle hours: 19,229 h Power-on hours: 81,347 h Note: The machine can be inspected under power upon request.

Condition: used, Year of construction: 1993, functionality: fully functional, Traub CNC lathe TNS26DG, TX8F, year of manufacture 1993 • 2x 12-station turrets with rotating tool drive VDI25 • C-axis on main/sub spindle • 163E on main spindle, 161E on sub spindle • Chip conveyor, bar feeder DN26 • Spare parts catalog, electrical diagram, ATC optics Ex site, directly from production By arrangement, approx. 2-3 weeks after order 100% payment before loading Without any warranty. Ex location/dismantled, as inspected and tested. Subject to prior sale. Kdjlhey D I Svecdwwsk

Condition: ready for operation (used), Year of construction: 2012, operating hours: 4,299 h, functionality: fully functional, machine/vehicle number: 15995726904, spindle motor power: 20 W, spindle speed (min.): 24,000 rpm, travel distance X-axis: 700 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 380 mm, Machine equipped with an integrated 4th axis by TSUDAKOMA. Kolhcdwoy D I R Eswsdk

Condition: used, Year of construction: 2006, Technical details: turning diameter: 220 mm turning length: 170 mm control: Fanuc Spindle 1 power: 15 kW Spindle 1 RPM: 2500 1/min Spindle 2 power: 15 kW Spindle 2 RPM: 2500 1/min Distance between spindle noses: 1100 mm Turret No.1 stations / rotary tools: 15/15 Power rotary tools turret 1: 4 kW RPM of rotary tools turret 1: 3000 1/min Turret No.2 stations / rotary tools: 15/15 Power rotary tools turret 2: 4 kW RPM of rotary tools turret 2: 3000 1/min Travel x/z turret 1: 250 / 300 mm Travel x/z turret 2: 250 / 920 mm Travel y Turret 1: ± 60 mm Travel y Turret 2: ± 60 mm Bar capacity spindle 1: 65 mm Bar capacity spindle 2: 65 mm power chuck: 254 mm Spindle bore sp. 1: 77 mm Spindle bore sp. 2: 77 mm dimensions of the machine ca.: 4600 x 2900 x 3000 mm weight of the machine ca.: 10400 kg Used CNC Counter spindle turning and milling center with 2 y-axes and gantry loader - SMW210 mm chuck on right spindle. Special chuck on left side is not part of the deal. - 2x 15 station turret -automatic gantry loader with turnaround station. 14 station-magazin left side Ksley D I Htohcdwwjdk conveyor belt for finished parts 415 x 3500 mm Max. Parts size Ø 200 x 120 mm Doublegripper capazity 2 x 8 kg No rotary tools will come with the machine. *

Condition: used, Year of construction: 2010, operating hours: 29,870 h, functionality: fully functional, machine/vehicle number: 8045000191A, DMG CTX 510 eco – CNC Universal Slant-Bed Lathe Manufacturer: DMG (Gildemeister / DMG MORI Group) Model: CTX 510 eco (Ecoline Series) Year of Manufacture: 2010 Control Unit: Siemens Overview The DMG CTX 510 eco is a robust and powerful universal CNC lathe designed for heavy-duty turning and precision machining. Featuring a high-torque spindle and a 45° slant-bed design for excellent chip flow and thermal stability, this machine is ideal for both small batches and production runs. Key Technical Specifications Max. Swing Diameter: 680 mm Max. Turning Diameter: 465 mm Max. Turning Length (Z-axis): 1,050 mm Spindle Speed: 3,250 RPM Main Spindle Power: 33 kW (40% DC) / 22 kW (100% DC) Spindle Torque: 630 Nm (High torque for heavy cutting) Bar Capacity: 76 mm Kdjlhey D Il Ascdwwok Rapid Traverse (X/Z): 30 m/min Turret & Tooling Number of Tool Stations: 12-position turret Tool Holder Type: VDI 40 Driven Tools (C-Axis): Equipped with C-Axis and milling capability for 3-axis machining. Included Equipment & Features Steady Rest ,Tailstock,Chip Conveyor Coolant System: High-pressure pump and tank. Physical Dimensions Weight: Approx. 7,800 kg Footprint: Approx. 4.5m x 2.4m x 2.0m Condition Well-maintained machine from a professional environment. Original DMG signature build from the FAMOT factory. Available for inspection

Condition: like new (used), Year of construction: 2018, functionality: fully functional, type of input current: three-phase, We offer this used Haas ST-10 CNC turning and milling center, year of manufacture 2018. Model: ST-10 Serial number: 3109692 Date of manufacture: 01/2018 Voltage: 400 V Phases: 3 Frequency: 50/60 Hz Rated current: 18 A Maximum current: 17 A Short-circuit interrupting current: 10,000 A Short-circuit current: 5,000 A Wiring diagram: 96-0284 Kjlhey D Eprscdwwodk If you have further questions or require more information, please feel free to send us a message or call us.

Condition: like new (used), Year of construction: 2014, operating hours: 925 h, functionality: fully functional, turning length: 500 mm, turning diameter over cross slide: 290 mm, turning diameter: 500 mm, spindle speed (max.): 5,500 rpm, spindle bore: 73 mm, travel distance X-axis: 210 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 525 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 22 m/min, rapid traverse Z-axis: 30 m/min, total height: 1,808 mm, total length: 4,447 mm, chuck outer diameter: 210 mm, total width: 2,378 mm, swing diameter over cross slide: 290 mm, spindle nose: FL 140h5, overall weight: 4,300 kg, Equipment: documentation/manual, rotational speed infinitely variable, 925 spindle hours—in other words, virtually as good as new; that’s certainly the case for this DMG MORI CTX ALPHA 500 V4! The machine comes from a prototype department where primarily plastics were machined. Kdslhey Duinecdwwjk

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Kdelhcdoy Dtkqowwok Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: ready for operation (used), Year of construction: 2008, spindle motor power: 22,000 W, spindle speed (max.): 4,000 rpm, travel distance X-axis: 200 mm, travel distance Z-axis: 400 mm, overall weight: 5,500 kg, number of axes: 3, This 3-axis CMZ TB-67M turn-mill centre was manufactured in 2008. It features a maximum turning diameter of 400 mm and a maximum swing over bed of 640 mm. The machine is equipped with a spindle speed of 4,000 rpm and a powerful spindle motor of 22 kW. If you are looking to get high-quality turning capabilities, consider the CMZ TB-67M machine we have for sale. Contact us for further details. Technical Specification Counter Spindle No Kdjlhcdey Drb Iswwsk Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, turning length: 1,585 mm, turning diameter: 300 mm, controller model: Siemens 840D Powerline, number of slots in tool magazine: 120, No minimum price – guaranteed sale to the highest bidder! Kelhsy Dqtiecdwwodk TECHNICAL DETAILS Turning length: 1,585 mm Turning diameter: 300 mm Tool magazine capacity: 120 positions MACHINE DETAILS Control: Siemens 840D Powerline EQUIPMENT Sub spindle C-axis Hollow clamping device (diameter 68 mm) on main spindle, left Measuring device with probe Oil mist separator

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 144205, turning length: 2,500 mm, controller model: MAZATROL PC-Fusion CNC 640MT, Equipment: chip conveyor, TECHNICAL DETAILS Turning length: 2,500 mm MACHINE DETAILS Kolhey Dp Acecdwwsdk Control: MAZATROL PC-Fusion CNC 640MT Tool magazine: 30 tool stations EQUIPMENT High-pressure coolant system Driven tools Chip conveyor Measuring probe/tool measurement Steadies (lunettes) Note: A minor repair has been carried out on the machine. The repair certificate is attached.

Condition: used, Year of construction: 2015, functionality: fully functional, Travel distances X-axis travel: 290 mm Z-axis travel: 560 mm W-axis travel: 640 mm Y-axis travel: ±55 mm Main Spindle Main spindle power: 28 kW Main spindle torque: 242 Nm Spindle nose: A2-6 Bar capacity: 64 mm Max. swing diameter: 508 mm Chuck diameter: 203 mm Spindle speed: 4,500 rpm Feedrates X-axis feedrate: 24 m/min Z-axis feedrate: 30 m/min W-axis feedrate: 30 m/min Y-axis feedrate: 12 m/min Turret Turret: 12 stations Tool holders: VDI40 Max. boring bar diameter: 40 mm Shank cross-section: 25×25 mm Driven Tools Driven tool speed: 4,000 rpm Driven tool power: 5.4 kW Driven tool torque: 24 Nm Index time: 0.16 s Sub Spindle Sub spindle max. speed: 6,000 rpm Kjley Dgfbjhcdwwodk Sub spindle torque: 70 Nm MACHINE DETAILS Electrical connection values: 66 kVA / 95 A / 400 V Pneumatic connection values: 7 bar / 150 l/min Weight: 7,000 kg Operating hours Power-on hours: 60,496 h Spindle hours: 19,299 h EQUIPMENT Bar feeder IRCO/Breuning SIMAG 80.1-2R-3000 Various channels Chip conveyor Tool measurement arm (Tool Setter) Transformer Cooling unit Coolant tank Fixed and driven tool holders Replacement main spindle (unrefurbished) Various collet chucks, size 65 Documentation (circuit diagrams, operator's manual, etc.)

Condition: good (used), Year of construction: 2021, functionality: fully functional, Fanuc control, 66 mm spindle bore, two turrets, two Y-axes, sub-spindle, tailstock function, tool measuring arm, programmable finished parts gripper, chip conveyor, Irco short bar loader magazine, Hainbuch chuck on both spindles, accessories: tool holders, driven tool holders, immediately available. Kelhcdsy Df E Tewwodk

Condition: ready for operation (used), Year of construction: 2011, spindle motor power: 22,000 W, spindle speed (max.): 3,800 rpm, travel distance X-axis: 1,670 mm, travel distance Y-axis: 505 mm, travel distance Z-axis: 190 mm, total height: 2,950 mm, total width: 2,960 mm, overall weight: 13,700 kg, product length (max.): 5,110 mm, number of axes: 9, This 9-axis Okuma MAC TURN 350-W was manufactured in 2011. It features a maximum turning diameter of 550 mm and a distance between centers of 1500 mm. The machine is equipped with a powerful main spindle and sub-spindle, both capable of 3800 rpm, and a milling spindle speed of 12,000 rpm. If you are looking to get high-quality turning and milling capabilities, consider the Okuma MAC TURN 350-W turn-mill centre we have for sale. Contact us for further details. • Control unit: OKUMA OSP P200L-H • Included control options: Collision Avoidance System (CAS), One Touch IGF, Helical Interpolation • Distance between centers: 1500 mm • Max swing diameter over covers: 550 mm • Max turning diameter: 550 mm • Bar capacity: 75 mm • Main spindle: • Attachment: ASA 8" Big Bore • Sub-spindle: • Attachment: ASA 8 Super Big Bore • Speed: 3800 rpm • Power: 22/15 kW • Milling spindle: • Taper: HSK A63 • Speed: 12,000 rpm • Power: 11 kW • Tooling: • Tool magazine: 44 positions • Lower turret: 12 positions with motorized tools • Axes: • Axis travels: 1670 mm / 1655 mm; 505 mm / 210 mm; 190 mm • B-axis: Continuous 210° • C-axis: 360,000 divisions • Coolant/pump pressure: 15 bar • Working hours (as provided): • 30870: 8:15 • 13909:49:34 • 6594: 8:59 • 9497:37:03 Kjlhcoy Ddiwsdwwsdk Additional equipment • Chip conveyor Technical Specification Counter Spindle No Driven Tools No

Condition: ready for operation (used), Year of construction: 2019, operating hours: 2,770 h, functionality: fully functional, machine/vehicle number: NL257181158, turning length: 705 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 795 mm, swing diameter over cross slide: 742 mm, swing diameter over bed slide: 920 mm, TECHNICAL DETAILS Working Area Swing diameter over bed max.: 920 mm Swing diameter over cross slide max.: 742 mm Turning length max.: 705 mm Bar capacity: 80 mm X-axis travel: 260 mm Y-axis travel: 50 mm Z-axis travel: 795 mm Main Spindle Power: 18.5/15 kW Max. speed: 4,000 rpm Chuck size: 10 inch Spindle bore: 91 mm Front bearing diameter: 140 mm Sub Spindle Power: 11/7.5 kW Max. speed: 4,000 rpm Chuck size: 6 inch Spindle bore: 45 mm Front bearing diameter: 85 mm Turret and Axes Tool stations: 12 Kdjley A Nf Ishcdwwok Tool shank cross-section: 25 mm Max. driven tool speed: 10,000 rpm Rapid traverse X-axis: 30,000 mm/min Rapid traverse Y-axis: 10,000 mm/min Rapid traverse Z-axis: 30,000 mm/min Rapid traverse B-axis: 30,000 mm/min MACHINE DETAILS Control: M730UM with CELOS Operating hours: 2,770 h Power-on hours: 10,820 h Dimensions & Weight Machine height: 2,000 mm Installation dimensions: 3,347 x 2,106 mm Weight: 5,820 kg EQUIPMENT Y-axis Sub spindle Main spindle with 10-inch chuck Sub spindle with 6-inch chuck Chip conveyor High-pressure coolant system Tool measuring system Parts catcher Workpiece ejector Interface for bar loader

Condition: excellent (used), Year of construction: 2020, operating hours: 7,320 h, machine/vehicle number: 3119208, turning length: 406 mm, turning diameter: 305 mm, spindle motor power: 14,900 W, spindle speed (max.): 4,000 rpm, spindle bore: 64 mm, travel distance X-axis: 200 mm, travel distance Z-axis: 406 mm, For sale: Used CNC lathe HAAS ST15 in very good technical condition. Operating hours: 7,320. Reason for sale: Standardization of machinery for compatibility with the rest of the machine park. Key features: • Automatic Door • Renishaw WIPS Probing System • Hybrid BOT/BMT Turret (Dual Mount Tooling) • Live Tooling (Driven Tools – milling option) • Sub-Spindle (6,000 RPM) • Parts Catcher (if installed) • Chip Conveyor • Control Cabinet Cooler • Wireless Networking (WiFi) • Rigid Tapping Kdjlhsy A I Nxjcdwwek • Extended Program Memory (1GB) • VPS Programming (Visual Programming System) For more information, please contact us by phone or email.

Condition: excellent (used), Year of construction: 2019, operating hours: 2,739 h, machine/vehicle number: 3113763, turning length: 406 mm, turning diameter: 305 mm, spindle motor power: 14,900 W, spindle speed (min.): 4,000 rpm, spindle bore: 64 mm, travel distance X-axis: 200 mm, travel distance Z-axis: 406 mm, mount diameter: 210 mm, For sale: Used HAAS ST15 CNC lathe in very good technical condition. Operating hours only 2,739. Reason for sale: standardization of machines for compatibility with the rest of the facility. Key options: - Renishaw WIPS Probing System → Renishaw measuring probe (WIPS) - 8” Hydraulic Chuck Kdeljy A Iw Njhcdwwsk - 12-Station BOT Turret - Parts Catcher - Chip Conveyor - Rigid Tapping - Extended Program Memory (1GB) - VPS Programming (Visual Programming System) - Custom Macros (trial active) For more information, please contact us by phone or email.

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 7024NL256160890J, spindle speed (max.): 10,000 rpm, travel distance Y-axis: 200 mm, rotational speed (max.): 4,000 rpm, bar diameter (max.): 80 mm, distance between centers: 700 mm, Condition: Ball screw drives in X, Y, and Z axes replaced; major maintenance package carried out approx. one year ago (machine has not been in operation since)! TECHNICAL DETAILS Distance between centers: 700 mm Kelhcdjy A Icrswwodk Spindle speed range: 1 - 4,000 rpm Tool spindle speed: 10,000 rpm Bar capacity: 80 mm Mounting: MT5, revolving tailstock Without center Turret: 12 stations, bolt-on turret Overhang for driven tools: ±100 mm Assemblies: Integrated MK4 bearing for live center Chip and coolant system: Scraper-type chip conveyor with magnetic separator, discharge height approx. 1,000 mm Coolant system: high pressure 5 bar, pump 800 W, delivery rate 20 l/min Coolant shower at chuck, including high-performance pump Compressed air blow-off system for tool holder sleeves Compressed air blow-off system for tailstock live center Line filter for coolant system MACHINE DETAILS Control: M730UM, CELOS - ERGOline Touch Total power: 18.5 / 18.5 / 15 kW (25% duty cycle / 50% duty cycle / continuous) Tool spindle power: 5.5 / 5.3 / 7 kW (3 min / 5 min / continuous) EQUIPMENT Interface for oil mist separator (diameter: 150 mm) Signal beacon: red, yellow, green, blue EtherNet/IP interface for automation Robot interface for portal robot DMG Mori Seiki Transformer: 45 kVA, three-phase autotransformer X-axis direction ISO Note: The machine is supplied without a chuck, tool pre-setter, or workholding devices.
