Gamba Machine Tools

Condition: used, Year of construction: 2009, x-travel 1.800 mm y-travel 700 mm z-travel 700 mm control iTNC 530 Heidenhain turning speed range - main spindle 20 - 18.000 min/-1 power capacity - main spindel 25 / 35 kW max. Torque 130 / 87 Nm tool taper HSK A63 DIN 69893 swivellable B: +/- 100 ° table surface area 2.100 x 700 mm max. table load 1.500 kg number of T-slots 7 table diameter 750 mm max. table load 500 kg number of T-slots 7 rotatable C: 360 ° number of toolpositions 30 pos. tool taper HSK A63 DIN 69893 max. tool weight 6,0 kg max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool length 300 mm change-time chip to chip 7,6 sec rapid traverse ( X / Y / Z ) 40 m/min Accelaration 4 m/s² feed speeds max. 40.000 mm/min Feed force ( X / Y / Z ) 8 kN total power requirement 70 kVA Cgodpfx Ajyhhtgjfnjn weight of the machine ca. 13,0 t dimensions of the machine ca. 7,0 x 6,2 x 2,8 m 5-Axis CNC - Travel Column Milling Machine DECKEL MAHO - DMF 180 New Design - Swivel-Head (B-Axis) - integrated rotary-table - internal coolant system - Operating-Hours: Spindle-Runtime: ca. 10.000h

Condition: new, Year of construction: 2026, functionality: fully functional, machine/vehicle number: 9101, travel distance Y-axis: 4,600 mm, travel distance Z-axis: 1,600 mm, rotational speed (max.): 6,000 rpm, Equipment: rotational speed infinitely variable, Machine configuration: • PowerPortal4000 • 45° diagonal milling head (C 0.01° / A 0.01°) • Camera system integrated in SHW diagonal milling head Cjdpfx Afeygtnaenogn • 4-point Hirth-type milling head interface • Heidenhain TNC 7 • HR 550 FS handwheel • Heidenhain optimization for 5-axis machining • X = freely selectable, Y = 4,600 mm, Z = 1,600 mm • ToolCenter with 90 tools • Coolant system 2,500 l • Coolant pump 70 bar / 30 l/min • Coolant/air switching • Wash gun in the working area • Main drive 75 kW up to 6,000 rpm • Tool holder SK 50 BIG-PLUS • Panelling and grating • Double chip conveyor • SHW-UniScan • Sealing air • Operating mode 3 • Hexagon wireless probe • LED workspace lighting • Second camera in the working area

Condition: excellent (used), Year of construction: 2008, travel distance X-axis: 10,000 mm, travel distance Y-axis: 2,500 mm, rotational speed (min.): 3,000 rpm, Description & Application This machining center with a movable column is another machine in the TOS Kurim portfolio boasting high flexibility, which is ensured by its modular concept and the possible use of versatile spindle heads. The workpiece clamping space is also designed to satisfy customer requirements. The machine design allows for a wide range of machining operations – milling boring roughing reaming and threading. The customers can use it for machining heat exchangers, steam turbine parts, shafts of wind turbines, Francis turbines engine blocks, locomotive, and car bogies etc. Technical Specifications (Subject to verification) Longitudinal stroke “X” axis 8000mm + 1000mm for pick up the milling head. Cross stroke “Z” axis 1500 mm Spindle headstock vertical travel “Y” axis 2500mm Two re-circulation ball screw on vertical axis Range feeds in longitudinal and transversal 1-20000 mm/min Range feeds in the vertical direction 1-16000 mm/min Twin Rotary Tables T-slot Table size 2500 x 2000 mm Distance between centers for 2 tables 4000 mm Stroke 1250 mm Spindle Spindle Taper CAT 50 Spindle speed range 20 - 4000 rpm Output of main motor 30kW Cooling through the spindle type FORM B Traverse of the quill 400 mm Diameter of the quill 170 mm Feed range 1-2000 rpm Rapid feed 4000 rpm Additional Spindle Heads Spindle heads type: IPS (Universal Type) Spindle taper CAT 50 Range of Spindle Speed 20-3200 rpm Max. torque of the spindle 1200 Nm Automatic hydraulic operated tool unclamping Automatic tool load from the tool magazine Horizontal milling head type: VA Spindle taper CAT 50 Cedjygdb Rjpfx Afnogn Manual tool load Spindle speed range 20-4000 rpm Max. Spindle torque 500 Nm Max. Length of the mill. Head 700 mm Head magazine for the heads: IPS, VA Tool Magazine Tool Magazine 40 pcs Max weight of the tool 25 kg Dia. Of the tool in full magazine 130 mm Max. Length of the tool 340 mm Electricals 575V, 3 Phase, 60Hz Input 50kVA Dimensions Length 17420 mm Width 10420 mm Height 5737 mm Weight 30700 kg Features Twin Heavy Duty Rotary Table Multi Spindle Heads with Head Changer Automatic Tool Changer Coolant Thru Spindle Chip conveyor

Condition: used, 5000 mm x 1200 mm 2 x Heidenhain 426 ISO50 Cgsdpfx Aeyf Nkhofnjn

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 8 m/min, rapid traverse Y-axis: 8 m/min, rapid traverse Z-axis: 8 m/min, feed rate X-axis: 8 m/min, feed rate Y-axis: 8 m/min, feed rate Z-axis: 8 m/min, pivoting range: 340 °, table length: 5,000 mm, table width: 1,730 mm, table height: 300 mm, Technical Specifications Travel Paths • X-axis (bed): 5,000 mm • Y-axis (vertical): 1,600 mm • Z-axis (spindle head): 1,500 (1,200) mm Control System • CNC control: Heidenhain TNC 415 Feed Rate • X, Y and Z axes steplessly adjustable from: 2 – 8,000 mm/min Universal Milling Head in Orthogonal Design • Motor-driven milling head swivel range: 340 degrees • Milling head swivel range: 180 degrees • Tool holder: SK 50 Clamping Table • Clamping surface: 5,000 mm x 1,730 mm • T-slots: 9 x 28 DIN 650 • T-slot spacing: 160 mm Cjdpfx Afeyf Ai Rjnogn Year of Manufacture: 1992 Partial overhaul: 2025 The machine has been recommissioned and inspected at MBM. It can be demonstrated under power at D-73479 Ellwangen. About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our core focus is on tool milling machines. Our services include, among others, spare parts supply, on-site customer service, machine overhauls, and control system upgrades. Our services: - Used machinery - Spare parts - Customer service - Machine service - Machine overhauls - Control system modernization _____ Used machine – used milling machine – used travelling column milling machine – orthogonal milling head – metalworking – tool milling machine – milling head – SHW machine – SHW spare parts – used milling machine – used CNC milling machine – used boring and milling machine – used metal milling machine – used metalworking mill – used CNC mill – CNC milling machines – CNC milling centers – milling machine – large-part machining – CNC large-part machining – milling – SHW – UF6 – UF 6 – Uniforce – SHW UF – SHW Uniforce – SHW Uniforce 6 – UFZ 6 – UFZ6L – UFZ 6 L – Heidenhain – MBM milling machine – MBM machine – column milling machine

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, travel distance X-axis: 17,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 2,500 mm, table length: 18,000 mm, table width: 4,500 mm, We are selling a studio milling machine from ITP Limited. The machine can either be collected or rented together with the hall at the special airport in Oberpfaffenhofen, southwest of Munich. 200 sqm for EUR 1,600 per month by arrangement with the landlord, plus a discounted purchase price. Cjdpfx Asyfw Nlsfnogn

Condition: used, Year of construction: 1999, x-travel 5.850 mm y-travel 1.200 mm z-travel 2.000 mm control HEIDENHAIN TNC 430 D table-size 6.120 x 1.000 mm table weight 20.000 Kg internal coolant system feed 20 bar Chip coveyor inkl. handwheel HEIDENHAIN HR-410 Tools changer 60 fach/tools taper ISO ISO 50 engine output 30 kW working speed 5.000 mm/min rapid taverse 12.000 mm/min Number of revolutions 20 - 3.000 rpm total power requirement 41 kW weight of the machine ca. 31 t Cgjdpjydfmijfx Afnen

Condition: used, Year of construction: 1999, x-travel 3.400 mm y-travel 1.250 mm z-travel 2.000 mm Control TNC- 430 PA table-size 4.700 X 1.200 mm V- travel 500 tool taper ISO 50 Cgjdpfxoydfmcs Afnsn milling head -swivable 0.001º/0.001º Grad main drive 37 kW Chip coveyor inkl handwheel HR-410 Tools changer 60 pos. milling head Automatic Head 45º weight of the machine ca. 35 t - Automatic Head 45º INCLUDED - Automatic Head 45º 0.001º/0.001º - Head 45º Max. Speed 3.000 rpm - 45º Head Taper ISO-50 - Twist Head Contiuous INCLUDED - Twist Head Max Speed 3.000 rpm - Twist Head Taper ISO-50 - Ram with Quill - Quill Diameter 150 mm. - Quill Taper ISO-50 - Pick up station AITEK for 45º and Twist Heads - Rotary Table ZEATZ Ø 1200 INCLUDED - RENISHAW MP 16+SP2/1

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, spindle speed (max.): 15,000 rpm, Matec 5000 Travel: 5000x800x800 mm Table size: 5000x850 mm Kessler spindle, 15,000 rpm Tool holder: SK40 Cedpfx Afsych R Ijnegn Tool magazine: 45 tools

Condition: like new (used), Year of construction: 2024, functionality: fully functional, travel distance X-axis: 4,200 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 950 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 50 m/min, spindle speed (max.): 15,000 rpm, MMV 4200 GANTRY-TYPE MACHINING CENTER FOR 5-AXIS SIMULTANEOUS MACHINING WITH HEIDENHAIN TNC 640 5-axis simultaneous gantry-type machining center with integrated water-cooled motor spindle. Control: HEIDENHAIN TNC 640 • Conversational programming • USB and Ethernet interface • 24" TFT color monitor • 3D visualization, programming graphics Spindle: Water-cooled motor spindle Spindle power: 46 kW Spindle speed: 50 - 15,000 rpm Spindle torque: 170 Nm Tool holder: ISO 40 DIN 69871 Pull stud: ISO7388/2 Type B (not included in the basic version) Travel: X = 4200 mm, Y = 1000 mm, Z = 950 mm Distance spindle nose to table: 0-950 mm Rapid traverse (X-Y-Z): 60/50/50 m/min B/C axis: 50/100 rpm Fixed table: Cast iron table with T-slots Number - width - spacing: 7 - 18 mm - 125 mm (central alignment slot 18H8) Clamping surface: 4400 x 1050 mm Maximum table load: 6000 kg (evenly distributed) Swivel head (B axis): Torque motor, swivel range +120°/-120° Rotary table (C axis): Torque motor, table diameter 900 mm Maximum table load: 2000 kg Rotary table accuracy: 0.05 mm +/-0.02 mm, recessed under the fixed table Stationary tool changer: Drum magazine on the left side of the machine with 40 tool stations Csdoychf Sepfx Afnsgn Tool change time (chip-to-chip, VDI2852): approx. 15s Coolant pump: Pressure 6 bar, delivery rate 40 l/min (nominal at pump) Work area lighting: 4 LED lamps Standard equipment: • Linear glass scales in X/Y/Z axes • Central lubrication with grease • Handwheel • Alarm lamp • Work area lighting • Electrical cabinet air conditioner

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 5,824 mm, travel distance Y-axis: 897 mm, travel distance Z-axis: 1,005 mm, rapid traverse X-axis: 6,000 m/min, rapid traverse Y-axis: 8,000 m/min, rapid traverse Z-axis: 8,000 m/min, spindle speed (max.): 4,000 rpm, rotational speed (max.): 4,000 rpm, Equipment: documentation/manual, SHW UFZ 4 Travel distances • X-axis (bed): 5,824 mm • Y-axis (horizontal spindle stock): 897 mm • Z-axis (vertical): 1,005 mm Control • CNC control: Heidenhain iTNC 530 Clamping plate • Clamping surface: 5,000 x 2,000 mm Cross-traversing rotary table • Diameter: 1,400 mm (flattened) • Cross-axis travel: 1,131 mm Rapid traverse • X-axis: 6,000 mm/min • Y- and Z-axis: 8,000 mm/min Horizontal and vertical milling head • Tool holder: SK 50 DIN 69871 • Speed range: 36 – 4,000 rpm • Internal coolant supply • Spindle orientation with cycle 13 • Tapping without compensating chuck • The milling head was recently completely overhauled Automatic tool changer • Tool magazine for 45 tools Coolant system • Belt filter Chip conveyor Splash and chip guard General overhaul including control upgrade in 2008 About the company MBM MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our core business is in the field of tool milling machines. Our services include, among others, spare parts supply, on-site customer service, machine overhauls as well as control system modernizations. Services: - Used machines - Spare parts - Customer service - Machine service - Machine overhauls - Control system modernization Cedpfx Asx Uw Egefnogn ----- Used machine – used milling machine – used travelling column milling machine – metal machining – tool milling machine – milling head – SHW machine – SHW spare parts – used milling machine – used cnc milling machine – used boring milling machine – used metal milling machine – used metal mill – used cnc mill – cnc milling machines – milling machine – large part machining – cnc large part machining – milling – Heidenhain – MBM milling machine – MBM machine – column milling machine

Condition: excellent (used), Year of construction: 2007, travel distance X-axis: 6,000 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,400 mm, feed rate X-axis: 30,000 m/min, feed rate Y-axis: 30,000 m/min, feed rate Z-axis: 30,000 m/min, spindle speed (max.): 2,000 rpm, table length: 4,000 mm, table width: 2,000 mm, CNC Bed-Type Milling Machine SACHMANN RAMBAUDI - MP-212 HS MACH-ID 9328 Make: SACHMANN RAMBAUDI Type: MP-212 HS Control: HeidenHain iTNC530 Year: 2007 KOSMO 3 indexing head Sk-50, 0,02 Degrees, 1195 Nm Spindle extention L = 600 mm with 2000 Rpm 3D Measuring probe MP60 ATC Chain 80 Positions Coolant system 1320 L with 4,8 Bar Rotary indexing table  2000 x 1600 x 15 ton V-Axis (in feed) 1500 mm Rotation 3 U/Min HeidenHein RON 700 encoder for Table rotation Ram size 500 x 500 with 56 kW Chip conveyor  X-Axis: 6000mm Y-Axis: 2000mm Z-Axis: 1400mm Table Length: 4000mm Table Width: 2000mm Table load: 25000 Power on spindle: 37kW Spindle speeds: 2000Rpm Spindle Taper: 50ISO/Bt/Mk Feed rate X-Axis: 30000mm/min. Feed rate Y-Axis: 30000mm/min. Feed rate Z-Axis: 30000mm/min. Millinghead auto-index:2.5 x 2.5° Length: 15000mm Width: 8000mm Height: 6000mm Weight: 85000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details! Cjdex Nh H Djpfx Afnegn

Condition: excellent (used), Year of construction: 2013, CNC gantry milling machine with 18 m travel! • Table size: 18,000 x 2,800 mm • Distance between columns: 3,650 mm • Max. table load: 3,000 kg/m² • Travel X-axis: 18,000 mm • Travel Y-axis: 3,600 mm • Travel Z-axis: 1,600 mm • Max./min. distance table / spindle: 2,496 / 896 mm • Spindle taper: BT50 • Max. spindle speed: 6,000 rpm • Spindle drive: 26 kW • Max. tool length: 350 mm • Tool magazine: 32 positions Cgsdpfsx Imaajx Afnjn • Max. tool diameter: 220 mm • Max. tool weight: 18 kg • Machine dimensions (L x W x H): 26.6 x 7.8 x 7.2 m • Control system: FANUC OiMD + 8.4’’ LCD Accessories: • Various angle heads Chip conveyor Very little used machine!

Condition: excellent (used), Year of construction: 1997, CNC travelling Column machine Table 10,000mm Length x 1100mm Width X Travel 8500mm Y Travel 1600mm Z (Ram Travel) 1200mm 60 Station tool changer Integrated horizontal & Vertical rotary table (CNC) Spindle BT50 Cedpfsx El E Ajx Afnegn Spindle 20 - 2000RPM Siemens Sinumerik CNC Control

Condition: used, travel distance X-axis: 16,000 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 4,000 rpm, spindle motor power: 37 W, X-AXIS TRAVEL: 16,000 MM Z-AXIS TRAVEL: 1,500 MM Cgjdpfx Afex A Ulwenen Y-AXIS TRAVEL: 3,500 MM SPINDLE MOTOR POWER: 37 KG SPINDLE NOSE CONNECTION: ISO 50 SPINDLE SPEED: 4,000 RPM HEIDENHAIN iTNC 430 CNC 80-POT TOOL CHANGER 2.5° X 2.5° AUTOMATIC HEAD INTERNAL AND EXTERNAL COOLANT HEXAGON WORKPIECE PROBE 2000 X 2000 MM ROTARY-TRANSLATING TABLE, 15 TON LOAD CAPACITY, 1500 MM V-AXIS STROKE OPERATOR CABIN WITH OPERATOR FIXED PLATES CHIP CONVEYOR

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: TM3507008, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 5,000 rpm, controller model: SELCA S 4045 PDH, TECHNICAL DETAILS Travel distances Longitudinal travel: 3,500 mm Cross slide travel: 1,100 mm Vertical travel: 1,500 mm Table Table dimensions: 3,800 x 1,000 mm Spindle Cgsdox Aph Hopfx Afnsn Spindle taper: ISO 50 Spindle speed: 5,000 rpm Tool changer Positions: 40 CNC control Model: SELCA S 4045 PDH MACHINE DETAILS Unfortunately, no specific information regarding connected load, dimensions, or weight of the machine is provided in the supplied text. EQUIPMENT No additional equipment information has been provided.

Condition: excellent (used), Year of construction: 1979, functionality: fully functional, machine/vehicle number: Ob 21882, travel distance X-axis: 15,000 mm, travel distance Y-axis: 5,150 mm, travel distance Z-axis: 2,000 mm, feed length Z-axis: 1,600 mm, spindle speed (max.): 630 rpm, spindle speed (min.): 8 rpm, total width: 6,400 mm, total height: 10,370 mm, total length: 19,300 mm, torque: 34,300 Nm, table load: 80,000 kg, overall weight: 137,000 kg, spindle diameter: 250 mm, W250H plate drilling and milling machine with S80B rotary table 4000x3550 mm, maximum load 80,000 kg. The machine is in very good technical condition. It is in continuous operation and can be inspected while machining a component. Cgjdpoxzzzvsfx Afnsn

Condition: good (used), Year of construction: 2000, machine/vehicle number: 7853, travel distance X-axis: 5,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 2,000 mm, table length: 6,000 mm, table width: 2,000 mm, table load: 17,000 kg, Travelling column milling machine | FPT Sirio-M50 - Heidenhain control system - 60-position automatic tool changer - Coolant treatment and filtration unit - Chip conveyor - Cooling unit, manufacturer Deerosdassi (Italy) - Electrical cabinet - Full machine enclosure (protective housing) Csdpfexzzlhex Afnogn An inspection is possible at any time by appointment.

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, rotational speed (max.): 7,000 rpm, spindle motor power: 34 W, Equipment: documentation/manual, rotational speed infinitely variable, Travelling column milling machine used with CNC H. TNC-530 Cjdpfx Ajxyw Tfjfnjgn

Condition: ready for operation (used), Year of construction: 1970, functionality: fully functional, machine/vehicle number: 50052, Year of manufacture: 1970 Serial number: 50 052 The machine was overhauled in 2007. GENERAL CHARACTERISTICS OF THE MACHINE The machine features a fixed gantry with a moving table. The gantry is equipped with a height-adjustable crossbeam, which can be fitted with one or two vertical spindles in the VF 120 version. The gantry can also be fitted with one or two side-mounted (horizontal) VF 160 headstocks. The clamping surface consists of two interconnected clamping tables, which can also be used individually when disconnected (only one table can be operated at a time). Clamping Table: Dimensions of one table: 1,600 x 3,000 mm Total length of connected tables: 7,000 mm Clamping surface of connected tables: 6,500 mm Clamping T-slots (width x pitch x number): 28 mm x 160 mm x 9 pcs Table height from base: 900 mm Travel of one table: 3,000 mm (connected tables: 6,500 mm) Table feed rate: 20 – 2,000 mm/min Rapid traverse: 4,000 mm/min Cgedsxxwy Aepfx Afnjn Gantry with height-adjustable crossbeam: Clearance between side columns: 2,020 mm Crossbeam height adjustment: 110 - 1,685 mm Crossbeam feed rate: 1,450 mm/min VF 160 Horizontal Headstock: Taper: ISO 60 Motor power: 30 kW Speed range: 15 – 710 rpm Feed rate: 10 – 2,000 mm/min Number of speeds: 16 VF 120 Vertical Headstock: Taper: ISO 50 Motor power: 18 kW Speed range: 28 – 910 rpm Number of speeds: 16 Overall machine dimensions (L x W x H): 14,780 mm x 5,650 mm x 4,800 mm

Condition: used, Year of construction: 1976, Machine type: Universal milling machine Manufacturer: SHW Model: UF21 Year of manufacture: 1976 Control type: NC Country of origin: Germany X-axis travel: 1050 mm Y-axis travel: 500 mm Z-axis travel: 500 mm Spindle taper ISO: SK40 Spindle head swivel right-left: 90° Quill travel: 180 mm Spindle speed range: 36–1800 rpm / 18 steps Cgjdpfexwnm Dox Afnjn Feed rate X+Z: 0.3–1800 mm/min Feed rate Y: 0.3–900 mm/min Rapid traverse X/Z: 1800 mm/min / Y: 900 mm/min Table size: 1200 x 550 mm Total power requirement: approx. 10 kW Estimated weight: 4400 kg Machine dimensions (L x W x H): approx. 3.1 x 2.5 x 2.2 m Spindle motor power: 6.8 kW

Condition: used, Year of construction: 1999, x-travel 12000 mm y-travel 3600 mm z-travel 1500 mm spindle turning speed range 3000 U/min Control: Heidenhain iTNC430 Milling head 2 axes, indexed 2.5° Vertical (Y-axis): 3600 mm Transverse (Z-axis): 1500 mm Longitudinal (X-axis): 12,000 mm Guide rail length: 14,700 mm Guide rail width: 1400 mm Lowest milling position of the spindle nose measured from the floor (head horizontal): 855 mm Low column design 870 x 900 x 2,625 mm: 3,000 kg High stand design 870x900x3,025 mm: 3,500 kg Motor power: 37 kW Mounting: ISO 50/ DIN 69871-A Speeds: 11.7:231:3000 rpm Feed range: 2:2500 mm/min Cgjdpfxsxwdygj Afnsn Rapid traverse X-axis: 12000 mm/min Z-Y axis: 15000 mm/min Feed motor power X-axis: 55 Nm Z-axis: 37 Nm Y-axis: 37 Nm Accuracy Positioning accuracy: 0.025 mm Repeatability: 0.015 mm Weight: approx. 42,000 kg Air supply to the machine: 300 L/min at 4.5 bar NOTE: The clamping plates and chip conveyors are not included in the scope of delivery. However, we can offer you both used and new clamping plates and chip conveyors on request.

Condition: reconditioned (used), Year of construction: 2016, travel distance X-axis: 6,500 mm, travel distance Y-axis: 1,800 mm, travel distance Z-axis: 1,300 mm, feed length X-axis: 10,000 mm, feed length Y-axis: 10,000 mm, feed length Z-axis: 10,000 mm, rapid traverse X-axis: 35 m/min, rapid traverse Y-axis: 35 m/min, rapid traverse Z-axis: 35 m/min, spindle speed (max.): 7,000 rpm, spindle speed (min.): 20 rpm, table length: 8,000 mm, table width: 1,100 mm, RepairFIT by Dornhöfer The difference. Including installation & commissioning! Year of manufacture: 2016 Capacities / Travel distances: Cgedpfxexvx Amj Afnon Longitudinal (X): 6,500 mm Vertical (Y): 1,800 mm Cross (Z): 1,300 mm Table size: Length: 8,000 mm Width: 1,100 mm Number of T-slots on the table surface: units: 7 Width of T-slots: 22 mm Distance between slots: 140 mm Paintwork: RAL 7021 (black grey) RAL 7035 (light grey) ref F-38 (DanobatGroup Blue) Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Type A Main drive: Drive power: 100% duty cycle 43 kW Spindle speed range: Max. spindle speed: 20 – 7,000 rpm Torque: 900 Nm Feeds: X, Y, and Z axis mm/min 2 – 10,000 Max. rapid traverse speed: X, Y, and Z axis 35,000 mm/min Base area SLP8000: (without enclosure) 13.0 x 4.5 m Overall height: approx. 4.4 m Weight: approx. 34,000 kg Heidenhain TNC 640 HSCI Automatic milling head, Diagonal H207 Adapter angle milling head SK50 with Hirth gearing Automatic tool changer, 60 magazine places Chip conveyor Preparation / integration of NC rotary table Adaptive control ACCURA HEADS Coolant system 2 RepairFIT is our proven solution for a profitable entry into our product lines. The machines offered in this line are procured by us through a strict selection process and undergo a thorough inspection (Deep-Dive Check). After intensive cleaning, any identified defects or faults are professionally repaired by our expert service team.

Condition: used, Year of construction: 1998, x-travel 4.300 mm y-travel 1.200 mm z-travel 1.500 mm Cgedpfexvtgaox Afnjn control Heidenhein TNC 426 PB table-size 6.120 X 1.000 mm taper ISO ISO-50 Number of revolutions 20 - 3.000 rpm work speed 5.000 mm/min handwheel HEIDENHAIN HR-410 table weight 20.000 Kg Tools changer 40 fach/tools rapid traverse 12.000 mm/min weight of the machine ca. 28 t

Condition: used, Year of construction: 2000, x-travel 22.000 mm y-travel 1.500 mm z-travel 3.000 mm control SIEMENS 840 D milling head -swivable 0,001/0,001 Grad milling head Universalfräskopf 45° Internal cooling system 20 bar Chip coveyor ja Tools changer 30 pos. coolant 1.100 l Tool taper DIN 69871A ISO 50 total power requirement 45 kW weight of the machine ca. 68 t The round table shown in the pictures as well as the plate field are not sold with ! urning Speeds 6.000 r.p.m. AutoIndex Head 45 º Head 360.000 Pos. Elbow 360.000 Pos. Main Motor Power 37 Kw. Nº Change Range 2 Ranges Automatic Tool Charger INCLUDED Tools at ATC 30 Coolant Through Tool 20 Bar INCLUDED Soluble Oil Tank with filter paper INCLUDED Head Coolant System + CF Box INCLUDED Longitudinal Chip Conveyor INCLUDED Operator?s Platformd with 2000 mm Vertical movement. INCLUDED Ready for Rotor Translating Table (Regulator + Wires) /INCLUDED Coolant System in Electrical Cabinet INCLUDED Machine Weight 68.000 Kg. Csdpexvtf Nsfx Afnsgn Machine Colour RAL 7038 – 5012 Portable Handwheel INCLUDED
