GCH Machinery

Condition: good (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 400CB1262, workpiece weight (max.): 20 kg, grinding wheel diameter: 350 mm, total width: 1,700 mm, total length: 1,800 mm, total height: 1,600 mm, type of input current: three-phase, overall weight: 2,000 kg, input frequency: 50 Hz, input voltage: 400 V, Universal cylindrical grinding machine Ziersch & Baltrusch Type URS 400 Ergonomy Iodpfxsz Db Ewo Akpsig Year of manufacture 2001

Condition: refurbished (used), Year of construction: 1992, machine/vehicle number: 92 0 20 10 19 031, total width: 1,900 mm, total length: 4,000 mm, total height: 2,000 mm, distance between centers: 1,200 mm, spindle speed (max.): 1,600 rpm, grinding spindle speed: 1,600 rpm, overall weight: 1,900 kg, input voltage: 380 V, We are offering this refurbished Karstens K19-1000 cylindrical grinding machine, manufactured in 1992. Iodpfsz Daliex Akpsig Voltage: 380 V Rated current: 48 A Inrush current: 126 A Fuse in the supply line: 35 A Control current: 2.5 A Machine weight: 1.9 t If you have any questions or require further information, please do not hesitate to send us a message or call us.

Condition: good (used), functionality: fully functional, The machine is in good working condition; testing is possible upon prior arrangement. 2 UNITS. Iodpfx Aez A Ucaokpsig

Condition: used, Year of construction: 2022, Studer Favorit 650 CNC Universal Cylindrical Grinding Machine with Fanuc Oi-TD CNC Control, S/No. 1042-0727 (2022), Distance between Centres 650mm, Centre Height 175mm, X Travel 285mm, Z Travel 800mm, Z Travel 800mm, External Grinding Swivel Range -15 deg to + 195 deg, 500mm Diameter Grinding Wheel, MKS Universal Work Head, MK4 Tailstock, Coolant Filter System, FMN-V12 Extraction System. 4,200kg. Country of Origin: Switzerland Location: These lots are located in Biggleswade, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. Isdpfx Aez Arnpekpsig

Condition: good (used), machine/vehicle number: 115 240, center height: 250 mm, grinding length: 1,000 mm, grinding diameter: 500 mm, a very well-maintained used external cylindrical grinding machine with internal grinding capability, SCHAUDT, Type: A 510 N 1000. Iiedpjzz Tkcofx Akpjg Center height: 250 mm, grinding diameter: 500 mm, grinding length: 1000 mm, with multiple grinding wheels.

Condition: used, Year of construction: 2002, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm Ijdszz S Awspfx Akpeig

Condition: used, Year of construction: 2020, operating hours: 21,398 h, machine/vehicle number: IntNr231185, EMAG WEISS W11 CNC SL650 – Universal Cylindrical Grinding Machine – Year of Construction: 2020 For sale is a used EMAG WEISS W11 CNC SL650 – a high-performance universal cylindrical grinding machine with CNC control. This machine is ideally suited for demanding grinding operations on individual parts, prototypes, and small to medium production runs. Machine Specifications Manufacturer: EMAG WEISS Type: W11-CNC SL650 Year of Construction: 2020 Operating Hours: Approx. 8,850 spindle hours / approx. 22,000 power-on hours Condition: Used, well-maintained, ready for immediate operation Technical Data Control: CNC-controlled (e.g., Heidenhain / Siemens / Fanuc – depending on the configuration) Iijdpozx Rvdsfx Akpeg Max. Grinding Length: 650 mm (between centers) Center Height: Approx. 200 mm External Grinding Diameter: Up to approx. 390 mm Max. Workpiece Weight (overhanging): Approx. 100 kg (MK4) Max. Workpiece Weight (between centers): Approx. 250 kg X-Axis Traverse: Approx. 380 mm Z-Axis Traverse: Approx. 1,150 mm Grinding Wheel Diameter: 400 – 500 mm depending on equipment Rated Power: 9 – 11 kW (approx. 12 – 15 hp) Peripheral Speed: 20 – 50 m/s Equipment and Performance Features CNC touchscreen operation with Windows-based interface – user-friendly programming via dialogue or DIN/ISO (optional) Two-in-one concept: The machine can be operated both conventionally and CNC-controlled. High-precision linear and ball screw guides for high accuracy Direct measuring system (glass scales) (optional on many machines) Automatic dressing of the grinding wheel with compensation Crash control & gap monitoring for machine and process safety Coolant system, emulsion separator, and chip conveyor available (depending on equipment) Preparation for automation / robot interface possible The machine can be inspected in operation by appointment. Subject to changes and errors in technical data and specifications as well as prior sale!

Condition: refurbished (used), Year of construction: 2026, Kellenberger 1000U universal grinding machine, refurbished Technical details: - distance between centers : 1000 mm - centers height : 125 mm - grinding diameter: 250 mm - table orientation : -/+ 8 ° - universal wheelhead - grinding wheels dimensions : 400 x 50 x 127 mm - motor power : 3 kW - spindle speed : 1500 / 1700 / 2200 - orientation of grinding wheel holder headstock : 270 ° (3 x 90°) - boring for internal spindle : 90 mm - orientation of part holder headstock : 180 ° - spindle speed : 20 - 400 rpm - spindle internal cone : Morse 5 - motor power : 0,9 kW - inner cone tailstock : Morse 4 - tailstock sleeve travel: 30 mm - dimensions : 2860 x 1680 x 1670 mm - weight : 2500 kg Accessories/options: - automatic cycle works - tailstock - lubricating tank with pump - 1 internal grinding spindle Iiodpfjzxnf Aox Akpjg - external grinding wheels - coolant tank with paper band filter type - wheel dresser - documentations - etc... The machine is partly overhauled, included: - new geometry - new electrical cabinet - bearings replaced - new painting - etc....

Condition: used, JONES AND SHIPMAN EIT 1076 PRODUCTION CYLINDRICAL GRINDING MACHINE MADE IN ENGLAND CAPACITY: 250 x 700.0mm DROP DOWN INTERNAL SPINDLE VARIABLE SPEED HEAD METRIC DIALS UNIVERSAL BED PAPER FILTRATION SYSTEM AUTO CYCLE Iiodpjzw U Twefx Akpjg

Condition: repair required (used), Type AS - 900 Machine No. 74054 Iodpfx Akszw H I Tspoig Centre distance 900 mm Centre height 150 mm Max. grinding wheel 400 x 80 x 127 mm Centre height 150 mm Centre distance 900 mm ..... Condition: The machine cannot be switched on! The following applies to this machine: Condition unknown! Scope of delivery as per attached images ....

Condition: used, Year of construction: 1995, operating hours: 9,000 h, functionality: fully functional, center height: 225 mm, grinding length: 1,600 mm, STUDER S40 CNC Universal Cylindrical Grinding Machine with Polygon Grinding Attachment For sale is a STUDER S40 CNC universal cylindrical grinding machine, manufactured in 1995, with a GE Fanuc Series 16-GC control system and a polygon grinding attachment. The machine is equipped for various cylindrical grinding tasks and enables, among other things, face, plunge, internal, and cylindrical grinding. Additionally, the machine is equipped for polygon grinding. Technical Data Manufacturer: STUDER / Studer AG Model: S40 CNC Year of manufacture: 1995 Machine No.: 011.0166.60.028 Control system: GE Fanuc Series 16-GC Center distance: 1,600 mm Cross slide X: max. 275 mm Resolution: 0.0001 mm Maximum table swivel: 8.5° Equipment – Polygon grinding attachment – 2 grinding wheels plus 1 internal grinding unit, selectable via the control system – Face, plunge, internal, and cylindrical grinding – Automatic truing device – Steady rest – Magnetic chuck – Three-jaw chuck – Collets – Grinding between centers – Cycle control – DXF import – Grinding wheels in corundum, diamond, and CBN available – STUDER hand-held control unit The machine is in used condition with signs of wear and tear consistent with its age and use. An inspection is possible after prior arrangement. Price: €60,000 negotiable plus VAT. Iiedpfszw E Npjx Akpjg Location: 74343 Sachsenheim Collection/shipping by arrangement. Errors, changes, and prior sale reserved.

Condition: used, 3 flanges for type 600 U – available for sale individually or as a set Iodpfszwxufex Akpeig

Condition: used, Year of construction: 1990, External/Internal Cylindrical Grinding TARDUGNO RIBON type MODULE 2A Between points: 1000 mm Centre height: 180 mm Workpiece holder spindle CM4 Maxi grinding diameter: Ø 360 mm Workpiece holder rotation: from 35 to 310 RPM Year of construction: 1990 Tilting table - 9° / + 6° Grinding wheel dimensions: Ø 406 mm x thickness 60 mm Scale on table X Spindle speed: 1500 - 1730 RPM Grindstone motor: 5,5 CV Hydraulic tailstock CM3 Auto wheel advance Internal grinding spindle: Max speed 20000 RPM Maxi boring: from 14 to 75 mm Lubricant tank+ paper filter Diamond system Iodpfxszww Sij Akpjig Tilting grindstone holder trolley Supplied with grinding wheels + steadies Voltage: 380 V Dimensions (L x W x H): 3800 x 2000 x 2200 mm Weight: approx 3,2 T

Condition: used, External/Internal Cylindrical Grinding GENDRON RU 28.100 Between points: 1000 mm Maxi grinding diameter: Ø 290 mm Tool holder rotation: from 70 to 370 RPM 4-jaws Ø 200 mm chuck Grinding wheel: Ø 300 mm Auto pass plug Swivel table External hydraulic group External lulbricant tank Iodozww Rfopfx Akpeig Voltage: 380 V Dimensions (L x W x H): 3000 x 1900 x 2000 mm Weight: approx 3 T

Condition: used, External/Internal Cylindrical Grinding JONES-SHIPMAN type 1310 Capacity: Ø 200 x 450 mm (8'' x 18'') Tilted table Grinding wheel: Ø 300 mm x thickness 25 mm x bore Ø 125 mm Drive wheel speed: 1750 and 2300 RPM Rotary grindstone holder support Supplied without internal grinding spindle Equipped with 1 lubricant tank Voltage : 380 V Length: 1800 mm Depth: 1600 mm Total height: 1900 mm Weight: approx 2 T Iiedpfx Akszww I Repeg

Condition: good (used), functionality: fully functional, Mitutoyo length measuring system, model KA 12 (for longitudinal and transverse movement) Retrofitting with a CNC control system for the draw-in device, including air conditioning unit, Center distance: 630 mm, the machine has no tailstock and was specifically used for chucking operations, Max. grinding diameter: 280 mm, Max. grinding wheel size: 400 x 40 x 127 mm (not included in the scope of supply), Grinding spindle speed: 2040 rpm, 6 speed stages of the tool spindle: 22.4 to 280 rpm, Iedpfx Akjzv Uhrspjig Drive motor: 4 kW, Accuracy / smallest division value: 0.001 mm, Taper in tailstock and tool spindle: Morse 4 Largest table longitudinal travel: 760 mm, Weight between centers: 120 kg, Total power consumption: approx. 9.3 kW, Machine weight: approx. 2600 kg, Machine dimensions: L 3075 x W 1650 x H 1500 mm Year of manufacture: corresponds to the serial number: 1989 - 1991 Swiveling headstock (± 90°) and grinding head (± 45°), Hydraulic table movement and automatic feed, Cooling system, Machine lighting, Operating manual in German and electrical diagrams.

Condition: used, KELLENBERGER KEL-VARIA RS 175 / 1000 is a CNC cylindrical grinder engineered for high precision, delivering exceptional accuracy and industrial reliability. Key capacities: centre height 175 mm, distance between centres 1000 mm, max. grinding diameter 349 mm; right-hand wheel Ø500×80 mm bore 127 mm; Z axis 1150 mm, X axis 320 mm; workpiece weight on centres up to 150 kg. Main specs: wheel speeds 1500–1800 rpm, peripheral speed 32 m/s, automatic indexing 0.1°; rapid feed 10 m/min; work spindle stepless 5–500 rpm, taper 5 CM (rotatable -30/+120°); tailstock taper 4 CM stroke 50 mm; table speed up to 8 m/min; max table angle 9°; grinding spindle motor 7.5 kW, work spindle motor 3 kW; 50 Hz 3x380 V; air 4 bar; machine weight ≈6000 kg; footprint L3600×W2000 mm. Accessories: coolant system, MARPOSS touch probe and measuring head, Positionar Passiv, grinding wheel with flange, lamp, tailstock with fine adjustment. Achieves tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical a Iijdpfx Ajzv I I Sokpjg

Condition: not inspected (used), Year of construction: 1987, functionality: unexamined, machine/vehicle number: 20119, We offer this Studer S35 cylindrical grinding machine, ready for use, manufactured in 1987. Manufacturer: Studer Model: S35 Year of manufacture: 1987 Iiedpezvvzyefx Akpog Condition: ready for use Category: 1373 Type: cylindrical grinding machine If you have any further questions or require additional information, please feel free to send us a message or call us.

Condition: good (used), Year of construction: 1988, grinding diameter 360 mm grinding length 1000 mm centre height 180 mm grinding wheel diameter 500 x203,2 x 50-100 mm total power requirement 12 KvA weight of the machine ca. 4,7 t Iedszu A Sispfx Akpeig dimensions of the machine ca. 3,3 x2,0 x 1,8 m - Includes belt filters - Includes grinding wheels

Condition: reconditioned (used), Year of construction: 2006, year of last overhaul: 2026, ⚙️ STUDER S30-1 CE – High-precision cylindrical grinding machine | Complete retrofit We offer a STUDER S30-1 CE for high-precision external and internal cylindrical grinding operations. The machine has undergone a complete retrofit by MIRA Retrofit, including the inspection and refurbishment of its main components, as well as a careful adjustment and fine-tuning process. The result is a machine that is ready for operation, with a high level of precision, reliability, and stability, and performance comparable to that of a new machine. Iedpezuzyljfx Akpoig Key specifications: 🔹 Distance between centers: 650 mm 🔹 Height between centers: 175 mm 🔹 Grinding: external and internal 🔹 Condition: complete retrofit – ready for operation 🔧 Inspection and fine-tuning All components have been carefully inspected and adjusted to ensure high geometric accuracy and reliable, stable operation. 📸 Photographs of our finished machine. 🚚 Available for immediate delivery. For more information, technical documentation, pricing, or any questions about the machine, please do not hesitate to contact us. MIRA Retrofit SA

Condition: used, TECHNICAL DETAILS - Distance between centers : 1000 [mm] - center height : 180 [mm] - Max. part weight between centers : 100 [kg] GRINDING WHEEL HOLDER HEADSTOCK - External grinding * Power : 7.5 [kW] * Grinding wheel dimensions : 500/80/203 [mm] PART-HOLDER HEADSTOCK - Speed : 10-800 [rpm] Iiodpfx Akszrp Edopeg POWER SUPPLY - Supply voltage : 400 [V] EQUIPMENT - CNC : Fanuc Oi-TF - 3 colors status lamp - Tool probe : Marposs - Coolant tank * with paper filtering unit * with cooling unit for coolant

Condition: used, Year of construction: 2001, Control Fanuc Top height above table 150 mm max. grinding diameter 300 mm centre distance 600 mm Iisdpfxezp Rzbo Akpjg max. grinding length 600 mm max. workpiece weight 150 kg Grinding wheel angle 0 ° Overall size 3.100 x 2.520 x 2.100 mm In our assessment, the machine is in good used condition and can be inspected under power by appointment. The machine was used for grinding eccentric shafts and is equipped with a Marposs gauging system. Accessories, tools, and work-holding devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: used, functionality: fully functional, Universal cylindrical grinding machine Ziersch & Baltrusch URS 750 (year of manufacture 1984) from a company liquidation. Conventional external and internal cylindrical grinding machine of German manufacture with a center distance of 750 mm – for grinding shafts, pins, and cylindrical mating surfaces. EQUIPMENT & TECHNOLOGY - Center distance: 750 mm - External and internal cylindrical grinding - Swiveling grinding head – conical grinding also possible - Solid bed design, stable guides, high runout accuracy - Digital readout (DRO, Fagor) available – see photos Ziersch & Baltrusch was a renowned West German manufacturer in the grinding machine segment. Well-maintained machines of this series are still in reliable use today. APPLICATION Ideal for job production, repair workshops, and general machine manufacturing. Iijdpfx Aszphf Rekpjg CONDITION Used, ready for operation. Located near Nuremberg, viewing by appointment. Sold as is, no warranty. ACCESSORIES (according to photos) - 2-axis digital readout (DRO, manufacturer Fagor) - Tailstock and centers (grinding between centers) - Swiveling workpiece spindle head (conical grinding) - Steady rests - Grinding wheels Price on request. We will be happy to advise you – competent advice and nationwide service.

Condition: ready for operation (used), functionality: fully functional, The Studer S30-12 CNC is a precision cylindrical external grinding machine from Fritz Studer AG. Brand: Studer Type: S30-12CNC Serial number: 1248.74 Iiodpfx Aszn Nqrskpeg Dimensions: L3250mm Dimensions: W2000mm Dimensions: H1950mm Wheel speed: 30 m/s

Condition: used, Year of construction: 1988, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm Control Kelco Iisdpfxozmy The Akpjg weight of the machine ca. 4 t
