Vertical machining center

BRIDGEPORT VCM 500 16 Cnc

Condition: good (used), Year of construction: 1990, CNC Cylindrical Grinding Machine Make: TSCHUDIN Type: HTG 22 - 862 Year 1990 with MARPOSS E14 control and measuring control E5. center width : 650 mm center height : 100 mm grinding length : 620 mm Weight : ca.4 500 Kg. Fpedpoid Aphefx Ad Nep Further data See : TECHNICAL DATA SHEET With many grinding stones and holders Complete machine documentation available. Machine in stock.

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BT30 - Spindle power : 6.7 [kW] - Spindle speeds : 10.000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 700 x 400 x 300 [mm] - Rapid traverses rates (X/Y/Z) : 50 / 50 /56 [m/min] - Cutting feed rates (X/Y/Z) : 1 - 30 [m/min] - Distance table / spindle nose (min./max.) : 330 - 630 [mm] TOOL CHANGER - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 21 - Tool exchange time : 0,8 [sec] TABLE - Table dimensions : 800 x 400 [mm] - Maximum weight upon table : 250 [kg] POWER SUPPLY - Supply voltage : 220 [V] - Total installed power : 9,5 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.050 x 2.220 [mm] - Machine height : 2.497 [mm] - Machine weight : 2.400 [kg] Fodpfx Adevt Eifj Nepp EQUIPMENT - CNC : Brother CNC-C00 - Interface : Ethernet / USB - Electronic handwheel - Type of divisor : 4e axe CNC intégré * Coolant tank * with high-pressure pump - Coolant through spindle - Electric transformer

Condition: used, TECHNICAL DETAILS Fodpfx Adouhb A Eo Nspp - Number of axes : 5 MILLING SPINDLE - Tool holder type : ISO30 - Spindle speeds : 18000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 705 / 425 / 610 [mm] A ROTARY AXIS - Travel : 360 [°] (+/-) - Indexing precision : 0.001 [°] B ROTARY AXIS - Travel : +180/-5 [°] (+/-) - Indexing precision : 0.001 [°] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 32 TABLE - Table dimensions : 1260 x 490 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 22 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2600 x 2300 [mm] - Machine height : 3000 [mm] - Machine weight : 5100 [kg] EQUIPMENT - CNC : iTNC 530 - Electronic handwheel - Type of divisor : 4e-5e axe intégré * manufacturer : Fehlmann * model : ATS 160 CNC * clamping diameter : 300 [mm] * center height : 160 [mm] * tightening type : Pneumatique - Coolant tank * with high-pressure pump - Oil mist extractor - Spindle cooling unit - Workpiece probe : Renishaw OMP 40-2 - Electric transformer

Condition: used, Year of construction: 2005, General Information: - Model: ROBODRILL α-T2 STAMA - Serial Number: 046VH155 - Year of Manufacture: 2005 - CNC Controller: FANUC (Model A04B-0094-B111#BD) - Weight: 2200 kg - Power Supply: 200 V, 50/60 Hz, Three-phase - Power Consumption: 10 kVA ----- Machining Capabilities: - Operations: - Milling (high-speed and high-precision milling) - Drilling - Rigid tapping ----- Axis Travel: - X-axis Travel: ~500 mm - Y-axis Travel: ~400 mm - Z-axis Travel: ~330 mm ----- Spindle: - Spindle Taper: BT30 - Standard Spindle Speed: up to 10,000 rpm ----- Tool Changer: - Type: Automatic tool changer - Tool Change Time: ~1.6 seconds ----- Rapid Traverse Rate: - Rapid Traverse Speed: 54 m/min on X, Y, and Z axes ----- Key Features: - Compact structure for high rigidity Fpedpfouru I Rox Ad Njp - High productivity with ultra-fast drilling and tapping cycles - Easy maintenance (integrated FANUC diagnostic interface) - Compatibility with automated production cells (co-branding with STAMA)

Condition: used, Year of construction: 2003, Bordstørrelse 600 x 300 mm X/Y/Z movements 480/360/270 mm Table load 250 kg Spindle taper BT 30 Spindle speeds 10-10000 rpm Fpedpfx Asu Sn Uxed Nep Tool changer w/21 stations Equipped with: 27 tool holders (no cutting tools) Can be supplied with automatic cell - against extra cost

Condition: ready for operation (used), Year of construction: 1998, table mounting size: 765 x 400 mm movements x/y/z: 650/410/510 mm spindle taper: BT 40 min./max. distance table/spindle: ca. 90/690 mm spindle turning speed range: 80 - 8000 rpm number of tool positions: 20 pieces Fpodpotwy Diefx Ad Njp carriages: ca. 30 m/min rapid move: ca. 30 m/min electrical connection: 380 V, ca. 15 kVA kW space needed: 2300 x 2100 x 2650 mm weight: 4000 kg

Condition: excellent (used), Year of construction: 1999, operating hours: 6,000 h, functionality: fully functional, travel distance X-axis: 505 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 610 mm, feed rate X-axis: 20,000 m/min, feed rate Y-axis: 20,000 m/min, feed rate Z-axis: 20,000 m/min, controller manufacturer: Heidenhain, controller model: TNC 426, workpiece weight (max.): 300 kg, table width: 380 mm, table height: 1,004 mm, table length: 920 mm, overall weight: 250 kg, spindle speed (min.): 50 rpm, spindle speed (max.): 18,000 rpm, spindle motor power: 10 W, Equipment: documentation/manual, rotational speed infinitely variable, The machine is equipped as follows: Fpodpfx Adov A Tyqj Njp -Tool holder: SK 30 -Tool changer with 24 places (automatic tool change) -Coolant system -Spindle cooling -Mist extraction -Chip drawer -RENiSHAW measuring probe

Condition: used, Year of construction: 2004, X-Axis 700 mm Y-Axis 360 mm Z-Axis 270 mm Table size length 600 mm width 300 mm Fpsdpjumrpzofx Ad Nep Number of tool pockets 21 Spindle taper BT-30 Max. spindle speed 10000 rpm Length x width x height 1828.8 × 1574.8 × 2209.8 Weight 1800.4 kg

Condition: used, Year of construction: 2000, grinding diameter 360 mm grinding length 1600 mm centre height 180 mm internal diameter 0 mm grinding depth 0 mm swing diameter 0 mm total power requirement 40 kW weight of the machine ca. 10000 kg dimensions of the machine ca. m K A R S T E N S (Germany) Universal “CNC” - Cylindrical Internal and Face Grinding Machine also for grinding excentric and cam profiles and polygons and even suitable for Threadgrinding Model K 51 – 1500 Year 2000 Serial No. 99 093 Height of centres 180 mm Distance between centres / grinding length 1,700/1.600 mm Cylindrical Grinding: Grinding Ø, approx. 5 - 360 mm Grinding wheel: Ø x width x bore 500 x 100 x 127 mm Grinding spindle speeds (35 m/s / 50 m/s) 1.900 / 2.200 rpm Drives of cyl./int/face spindle units 7.5/4,0/7,5 kW Grinding Wheelhead: 3 Positions = B-Axis Head swivels in 3 positions = 240 ° / 17,5 degree X-axis adjustment in total 360 mm Increments for infeed 0,001 – 125 mm Workpiece wheelhead = C-Axis Spindle speeds steplessly adjustable 10 – 1.000 rpm Spindle taper / Spindle bore MK 4 / 24 mm Table speeds 0,01 – 10.000 mm/min Total electrical load 40 kW - 400 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features: * Very versatile CNC Grinding Machine for almost all grinding purposes like External/Internal and Face grinding as well as for Excentric- / Cam- / Polygone Grinding and even for Thread Grinding * Free programmable CNC System make BWO Model 900 C with many grinding cycles and for easy input of the work-parameters. Graphic support, any many more features. * 3 position wheelhead with 3 Grinding spindles as B-Axis, one with measuring feeler (Z - Position) * MOVOMATIC Measuring Device Model ES 400 for diameter control, Probe head CR 60, to be mounted on table. * MPM Automatic Grinding wheel balancing Device, Dressing devices with Fpedpfot Hw Rdex Ad Nep diamantflees mounted on table surface and also motorized Diamantroll Profile dresser on table (for thread profiles, etc.) * Workhead and tailstock can be easily moved on table by air cushion. Hydraulic quill on tailstock. * No Coolant Device available ! Condition : Good to very good. Machine can be inspected under power. Delivery : Ex stock as inspected. Payment : Net, after conclusion of contract.

Condition: used, Year of construction: 2005, - Fagor 8055 CNC control - Additional tank for internal spindle cooling (15 bar) 400 liters Fpedpfx Adjtvf Hte Nep - Year of construction 2005 Technical data: - Travel X/Y/Z: 610 / 455 / 520 mm - Rapid traverse: 24 m/min - Working spindle speed: 8000 rpm - Tool holder: BT40 - Table size: 762 x 363 mm - Maximum table load: 350 kg - Motor power: 18 kW - Operating voltage: 400 V - Weight: 3140 kg
